GE DSXH47GG Manual

For answers to your Monogram,® GE Profile™
or GE®appliance questions, visit our website
at geappliances.com or call GE Answer Center®
service, 800.626.2000.
Specification Revised 3/10 360471
Dimensions and Installation Information (in inches)
Exhaust Options: 3-way via rear, right, and bottom.
Circuit Requirements: An individual, properly grounded
branch circuit, protected by a 30-amp circuit breaker or
a time-delay fuse, is required.
Note: Dryer wall outlet must be located within 36”
of service cord entry and accessible when dryer is
mounted in position.
Installation Information: For complete information, see
installation instructions packed with your dryer.
SIDE VIEW
28-1/2
48-1/2
4-3/4
Optional
Vent Knockout
Door Open
90°
4-3/8
REAR VIEW
27
5
2-1/4
36
Under
Counter
36
3/16"
Gas Pipe Connection
Electric
Connection
13-9/16
Gas Dryer Rating
120V 60Hz, 6A
DSXH47GG
GE®5.8 Cu. Ft. Extra-Large Capacity Frontload Gas Dryer

360471
Specification Revised 3/10
Special Installation Requirements:
Stacked Installation:
•Bracketforstackingdryer,DSXH47EG/GG,orderPub.No.14-A026orSTACKIT1WWatadditionalcost.
Undercounter installation:
•TheWSSH300GandDSXH47EG/GGrequireacustom-sizedcountertop(36inchestotheundersideofthecountertop).
Nospecialwasherordryertopisrequired.
Alcove or Closet Installation:
•Ifyourdryerisapprovedforinstallationinanalcoveorcloset,itwillbestatedonalabelonthedryerback.
•ThedryerMUSTbeexhaustedtotheoutside.
•Minimumclearancesbetweendryercabinetandadjacentwallsorothersurfacesare:0"eitherside,3"frontandrear
•Minimumverticalspacefromfloortooverheadcabinets,ceilings,etc.is52".
•Closetdoorsmustbelouveredorotherwiseventilatedandmustcontainaminimumof60sq.in.ofopenareaequally
distributed.Ifthisclosetcontainsbothawasherandadryer,doorsmustcontainaminimumof120sq.in.ofopenarea
equally distributed.
•Nootherfuel-burningapplianceshallbeinstalledinthesameclosetwithagasdryer.
Bathroom or Bedroom Installation:
•ThedryerMUSTbeexhaustedtotheoutdoors.
•Theinstallationmustconformwiththelocalcodes,orintheabsenceof
localcodes,withtheNationalElectricCodeandNationalFuelGasCode,ANSIZ223forgasdryers.
Minimum Clearance other than Alcove or Closet Installations:
•Minimumclearancestocombustiblesurfaces0"bothsides,3"rear.
For more information on venting kits and accessories,
please call 1-800-GE-CARES.
DSXH47GG
GE®5.8 Cu. Ft. Extra-Large Capacity Frontload Gas Dryer
For answers to your Monogram,® GE Profile™
or GE®appliance questions, visit our website
at geappliances.com or call GE Answer Center®
service, 800.626.2000.

Specification Revised 3/10 360471
Dryer Exhausting Information – Metal Duct Only
For complete information, see installation instructions packed with your dryer.
Ducting Materials: For best performance, this dryer should be vented with 4” diameter
allrigidmetalexhaustduct.Ifrigidmetalductcannotbeused,thenUL-listedflexible
metal(semi-rigid)ductingcanbeused(KitWX08X10077).Inspecialinstallations,itmay
benecessarytoconnectthedryertothehouseventusingaflexiblemetal(foil-type)duct.
AUL-listedflexiblemetal(foil-type)ductmaybeusedONLYininstallationswhererigid
metalorflexiblemetal(semi-rigid)ductingcannotbeusedANDwherea4”diametercan
be maintained throughout the entire length of the transition duct. Please see installation
instructionpackedwithyourdryerforcompleteinstructionswhenusingflexiblemetal(foil
type)ducting.
Exhaust Length Calculation:
1. Determinethenumberof90°turnsneededforyourinstallation.Ifyouexhausttothe
side or bottom of dryer, add one turn.
2. Themaximumlengthof4’rigid(aluminumorgalvanized)ductwhichcanbetoleratedis
shown in the table.
 Aturnof45°orlessmaybeignored.Two45°turnswithintheductlengthshouldbe
treated as a 90° elbow.
A turn over 45° should be treated as a 90° elbow.
Dryers must be exhausted to the outside.
Caution: For personal safety do not terminate exhaust into a chimney, under any enclosed
housefloor(crawlspace),orintoanattic,sincetheaccumulatedlintcouldcreateafire
hazardormoisturecouldcausedamage.Neverterminatetheexhaustintoacommonduct
or plenum with a kitchen exhaust, since the combination of lint and grease could create a
fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird
nesting,etc.Thewallcapmustalsobelocatedatleast12"abovethegroundoranyother
obstruction with the opening pointed down.
For more information on venting kits and accessories, please call 1-800-GE-CARES.
DSXH47GG
GE®5.8 Cu. Ft. Extra-Large Capacity Frontload Gas Dryer
0 60 ft. 48 ft.
1 52 ft. 40 ft.
Frontload dryers: 2 44 ft. 32 ft.
DSXH43EF/GF 3 32 ft. 24 ft.
DSXH47EG/GG 4 28 ft. 16 ft.
Number
of
90°
turns
Maximum length of
4” dia. rigid metalduct
Exhaust hood type
A
4" opening
B
2-1/2"
opening
A
B
2-1/2
4
Best performance

Specification Revised 3/10 360471
DRYNESS
SENSORDRY
TIMEDDRY
TEMPERATURE
OPTIONS SELECT START PAUSE
CANCEL
DSXH47EG_GGWW
Features and Benefits
• 5.8Cu.Ft.Extra-LargeCapacity-Handlesanylarge-sizeitems
and family-size loads
• RotaryElectronicControlswithCycleStatusLights-Makeiteasy
to select and monitor wash cycles
• PaintedDrum-Painteddrumcoatedwitharustprooffinishto
stand up to heavy use
• FourTemperatureOptions-Providestherighttemperatureforthe
right drying results
• On/OffEnd-Of-CycleSignal-Canbeturnedonsoyoucanhearit
from another room, or turned off when you do not want to
disturb others
• FourAutoDryCycles-Avarietyoffastandflexibleoptionsfor
drying clothes
• SensorDry™- Continually monitors moisture levels to help clothes
look better longer
• InteriorDryerLight-Letsyouseeeverythinginsideforeasy
loading and unloading
• Reverse-A-Door-Offersaddedinstallationflexibility
• ModelDSXH47GGWW–Whiteonwhite
DSXH47GG
GE®5.8 Cu. Ft. Extra-Large Capacity Frontload Gas Dryer
