DRSR483EDCC/WW – GE®Super 7.0 Cu. Ft. Capacity Electric Dryer with Stainless Steel Drum
Specification Revised 3/04
370137
GE Appliances
Dryer Dimensions (in inches)
Exhaust Options:
4-way via rear, right, left and bottom.
NEMA Receptacle codes:
3-prong dryer cord/30A/4' long (cat #WX9X2) is for NEMA10-30R
receptacle
4-prong dryer cord/30A/4' long (cat #WX9X18) is for NEMA14-30R
receptacle
Circuit Requirements:
An individual, properly-grounded branch circuit, protected by a 30-amp circuit
breaker or a time-delay fuse, is required.
Electric Dryer Rating:
240V, 5600W, 24A, 60Hz
208V, 4400W, 22A, 60Hz
Note: Dryer wall outlet must be located within 36" of service cord entry and
accessible when dryer is mounted in position.
Installation Information: For complete information, see installation
instructions packed with your dryer.
36 42
27
23-1/2
2-1/2
25-1/2*
Side View Rear View
8-1/2
28-1/4
23-1/2
11-1/2
*24-1/2" from the edge of the side panel to the front.
25-1/2" from front to edge of endcaps.
For answers to your Monogram,
®GE Profile™or
GE®appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
5''
Back View
Power
Cord Hole
4-1/2''
Power Cord Locations

GE Appliances
DRSR483EDCC/WW – GE®Super 7.0 Cu. Ft. Capacity Electric Dryer with Stainless Steel Drum
For complete information, see installation instructions packed with your dryer.
Ducting Materials:
For best performance, this dryer should be vented with 4” diameter all-rigid metal exhaust duct. If “all-rigid metal”
duct cannot be used, then “flexible all-metal” venting can be used, but it will reduce the maximum recommended
duct length.
Exhaust Length Calculation:
1. Determine the number of 90° turns needed for your installation. If you exhaust to the side or bottom of dryer,
add one turn.
2. The maximum length of 4" rigid (aluminum or galvanized) duct which can be tolerated is shown in the table.
The maximum length for flexible ducts are less than for rigid duct.
2. A turn of 45° or less may be ignored. Two 45° turns within the duct length should be treated as a 90° elbow.
A turn over 45° should be treated as a 90° elbow.
Exhausting the dryer to the outside is strongly recommended to prevent large amounts of moisture and lint
from being blown into the room. Gas dryers or any dryer located in a closet must be exhausted to the outside.
Caution: For personal safety do not terminate exhaust into a chimney, under any enclosed house floor (crawl
space), or into an attic, since the accumulated lint could create a fire hazard or moisture could cause damage.
Never terminate the exhaust into a common duct or plenum with a kitchen exhaust, since the combination of lint
and grease could create a fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird nesting, etc. The wall cap
must also be located at least 12" above the ground or any other obstruction with the opening pointed down.
Other terminations, such as louvered wall boxes, are acceptable provided they are equivalent to a 4" opening
dampered wall cap.
For more information on venting kits and accessories, please call 1-800-GE CARES.
For answers to your Monogram,
®GE Profile™or
GE®appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
Specification Revised 3/04
370137
Dryer Exhausting Information – Use Metal Duct Only
Vertical and Horizontal Ducting
0 150 ft. 127 ft. 75 ft. 52 ft.
1 140 ft. 117 ft. 65 ft. 42 ft.
2 130 ft. 107 ft. 55 ft. 32 ft.
7.3 Capacity Electric 3 120 ft. 97 ft. 45 ft. 22 ft.
and Gas Dryers 4 110 ft. 87 ft. 35 ft. 12 ft.
0 90 ft. 60 ft. 55 ft. 45 ft.
1 60 ft. 45 ft. 40 ft. 30 ft.
7.0 and 6.0 2 45 ft. 35 ft. 30 ft. 20 ft.
Capacity Models 3 35 ft. 25 ft. 20 ft. 15 ft.
all Electric Dryers 4 25 ft. 15 ft. 15 ft. 10 ft.
0 90 ft. 60 ft. 55 ft. 45 ft.
7.0 and 6.0 1 60 ft. 45 ft. 40 ft. 30 ft.
Capacity Models 2 45 ft. 35 ft. 30 ft. 20 ft.
all Gas Dryers 3 35 ft. 25 ft. 20 ft. 15 ft.
0 60 ft. 48 ft. 30 ft. 18 ft.
1 52 ft. 40 ft. 22 ft. 14 ft.
2 44 ft. 32 ft. 14 ft. 10 ft.
5.7 Capacity Electric 3 32 ft. 24 ft. — —
and Gas Dryers 4 28 ft. 16 ft. — —
Number
of
90°
Turns
Maximum Length of 4"
Dia. Rigid Metal Duct
Maximum Length of 4"
Dia. Flexible Metal Duct
Exhaust Hood Type Exhaust Hood Type
Domestic
Dryer Models
A
4" Opening
B
2-1/2"
Opening
A
4" Opening
B
2-1/2"
Opening
A
4
Best Performance
B
2-1/2
A
Special Installation Requirements
Alcove or Closet Installation:
• If your dryer is approved for installation in an alcove or closet, it will be stated on a label on the dryer back.
• The dryer MUST be exhausted to the outside.
• Minimum clearances between dryer cabinet and adjacent walls or other surfaces are:
0" either side
3" front and rear
• Minimum vertical space from floor to overhead cabinets, ceilings, etc. is 52”.
• Closet doors must be louvered or otherwise ventilated and must contain a minimum of 60 sq. in. of
open area equally distributed. If this closet contains both a washer and a dryer, doors must contain
a minimum of 120 sq. in. of open area equally distributed.
• No other fuel-burning appliance shall be installed in the same closet with a gas dryer.
Bathroom or Bedroom Installation:
• The dryer MUST be exhausted to the outdoors.
• The installation must conform with the local codes, or in the absence of local codes, with the
National Fuel Gas Code, ANSI Z223.
Minimum Clearances other than Alcove or Closet Installation:
• Minimum clearances to combustible surfaces
0" both sides
3" rear

GE Appliances
DRSR483EDCC/WW – GE®Super 7.0 Cu. Ft. Capacity Electric Dryer with Stainless Steel Drum
FABRIC CARE
4HeatSettings
WRINKLE CARE
ExtendedCoolAirTumble
SIGNAL
START
COTTONS
AUTOMATIC
MOREDRY
MOREDRY
COOLDOWN
OPTIMUMDRY
LESSDRY
WRINKLECARE
WRINKLE
CARE
LESSDRY
DEWRINKLE
DAMPDRY
MIN
20
QUICKFLUFF
10
30405060
70
80
EASYCARE
TIMEDDRY
STARTCOTTONS
REG.HEAT
FLUFF
NOHEAT
DELICATES
LOWHEAT
EASYCARE
MED.HEAT
OFFOFF
ONLOUD
MEDIUM
AUTOMATIC
WRINKLEFREE
PERM.PRESS
DELICATES
8
C
l
o
t
h
e
s
C
a
r
e
C
y
c
l
e
s
-
S u
p
e
r
C
a
p
a
c
i
t
y
Features and Benefits
• Stainless Steel drum – It resists rust and won’t chip, peel or snag clothes.
• Auto Dry – Uses thermostats to monitor air temperature and reduce fabric wear.
• Four heat selections – Provide the right temperature for the right drying results.
• Wrinkle Care Extended Tumble – Continues to tumble clothes without heat to help
prevent wrinkling and creasing.
• Interior Dryer Light – Lets you see everything inside for easy loading and unloading.
• Eight dry cycles – A variety of fast flexible options for drying clothes.
• Variable end-of-cycle signal – Adjustable volume offers added flexibility.
• Quiet-by-Design™– Engineered for quiet operation.
• Reverse-A-Door – Offers added installation flexibility.
• Upfront Lint Filter – Easy to reach and clean.
• Model DRSR483EDWW – White on white
• Model DRSR483EDCC – Bisque on bisque
