GE Profile DPVH890EJ Service manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Specification Created 7/08 270198
Listed by
Underwriters
Laboratories
Dimensions and Installation Information (in inches)
Exhaust Options: 4-way via rear, left, right and bottom.
Circuit Requirements: An individual, properly grounded
branch circuit, protected by a 30-amp circuit breaker or
a time-delay fuse, is required.
Note: Dryer wall outlet must be located within 36”
of service cord entry and accessible when dryer is
mounted in position.
Installation Information: For complete information, see
installation instructions packed with your dryer.
S D
T D A F
W U
P
SENSORDRY
TIMEDRY
S
D
L
D
T
D
Harmony
27”
32.34”
39-3/4”
32.34
39-3/4”
4-1/8”
3”
DPVH880
Electric Dryer Rating
240V 5600W, 24A, 60Hz
DPVH890EJ
GE Profile™7.5 Cu. Ft. Colossal Capacity Electric Dryer With Steam

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Special Installation Requirements:
Stacked Installation:
•Bracketsforstackingdryeroverwasherareavailableatanadditonalcost
Alcove or Closet Installation:
•Ifyourdryerisapprovedforinstallationinanalcoveorcloset,itwillbe
stated on a label on the dryer back.
•ThedryerMUSTbeexhaustedtotheoutside.
•Minimumclearancesbetweendryercabinetandadjacentwallsorother
surfaces are: 0" either side, 3" front and rear
•Minimumverticalspacefromfloortooverheadcabinets,ceilings,etc.is52".
•Closetdoorsmustbelouveredorotherwiseventilatedandmustcontaina
minimumof60sq.in.ofopenareaequallydistributed.Ifthisclosetcontains
both a washer and a dryer, doors must contain a minimum of 120 sq. in. of
open area equally distributed.
•Nootherfuel-burningapplianceshallbeinstalledinthesameclosetwith
a gas dryer.
Bathroom or Bedroom Installation:
•ThedryerMUSTbeexhaustedtotheoutdoors.
•Theinstallationmustconformwiththelocalcodes,orintheabsenceof
localcodes,withtheNationalFuelGasCode,ANSIZ223.
Minimum Clearance other than Alcove or Closet Installations:
•Minimumclearancestocombustiblesurfaces0"bothsides,3"rear.
For more information on venting kits and accessories,
please call 1-800-GE-CARES.
Stacked Dimensions (in inches)
79"
Harmony
27
1 5
29-1/2
Storage Pedestal Dimensions
(in inches)
SPSD157JMG - Champagne
SPSD157JMV - Vermillion Red
SPSD157JWW - White
Thisoptional15"pedestalraises
the door opening and height of
the washer or dryer. Feet on 15"
pedestalallowittoadjustto15-
3/8" height.
Listed by
Underwriters
Laboratories
Specification Created 7/08 270198
DPVH890EJ
GE Profile™7.5 Cu. Ft. Colossal Capacity Electric Dryer With Steam

Dryer Exhausting Information – Metal Duct Only
For complete information, see installation instructions packed with your dryer.
Ducting Materials: For best performance, this dryer should be vented with 4” diameter all
rigidmetalexhaustduct.If“allrigidmetal”ductcannotbeused,then“flexibleallmetal”
ventingcanbeused,butitwillreducethemaximumrecommendedductlength.
Exhaust Length Calculation:
1. Determinethenumberof90°turnsneededforyourinstallation.Ifyouexhausttothe
side or bottom of dryer, add one turn.
2. Themaximumlengthof4’rigid(aluminumorgalvanized)ductwhichcanbetoleratedis
 showninthetable.Themaximumlengthforflexibleductsarelessthanforrigidduct.
 Aturnof45°orlessmaybeignored.Two45°turnswithintheductlengthshouldbe
treated as a 90° elbow.
A turn over 45° should be treated as a 90° elbow.
Exhausting the dryer to the outside is strongly recommended to prevent large amounts
of moisture and lint from being blown into the room. Gas dryers or any dryer located in a
closet mustbeexhaustedtotheoutside.
Caution: Forpersonalsafetydonotterminateexhaustintoachimney,underanyenclosed
housefloor(crawlspace),orintoanattic,sincetheaccumulatedlintcouldcreateafire
hazardormoisturecouldcausedamage.Neverterminatetheexhaustintoacommonduct
orplenumwithakitchenexhaust,sincethecombinationoflintandgreasecouldcreatea
fire hazard.
Exhaustductsshouldbeterminatedinadamperedwallcaptopreventbackdrafts,bird
nesting,etc.Thewallcapmustalsobelocatedatleast12"abovethegroundoranyother
obstruction with the opening pointed Down.
Otherterminations,suchaslouveredwallboxes,areacceptableprovidedtheyare
equivalent to a 4" opening dampered wall cap.
For more information on venting kits and accessories, please call 1-800-GE-CARES.
Listed by
Underwriters
Laboratories
Specification Created 7/08 270198
DPVH890EJ
GE Profile™7.5 Cu. Ft. Colossal Capacity Electric Dryer With Steam

M
IXED
L
OADS
W
RINKLE
F
REE
A
CTIVE
W
EAR
S
PEED
D
RY
T
IMED
D
RY
A
IR
F
LUFF
W
ARM
U
P
D
ELICATES
P
OWER
SENSOR DRY
TIME DRY
C
OTTONS
S
ENSOR
D
RY
L
EVEL
D
RY
T
EMP
BACK
MY
CYCLE DAMP
ALERT EXTEND
TUMBLE DRUM
LIGHT
LOCK
D
EWRINKLE
Harmony
DPVH580EH/GH
Features and Benefits
• 7.5Cu.Ft.ColossalCapacity-Thiscolossalsizedryerwillbereadyandable
to take on everything the washer sends its way
• SteamRefresh-Helpsreducewrinkles,odorsandrejuvenatesclothes
• SteamDewrinkle-Removeswrinklesandrefreshescleanclothes
• ReverseTumble-Byreversingtherotationofthedrum,youcanexpectgentle,
fast even drying
• DuoDry™System-Quicklyandconsistentlydriesalltypesofclothes
• SpecialtyDryCycles-Providejusttherightlevelsofdryingforbetterfabriccare
• BaffleDry-Built-indryingrackandhanger-clipdesignmultipliesthedrying
options for hard-to-dry items or delicates
• CleanSpeak™CommunicationSystem-Thewashercommunicates
electronically with the dryer, which then presets dry cycles for better clothes
care, increased time savings and greater convenience
• StainlessSteelDrum-Resistsrustandwon'tchip,peelorsnagclothes
• DelayStart-Letsyoudothelaundryonyourterms
• OptionalStackingBracket(GEFLSTACK)-Availableatanadditionalcost
• ModelDPVH890EJMG–Champagne
• ModelDPVH890EJMV–VermillionRed
• ModelDPVH890EJWW–White
Specification Created 7/08 270198
DPVH890EJ
GE Profile™7.5 Cu. Ft. Colossal Capacity Electric Dryer With Steam
