GE Digital Energy L30 User manual

831776A2.CDR
L30 Line Current Differential
System
UR Series Instruction Manual
L30 revision: 7.0x
Manual P/N: 1601-9050-Y2 (GEK-113670A)
GE Digital Energy
650 Markland Street
Markham, Ontario
Canada L6C 0M1
Tel: [phone] Fax: [phone]
Internet: http://www.GEDigitalEnergy.com
GE Multilin's Quality Management
System is registered to ISO
9001:2008
QMI # 005094
UL # A3775
*1601-9050-Y2*
LISTED
52TL
IND.CONT. EQ.
E83849
GE
Digital Energy

Copyright © 2012 GE Multilin Inc. All rights reserved.
L30 Line Current Differential System UR Series Instruction Manual revision 7.0x.
FlexLogic, FlexElement, FlexCurve, FlexAnalog, FlexInteger, FlexState, EnerVista,
CyberSentry, HardFiber, Digital Energy, Multilin, and GE Multilin are trademarks
or registered trademarks of GE Multilin Inc.
The contents of this manual are the property of GE Multilin Inc. This
documentation is furnished on license and may not be reproduced in whole or
in part without the permission of GE Multilin. The content of this manual is for
informational use only and is subject to change without notice.
Part number: 1601-9050-Y2 (November 2012)

GE Multilin L30 Line Current Differential System iii
