P/N 1068351 • REV 10 • ISS 03JUN09
1200C-2000C Fire Alarm Control
Panel, Repeater, and Black Box
Installation Manual

Copyright © 2009 GE Security, Inc.
This document may not be copied in whole or in part or otherwise reproduced without prior
written consent from GE Security, Inc., except where specifically permitted under US and
international copyright law.
Disclaimer The information in this document is subject to change without notice. GE Security, Inc.
(“GE Security”) assumes no responsibility for inaccuracies or omissions and specifically disclaims
any liabilities, losses, or risks, personal or otherwise, incurred as a consequence, directly or
indirectly, of the use or application of any of the contents of this document. For the latest
documentation, contact your local supplier or visit us online at www.gesecurity.eu.
This publication may contain examples of screen captures and reports used in daily operations.
Examples may include fictitious names of individuals and companies. Any similarity to names
and addresses of actual businesses or persons is entirely coincidental.
Trademarks and patents GE and the GE monogram are trademarks of General Electric Company. Other trade names
used in this document may be trademarks or registered trademarks of the manufacturers or
vendors of the respective products.
Intended use Use this product only for the purpose it was designed for; refer to the data sheet and user
documentation for details. For the latest product information, contact your local supplier or visit
us online at www.gesecurity.eu
Certification and compliance
2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as
unsorted municipal waste in the European Union. For proper recycling, return this product to
your local supplier upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see: www.recyclethis.info.
2004/108/EC (EMC directive): Non-European manufacturers must designate an authorized
representative in the Community. Our authorized manufacturing representative is:
GE Security B.V., Kelvinstraat 7,
6003 DH Weert, The Netherlands.
2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union. See the product documentation for specific
battery information. The battery is marked with this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information see: www.recyclethis.info.
Contact information For contact information see our Web site: www.gesecurity.eu.

1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual I
Content
Important information II
Introduction II
Product compatibility II
Support II
Limitation of liability II
Installation and commissioning 1
Cabinet layout for 1200C control panels 1
Cabinet layout for 2000C control panels 2
Inside door layout for 1200C-2000C control panels 3
General installation and connection guidelines 4
Connecting the LC1502 loop module 5
Connecting the SD2000 common I/O module 6
Connecting the FEP2000N main controller module 12
Connecting the NC2011 and NC2051 network modules 13
Connecting the LON2000 serial communication module 15
Connecting the ZE2016 and ZE2064 zone LED modules 16
Connecting the mains power supply 17
Connecting the batteries 24
Commissioning the control panel 26
Basic configuration options 29
Maintenance 30
Fire system maintenance 30
Battery maintenance 31
Technical specifications 32
Appendixes 35
Appendix A: Modules 35
Appendix B: Dimensions and weights 37
Appendix C: Maximum zones and loops 38
Appendix D: Cable specifications 39
Appendix E: Product compliance 41

II 1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual
Important information
Introduction
This is the installation manual for GE Security FP1200C-2000C addressable fire
control panels, repeaters, and emulators. Read these instructions and all related
documentation entirely before installing or operating this product.
All 1200C-2000C control panels are designed to comply with the requirements of
European standards EN 54-2 for control and indicating equipment, and EN 54-4 for
power supply equipment)
For further details on EN 54 compliance and for a complete list of CPD-compliant
control panels in this range, see “Appendix E: Product compliance” on page 41.
Product compatibility
All models are compatible with GE Security Aritech fire detectors and manual call
points. Compatibility with third-party products cannot be guaranteed. Consult your
local supplier for further information.
Support
For assistance installing, operating, maintaining, and troubleshooting this product,
please contact your local supplier.
Limitation of liability
Installation in accordance with this manual, applicable codes, and the instructions of
the authority having jurisdiction is mandatory. GE Security shall not under any
circumstances be liable for any incidental or consequential damages arising from
loss of property or other damages or losses owing to the failure of GE Security
products beyond the cost of repair or replacement of any defective products.
GE Security reserves the right to make product improvements and change product
specifications at any time.
While every precaution has been taken during the preparation of this manual to
ensure the accuracy of its contents, GE Security assumes no responsibility for errors
or omissions.

1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual 1
Installation and commissioning
WARNING: This product must be installed and maintained by qualified personnel
adhering to the CEN/TS 54-14 standard (or the corresponding national standard) and
any other applicable regulations.
Cabinet layout for 1200C control panels
Figure 1: Typical cabinet layout for 1200C control panels
1. FEP2000N mains controller module
2. PS1200N power supply interface module
3. LC1502 loop module
4. SD2000 common I/O module
5. PS2000N power supply unit
6. Earth stud
7. Fuse terminal block
8. 12V batteries
For detailed module information for all control panels see “Appendix A: Modules” on
page 35

2 1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual
Cabinet layout for 2000C control panels
Figure 2: Typical cabinet layout for 2000C control panels
1. FEP2000N mains controller module
2. Earth studs
3. PS1200N power supply interface
module
4. LC1502 loop modules
5. SD2000 common I/O module
6. 12V batteries
7. Fuse terminal block
8. PS2000N power supply unit
For detailed module information for all control panels see “Appendix A: Modules” on
page 35.

1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual 3
Inside door layout for 1200C-2000C control panels
Figure 3: Typical inside door layout for 1200C-2000C control panels
1. KP2000 keypad module
2. LCD1200 LCD screen
3. FC1200N or FC2012 host CPU module
4. NC2011 or NC2051 network module (optional)
5. ZE2016 or ZE2064 zone LED module
6. HDIS2000N or HDIS2000-F LED display module
For detailed module information for all control panels see “Appendix A: Modules” on
page 35.

4 1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual
General installation and connection guidelines
Where to install the control panel
Make sure the installation location is free from construction dust and debris, and
immune to extreme temperature ranges and humidity (see “Technical specifications”
on page 32 for more information on the operating temperature and relative humidity
specifications).
Allow for enough floor and wall space so the panel can be installed and serviced
without any obstructions. The cabinet should be mounted so that the user interface is
at eye level.
Recommended cables
Recommended cables for your fire system are shown in the table below. For more
detailed information on cable characteristics and requirements see “Appendix D:
Cable specifications” on page 39.
WARNING: Failure to use the recommended cable may impact system performance.
Table 1: Recommended cables
Cable Cable description Maximum cable length
Mains cable 3 x 1.5 mm N/A
Loop cable Shielded, twisted pair cable 2 km
RS485 network cable CAT5 800 m
Fibre optic network cable ST duplex 50/125, 62.5/125, or
100/140
1.7 km (see note below)
LON network cable CAT5 1.5 km
RS232 serial communication
cable
7-way RS232 null modem cable
with full handshaking
12 m
Note: Under ideal conditions the maximum distance between nodes is 1.7 km, but an
optical power budget calculation should be performed to determine the correct
maximum distance for each site.
Installing or replacing control panel modules
WARNING: Always back up site data before installing or replacing modules.
When control panel modules are replaced or additional modules installed, the control
panel automatically reconfigures and all site data is lost. Always back up site data
before installing or replacing modules.

1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual 5
Connecting the LC1502 loop module
The LC1502 loop module allows for the connection of up to two Class A loops or up to
four Class B loops.
The maximum number of loop modules that can be installed will depend on the
control panel model – see “Appendix C: Maximum zones and loops” on page 38 for
more information.
A calculation should be performed for each loop to ensure that the minimum
required loop voltage is maintained for the expected load conditions.
The LC1502 module is located in the cabinet box, between the PS1200N module and
the SD2000 (or VDS2000) module.
Figure 4: LC1502 loop module
1. Loop Class configuration jumpers A and B
2. Class B loop 1 or Class A loop 1 out
3. Class B loop 2 or Class A loop 1 return
4. Class B loop 3 or Class A loop 2 out
5. Class B loop 4 or Class A loop 2 return
Note: For EN 54 compliance an isolator must be installed after every 32 devices.
Loop Class configuration
Configure the loop Class using jumpers A and B on the loop module (Figure 4 above).
All three A/B jumpers must be configured for each loop module. When more than one
loop module is installed jumper configuration must be the same for all modules.
• Select jumper A for up to two Class A loops for each loop module
• Select jumper B for up to four Class B loops for each loop module

6 1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual
Connecting the SD2000 common I/O module
The SD2000 common I/O module provides the common inputs and outputs for the
control panel.
The SD2000 module is located in the rear cabinet and is the last module in the group.
It is connected to the LC1502 module.
Note: This module is not included with French or German control panels.
Figure 5: SD2000 common I/O module
1. IN5 fire routing return input (VdS mode only)
2. IN6 fire protection fault input (VdS mode only)
3. IN7 fire routing fault input (VdS mode only)
4. IN8 general input
5. OUT1 fire alarm equipment output
6. OUT2 fire routing equipment output
7. OUT3 fire protection equipment output
8. OUT4 fault routing output
9. OUT5 to OUT8 programmable relays 1 to 4

1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual 7
Programmable relays
The common I/O module has four programmable relays. Each relay has common (C),
normally closed (NC), and normally open (NO) contacts.
Figure 6: Common I/O module programmable relays
1. OUT8 programmable relay 4 LED
2. OUT7 programmable relay 3 LED
3. OUT6 programmable relay 2 LED
4. OUT5 programmable relay 1 LED
5. OUT8 programmable relay 4
6. OUT7 programmable relay 3
7. OUT6 programmable relay 2
8. OUT5 programmable relay 1

8 1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual
Class A loop supervised outputs
For Class A loops the common I/O module provides four supervised outputs:
• Fire alarm equipment output (OUT1)
• Fire routing equipment output (OUT2)
• Fire protection equipment output (OUT3)
• Fault routing output (OUT4)
All outputs supply 24 VDC when active.
Figure 7: Common I/O module supervised outputs for Class A loops
1. OUT4 fault routing output LED
2. OUT2 fire routing equipment output LED
3. OUT3 fire protection equipment output LED
4. OUT1 fire alarm equipment output LED
5. OUT4 fault routing output
6. OUT3 fire protection equipment output
7. OUT2 fire routing equipment output
8. OUT1 fire alarm equipment output
Table 2: Supervised output specifications for Class A loops
Output Output number termination Polarity Behaviour
Fire alarm
equipment
OUT1 3K3Non-reversed
Fire routing
equipment
OUT2 3K3Non-reversed
Fire protection
equipment
OUT3 3K3Non-reversed
Fault routing OUT4 3K3Non-reversed Active in normal
position

1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual 9
Class B loop relay outputs
For Class B loops the common I/O module provides four relay outputs:
• Sounder output (OUT1)
• Fire brigade output (OUT2)
• Fire protection equipment output (OUT3)
• Fault routing output (OUT4)
Two relay configurations are available for each output. The relay behaviour is
configured using jumpers J2 to J7, J12 to J13, and J18 to J19 on the module PCB.
Configuration of outputs 1 to 3
Jumper configuration options for relay outputs 1 to 3 are shown below.
Jumper configuration options for relay outputs 1 to 3 with Class B loops
Output Output number Option 1 Option 2 Comments
Sounder OUT1 J12 IN J12 OUT J18 OUT
J13 OUT J13 IN J19 OUT
Fire brigade OUT2 J2 IN J2 OUT J18 OUT
J3 OUT J3 IN J19 OUT
Fire protection
equipment OUT3 J4 IN J4 OUT
J5 OUT J5 IN
Figure 8: Jumper configuration options

10 1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual
Configuration of output 4
Jumper configuration options for relay output 4 are shown below. The switch is
closed when there is a fault and open when there is no fault.
Jumper configuration options for output 4 with Class B loops
Output Output number Option 1 Option 2 Comments
Fire routing OUT4 J6 IN J6 OUT
J7 OUT J7 IN
Figure 9: Jumper configuration options
Supervised inputs
The common I/O module has four inputs.
Input function for EN, NEN, and EP modes
In EN, NEN, and EP mode the four inputs have no dedicated function and are freely
programmable using I/O logic.

1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual 11
Input function for VdS mode
In VdS mode inputs 5 to 8 are allocated as follows:
• General input (IN8)
• Fault routing fault input (IN7)
• Fire protection fault input (IN6)
• Fault routing return input (IN5)
Figure 10: Common I/O module supervised inputs in VdS mode
1. IN5 general input OR fault routing return input (VdS mode)
2. IN6 general input OR fire protection fault input (VdS mode)
3. IN7 general input OR fault routing fault input (VdS mode)
4. IN8 general input

12 1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual
Connecting the FEP2000N main controller module
The FEP2000N main controller module is located in the rear cabinet. It is the first
module of the group and is connected to the PS1200N module.
Figure 11: Main controller module auxiliary inputs
1. IN4 auxiliary input 4
2. IN3 auxiliary input 3
3. IN2 auxiliary input 2
4. IN1 auxiliary input
5. FC1200N or FC2012 host CPU module connector

1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual 13
Connecting the NC2011 and NC2051 network modules
The NC2011 and NC2051 network modules enable a wide range of network
topologies when networking 1200C-2000C control panels and repeaters.
The NC2011 and NC2051 modules are located on the inside of the control panel door
(top layer) and connected to the FC1200N or FC2012 host CPU module.
General information
All network nodes use the ARCNET protocol. Every node on the network must have a
network module installed.
Where cabling runs between buildings or in high-noise or harsh environments a fibre-
optic network should be used.
NC2011 network module for RS485 networks
Figure 12: NC2011 network module
1. Termination jumper
2. Shield
3. Earth jumper
Table 3: NC2011 jumper configuration
Jumper Setting Description
Termination jumper (T+) A Not terminated
B Terminated
Earth jumper (S) A Not earthed
B Earthed

14 1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual
NC2051 network module for fibre-optic networks
Figure 13: NC2051 network module

1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual 15
Connecting the LON2000 serial communication module
The LON2000 serial communication module allows serial communication between
1200C-2000C series addressable control panels and 700 series conventional control
panels. It cannot be used with repeaters.
The module is installed onto the P13, 20-PIN male connector of the FC1200N or
FC2012 host CPU module located on the inside of the control panel door.
Figure 14: LON2000 serial communication module
1. Service switch
2. Termination jumper (J1)
Termination
If a LON2000 serial communication module is installed into the first or last control
panel of a LON network, then the termination jumper (J1) must be inserted to
terminate the communication port.
Termination jumper (J1) Description
Inserted The serial communication port is terminated with 120
Not inserted The serial communication port is not terminated

16 1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual
Connecting the ZE2016 and ZE2064 zone LED modules
The ZE2016 and ZE2064 zonle LED modules are used to increase the number of
visible zones for 1200C and 2000C control panels.
The maximum number of zone modules that can be installed will depend on the
control panel model – see “Appendix C: Maximum zones and loops” on page 38 for
more information.
The ZE2016 and ZE2064 modules are located on the inside of the control panel door
and are connected to the HDIS2000N or HDIS2000-F LED display module.
Caution: The ZE2016 and ZE2064 zone LED modules must ntot be installed together
in the same control panel.
