GE GSS25WGMCWW and Operating instructions

0www.GEPpp/iances.com
Safety Information
Adapter Plugs ................... 4
Electricity ....................... 4
Extension Cords ................. 3
Proper Disposal ................. 3
Safety Precautions ............. 2, 3
Operating Instructions
Automatic Icemaker ............. 9
Controls ....................... 5
Crispers and Pans .............. 8-9
Ice and Water Dispenser ......... 10
Shelves, Bins and Racks ........ 6-8
Water Filter Cartridge ............ 6
Care and Cleaning
Cleaning ................... 11, 12
Lightbulbs ..................... 13
Installation Instructions
Preparing to Install
the Refligerator ............. 14, 15
Water Line Installation ....... 16-20
Troubleshooting Tips
Beffwe You Call For Service ...22-25
Normal Operating Sounds ....... 22
Consumer Support
Consumer Support ...... Back Cover
Performance Data Sheet ......... 27
Product Registration ......... 29, 30
State of California Water
Treatment Device Certificate ..... 28
Warranty (Canadian) ........... 25
Warranty (U.S.) ................ 26
Write your model and serial numbers here:
Model #
Serial #
Find these numbers on a label inside
the refi'igerator compartment at the top
on the right side behind the controls.
Models20,22and25
C6te _ c6te
Refrigerateurs
La section fran_aise commence a la page 31
Lad() a lad()
Refrigeradores
La seccion en espa_ol empieza en la pagina 59
197D3351PO02 49-60131 0701 Jfl

IMPORTANTSAFETYINFORMATION.
READALLINSTRUCTIONSBEFOREUSING.
WARNING'!
Use this appliance only for its intended purpose as described in this Owner's Manual
SAFETYPRECAUTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
This refiigerator must be properly installed
and located in accordance with the Installation
Instrucuons before it is used.
Do not allow children to clilnb, stand or hang
on the shelves in the refrigerator. They could
damage the refrigerator and seriously injure
thelnselves.
Do not touch the cold surfaces in the freezer
colnpartment when hands are damp or wet. Skin
may stick to these extrelnely cold surfaces.
Do not store or use gasoline or odmr flammable
vapors and liquids in the vicinity of this or aW
other appliance.
In refrigerators with autolnatc icelnakers,
avoid contact with the lnoving parts of the
ejector mechanism, or _4th the heating element
that releases the cubes. Do not place fingers or
hands on the automatic icelnaking mechanism
while the refrigerator is plugged in.
Keep fingers out of the "pinch point" areas;
clearances between the doors and between
the doors and cabinet are necessarily small.
Be carefifl closing doors when children are
in the area.
Unplug the refiigerator before cleaning and
making repairs.
NOTE:Westrong/}/recommendthatanyservicingbe
performedbyaqualifiedindividual
Setting the freezer control to fl_e 0(off) position
does not relnove power to the light circuit.
Do not refreeze frozen foods which have
thawed colnpletely.
2

www.GEAppliances.com
DANGER! RISK OFCHILDENTRAPMENT
PROPERDISPOSALOFTHEREFRIGERATOR
Child entrapment and suffbcation are not problems
of the past. Junked or abandoned refrigerators are
still dangerous...even ifthey _411sit far 'Oust a few
days." Ifyou are getting rid of your old refiigerator,
please follow the instructions below to help prevent
accident.s.
Before You ThrowAway YourOldRefrigerator
or Freezer:
Take off dm doors.
Leave the shelves in place so that chil&en may
not easily climb inside.
CFCDisposal
Your old refrigerator may have a cooling system
that used CFCs (chlorofluorocarbons). CFCs are
believed to harm stratospheric ozone.
Ifyou are fllro_4ng awayyour old refiigerator, make
sure the CFC refrigerant is removed fbr proper
disposal by a qualified se_s@er. If you intentionally
release this CFC refiigerantyou can be subject to
fines and imprisonment under provisions of
environmental legislation.
USEOFEXTENSIONCORDS
Because of potential safety hazards under certain conditions, we strongly recommend
against the use of an extension cord.
However, ifyou must use an extension cord, it is absolutely necessapy that it be a UL-listed (in the United
States) or a CSA-listed (in Canada), 3-,_4regrounding type appliance extension cord having a grounding
type plug and outlet and that the electrical rating of the cord be 13 amperes (minimum) and 120 volts.
3

IMPORTANTSAFETYINFORMATION.
READALLINSTRUCTIONSBEFOREUSING.
WARNING'!
HOWTOCONNECTELECTRICITY
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord. For
personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped _@h
a 3-prong (grounding) plug which ulates _aLflla
standard 3-prong (grounding) wall outlet to
minimize dm possibility of electric shock hazard
from this appliance.
HmTe tim wall outlet and circuit checked by a
qualified electrician to make sure tim outlet is
properly _'ounded.
If the outlet is a standard 2-prong outlet, it isyour
personal responsibility and obligation to have it
replaced with a properly grounded 3-prong wall
outlet.
The refrigerator should always be plugged into its
o_m indMdual electrical outlet which has a voltage
rating that matches the rating plate.
This provides die best perfbnnance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
Never unplug your refrigerator by pulling on the
power cord. Always _'ip plug firmly and pull straight
out from the outlet.
Repair or replace immediately all power cords that
have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage
along its length or at either end.
When moving the refrigerator a_vtyfrom the
wall, be carefifl not to roll over or dmnage the
power cord.
USEOFADAPTERPLUGS(A_pterp/u_notpermi,e_inC_n_)
Because of potential safety hazards under certain conditions, we strongly recommend against
the use of an adapter plug.
However, ifyou lnUSt use an adapter, where local
codes permit, a temporaryconnectionulay be made
to a properly _'ounded 2-prong wall outlet by use
era UL-listed adapter available at lnOSt local
hardware stores.
The larger slot in die adapter must be aligned widl
the larger slot in the wall oudet to provide proper
polarity in the connection of dm power cord.
When disconnecting the power cord frOUlthe
adapter, always heM the adapter in place _Lth one
hand while pulling the power cord plug _Lth the
other hand. If this is not done, the adapter ground
temfinal is vepylikely to break with repeated use.
If the adapter _'ound terminal breaks, DONOTUSE
the refrigerator until a proper ground has been
established.
Attachingtheadaptergroundterminaltoa wall outlet
coverscrewdoesnotgroundtheapplianceunlessthe
coverscrewismetal,andnotinsulated,andthewall
outlet isgroundedthroughthehousewiring.Youshould
havethecircuitcheckedbya qualifiedelectriciantomake
suretheoutletisproperlygrounded.
READANDFOLLOWTHISSAFETYINFORMATIONCAREFULLY.
SAVETHESEINSTRUCTIONS
4

Aboutthe controlsontherefrigerator, www.GEAppliances.com
9 iS COLDEST
0iS OFF
FREEZER FRESHFOOD
I
I
Initially, set the fresh food control at 5and the freezer control at 5and
allow 12hours for the temperature to stabilize.
Several adjustments may be required. Adjust the controls one
increment at a time, and allow 12 hours after each adjustment for the
refrigerator to reach the temperature you set.
Setting the freezer control to 0stops cooling in both the fresh food
and freezer compartments but does not shut off electrical power to
the refrigerator.
Control settings will vary based on personal preferences, usage, and
operating conditions and may require more than one adjustment.
5

Aboutthe water filter cartridge.
On some models
Water Filter Cartridge
¸
ii:i(iiiiiiiiii ij(!!ji!i:iiiiill
I
Place the top of the cartridge up
inside the cartridge holder and
slowly turn it to the right.
RESETWATERFILTER
HOLD3 SECS
(on some models)
The water filter cartridge is located in tim
back upper right comer of the refrigerator
comparunent.
When to Replace the Filter on
Models With a Replacement
Indicator Light
There is a replacement indicator light for
the water filter cartridge on tim dispenser.
This light _ill ulrn orange to tell you that
you need to replace the filter soon.
The filter cartridge shouM be replaced
when the replacement indicator light uu_s
red or ifthe flow of water to the dispenser
or icemaker decreases.
When to Replace the Filter on
Models Without a Replacement
Indicator Light
The filter cartridge shouM be replaced
eveUsix monthsor earlier if the flow of
water m the water dispenser or icelnaker
decreases.
Installing the Filter Cartridge
O Ifyou are replacing the cartridge, first
relnove the oM one by slowly turning it
to the left. Do notpull clown on the
cartridge. A small amount of water may
&ip down.
On models without a replacement
indicator light, apply fl_emonth and
year sticker to the new cartridge to
remind you to replace the filter in six
months.
@Fill the replacement cartridge with water
from the tap to allow for better flow
from the dispenser immediately after
installation.
_ Lining up tim arrow on the cartridge
and tl_ecartridge hoMer, place the
top of the new cartridge up inside
the hoMer. 0o notpush it up into
the hoMer.
Slowly turn it to the right until the filter
cartridge stops. DONOTOVERTIGHTEN.
Asyou turn the cartridge, it xdll
automatically raise i_selfinto position.
Cartridge _4ll rotate about 1/2 ram.
Run water from the dispenser for 3
minutes (about one and a half gallons)
to clear the system and prevent
sputtering.
Press and hoM the RESETWATERFITTER
pad (on some models) on the dispenser
for 3 seconds.
NOTE:A newly-installed water filter
camidge may cause water to spurtfroln
the dispenser.
Filter Bypass Plug
You must usethe fiher b}i_assplug
when a replacement filter cartridge is not
available. The dispenser and the icelnaker
_411not operate without the filter or filter
b}l)assplug.
ReplacementFilters:
Toorderadditionalfiltercartridgesin
theUnitedStates,visitourWebs#e,
wvvvv.GEAppliances.com,orcall
GEPartsandAccessories,800-626-2002.
GWF
Suggested Retail $34.95
Customers in Canada should consult the
yellow pages far the nearest Camco Service
Center.
Aboutthe shelvesandbins.
Not all features are on all models.
6
Bins on the Fresh Food Compartment Door
Adjustable bins can easily be can'ied from
refrigerator to work area.
Toremove:Lift the front of the bin up, then
pull out.
Toreplaceorrelocate:Engage dm bin in the
moMed supports of the door, and push in.
Bin will lock in place.
Thesnuggerhelps prevent tipping, spilling
or sliding of small items stored on dm door
shel£ Place a finger on either side of the
dMder near the rear and move it back
and fbrth to fit your needs.

wvvvv.GEAppliances.com
Rearranging the Shelves
RefrigeratorShelves:
ToRemove
FreezerShelves:
ToRemove
)
ToReplace
{Ophook _-'
0 Lowerto
--"
lockin
place
I1
FreezerBaskets:
ToRemove
Remove fl_e basket by pulling it fbxward,
lifdng up the front, and sliding it past the
stop location.
Slide-Out Spillproof Shelf (onsomemodels)
The slide-out spillproof shelf allows you to
reach items stored behind others. The
special edges are designed to help prevent
spills fi'om dripping to lower shelves.
Makesureyoupushtheshelvesall the wayback
in beforeyouclosethedoor.
Spillproof Shelves (onsomemodels)
Spillproofshelves have special edges
to help prevent spills fl'om chipping to
lower shelves.
Quick Space Sheff (onsomemodels)
This shelf splits in half and slides tinder
itself fbr storage of tall items on the shelf
below.
/
!
Deep Door Shelves
Detachable shelf extenders deepen and
enclose fixed door shebes, providing
more storage room and greater storage
flexibility.
Toremove:Lift the shelf extender straight up
then pull out.
Toreplace:Engage the shelf extender in the
molded support_s on the door and push in.
It will lock in place. 7

Aboutthe additionalfeatures.
Not all features are on all models.
ShelfSaver TM Rack
Use this rack to store beverage cans fior
easy access.
It can also 11o1(ta 9"x 13" baking dish.
Aboutthe crispersandpans.
Not all features are on all models.
Fruit and Vegetable Crispers
Excess water that may accumulate in the
bottom of the drawers should be _6ped dU.
Trivet
Trivet and Divider (onsomemodels)
The trivet is designed to keep your fruits
and vegetables off the floor of file drawer
and away from an), moisture fllat might
fbrm. The dMder will keep the larger fruits
and vegetables from falling or rolling onto
the more delicate ones. Bylifting straight
up on the divider, you can detach it from
the trNet and adjust it from side to side,
then push down and into position.
Divider
f i Adjustable Humidity Crispers
Slide tim control all the way to the
High or _A setting to provide high
humidi Vrecommended for most
vegetables.
Slide the control all the way to the Lowor
_ setting to provide lower humidity levels
recommended fiormost fruits.
Normal
Coldest
8
Convertible Meat Pan
The convertible meat pan has it.sown cold
air duct to allow a stream of cold air from
the freezer compartment to flow around
the pan.
Thevariable temperature control regulates
the air flow from the freezer comparunent.
Set control lever up to convert the pan
to normal refrigerator temperature and
provide extra vegetable storage space. Cold
air duct is turned of£ Variable settings
between these extrelnes can be selected.
Set control lever downto the coldest setting
to store fresh meats. Iflever is left in meat
position fbr a long period of time, some
frost m Wtitan on the inside of the pan.

Aboutcrisperremoval vvww.GEAppliances.com
Not all features are on all models.
Crisper
Guides
When replacing the crispers, make
sure you slide them through the
crisper guides.
Crisper Removal
Crispers can easily be removed by tilting up
slightly and pulling past stop location.
Aboutthe automaticicemaker.
If the door prevent_syou from taking out
the crispers, the refrigerator _ill need to
be rolled fbtward until the door opens
enough m slide the crispers out. In some
cases, when you roll the refiigeramr out,
you _411need to move the refrigerator to
the lef_ asyou roll it out.
A newly-installed refrigerator may take 12-24 hours to begin making ice.
Power
switch Icemaker
!po__werL,ght
Automatic Icemaker (onsomemodels)
The icemaker will produce seven cubes
per (¢_cle-approximately 100-130 cubes
in a 24-hour period, depending on freezer
conlpartment telnperatm'e, room
temperature, number of door openings
and other use conditions.
If file refrigerator is operated befbre file
water connection is made to tim icemaker,
set the power switch in the 0 (oh')position.
When the refrigerator has been connected
to the water supply, set the power switch to
the I (on)position.
The icemaker will fillwit1 water when it
cools to 15°F. A newly-installed refiigerator
may take 12 to 24 hours to begin making
ice cubes.
Throw awW the first Dw batches of ice to
allow the water line to clear.
Be sure nothing interferes with the sweep of
the feeler ann.
It is normal for several cubes to bejoined
together.
If ice is not used frequently, oM ice cubes
will become cloudy, taste stale and shrink.
If ice cubes get snmk in tim icemaker,flm
green power light will blink. To correct dds,
set the power switch to 0 (oh)and relnove
the cubes. Set the power swit(:h m I(on)to
restart the icelnaker. After the icemaker has
been turned on again, there will be a del W
of about 45 minutes befbre the icelnaker
resumes operation.
NOTE:Inhomeswithlower-than-averagewater
pressure,youmayheartheicemakercyclemultiple
timeswhenmakingonebatchof ice.
iI
i__III_I_IIIIII
Thereis an upper freezer shelf
above the icemaker that can be
used for storage.
-_-_2272727
Ice Storage Drawer
Toaccessice,pull the drawer out. Toremove the drawer, pull it straight out
and lift it past the stop location.
Icemaker Accessory Kit
If your refiigerator did not come already
equipped with an automatic icemaker,
an icemaker accesso Ukit is m_ailable at
extra cost.
Check the back of the refrigerator for
the specific icemaker kit needed for
your model. 9

Aboutthe ice and water dispenser.
On some models
To Use the Dispenser
SpillShelf
Select CUBEDICE_, CRUSHEDICE
or WATER_.
Press the glass gendy against the top of the
dispenser cradle.
The spill shelf is not self&aining. To
re&me water spotting, the shelf and its _'ille
shouM be cleaned regularly.
If no wateris dispensedwhentherefrigeratoris
first installed,theremaybe air in thewaterline
system.Pressthedispenserarmforat least two
minutestoremovetrappedair fromthewaterline
andtofill thewatersystem.Toflushoutimpurities
in thewaterline,throwawaythefirstsixglassfuls
of water.
CAUTION:Neverputfingersoranyother
objectsintotheicecrusherdischargeopening.
Locking the Dispenser (onsomemodels)
Press file LOCK
_i_ii i: CONTROLpad fbr 3
seconds to lock the
dispenser and control
L0_ROL_0_TcROL!panel.andhoMTod,eunlock,padagainpress
for 3 seconds.
Dispenser Light
This pad ulrns the night
lightin the dispenser on
_il_ l:!i_ dispensercomesandoff.onThewhencradlelighttheisalS°
pressed. If this light
burns out, it shouM be
replaced with a 6 watt
maximum, 12 volt DC
bulb.
Ice Storage Drawer
on Dispenser Models
Toremove:
Set the icelnaker power switch to the 0 (off)
position. Pull the (kawer straight out and
then lift past the stop position.
Toreplace:
When replacing the drawer, make sure to
push it firefly into place. If it does not go all
the wW back, remove it and rotate the drive
mechanism 1/4 turn. Then push the
drawer back again.
10
Important Facts About Your Dispenser
Do not add ice from trays or bags to
dm storage bin. It may not crash or
dispense well.
Avoid oveKilling glass widl ice and use of
narrow glasses. Backed-up ice canjam the
chute or cause the door in the chute m
freeze shut. If ice is blocking the chute,
poke it through with a wooden spoon.
Beverages and foods shouM not be
quick-chilled in the ice storage bin.
Cans, botdes or food packages in the
storage bin m Wcause the icelnaker
or mlger to jam.
To keep dispensed ice from missing
dm glass, put dm glass close to, but not
touching, the dispenser opening.
Some crashed ice may be dispensed even
though you selected CUBEDICE.This
happens occasionally when a few cubes
have been left in the crasher.
After crushed ice is dispensed, some
water may (kip from the chute.
Sometimes a small mound of snow will
form on the door in the ice chute. This
condition is normal and usually occurs
when you have dispensed crashed ice
repeatedly. The snow will eventually
evaporate.

Careand cleaning ofthe refrigerator. .OEAppliances.com
Dispenser drip area.
Cleaning the Outside
Thedispenser drip area, (on some models)
beneadl dm _ille, should be xdped dry. Water
left in this area may leave deposits. Remove
tile deposit.s by adding undiluted vinegar to
the well. Soak until the deposit.s disappear
or become loose enough to rinse away.
Thedispensercradle(on some models).
Before cleaning, lock tile dispenser by
pressing and holding the LOCKCONTROL
pad for 3 seconds. Clean with warm water
and baking soda solution-about a
tablespoon (15 ml) of baking soda to a
quart (1 1)of water. Rinse thoroughly
and wipe (hy.
Thedoorhandlesandtrim.Clean with a
cloth dampened with soapy water. Dpy
_6tb a soft cloth.
Keep theoutsideclean.Wipe wifll a clean
clofll lightly dampened with kitchen
appliance wax or mild liquid dish detergent.
DUand polish _4th a clean, sof_cloth.
Donotwipetherefrigeratorwith a soileddish
clothor wet towel Thesemayleavea residue
thatcanerodethepaint.Donotusescouring
pads,powderedcleaners,bleachor cleaners
containingbleachbecausetheseproductscan
scratchandweakenthepaintfinish.
Cleaning the Inside
Tohelp prevent odors, leave an open box of
baking soda in dm fi'esh food and freezer
compartments.
Unplugtherefrigeratorbeforecleaning.If dlis
is not practical, wring excess lnoismre out of
sponge or cloth when cleaning around
switches, lights or controls.
Use warm water and baking soda solution-
about a tablespoon (15 ml) of baking soda
to a quart (11) of water. This both cleans
and neutralizes odors. Rinse and wipe (hy.
After cleaning die door gaskets, apply a thin
layer of petroleum jelly to die door gaskets
at the hinge side. This helps keep the
gasket.s fi'Oln sticking and bending out
of shape.
Drainopening&freezercompartment.
During yearly cleaning, reznove bottom
freezer basket and flush a solution of baking
soda-1 teaspoon (5 ml) and 2 cups (500
lnl) of hot (not boiling) water ithrough the
drain line with the help of a meat baster.
This will help eliminate odor and reduce
the likelihood of a clogged drain line. If
drain becomes clogged, use a meat baster
and baking soda solution to force the clog
through the drain line.
Avoidcleaningcoldglassshelveswith hotwater
becausetheextremetemperaturedifferencemay
causethemtobreak.Handleglassshelves
carefully.Bumpingtemperedglasscancauseit to
shatter.
Donotwashanyplasticrefrigeratorparts in the
dishwasher.
Condenser
There is no need for routine condenser
cleaning in normal home operating
environmems. However, in environments
that m Wbe particularly (tusb_or _'easy, tile
condenser should be cleaned periodically
for efficient refiigerator operation.
Cleaning the condensec
The condenser is located inside the back
of the refrigerator. To access it, first unplug
tile refiigerator. Then remove tile access
cover. The condenser is on the tight side.
11

Careand cleaning ofthe refrigerator.
Behind the Refrigerator
Be carefld when lnoving the refrigerator
away frOln the wall. All types of floor
coverings can be damaged, particularly
cushioned coverings and those _ith
embossed sm{>mes.
Pull the refrigerator straight out and return
it to position by pushing it straight in.
Moving the refiigerator in a side direction
may result in damage to the floor coveting
or refiigerator.
Whenpushingtherefrigeratorback,makesure
youdon't roll overthepowercordor icemaker
supplyline (onsomemodels).
Preparing for Vacation
For long vacations or absences, remove
food and unplug the refrigerator. Clean the
inmrior with a baking soda solution of one
tablespoon (13 ml) of baking soda to one
quart (1 l) of water. Leave the doors open.
Set fl_eicelnaker power switch to the 0(oh)
position and shut offthe water supply to the
refrigerator.
If the telnperamre can drop below freezing,
have a qualified servicer (kain the water
supply systeln (on some models) to prevent
serious property, damage chle to flooding.
Preparing to Move
Secure all loose items such as grille, shelves and drawers by taping them securely
in place to prevent damage.
Besuretherefrigeratorstaysin anuprightposition&flog moving.
12

Replacingthe lightbulbs. .OEApp,a,oes.oom
Turning the control to the 0(off) position does not remove power to the light circuit.
Fresh Food Compartment--Upper Light
0 Unplug the refrigerator.
The bulb is located behind the controls.
Replace _ith an appliance bulb of the
same or lower wattage.
Plug the refrigerator back in.
Fresh Food Compartment--Lower Light (onsomemodels)
Thislightis locatedabovethetopdrawer. _ After replacing with an appliance
-- bulb of the same or lower wattage,
Unplug the refrigerator, replace the shield.
0 Grasp the lip at the bottom of the light I_ Plug the refrigerator back in.
shield and pull it up and fbtwar(t.
Freezer Compartment
Unplug the refrigerator.
0 Remove the shelfOust below light shield.
(The shelf will be easier to remove if it is
emptied first.)
LifLup on the light shield to remove.
l_Afler replacing with an appliance
bulb of the same or lower wattage,
reinstall the shield by hanging it
from the three tabs.
Reinstall the shelf and plug the
refrigerator back in.
Dispenser
Unplug the refrigerator.
_The bulb is located on the dispenser
under the control panel.
Remove the lightbulb by turning
it counterclockwise.
Replace the bulb with a bulb of the
same size and wattage.
Plug the refrigerator back in.
13

Installation
Instructions Refrigerator
Models 20, 22, 25
Questions ?Call 800-GE-CARES (800-432-2737) or Visit our Website at: www.GEAppliances.com
In Canada, call 1-800-361-3400 orVisitourWebsiteat:www.geappliances.ca
BEFORE YOU BEGIN
Read these instructions completely and carefully.
"IMPORTANT -S.vethese
instructions for local inspector's use.
. IMPORTANT - Obse,,,eall
governing codes and ordinances.
*Note to Installer - Be sure to leave these
instructions with the Consmner.
*Note to Consumer - Keep these instructions
for fimlre reference.
* Skill level - Installation of this appliance requires
basic mechanical skills.
* Completion time - Refrigerator Installation
15 minutes
* Proper installation is tile responsibility of tile
installer.
* Product failure due to improper installation is not
covered under the Warranty.
WATER SUPPLY TO THE ICEMAKER
(on some models)
If tile refrigerator has an icemaker, it will have to be
connected to a cold water line. AGE water supply kit
(containing robing, shutoffvalve, fittings and
instructions) is available at extra cost from your dealer,
by visiting our Website at _,GEAppliances,com
(in Canada, at _.geappliances.ca) or from Parts
and Accessories, 800-626-2002.
REFRIGERATOR LOCATION
•Do not install tile refrigerator where tile temperature
will go below 60°F (16°(;) because it will not run often
enough to maintain proper temperatures.
• Install it on a floor strong enough to support it fiflly
loaded.
CLEARANCES
Allow tile following clearances for ease of installation,
proper air circulation and plumbing and electrical
connections.
• Sides 1/8" (4 HIHl)
•Top 1" (25 HIHl)
• Back 1" (25 HIHl)
A door clem'ance of 3/4" (19 ram) is needed fbr a 90 °
door opening which provides better access to the food
storage m'ea.
ROLLERS
The rollers have 3purposes:
•Rollers adjust so tile door closes easily when opened
about halfivay.
• Rollers adjust so the refrigerator is firmly positioned on
the floor and does not wobble.
• Rollers allowyou m move the refiigeramr away from
the wall for cleaning.
To adjust the rollers, remove file base grille by pulling it
out at file bottom.
Turn file roller adjusting screws clockwise to raise file
refrigerator, counterclockwise to lower it. Use an
adjustable _wench (3/8" hex head bolt) or pliers.
To replace base grille, line up tile clips on back of grille
between tile bar and tile bottom of the cabinet. Push
forward until grille snaps into place.
14

Installation Instructions
DOOR ALIGNMENT
Mter leveling, make sm'e fllat doo_s 7_'eeven at tim top.
To make the doors even, a(_ust the refligerator door.
O Using a 5/16" socket wrench, ulrn tim door adjusting
screw to the fight to raise the door, to the left to lower
it. (A nylon plug, embedded in the threads of the pin,
prevent_s the pin fi'Oln ulrning unless a wrench isused.)
O After one or two turns of the wrench, open and close
the fi'esh food door and check the alignment at the top
of the doors.
Toremovethebase
grille,openthedoors
andthenpullthe
grillestraightout.
5/16"Socket
Wrench
15

Installation instructions
iNSTALLiNG THE WATER LINE
BEFORE YOU BEGIN
Recommended copper water supply kits are WX8X2,
WX8X3 or WX8X4, depending on the amount of
ulbing you need. Approved plastic water supply lines
are GE SmartConnecff MRefl'igerator Tubing
(WX08X10002, WX08X10006, WX08X10015 and
WX08X10025).
When connecting your refrigerator to a GE Reverse
Osmosis Water System, the only approved installation
is with a GE RVKit. For other reverse osmosis water
systems, fbllow the rnam6imturer's recommendations.
If the water supply to the refrigerator is from a Reverse
Osmosis Water Filtration System AND the refrigerator
also has a water filter, use the refrigerator's filter bypass
plug. Using the refrigerator's water filtration cartridge
in conjunction with the RO filter can result in hollow
ice cubes and slower water flow from the water
dispenser.
This water line installation is not warranted by the
refl'igerator or icemaker manufimmrer. Follow these
instructions careflllly to minimize the risk of expensive
water dmnage.
Water hmnmer (water banging in the pipes) in house
plumbing can cause dmnage to refrigerator parts and
lead to water leakage or flooding. Call a qualified
plumber to correct water hammer befbre installing
the water supply line to the refrigerator.
To prevent burns and product damage, do not hook
tip the water line to the hot water line.
If you use your refrigerator befbre connecting the
water line, make sure the icemaker power switch is in
the 0(off)position.
Do not install the icemaker robing in areas where
temperatures fall below freezing.
When using any electrical device (such as a power
drill) during installation, be sure the device is double
insulated or grounded in a manner to prevent the
hazard of electric shock, or is battm T powered.
All installations must be in accordance with local
plumbing code requirements.
WHAT YOU WILL NEED
/
•Copper or GE SmartConnecff u Refrigerator Tubing
kit, l/4" outer diameter to connect the refrigerator to
the water supply. If using copper, be sure both ends of
the tubing are cut square.
To determine how much robing you need: measure
the distance from the water valve on the back of the
refrigerator to the water supply pipe. Then add 8'
(2.4 m). Be sure there is sufficient extra robing (about
8' [2.4 m] coiled into 3 turns of about 10" [25 cm]
diameter) to allow the refrigerator to move out from
the wall after installation.
GE SmartConnecff v Refrigerator Tubing Kits are
available in the fbllowing lengths:
2' (.6 m) -WX08X10002
6' (1.8 111) -WX08Xl0006
15' (4.6 m) -WX08X10015
25' (7.6 111) - WX08X10025
Be sure that the kit you select allows at least 8' (2.4 m)
as described above.
NOTE: The only GE approved plastic tubing is that
supplied in GE SmartConnect TM Refrigerator Tubing
kits. Do not use any other plastic water supply line
because the line is under pressure at all times. Certain
types of plastic will crack or rupture with age and cause
water damage to your home.
16

Installation instructions
WHAT YOU WILL NEED (CONT.)
•AGE water supply kit (containing ulbing, shutoff
valve and fittings listed below) is available at extra
cost fi'om your dealer or fi'oln Parts and Accessories,
800-626-2002.
•Acold water supply. Tile water pressure must be
between 20 and 120 p.s.i. (1.4-8.2 bar) on models
without a water filter and between 40 and 120 p.s.i.
(2.8-8.2 bar) on models with a water filter.
• Power drill.
•1/2" or adjustable wrench.
• Straight and Phillips blade screwdriver.
• Two 1/4" outer diameter compression nuts and
2ferrules (sleeves)-to connect tile copper ulbing
to the shutoffvalve and the refi'igerator
water valve.
OR
• If you are using a GE SmartConnect TM Refi'igerator
Tubing kit, the necessa Ufittings are preasselnbled to
the robing.
• If your existing copper water line has a flared fitting
at the end, you will need an adapter (available at
plumbing supply stores) to connect the water line to
the refi'igerator OR you can cut off the flared fitting
with a tube cutter and then use a compression fitting.
Do not cut fbrlned end fi'oln GE SmartConnect TM
Refi'igerator robing.
• Shutoff valve to connect to tile cold water line.
The shutoffvalve should have a water inlet with a
minimum inside diameter of 5/32" at the point of
connection to the COLD WATER LINE. Saddle-type
shutoffvalves are included in many water supply kits.
Before purchasing, make sure a saddle-type valve
complies with your local plumbing codes.
Install tile shutoffvalve on tile nearest fi'equently used
drinking water line.
Ill SHUT OFF THE MAIN WATER
SUPPLY
Turn on tile nearest fmlcet long enough to clear tile
line of water.
[] CHOOSE THE VALVE LOCATION
Choose a location for tile valve that is easily
accessible. It is best to connect into the side of a
vertical water pipe. When it is necessa D, to connect
into a horizontal water pipe, make the connection
to tile top or side, rather than at tile bottom,
to avoid drawing off any sediment fi'OUltile
water pipe.
DRILL THE HOLE FOR THE VALVE
Drill a 1/4" hole in tile water pipe (even
if using a self:piercing valve) using a sharp bit.
Relnove any burrs resulting fi'oln drilling the hole in
the pipe. Take care not to allow water to drain into
the drill. Failure to drill a 1/4" hole may result in
reduced ice production or smaller cubes.
17

Installation instructions
INSTALLING THE WATER LINE (cont.)
I_ FASTEN THE SHUTOFF VALVE
Fasten the slmtoffvalve to the cold water pipe with
the pipe clamp.
PipeClamp --
Saddle-Type J
ShutoffValve
,)
VerticalCold
WaterPipe
NOTE: Commonwealth of Massachusetts Plumbing
Codes 248CMR shall be adhered to. Saddle valves
are illegal and use is not permitted in Massachusetts.
Consult with your licensed plumber.
[] TIGHTEN THE PIPE CLAMP
Tighten the clamp screws until the sealing washer
begins to swell.
NOTE: Do not overtighten or you may crush the
mbing.
" Washer
PipeClamp End
ClampScrew
ROUTE THE TUBING
Route the robing between the cold water line and
the refl'igerator.
Route the robing through a hole drilled in the wall
or floor (behind the refl'igerator or adjacent base
cabinet) as close to the wall as possible.
NOTE: Be sure there is sufficient extra robing
(about 8' [2.4 m] coiled into 3 turns of about 10"
[25 cm] diameter) to allow the refl'igerator to move
out fl'om the wall after installation.
17]CONNECT THE TUBING TO THE
VALVE
Place the compression nut and ferrule (sleeve) fbr
copper robing onto the end of the robing and
connect it to the shutoffvalve.
Make sure the robing is flflly inserted into the valve.
Tighten the compression nut securely.
For plastic robing from a GE SmartConnect TM
Refrigerator Tubing kit, insert the molded end
of the robing into the shutoffvalve and tighten
compression nut until it is hand tight, then tighten
one additional turn with a wrench. Overtightening
may cause leaks.
Saddle-Type
ShutoffValve SmartConnectTM
Tubing
PackingNut --
Outlet Valve -- Ferrule (sleeve)
NOTE: Commonwealth of Massachusetts Plumbing
Codes 248CMR shall be adhered to. Saddle valves
are illegal and use is not permitted in Massachusetts.
Consult with your licensed plumber.
I-8-1FLUSH OUT THE TUBING
Turn the main water supply on and flush out the
tubing until the water is clear.
Shut the water off at the water valve after about
one quart (1 liter) of water has been flushed
through the robing.
18

Installation Instructions
191CONNECT THE TUBING TO THE
REFRIGERATOR
NOTES:
•Before making tile connection to tile refrigerator,
be sure the refrigerator power cord is not plugged
into the wall outlet.
Ifyour refrigerator does not have a water filter, we
recommend installing one if your water supply
has sand or particles that could clog the screen of
the refrigerator's water valve. Install it in the water
line near the refrigerator. If using a GE
SlnartConnect TM Refrigerator Tubing kit, you
will need an additional ulbe (WX08X10002)
to connect the filter. Do not cut plastic tube
to install filter.
Some models have tile refrigerator connection at
the end of robing located outside the compressor
COlnparmlent access cover. On other models, the
COlllpressor conlparmlent access cover must be
renloved in order to access the refrigerator
connection at tile water valve.
On models using tile refrigeration connection at
the water valve, remove the plastic flexible cap.
©
Place tile compression nut and ferrule (sleeve)
onto the end of the robing as shown. On a GE
SlnartConnect Refrigerator Tubing kit, the nuts
are already assembled to the robing.
I-_ CONNECT THE TUBING TO THE
REFRIGERATOR (CONT.)
Insert tile end of tile robing into tile refrigerator
connection as fhr as possible. While holding the
robing, tighten the fitting.
For plastic robing from a GE SmartConnect
Refrigerator Tubing kit, insert tile molded end of
the tubing into the refrigerator connection and
tighten the compression nut until it is hand tight,
then tighten one additional turn with a wrench.
Overtightening may cause leaks.
Fasten tile robing into tile clamp provided as
shown to keep it in position. You may need to PU
open the clamp.
One of the illustrations below will look like the
connection on your refrigerator.
Tubing
Clamp _
1/4"
Compression
Nut
1/4"
Tubing
Ferrule
(sleeve)
Refrk SmartConnectTM
Connection Tubing
1/4" 1/4"
Tubing Compression •
/Tub,ng
Clamp [1 /Nut
Ferrule
(sleeve)_
Refrigeratol
Connection Tubing
I_1TURN THE WATER ON AT THE
SHUTOFF VALVE
Tighten any connections that leak.
Reattach tile access cover.
19

Installation Instructions
INSTALLING THE WATER LINE (cont.)
I_IPLUG IN THE REFRIGERATOR
Arrange the coil of robing so that it does not vibrate
against the back of the refl'igerator or against the
wall. Push the refl'igerator back to the wall.
START THE ICEMAKER
Set the icemaker power switch to the I (on)position.
The icemaker will not begin to operate until it
reaches its operating temperature of 15°F (-9°C)
or below. It _ill then begin operation automatically
if the icemaker power switch is in the I (on) position.
NOTE: In lower water pressure conditions, the
water valve m W turn on up to 3 times to deliver
enough water to the icemaker.
20
