Color Logic
Select the correct FABRIC CARE setting. Match the particular color
below the words with the same color on the Cycle Dial.
Example: Drying a load of clothing labeled permanent press.
Choose the FABRIC CARE setting -—for this load it would be the
EASY CARE MED. HEAT (which is a particular color).
Turn the Cycle Dial to the area that has the same color as the
FABRIC CARE setting you have chosen—for this load it would be
the EASY CARE PERM PRESS.
2
1
Fabric Care
COTTONS For regular to heavy cottons.
REG. HEAT
EASY CARE For synthetics, blends, delicates and
MED HEAT items labeled permanent press.
FLUFF For fluffing items without heat. Use the
NO HEAT TIMED DRY cycle.
DELICATES For delicates, synthetics and items labeled
LOW HEAT tumble dry low.
ULTRA CARE For lingerie and special care fabrics.
GENTLE HEAT
Drying Cycles — Automatic cycles automatically sense
fabric dryness. Select MORE DRY for
heavier fabrics, LESS DRY for lighter
fabrics. Timed cycles run for the
selected time.
COTTONS For cottons and most towels. For most loads select
AUTOMATIC the OPTIMUM DRY setting.
EASY CARE For synthetic blends and delicates.
PERM PRESS/
DELICATES
ULTRA CARE For special care fabrics such as rayons, woolens
and silks.
TIMED DRY Set the Cycle Selector at the desired drying time.
QUICK DRY For one or two items.
DRYEL®For use with Dryel “dry clean only” fabric care
system. Use the MED-HEAT fabric care setting.
See product package for instructions.
DEWRINKLE For removing wrinkles from items that are clean and
dry or that are very lightly damp.
START
START
FABRIC CARE
DELICATES
LOW HEAT
COTTONS
REG. HEAT EASY CARE
MED. HEAT
FLUFF
NO HEAT
WRINKLE CARE
EXTENDED COOL AIR TUMBLE ELECTRONIC TONE
5 HEAT SETTINGS
OFF ON
SIGNAL
OFF ON
ULTRACARE
GENTLE HEAT
Jeans/Towels
Shirts
MORE DRY
1 or 2 items
LESS DRY
Rayon/Silk
LESS DRY
Woolens/Linens
MORE DRY
Wrinkle Free Cottons
MORE DRY
Knits
LESS DRY
WRINKLE CARE
WRINKLE
CARE
WRINKLE CARE
OPTIMUM DRY COOL DOWN
DEWRINKLE
DRYEL
QUICK DRY
COTTONS
TIMED DRY
PERM. PRESS
DELICATES
EASY CARE
80
MIN
7060
40 50
20
30 ULTRA CARE
D
r
y
n
e
s
s
S
e
n
s
o
r
C
y
c
l
e
123
Owners Manual Supplement for model DPSR513
(replaces pages 6, 7, and 8 of your Owner’s Manual)
About the dryer control panel.
NOTE: Drying times will vary according to the type of heat used (Electric, Natural or LP gas), size of load, types of fabrics, wetness of clothes,
and condition of exhaust ducts.
Start — Close the dryer door. Select START. Opening the door during operation will stop the dryer. To
restart the dryer, close the door and select START to complete the cycle.
3
12
Pub. No. 49-90039
JR 12-99
Printed in Canada

About your dryer features.
End of Cycle Signal
This signal will sound just before the end of the
cycle to remind you to remove the clothes.
If you selected the WRINKLE CARE option
the signal will sound at the end of the drying
time and will sound several times during the
WRINKLE CARE cycle. This will remind you that
it is time to remove the clothes.
NOTE:
■ Remove garments promptly at the sound
of the signal. Place clothes on hangers
so wrinkles won’t set in.
■ Use the END OF CYCLE SIGNAL especially
when drying fabrics like polyester knits and
permanent press. These fabrics should
be removed so wrinkles won’t set in.
E
L
E ELECTRONIC TONE
SIGNAL
OFF ON
Drum Lamp
Before replacing the light bulb, be sure to
unplug the dryer power cord or disconnect
the dryer at the household distribution panel
by removing the fuse or switching off the circuit
breaker. Reach above dryer opening from inside
the drum. Remove the bulb and replace with the
same size bulb.
Drying Rack
A handy drying rack may be used for drying
articles such as stuffed toys, pillows or washable
sweaters.
Hook the rack over the lint filter so the rack
extends into the dryer drum.
NOTE:
■The drying rack must be used with the
TIMED CYCLE.
■Do not use this drying rack when there are
other clothes in the dryer.
Wrinkle Care
Use this option to minimize the wrinkles in
clothes. It provides approximately 15 minutes
of no-heat tumbling after the clothes are dry.
This option can only be used with the
Automatic cycles.If you are using the CYCLE
SIGNAL and you select the WRINKLE CARE option,
a signal will sound at the end of the drying time
and several times during the WRINKLE CARE cycle.
This will remind you that it is time to remove the
clothes.
If WRINKLE CARE is not ON, the dryer will stop
once the timer reaches the WRINKLE CARE mark
on the cycle dial.
A
RE
A
T
WRINKLE CARE
EXTENDED COOL AIR TUMBLE
OFF ON
SensorDry
This feature is only activated in the
automatic cycles.
SensorDry provides greater drying accuracy
than standard machines, resulting in shorter
dry times and better clothes care. As the
clothes tumble, they touch a moisture sensor.
The sensor will stop the heating cycle as soon as
the clothes have reached the selected dryness.
On some models, there is a Dryness Sensor
Cycle indicator light. This light is illuminated
during automatic cycles. When the SensorDry
feature stops the heating cycle, the light will
go out and the cool down period will begin.
Note: The clothes will be hot if they are
removed immediately after the indicator
light goes out.
SensorDry
