GE Spacemaker DSKS433EBWW Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
360432
Specification Revised 5/09
Listed by
Underwriters
Laboratories
DSKS433EB
GE Spacemaker® Stationary Dryer
Dimensions and Installation Information (in inches)
Shown with WSLP1100A or WSLS1100A and Stack Rack DSDR24D
WSLP1500J
Portable
Washer
or
WSLS1500J
Stationary
Washer
DSKS433EB and
DSKS333EC
Dryer
Stack Rack
DSDR24D
22-7/8
1-5/8
5-1/2
20
79-1/4
38"
WSLP1500J
Portable
or
37-1/2"
WSLS1500J
Stationary
24-1/2 25-1/2
31-1/2
Top
Vent
WSLP1100A
Stationary
Washer
DSKS333EC
Dryer
Stack Rack
DSDR24D
22-7/8
1-5/8
5-1/2
20
77-3/4
38
25-1/2
Top
Vent
31-1/2
stack rack DSR24 w/DDP1380T
24-1/2
33-1/4
46
33-1/4

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
360432
Specification Revised 5/09
Listed by
Underwriters
Laboratories
DSKS433EB
GE Spacemaker® Stationary Dryer
Dimensions and Installation Information (in inches)
Special Installation Requirements
Alcove or Closet Installation:
• If your dryer is approved for installation in an alcove or closet, it will be stated on
a label on the dryer back.
• The dryer MUST be exhausted to the outside.
• Minimum clearances between dryer cabinet and adjacent walls or other
surfaces are:
0" either side
3" front and rear
• Minimum vertical space from floor to overhead cabinets, ceilings, etc. is 52”.
• Closet doors must be louvered or otherwise ventilated and must contain a
minimum of 60 sq. in. of open area equally distributed. If this closet contains
both a washer and a dryer, doors must contain a minimum of 120 sq. in. of open
area equally distributed.
• No other fuel-burning appliance shall be installed in the same closet with
a gas dryer.
Bathroom or Bedroom Installation:
• The dryer MUST be exhausted to the outdoors.
• The installation must conform with the local codes, or in the absence of local
codes, with the National Electric Code and National Fuel Gas Code, ANSI Z223
for gas dryers.
Minimum Clearances other than Alcove or Closet Installation:
• Minimum clearances to combustible surfaces
0" both sides
3" rear
Best performance
Domestic
dryer models
Maximum length of 4"
dia. rigid metal duct
Number
of
90°
turns
Exhaust hood type
A
4"
opening
B
2-1/2"
opening
DSKS433EB
DSKS333EC
DSKP333EC
WSM2780H
0
1
2
3
46 ft.
38 ft.
31 ft.
24 ft.
37 ft.
30 ft.
22 ft.
15 ft.
WSM2700H
0
1
2
3
56 ft.
46 ft.
34 ft.
32 ft.
42 ft.
36 ft.
28 ft.
18 ft.
WSM2420D
WSM2480D
0
1
2
43 ft.
33 ft.
23 ft.
36 ft.
26 ft.
16 ft.
A
4
B
2-1/2

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
360432
Specification Revised 5/09
Listed by
Underwriters
Laboratories
DSKS433EB
GE Spacemaker® Stationary Dryer
Dimensions and Installation Information (in inches)
For complete information, see installation instructions packed with your dryer.
Ducting Materials:
For best performance, this dryer should be vented with 4" diameter all rigid metal
exhaust duct. If rigid metal duct cannot be used, then UL-listed flexible metal (semi-rigid)
ducting can be used (Kit WX08X10077). In special installations, it may be necessary to
connect the dryer to the house vent using a flexible metal (foil-type) duct. A UL-listed
flexible metal (foil-type) duct may be used ONLY in installations where rigid metal or
flexible metal (semi-rigid) ducting cannot be used AND where a 4” diameter can be
maintained throughout the entire length of the transition duct. Please see installation
instruction packed with your dryer for complete instructions when using flexible metal
(foil type) ducting.
Exhaust Length Calculation:
1. Determine the number of 90° turns needed for your installation. If you exhaust to the
side or bottom of dryer, add one turn.
2. The maximum length of 4' rigid (aluminum or galvanized) duct which can be tolerated
is shown in the table.
A turn of 45° or less may be ignored. Two 45° turns within the duct length should be
treated as a 90° elbow. A turn over 45° should be treated as a 90° elbow.
Dryers must be exhausted to the outside.
Caution: For personal safety do not terminate exhaust into a chimney, under any
enclosed house floor (crawl space), or into an attic, since the accumulated lint could
create a fire hazard or moisture could cause damage. Never terminate the exhaust into
a common duct or plenum with a kitchen exhaust, since the combination of lint and
grease could create a fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird
nesting, etc. The wall cap must also be located at least 12" above the ground or any
other obstruction with the opening pointed down.
Dryer Note: Dryer wall outlet must be located within 36" of service
cord entry and accessible when dryer is mounted in position.
DSKS433EBWW
80
100
10
90
OFF
OFF
60
50
40
30
20
70
PERM. PRESS & DELICATESCYCLE
TIMED CYCLE
PUSH TO START
AUTO
REGULAR
TEMPERATURE
REGULAR
(HIGH HEAT)
PERM PRESS
(MED.HEAT)
DELICATES
(LOW HEAT)
FLUFF
(NO HEAT)
*
OFF
cool down
cool
down
*
33-1/4
24-1/2 23-7/8

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
360432
Specification Revised 5/09
Listed by
Underwriters
Laboratories
DSKS433EB
GE Spacemaker® Stationary Dryer
Features and Benefits
• Auto Dry – Uses thermostats to monitor air temperature and
reduce fabric wear
• Multiple Heat Selections – Offers enhanced drying
performance and fabric care
• Multiple Dry Cycles – Deliver optimal drying results
• Rotary Mechanical Controls – Are straightforward and easy
to turn
• Upfront Lint Filter – Easy to reach and clean
• Model DSKS433EBWW – White on white
• Model DSKS433EBWH – White
DSKS433EBWW
80
100
10
90
OFF
OFF
60
50
40
30
20
70
cool down
PERM. PRESS & DELICATESCYCLE
*PREFERRED
REGULARSETTING
TIMED CYCLE
PUSH TO START
AU TO
REGULAR
TEMPERATURE
REGULAR
(HIGH HEAT)
PERM PRESS
(MED.HEAT)
DELICATES
(LOW HEAT)
FLUFF
(NO HEAT)
NORMAL DRY
*
OFF
cool down
cool
down
EXTRA DRY
*
NORMAL DRY
EXTRA DRY
