GE Medical Systems LOGIQ 7 User manual

GE Medical Systems
Technical
Publications
Direction 5116269-100
Rev. 2
LOGIQ 7/LOGIQ 7 Pro Advanced Reference
Manual
R4.2.0/R4.2.0Pro
Copyright© 2004, 2005 By General Electric Co.
Operating Documentation

Regulatory Requirement
This product complies with regulatory requirements of the following European
Directive 93/42/EEC concerning medical devices
This manual is a reference for the LOGIQ 7/LOGIQ 7 Pro. It applies to all versions of the
SW R4.2.0/R4.2.0Pro and later software for the LOGIQ 7/LOGIQ 7 Pro ultrasound
systems.
GE Medical Systems
GE Medical Systems: Telex 3797371
P.O. Box 414, Milwaukee, Wisconsin 53201 U.S.A.
(Asia, Pacific, Latin America, North America)
GE Medical Systems
283, rue de la Miniere,78533 Buc Cedex
France

LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual i-1
Direction 5116269-100 Rev. 2
Revision History
List of Effective Pages
Table i-1: Reason for Change
REV DATE REASON FOR CHANGE
Rev. 1 Aug. 30th, 2004 Initial Release
Rev. 2 February 25, 2005 R4.2.0/R4.2.0Pro Release
Table i-2: List of Effective Pages
PAGE NUMBER REVISION NUMBER PAGE NUMBER REVISION NUMBER
Title Page Rev. 2 Chapter 2 Rev. 2
Revision History Rev. 2 Chapter 3 Rev. 2
Table of Contents Rev. 2 Index Rev. 2
Chapter 1 Rev. 2
Please verify that you are using the latest revision of this document.
Information pertaining to this document is maintained on GPC (GE
Medical Systems Global Product Configuration). If you need to know the
latest revision, contact your distributor, local GE Sales Representative or
in the USA call the GE Ultrasound Clinical Answer Center at
1 800 682 5327 or 1 262 524 5698.

i-2 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual
Direction 5116269-100 Rev. 2
This page intentionally left blank.

Table of Contents
LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual TOC-1
Direction 5116269-100 Rev. 2
Table of Contents
Chapter 1 — Acoustic Output
Bioeffects
Concerns Surrounding the Use of Diagnostic Ultrasound - - - - - - - - - 1-2
Acoustic Output Data
Maximum output summary- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-3
Chapter 2 — Measurement Formulas
Cardiac Measurement
Cardiac measurement abbreviation list - - - - - - - - - - - - - - - - - - - - - - 2-2
Measurement Formulas
Formulas–Generic - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-14
Formulas-Urology - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-15
Formulas-Abdominal/Small Parts - - - - - - - - - - - - - - - - - - - - - - - - - 2-16
Formulas–OB- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-17
Formulas–GYN - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-21
Formulas–Vascular- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-23
Formulas-Cardiac - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-24
Chapter 3 — OB Tables
OB Tables
ASUM - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-2
Berkowitz- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-8
Bertagnoli - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-9
Brenner - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-9
Campbell - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-10
Chitty - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-10
Eriksen - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-16
Erik-Nes - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-17
Goldstein - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-19
Hadlock - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-20
Hansmann - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-27
Hellman - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-35
Hill - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-35
Hohler - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-36
Jeanty - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-36
JSUM - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-48
Kurtz - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-52
Mayden - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-53
Mercer - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-54

TOC-2 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual
Direction 5116269-100 Rev. 2
Merz - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-55
Moore - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-65
Nelson - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-65
Osaka - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-66
Paris - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-70
Rempen - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-73
Robinson - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-78
Tokyo - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-78
Tokyo Shinozuka - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-82
Williams - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-88
Yarkoni - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-88

LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual 1-1
Direction 5116269-100 Rev. 2
Chapter 1
Acoustic Output
Provides Acoustic Output information and tables, as
well as possible bioeffects and prudent use.

Acoustic Output
1-2 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual
Direction 5116269-100 Rev. 2
Bioeffects
Concerns Surrounding the Use of Diagnostic Ultrasound
During a diagnostic ultrasound examination, high frequency
sound penetrates and interacts with tissue in and around the
area of anatomy tobe imaged. Only a smallportion of this sound
energy is reflected back to the probe for use in constructing the
image while the remainder is dissipated within the tissue. The
interaction of sound energy with tissue at sufficiently high levels
can produce biological effects (aka bioeffects) of either a
mechanical or thermal nature. Although the generation of
bioeffect is intentional with therapeutic ultrasound, it is generally
undesired in diagnostic applications and may be harmful in
some conditions.
NOTE: The American Institute of Ultrasound in Medicine has published
a document entitled "Medical Ultrasound Safety". This three
part document covers Bioeffects and Biophysics, Prudent Use
and Implementing ALARA.
Ultrasound users should read the AIUM to become more familiar
with Ultrasound safety.
NOTE: Only for U.S.A. : A copy of this document is included as part of
the documentation package (Document 2163920-100).
To contact the AIUM concerning their publications:
• In the USA, by telephone at 1-800-638-5352.
• To write them, use the following address:
AIUM
14750 Sweitzer Lane
Suite 100
Laurel, MD, USA 20707-5906

Acoustic Output Data
LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual 1-3
Direction 5116269-100 Rev. 2
Acoustic Output Data
Maximum output summary
The following tables list the typical maimum acoustic output
levels achievalbe with LOGIQ 7/LOGIQ 7 Pro for all probes and
operational modes. It is intended that this is information be
useful in making ALARA decisions and selecting the most
appropriate probe for the application. In accordance with US
FDA Guidelines, the overall maximum acoustic SPTA intensity
for LOGIQ 7/LOGIQ 7 Pro is limited to 720 mW/cm2and MI is
limited to 1.9. Modes for which TI does not exceed 0.1 are
indicated by <0.1.
• The accuracy of acoustic output table of this manual : +0%/-
50%
• Accuracy of TI and MI is ±50%.
Table 1-1 shows all of the probes’ operating modes. The
following pages contain probe acoustic output tables for those
noted in Table 1-1.
Table 1-1: Summary Table
Operating Mode
Transducer Modell
3C 3.5C 3.5CS 5C E8C BE9C 8C M7C* 7L 10L
B-mode YES YES YES YES <1 <1 <1 YES <1 YES
M-mode
(inc.B-mode) YES YES YES YES <1 <1 <1 YES <1 YES
Color Flow (inc.
B-mode) YES YES YES YES YES YES YES YES YES YES
Pulsed Doppler
(inc.B-mode) YES YES YES YES YES YES YES YES YES YES
B-Flow n/a YES YES n/a n/a n/a n/a n/a YES YES
Contrast n/a YES YES n/a n/a n/a n/a n/a YES YES
CW Doppler n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
Other
(specify) n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
*LOGIQ 7 Only

Acoustic Output
1-4 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual
Direction 5116269-100 Rev. 2
Table 1-2: Summary Table
Operating Mode
Transducer Modell
M12L i12L T739 3S 7S 10S 6T M3S* P2D P6D
B-mode YES YES YES YES YES YES YES <1 n/a n/a
M-mode
(inc.B-mode) YES YES YES YES <1 YES YES <1 n/a n/a
Color Flow (inc. B-
mode) YES YES YES YES YES YES YES YES n/a n/a
Pulsed Doppler
(inc.B-mode) YES YES YES YES YES <1 YES YES n/a n/a
B-Flow YES n/a YES n/a n/a n/a n/a n/a n/a n/a
Contrast n/a n/a n/a YES n/a n/a n/a YES n/a n/a
CW Doppler n/a n/a n/a YES YES YES YES YES YES <1
Other
(specify) n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
*LOGIQ 7 Only

Acoustic Output Data
LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual 1-5
Direction 5116269-100 Rev. 2
List of Acoustic Output Parameters
Table 1-3: List of Acoustic Output Parameters
FDA IEC Meaning—IEC 60601-2-37 / FDA & NEMA UD2, UD3
aαAcoustic Attenuation Coefficient / Derating factor (usually 0.3 dB/cm-MHz)
Aaprt Aarpt -12db Output Beam Area / Active aperture area
CMI Normalizing Coefficient
Deq Deq Equivalent Aperture Diameter / (same)
d-6 d-6 Pulse Beam Width / Beam diameter at –6 dB
deq deq Equivalent Beam Diameter
fcƒawf Acoustic Working Frequency / Center frequency
Ipa Ipa Pulse-Average Intensity
Ipa.3 Ipa,αAttenuated Pulse-Average Intensity
PII Ipi Pulse-Intensity Integral
PII.3 Ipi,αAttenuated Pulse-Intensity Integral
ITA Ita(z)Temporal-Average Intensity
ITA.3(Z) Ita,α(z)Attenuated Temporal-Average Intensity / (at depth z)
ISPTA(Z) Izpta(z)Spatial-Peak Temporal-Average Intensity
ISPTA.3(Z) Izpta,α(z)Attenuated Spatial-Peak Temporal-Average Intensity
MI MI Mechanical Index
WoP Output Power / Time average acoustic power at the source
W.3(Z) PαAttenuated Output Power / Time average acoustic power derated to depth z
Wo1 P1Bounded Output Power / Power emitted from the central 1cm of aperture
PII piPulse Pressure Squared Integral / Pulse intensity integral
prprPeak-Rarefactional Acoustic Pressure / (same)
pr.3 prαAttenuated Peak-Rarefactional Acoustic Pressure / (same)
PRF prr Pulse Repetition Rate / Pulse repetition frequency
TI TI Thermal Index / (same)
TIB TIB Bone Thermal Index / (same)
TIC TIC Cranial-Bone Thermal Index / (same)
TIS TIS Soft-Tissue Thermal Index / (same)
PD tdPulse Duration / (same)
x-12,y-12 X, Y -12 dB Output Beam Dimensions / (same)
ZZ Distance from the Source to a Specified Point / (same)
Zsp ZbDepth for TIB / Depth at which the relevant index is maximum
Zbp Zbp Break-Point Depth / (same)
Zsp ZsDepth for TIS / Depth at whcih the relevant index is maximum

Acoustic Output
1-6 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual
Direction 5116269-100 Rev. 2
3C Probe
NOTE:
a. This index is not required for this operation mode; see section 4.1.3.1 of the
Output Display Standard(NEMA UD-3)
b. This probe is not intended for transcranial or neonatal cephalic uses.
c. This formulation for TIS is less than that for an alternate formulation in this
mode.
# No data are reported for this operating condition since the global maximum
index value is not reported for the reason listed.
Table 1-4: Transducer Mode: 3C Operating Mode: B-Mode
Index Label MI TIS TIB TIC
scan non-scan non-
scan
Aaprt< Aaprt>1
Global Maximum: Index Value 1.5 1.4 - - - 2.7
IEC FDA Units
pra p
r.3 (MPa) 2.4
PWo (mW) 144.7 - -144.7
min of [Pα(zs, Ita,α(zs)] [(W.3(Z1),ITA.3(z1)]) -
zsz
1(cm) -
zbp z
bp (cm) -
zbz
sp (cm) -
zat max. Ipi,αzsp (cm) 3.3
deq(zb) deq(zsp) (cm) -
ƒawf fc(MHz) 2.6 2.6 - - - 2.6
Dim of Aaprt X(cm) 1.4 - - - 1.4
Y(cm) 1.0 - - - 1.0
tdPD (µsec) 1.0
prr PRF (Hz) 2927.4
prat max. Ipi pr@PIImax (MPa) 3.2
deq at max. Ipi d
eq@PIImax (cm) -
Focal Length FLX(cm) 3.5 - - 3.5
FLY(cm) 7.0 - - 7.0
Ipa,αat max. MI IPA.3@MImax (W/cm2)447.4
Frequency (MHz) T4.0 T4.0 - - - T4.0
Image Depth (cm) 24.0 10.0 - - - 10.0
Assoc Acoustic Paramete
Other infromation
Operating Control Conditions

Acoustic Output Data
LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual 1-7
Direction 5116269-100 Rev. 2
3C Probe (continued)
NOTE:
a. This index is not required for this operation mode; see section 4.1.3.1 of the
Output Display Standard(NEMA UD-3)
b. This probe is not intended for transcranial or neonatal cephalic uses.
c. This formulation for TIS is less than that for an alternate formulation in this
mode.
# No data are reported for this operating condition since the global maximum
index value is not reported for the reason listed.
Table 1-5: Transducer Mode: 3C Operating Mode: M-Mode (inc.B-mode)
Index Label MI TIS TIB TIC
scan non-scan non-
scan
Aaprt< Aaprt>1
Global Maximum: Index Value 1.5 1.4 - <1 1.6 2.4
IEC FDA Units
pra p
r.3 (MPa) 2.4
PWo (mW) 144.7 - 33.5 126.1
min of [Pα(zs, Ita,α(zs)] [(W.3(Z1),ITA.3(z1)]) #
zsz
1(cm) #
zbp z
bp (cm) #
zbz
sp (cm) 3.3
zat max. Ipi,αzsp (cm) 3.3
deq(zb) deq(zsp) (cm) 0.4
ƒawf fc(MHz) 2.6 2.6 - # 2.6 2.6
Dim of Aaprt X(cm) 1.4 - # 1.4 1.4
Y(cm) 1.0 - # 1.0 1.0
tdPD (µsec) 1.0
prr PRF (Hz) 2927.4
prat max. Ipi pr@PIImax (MPa) 3.2
deq at max. Ipi d
eq@PIImax (cm) 0.4
Focal Length FLX(cm) 3.5 - # 3.5
FLY(cm) 7.0 - # 7.0
Ipa,αat max. MI IPA.3@MImax (W/cm2)448.9
Frequency (MHz) T4.0 T4.0 - # T4.0 T4.0
Image Depth (cm) 24.0 10.0 - # 24.0 24.0
Assoc Acoustic Paramete
Other infromation
Operating Control Conditions

Acoustic Output
1-8 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual
Direction 5116269-100 Rev. 2
3C Probe (continued)
NOTE:
a. This index is not required for this operation mode; see section 4.1.3.1 of the
Output Display Standard(NEMA UD-3)
b. This probe is not intended for transcranial or neonatal cephalic uses.
c. This formulation for TIS is less than that for an alternate formulation in this
mode.
# No data are reported for this operating condition since the global maximum
index value is not reported for the reason listed.
Table 1-6: Transducer Mode: 3C Operating Mode: CF-Mode (inch.M-mode)
Index Label MI TIS TIB TIC
scan non-scan non-
scan
Aaprt< Aaprt>1
Global Maximum: Index Value 1.6 1.4 1.1 - 3.2 2.5
IEC FDA Units
pra p
r.3 (MPa) 1.9
PWo (mW) 144.7 90.3 90.3 152.8
min of [Pα(zs, Ita,α(zs)] [(W.3(Z1),ITA.3(z1)]) -
zsz
1(cm) -
zbp z
bp (cm) -
zbz
sp (cm) 3.3
zat max. Ipi,αzsp (cm) 3.3
deq(zb) deq(zsp) (cm) 0.4
ƒawf fc(MHz) 2.6 2.6 2.5 - 2.6 2.6
Dim of Aaprt X(cm) 1.4 0.9 - 1.4 1.9
Y(cm) 1.0 1.0 - 1.0 1.0
tdPD (µsec) 1.0
prr PRF (Hz) 635.2
prat max. Ipi pr@PIImax (MPa) 3.3
deq at max. Ipi d
eq@PIImax (cm) 0.4
Focal Length FLX(cm) 3.5 2.2 - 4.8
FLY(cm) 7.0 7.0 - 3.5
Ipa,αat max. MI IPA.3@MImax (W/cm2)447.7
Frequency (MHz) D2.5 D2.5 D2.5 - D2.5 D2.5
Image Depth (cm) 3.5 4.8 3.5 - 3.5 4.8
Vel Scale (kHz) 1.80 4.90 1.1 - 1.07 4.90
Penet On On On - On On
ROI 60deg 5deg - - - 5deg
PS 14 14 16.0 - 16 14
Assoc Acoustic Paramete
Other infromation
Operating Control Conditions

Acoustic Output Data
LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual 1-9
Direction 5116269-100 Rev. 2
3C Probe (continued)
NOTE:
a. This index is not required for this operation mode; see section 4.1.3.1 of the
Output Display Standard(NEMA UD-3)
b. This probe is not intended for transcranial or neonatal cephalic uses.
c. This formulation for TIS is less than that for an alternate formulation in this
mode.
# No data are reported for this operating condition since the global maximum
index value is not reported for the reason listed.
Table 1-7: Transducer Mode: 3C Operating Mode: PWD-Mode (inch.B-mode)
Index Label MI TIS TIB TIC
scan non-scan non-
scan
Aaprt< Aaprt>1
Global Maximum: Index Value 1.6 1.4 1.1 - 3.2 2.2
IEC FDA Units
pra p
r.3 (MPa) 2.5
PWo (mW) 144.7 90.3 90.3 103.9
min of [Pα(zs, Ita,α(zs)] [(W.3(Z1),ITA.3(z1)]) -
zsz
1(cm) -
zbp z
bp (cm) -
zbz
sp (cm) 2.6
zat max. Ipi,αzsp (cm) 3.3
deq(zb) deq(zsp) (cm) 0.5
ƒawf fc(MHz) 2.6 2.6 2.5 - 2.5 2.5
Dim of Aaprt X(cm) 1.4 0.9 - 0.9 0.9
Y(cm) 1.0 1.0 - 1.0 1.0
tdPD (µsec) 1.0
prr PRF (Hz) 1796.0
prat max. Ipi pr@PIImax (MPa) 3.3
deq at max. Ipi d
eq@PIImax (cm) 0.5
Focal Length FLX(cm) 3.5 2.2 - 2.2
FLY(cm) 7.0 7.0 - 7.0
Ipa,αat max. MI IPA.3@MImax (W/cm2)447.4
Frequency (MHz) D2.5 T4.0 D2.5 - D2.5 D2.5
Image Depth (cm) 3.5 10.0 2.2 - 2.2 2.2
Vel Scale (kHz) 0.64 - 1.23 - 1.23 1.23
SV 3 - 6 - 6 6
Penet on - on - on on
Assoc Acoustic Paramete
Other infromation
Operating Control Conditions

Acoustic Output
1-10 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual
Direction 5116269-100 Rev. 2
3.5C Probe
NOTE:
a. This index is not required for this operation mode; see section 4.1.3.1 of the
Output Display Standard(NEMA UD-3)
b. This probe is not intended for transcranial or neonatal cephalic uses.
c. This formulation for TIS is less than that for an alternate formulation in this
mode.
# No data are reported for this operating condition since the global maximum
index value is not reported for the reason listed.
Table 1-8: Transducer Mode: 3.5C Operating Mode: B-Mode
Index Label MI TIS TIB TIC
scan non-scan non-
scan
Aaprt< Aaprt>1
Global Maximum: Index Value 1.5 <1 - - - 2.3
IEC FDA Units
pra p
r.3 (MPa) 2.4
PWo (mW) #- -216.5
min of [Pα(zs, Ita,α(zs)] [(W.3(Z1),ITA.3(z1)]) -
zsz
1(cm) -
zbp z
bp (cm) -
zbz
sp (cm) -
zat max. Ipi,αzsp (cm) 3.6
deq(zb) deq(zsp) (cm) -
ƒawf fc(MHz) 2.4 # - - - 2.0
Dim of Aaprt X(cm) #- - -3.3
Y(cm) #- - -1.3
tdPD (µsec) 0.7
prr PRF (Hz) 2383.2
prat max. Ipi pr@PIImax (MPa) 3.2
deq at max. Ipi d
eq@PIImax (cm) -
Focal Length FLX(cm) #- - 4.8
FLY(cm) #- - 6.6
Ipa,αat max. MI IPA.3@MImax (W/cm2)288.4
Frequency (MHz) T5.0 # - - - T4.0
Image Depth (cm) 30.0 # - - - 8.0
Assoc Acoustic Paramete
Other infromation
Operating Control Conditions

Acoustic Output Data
LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual 1-11
Direction 5116269-100 Rev. 2
3.5C Probe (continued)
NOTE:
a. This index is not required for this operation mode; see section 4.1.3.1 of the
Output Display Standard(NEMA UD-3)
b. This probe is not intended for transcranial or neonatal cephalic uses.
c. This formulation for TIS is less than that for an alternate formulation in this
mode.
# No data are reported for this operating condition since the global maximum
index value is not reported for the reason listed.
Table 1-9: Transducer Mode: 3.5C Operating Mode: M-Mode (inc.B-mode)
Index Label MI TIS TIB TIC
scan non-scan non-
scan
Aaprt< Aaprt>1
Global Maximum: Index Value 1.5 <1 - <1 1.0 2.0
IEC FDA Units
pra p
r.3 (MPa) 2.4
PWo (mW) #- 34.8 186.2
min of [Pα(zs, Ita,α(zs)] [(W.3(Z1),ITA.3(z1)]) #
zsz
1(cm) #
zbp z
bp (cm) #
zbz
sp (cm) 3.6
zat max. Ipi,αzsp (cm) 3.6
deq(zb) deq(zsp) (cm) 0.6
ƒawf fc(MHz) 2.4 # - # 2.4 2.0
Dim of Aaprt X(cm) #- #2.43.3
Y(cm) #- #1.31.3
tdPD (µsec) 0.7
prr PRF (Hz) 2383.2
prat max. Ipi pr@PIImax (MPa) 3.2
deq at max. Ipi d
eq@PIImax (cm) 0.6
Focal Length FLX(cm) #- # 4.8
FLY(cm) #- # 6.6
Ipa,αat max. MI IPA.3@MImax (W/cm2)288.4
Frequency (MHz) T5.0 # - # T5.0 T5.0
Image Depth (cm) 30.0 # - # 30.0 30.0
Assoc Acoustic Paramete
Other infromation
Operating Control Conditions

Acoustic Output
1-12 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual
Direction 5116269-100 Rev. 2
3.5C Probe (continued)
NOTE:
a. This index is not required for this operation mode; see section 4.1.3.1 of the
Output Display Standard(NEMA UD-3)
b. This probe is not intended for transcranial or neonatal cephalic uses.
c. This formulation for TIS is less than that for an alternate formulation in this
mode.
# No data are reported for this operating condition since the global maximum
index value is not reported for the reason listed.
Table 1-10: Transducer Mode: 3.5C Operating Mode: CF-Mode (inch.M-mode)
Index Label MI TIS TIB TIC
scan non-scan non-
scan
Aaprt< Aaprt>1
Global Maximum: Index Value 1.7 <1 - <1 2.1 2.3
IEC FDA Units
pra p
r.3 (MPa) 1.8
PWo (mW) #- 31.5 214.2
min of [Pα(zs, Ita,α(zs)] [(W.3(Z1),ITA.3(z1)]) #
zsz
1(cm) #
zbp z
bp (cm) #
zbz
sp (cm) 5.0
zat max. Ipi,αzsp (cm) 5.0
deq(zb) deq(zsp) (cm) 0.5
ƒawf fc(MHz) 3.1 # - # 3.1 2.0
Dim of Aaprt X(cm) #- #3.33.3
Y(cm) #- #1.31.3
tdPD (µsec) 0.8
prr PRF (Hz) 635.2
prat max. Ipi pr@PIImax (MPa) 4.5
deq at max. Ipi d
eq@PIImax (cm) 0.5
Focal Length FLX(cm) #- # 4.8
FLY(cm) #- # 6.6
Ipa,αat max. MI IPA.3@MImax (W/cm2)452.8
Frequency (MHz) D3.3 # - # D3.3 D2.0
Image Depth (cm) 4.8 # - # 4.8 4.8
Vel Scale (kHz) 1.80 # - # 1.23 7.69
Penet Off # - # Off On
ROI 70deg # - # - 5deg
PS 12 # - # 16 12
Assoc Acoustic Paramete
Other infromation
Operating Control Conditions

Acoustic Output Data
LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual 1-13
Direction 5116269-100 Rev. 2
3.5C Probe (continued)
NOTE:
a. This index is not required for this operation mode; see section 4.1.3.1 of the
Output Display Standard(NEMA UD-3)
b. This probe is not intended for transcranial or neonatal cephalic uses.
c. This formulation for TIS is less than that for an alternate formulation in this
mode.
# No data are reported for this operating condition since the global maximum
index value is not reported for the reason listed.
Table 1-11: Transducer Mode: 3.5C Operating Mode: PWD-Mode (inch.B-mode)
Index Label MI TIS TIB TIC
scan non-scan non-
scan
Aaprt< Aaprt>1
Global Maximum: Index Value 1.7 <1 - <1 2.1 <1
IEC FDA Units
pra p
r.3 (MPa) 3.0
PWo (mW) #- 31.5 #
min of [Pα(zs, Ita,α(zs)] [(W.3(Z1),ITA.3(z1)]) #
zsz
1(cm) #
zbp z
bp (cm) #
zbz
sp (cm) 3.7
zat max. Ipi,αzsp (cm) 5.0
deq(zb) deq(zsp) (cm) 0.3
ƒawf fc(MHz) 3.1 # - # 2.0 #
Dim of Aaprt X(cm) #- #2.4#
Y(cm) #- #1.3#
tdPD (µsec) 0.8
prr PRF (Hz) 1796.0
prat max. Ipi pr@PIImax (MPa) 4.5
deq at max. Ipi d
eq@PIImax (cm) 0.3
Focal Length FLX(cm) #- # #
FLY(cm) #- # #
Ipa,αat max. MI IPA.3@MImax (W/cm2)452.3
Frequency (MHz) D3.3 # - # D2.0 #
Image Depth (cm) 4.8 # - # 3.5 #
Vel Scale (kHz) 0.64 - - # 1.23 #
SV 1 - - # 4 #
Penet Off - - # On #
Assoc Acoustic Paramete
Other infromation
Operating Control Conditions

Acoustic Output
1-14 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual
Direction 5116269-100 Rev. 2
3.5C Probe (continued)
NOTE:
a. This index is not required for this operation mode; see section 4.1.3.1 of the
Output Display Standard(NEMA UD-3)
b. This probe is not intended for transcranial or neonatal cephalic uses.
c. This formulation for TIS is less than that for an alternate formulation in this
mode.
# No data are reported for this operating condition since the global maximum
index value is not reported for the reason listed.
Table 1-12: Transducer Mode: 3.5C Operating Mode: Contrast
Index Label MI TIS TIB TIC
scan non-scan non-
scan
Aaprt< Aaprt>1
Global Maximum: Index Value 1.5 2.0 - - - 1.5
IEC FDA Units
pra p
r.3 (MPa) 2.7
PWo (mW) 141.8 - - 141.8
min of [Pα(zs, Ita,α(zs)] [(W.3(Z1),ITA.3(z1)]) -
zsz
1(cm) -
zbp z
bp (cm) -
zbz
sp (cm) -
zat max. Ipi,αzsp (cm) 3.5
deq(zb) deq(zsp) (cm) -
ƒawf fc(MHz) 3.2 3.2 - - - 3.2
Dim of Aaprt X(cm) 3.3 - - - 3.3
Y(cm) 1.3 - - - 1.3
tdPD (µsec) 0.4
prr PRF (Hz) 2383.2
prat max. Ipi pr@PIImax (MPa) 4.1
deq at max. Ipi d
eq@PIImax (cm) -
Focal Length FLX(cm) 4.8 - - 4.8
FLY(cm) 6.6 - - 6.6
Ipa,αat max. MI IPA.3@MImax (W/cm2)337.0
Frequency (MHz) CHA
3.0 CHA 3.0 ---CHA 3.0
Image Depth (cm) 30.0 8.0 - - - 8.0
Assoc Acoustic Paramete
Other infromation
Operating Control Conditions
