GE Profile J2S968BH User manual

Specification Revised 11/03
221203
J2S968BH/KH/SH/TH – GE Profile™30" Slide-In Dual-Fuel Range
Dimensions (in inches) and Installation Information
2-7/8"
To Front
Surface Of
Countertop
20-5/8"
Door Clearance
From Front
Surface of
Countertop
31-1/4
30
27-1/2
44-3/4
4
Accessory
Backguard
36
2"
(Grates)
24
Acceptable
Gas Line &
Electrical
Outlet Area
Max. depth of
cord, plug,
receptacle box
& gas hookup
3-1/2 to prevent
interference
with drawer
30 Min.
30 Min.
Shave Raised EdgeTo Clear
31-1/8 Wide Control Panel
36
4 Min.
From Walls
23-3/16
18 Min.
13 Max.
3
29-15/16 Min.
30-1/16 Max.
25
9/16
7
12
15
For answers to your Monogram,® GE Profile™or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
Installation Information: Before installing, consult installation instructions
packed with product for current dimensional data.
TM
You must use the rear filler strip kit shipped with the range or the
optional accessory backguard (JXS31, JXS32, JXS33, JXS34) when
installing these ranges.
Note: Cabinets installed adjacent to slide-in ranges must have an
adhesion spec of at least 194°F temperature rating.
Optional Kits for Slide-In Gas Ranges:
(Available at additional cost)
Counter Cutout Dimensions (in inches)
23-3/16
30
If you are NOT using the
optional Filler or Backguard:
30
If you are using the
optional Filler or Backguard:
25
All GE ranges are equipped
with an Anti-Tip device.
The installation of this
device is an important,
required step in the
installation of the range.
Lower/Side Trim Kits
JXS52BB—Lower Trim Kit (Black)
JXS53WW—Lower Trim Kit (White)
JXS55CC—Lower Trim Kit (Bisque)
Endcap Kit
JXS40—Endcap kit to accommodate
replacement where countertop may
already be notched.
Accessory Backguards
JXS31—White Accessory Backguard
JXS32—Brushed-Chrome Accessory
Backguard
JXS34—Black Accessory Backguard
JXS35—Bisque Accessory Backguard
R
Listed by
Underwriters
Laboratories

Specification Revised 11/03
221203
TM
J2S968BH/KH/SH/TH –GE Profile™30" Slide-In Dual-Fuel Range
I
H
8
6
4
2
L
O
L
O
2
4
6
8
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
I
H
8
6
4
2
L
O
2
4
6
8
Features and Benefits
•Precise Air™convection system –Delivers even air and heat circulation for superior baking
and roasting results.
•Convection bake (multi-rack) –Provides ideal convection baking for multiple racks of food,
ensuring superb results.
•Convection roast –Provides even cooking and consistent results, roasting meats up to 25%
faster than a conventional oven.
•Self-Clean oven –Conveniently cleans the oven cavity without the need for scrubbing.
•Glass touch controls –Features the smooth glass design that is easy-to-operate and
easy-to-clean.
•Power Boil™burner –Delivers 15,000 BTUs of forceful heat for rapid boiling.
•Precise simmer burner –Offers a low setting of 600 BTUs, ensuring more temperature
control for simmering.
•Certified Sabbath mode –Prepared foods can stay warm in accordance with Kosher law.
•Model J2S968BHBB –Black on black
•Model J2S968SHSS –Stainless steel
•Model J2S968THWW –True white
•Model J2S968KHCC –True bisque
