GE Monogram ZFGP21HYSS User manual

Owner’s
Manual
Double Door, Double Drawer,
Stainless Steel, Free-Standing
Refrigerators
monogram.com
49-60584
01-09 JR

Consumer Information
Stainless Steel Refrigerator
2
Introduction
Your new Monogram refrigerator makes an eloquent statement of style, convenience and kitchen
planning flexibility. Whether you chose it for its purity of design, practical storage arrangements or
assiduous attention to detail—or for all of these reasons—you’ll find that your Monogram refrigerator’s
superior blend of form and function will delight you for years to come.
The information on the following pages will help you operate and maintain your refrigerator properly.
If you have any other questions, visit our Website at: monogram.com
Contents
Consumer Services
Important Phone Numbers . . . . . . . . . . . . . . . . . .27
Model and Serial Numbers . . . . . . . . . . . . . . . . . . . .3
Performance ata Sheet . . . . . . . . . . . . . . . . . . . .25
ProblemSolver ..........................20–24
ProductRegistration ..........................3
SafetyInstructions ........................4–7
State of California
Water Treatment evice Certificate . . . . . . . . . .26
Warranty ..........................BackCover
Care and Cleaning
Cleaning—Outside and Inside . . . . . . . . . . . . . . . .18
Light Bulb Replacement . . . . . . . . . . . . . . . . . . . . . 19
Moving .....................................18
Vacation ....................................18
Operating Instructions
Automatic Icemaker . . . . . . . . . . . . . . . . . . . . . . . . .17
Additional Features . . . . . . . . . . . . . . . . . . . . . . . . . .15
Crispers.....................................16
Internal Water ispenser . . . . . . . . . . . . . . . . . . . .10
OtherControls................................9
Performance Air Flow System . . . . . . . . . . . . . . . . .8
Shelves and Bins . . . . . . . . . . . . . . . . . . . . . . . . .12–14
Temperature Controls . . . . . . . . . . . . . . . . . . . . . . . .8
TurboCool™...................................9
WaterFilter .................................11
Before
using
your
refrigerator
Read this manual carefully. It is intended to help
you operate and maintain your new refrigerator
properly.
Keep it handy for answers to your questions.
If you don’t understand something or need
more help, there is a list of toll-free consumer
service numbers included in the back section
of this manual.
OR
Visit our Website at: monogram.com

3
Write
down
the model
& serial
numbers
You’ll see them on a label inside the fresh food
compartment at the top on the right side.
Please write these numbers on the Consumer
Product Ownership Registration Card included
with the packing material.
Before sending in this card, please also write
these numbers here:
Model Number
Serial Number
Use these numbers in any correspondence
or service calls concerning your refrigerator.
If you
received a
damaged
refrigerator
Immediately contact the dealer (or builder) that
sold you the refrigerator.
Save time
& money
Before you request service, check the Problem
Solver in the back of this manual.
It lists causes of minor operating problems that
you can correct yourself.
If you
need
service
To obtain service, see the Consumer Services
page in the back of this manual.
We’re proud of our service and want you to be
pleased. If for some reason you are not happy
with the service you receive, here are steps to
follow for further help.
For customers in the USA:
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are still not pleased, write all
the details—including your phone number—to:
Manager, Customer Relations
GE Appliances
Appliance Park
Louisville, KY 40225
For customers in Canada:
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are still not pleased, write all
the details—including your phone number to:
Manager, Consumer Relations
Mabe Canada Inc.
1 Factory Lane, Suite 310
Moncton, N.B. E1C 9M3
Consumer Information
Stainless Steel Refrigerator

READ AND SAVE T ESE INSTRUCTIONS
wWARNING: When using this appliance,
always exercise basic safety precautions, including
the following:
• Use this appliance only for its intended purpose
as described in this Owner’s Manual.
• This refrigerator must be properly installed in
accordance with the Installation Instructions
before it is used.
• Do not allow children to climb, stand or hang
on the shelves in the refrigerator. They could
damage the refrigerator and seriously injure
themselves.
• Do not touch the cold surfaces in the freezer
compartment when hands are damp or wet.
Skin may adhere to these extremely cold surfaces.
• Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
• In refrigerators with automatic icemakers,
avoid contact with moving parts of the ejector
mechanism, or with the heating element located
on the bottom of the icemaker. o not place
fingers or hands on the automatic icemaking
mechanism while the refrigerator is plugged in.
• Keep fingers out of the “pinch point” areas:
clearances between the doors and between
the doors and cabinet are necessarily small.
Be careful closing doors when children are
in the area.
• Unplug your refrigerator before cleaning and
making repairs. NOTE: We strongly recommend
that any servicing be performed by a qualified
individual.
• Before replacing a burned-out light bulb,
the refrigerator should be unplugged in order
to avoid contact with a live wire filament.
(A burned-out light bulb may break when
being replaced.)
N TE: Turning control to OFF does not remove
power to the light circuit.
• Do not refreeze frozen foods which have thawed
completely.
IMPORTANT SAFETY INSTRUCTIONS
wDANGER: RISK OF C ILD ENTRAPMENT
Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are
still dangerous…even if they will sit for “just a few
days.” If you are getting rid of your old refrigerator,
please follow the instructions below to help prevent
accidents.
Before you throw away your old refrigerator
or freezer:
•Take off the doors.
•Leave the shelves in place so that children
may not easily climb inside.
REFRIGERANTS
All refrigeration products contain refrigerants, which
under federal law must be removed prior to product
disposal.
If you are getting rid of an old refrigeration product,
check with the company handling the disposal
about what to do.
4

5
MESURES E SÉCURITÉ IMPORTANTES
LIRE ET CONSERVER CES INSTRUCTIONS
wAVERTISSEMENT : Lorsque vous
utilisez le réfrigérateur, observez toujours certaines
précautions de base, notamment :
• N’utilisez le réfrigérateur que pour son usage
prévu, comme décrit dans le présent manuel.
• Installez le réfrigérateur conformément aux
directives d’installation avant de l’utiliser.
• Ne laissez pas les enfants grimper, s’asseoir,
se tenir debout ni se pendre aux clayettes
du réfrigérateur. Ils pourraient endommager
le réfrigérateur et se blesser gravement.
• Une fois le réfrigérateur en marche, ne touchez
pas les surfaces froides du congélateur, surtout
si vous avez les mains humides ou mouillées :
la peau risque d’adhérer à ces surfaces très
froides.
• N’entreposez et n’utilisez pas d’essence ou
autres vapeurs et liquides inflammables à
proximité de cet appareil ou de tout autre
appareil électroménager.
• our les réfrigérateurs dotés d’une machine
à glaçons automatique, évitez le contact avec
les pièces mobiles du mécanisme éjecteur,
ou avec l’élément chauffant situé à la partie
inférieure de la machine à glaçons. Ne posez
pas les doigts ou les mains sur le mécanisme
de la machine à glaçons pendant que
le réfrigérateur est branché.
• Éloignez les doigts des parties du réfrigérateur
où l’on peut facilement se pincer : les espaces
entre les portes et entre les portes et les placards
sont toujours étroits. Soyez prudent lorsque
vous fermez les portes de l’appareil en présence
des enfants.
• Débranchez votre réfrigérateur avant
de le nettoyer et de le réparer. REMARQUE : Nous
vous recommandons vivement de confier toute
réparation à un technicien qualifié.
• Avant de remplacer une ampoule grillée,
le réfrigérateur doit être débranché afin
d’éviter tout contact avec un fil sous tension.
(Une ampoule grillée peut se briser pendant
l’opération).
REMARQUE : Lorsque vous placez la commande
sur éteint, l’alimentation électrique de l’ampoule
n’est pas coupée.
• Ne faites pas recongeler des aliments surgelés
qui ont complètement dégelé.
wDANGER: RISQUES POUR LES ENFANTS
Les enfants pris au piège ou morts d’asphyxie sont
toujours d’actualité. Les appareils de réfrigération
abandonés sont toujours aussi dangereux, même
si on n’attend que “quelque jours” pour s’en
débarasser. Si vous ne gardez pas votre ancien
appareil, veuillez suivre les directives ci-dessous
afin de prévenir les accidents.
Avant de vous débarasser de votre vieux
appareil de réfrigération :
•émontez les portes.
•Laissez les clayettes en place afin d’empêcher
les enfants de grimper à l’intérieur.
REFRIGERANTS
Tous les appareils de réfrigération contiennent
des refrigerants qui, conformément aux lois
fédérales, doivent être enlevés avant toute
élimination de l’appareil.
Si vous vous débarrassez de vieux appareils de
réfrigération, vérifiez, auprès de la société qui
s’occupe de leur élimination, ce que vous
devez faire.

SAVE T ESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
OW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove
the third (ground) prong from the power cord.
For personal safety, this appliance must be
properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall outlet
to minimize the possibility of electric shock
hazard from this appliance.
Have the wall outlet and circuit checked by
a qualified electrician to make sure the outlet
is properly grounded.
Where a standard 2-prong wall outlet is
encountered, it is your personal responsibility
and obligation to have it replaced with a
properly grounded 3-prong wall outlet.
The refrigerator should always be plugged into
its own individual electrical outlet which has
a voltage rating that matches the rating plate.
This provides the best performance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
Never unplug your refrigerator by pulling
on the power cord. Always grip plug firmly
and pull straight out from the outlet.
Repair or replace immediately all power cords
that have become frayed or otherwise damaged.
o not use a cord that shows cracks or abrasion
damage along its length or at either end.
When moving the refrigerator away from the wall,
be careful not to roll over or damage the power cord.
USE OF EXTENSION CORDS
Because of potential safety hazards under
certain conditions, we strongly recommend
against the use of an extension cord.
However, if you must use an extension cord, it is
absolutely necessary that it be a UL-listed, 3-wire
grounding type appliance extension cord having
a grounding type plug and outlet and that
the electrical rating of the cord be 15 amperes
(minimum) and 120 volts.
6

7
CONSERVEZ CES DIRECTIVES
MESURES E SÉCURITÉ IMPORTANTES
RACCORDEMENT ÉLECTRIQUE
Ne coupez ni retirez en aucun cas la troisième
broche (mise à la terre) de la fiche du cordon
d’alimentation. our votre sécurité, cet appareil
doit être correctement mis à la terre.
Le cordon d’alimentation de cet appareil est
muni d’une fiche à 3 broches (mise à la terre)
qui se branche dans une prise mural ordinaire
à 3 alvéoles (mise à la terre) pour réduire au
minimum les risques du chocs électriques.
Faites examiner la prise de courant et le circuit
par un électricien qualifié pour vous assurer
que la prise est correctement mise à la terre.
Si la prise murale est du type standard à 2 alvéoles,
il vous incombe de la faire remplacer par une prise
à 3 alvéoles correctement mise à la terre.
La machine à glaçons doit toujours être
branché dans sa propre prise de courant,
dont la tension nominale est identique
à celle indiquée sur la plaque signalétique.
Cette précaution est recommandée pour garantir
un rendement optimum et éviter une surcharge des
circuits électriques de la résidence, ce qui pourrait
créer un risque d’incendie par surschauffe des fils.
Ne débranchez jamais l’appareil en tirant le cordon
d’alimentation. Saisissez fermement la fiche
du cordon et tirez droit pour la retirer de la prise.
Réparez ou remplacez immédiatement tout cordon
effiloché ou endommagé. N’utilisez pas un cordon
fendillé ou présentant des signes d’usure.
Lorsque vous déplacez l’appareil du mur, faites
attention de ne pas la faire rouler sur le cordon
d’alimentation afin de ne pas l’endommager.
CORDONS PROLONGATEURS
Nous vous recommandons fortement de ne pas
utíliser de cordons prolongateurs à cause des
risques potentiels qu’ils présentent dans certaines
conditions.
Toutefois si vous décidez d’utiliser tout de même
un cordon prolongateur, il est absolument nécessaire
qu’il s’agisse d’un cordon à 3 fils avec mise à la terre
pour appareils électroménagers homologué UL
aux États-Unis) ou homologué CSA (au Canada),
pourvu d’une fiche et d’une prise mises à la terre
de 15 ampères (minimum) et de 120 volts.

8
Temperature
controls
The temperature controls are preset in the factory at 37°F
for the fresh food compartment and 0°F for the freezer
compartment. Allow 24 hours for the temperature to stabilize
to the preset recommended settings.
The temperature controls can display both the SET temperature
as well as the actual temperature in the fresh food and freezer
compartments. The actual temperature may vary slightly
from the SET temperature based on usage and operating
environment.
Setting either or both controls to FF stops cooling in both
the freezer and fresh food compartments but does not shut
off electrical power to the refrigerator.
N TE: The refrigerator is shipped with protective film covering
the temperature controls. If this film was not removed during
installation, remove it now.
To change the temperature, press and release
the (warmer) or (colder) pad. The SET light
will come on and the display will show the set
temperature. To change the temperature, tap
either the (warmer) or (colder) pad until
the desired temperature is displayed. Fresh food
temperatures can be adjusted between 34°F
and 44°F and the freezer temperatures can be
adjusted between -6°F and +6°F.
Once the desired temperature has been
set, the temperature display will return to
the actual fresh food and freezer temperatures
after 5 seconds. Several adjustments may
be required. Each time you adjust controls,
allow 24 hours for the refrigerator to reach
the temperature you have set.
To turn the cooling system off, tap
the (warmer) pad for either the fresh food
compartment or the freezer until the display
shows OFF. To turn the unit back on, press
the (colder) pad for either the fresh food
compartment or freezer. The SET light will
illuminate on the side you selected. Then press
the (colder) pad again (on the side where
the SET light is illuminated) and it will go to
the preset points of 0°F for the freezer and 37°F
for the fresh food compartment.
Operating Instructions
Stainless Steel Refrigerator
Performance
Air Flow
System
The Performance Air-Flow System is designed to
maximize temperature control in the fresh food
and freezer compartments. This unique special
feature consists of the Air Tower along the top
and back walls of the fresh food compartment
and the Air Tunnel on the bottom portion of
the freezer rear wall. Placing food in front of
the louvers on these components will not affect
performance.
Although the Air Tower and the Air Tunnel
can be removed, doing so will affect temperature
performance. (For removal instructions, on-line,
24 hours a day, contact us at GEAppliances.com
or call 800.444.1845. In Canada, call us at
1.800.561.3344.)

9
ow
TurboCool
™
works
TurboCool rapidly cools
the refrigerator compartment in
order to more quickly cool foods.
Use TurboCool when adding
a large amount of food to the refrigerator
compartment, putting away foods after they
have been sitting out at room temperature
or when putting away warm leftovers. It can
also be used if the refrigerator has been
without power for an extended period.
Once activated, the compressor will turn on
immediately and the fans will cycle on and
off at high speed as needed for 8 hours.
The compressor will continue to run until
the refrigerator compartment cools to
approximately 34°F (1°C), then it will cycle
on and off to maintain this setting. After
8 hours, or if TURBOCOOL is pressed again,
the refrigerator compartment will return
to the original setting.
Other Controls
Stainless Steel Refrigerator
ow to use
TurboCool
1Press TURBOCOOL. The refrigerator
temperature display will show TC.
2After TurboCool is complete,
the refrigerator compartment
will return to the original setting.
N TES:
•The refrigerator temperature cannot
be changed during TurboCool.
•The freezer temperature is not affected during
TurboCool.
•When opening the refrigerator door during
TurboCool, the fans will continue to run if
they have cycled on.
Energy Saver
This product is equipped with
an Energy Saver feature.
The refrigerator is shipped
with the Energy Saver feature N.
Over time, moisture can form on the front
surface of the refrigerator cabinet and cause
rust. If moisture does appear on the front surface
of the refrigerator cabinet, turn off the Energy
Saver feature by pressing and releasing
the ENERGY SAVER pad on the control panel.
Door Alarm
The door alarm will sound
if either door is open for more than
2 minutes. The beeping sound will
stop when you close the door.

10
Internal Water ispenser
Stainless Steel Refrigerator
Internal Water
Dispenser
The water dispenser is located on the left wall
inside the refrigerator compartment.
To dispense water:
1Hold the glass against the recess.
2Push the water dispenser button.
3Hold the glass underneath the dispenser
for 2–3 seconds after releasing the dispenser
button. Water may continue to dispense
after the button is released.
If no water is dispensed when the refrigerator is
first installed, there may be air in the water line
system. Press the dispenser button for at least
2 minutes to remove trapped air from the water
line and to fill the water system. During this
process, the dispenser noise may be loud as
the air is purged from the water line system.
To flush out impurities in the water line, throw
away the first 6 glassfuls of water.
N TE: To avoid water deposits, the dispenser
should be cleaned periodically by wiping with
a clean cloth or sponge.

Water filter
Water Filter Cartridge
The water filter cartridge is
located in the back upper
right corner of the
refrigerator compartment.
When to Replace the Filter
There is a replacement indicator light for the
water filter cartridge on the temperature display.
This light will turn orange to tell you that you
need to replace the filter soon. The filter cartridge
should be replaced when the replacement
indicator light turns red or if the flow of water to
the dispenser or icemaker decreases.
On models with external dispensers, the top of
the LC screen will display, “Replace Water Filter.”
Installing the Filter Cartridge
1If you are replacing the
cartridge, first remove
the old one by slowly turning it
to the left. O NOT pull down on
the cartridge. A small amount of
water may drip down.
CAUTI N: If air has been trapped in
the system, the filter cartridge may be ejected as
it is removed. Use caution when removing.
2Remove the protective foil from the end of the
cartridge.
3Fill the replacement cartridge with water from the
tap to allow for better flow from the dispenser
immediately after installation.
4Lining up the arrow on the
cartridge and the cartridge
holder, slowly rotate the
cartridge clockwise until it
stops. When the cartridge is
properly installed, you will feel
it “click” as it locks into place.
Do not overtighten.
5Run water from the dispenser for 3 minutes
(about 11⁄2gallons) to clear the system
and prevent sputtering. See To Use the
Dispenser section.
6Press and hold the RESET WATER
FILTER pad for 3 seconds.
N TE: A newly-installed water
filter cartridge may cause water
to spurt from the dispenser.
Filter Bypass lug
You must use the filter bypass plug when
a replacement filter cartridge is not available.
The icemaker will not operate without the filter
or filter bypass plug.
Replacement Filters:
To order additional filter cartridges
in the United States, visit our Website,
GEAppliances.com, or call GE arts and
Accessories, 800.626.2002.
Filter Model MWF
Customers in Canada should consult the yellow
pages for the nearest Mabe Service Center.
Water Filter
Stainless Steel Refrigerator
11

The slide-out spillproof shelf allows you to reach
items stored behind others. The special edges
are designed to help prevent spills from dripping
to lower shelves.
To remove:
1Remove all items from shelf.
2Slide the shelf out until it stops.
3Lift the front edge of the shelf until the central
tabs are above the front bar.
4Continue pulling the shelf forward until
it can be removed.
To replace:
1Place the rear shelf tabs just in front
of the central notches on the shelf frame.
2Slide the shelf in until the central tabs
are slightly behind the front bar.
3Lower the shelf into place until it is horizontal
and slide the shelf in.
Make sure that the shelf sits flat after reinstallation
and doesn’t move freely from side to side.
Make sure you push the shelves all the way
in before you close the door.
12
Rearranging
the shelves
Shelves in the refrigerator compartment
are adjustable.
Refrigerator Compartment
To remove:
1Remove all items from the shelf.
2Tilt the shelf up at the front.
3Lift the shelf up at the back and bring
the shelf out.
To replace:
1While tilting the shelf up, insert the top hook
at the back of the shelf in a slot on the track.
2Lower the front of the shelf until the bottom
of the shelf locks into place.
1
Shelves and Bins
Stainless Steel Refrigerator
Slide-out
spillproof
shelf
This shelf splits in half and slides under itself
for storage of tall items on the shelf below.
This shelf can be removed and replaced or
relocated just like Slide-Out Spillproof Shelves.
On some models, this shelf can not be used
in the lowest position.
QuickSpace
™
shelf
Some models have wire shelves that
can be adj sted in the same manner.
2
1
2

13
To Remove the Full-Width Upper Basket:
1Open the bottom freezer drawer until
it stops.
2Pull the basket out to the stop location.
3Lift the basket up at the front to release it from
the slides.
4Lift the back up and out of the slide.
When Replacing the Full-Width Upper
Basket:
rop the upper rear wire rail of the basket into
place behind the plastic tabs. Then drop the front
end of the basket into place and slide the basket
back into the closed position.
N TE: Always be sure to fully close this basket.
To Remove the Full-Width Basket on
Top Freezer Drawer Models:
1Open the top freezer drawer until it stops.
2The freezer basket rests on the inside tabs
on the drawer slides.
3Lift the front end of the basket so that the front
two alignment tabs come out of the slide bracket
first. Then rotate the front edge of the basket up
while lifting the remaining two rear alignment tabs
out of the slide bracket.
4Make sure the plastic sleeves remain attached
to the 4 slots on the slide brackets.
When Replacing the Full-Width Basket:
Tilt the basket back and lower it down into
the drawer. Rotate the basket to a horizontal position
and press it down into the 4 alignment tabs.
N TE: Always be sure that all 4 basket slots
are engaged in the slide brackets before sliding
back into the freezer.
Basket
removal (top
drawer)
Shelves and Bins
Stainless Steel Refrigerator
Appearance may vary
Appearance may vary
Tab
Basket
removal
(bottom
drawer)

To Remove the Deep Full-Width Lower
Basket:
1Open the bottom freezer drawer until
it stops.
2Lift the rear of the basket up so the two rear
alignment tabs are pulled out of the slide
bracket.
3Rotate the basket up and out of the drawer.
When Replacing the Deep Full-Width
Lower Basket:
Lower the front end of the basket into position so
that the two front alignment tabs enter the slide
bracket. Then lower the rear of the basket into
place, ensuring the two rear alignment tabs
are pressed into place in the slide bracket.
N TE: Always be sure that all 4 basket slots are
engaged in the slide brackets before sliding back
into the freezer.
Shelves and Bins
Stainless Steel Refrigerator
14
Adjustable bins can easily be carried from
refrigerator to work area.
To remove: Lift bin straight up, then pull out.
To replace or relocate: Slide in the bin just above
the molded door supports, and push down.
The bin will lock in place.
The snugger helps prevent tipping, spilling
or sliding of small items stored on the door shelf.
Grip the finger hold near the rear of the snugger
and move it to fit your needs.
Adjustable
bins on
the door
Appearance may vary
Basket removal
(bottom
drawer)
(cont.)
To remove: Lift the bin straight up, then
pull out.
To replace: Engage the bin in the molded
supports on the door and push down. It will lock
in place.
Non-
Adjustable
bins on
the door
To remove: Lift the rack straight up, then pull out.
To replace: Engage the rack in the molded
supports on the door and push down. It will lock
in place.
Non-
Adjustable
beverage
rack

15
The doors are factory set for a 150°
door swing. To avoid contact damage
to the refrigerator doors or to adjacent
cabinetry or walls, observe the minimum
clearances shown.
• Allow 4" clearance on each side
to an adjacent wall for a 90° opening
and access to drawers.
• Allow 15" clearance on each side
to an adjacent wall for removal of drawers.
If the top of the doors are uneven, first try to raise
the lowest door by turning the leveling leg on
the same side as the door until the doors are
even. If the unit rocks, re-adjust the leveling
legs to the extent that the unit is stable.
If the doors remain uneven, turn the adjustable
pin to raise, or lower, the left door to match
the right door. Use a 1/4″Allen wrench
to turn the pin.
Additional Features
Stainless Steel Refrigerator
Door
alignment
Door swing
clearances
15" 15"
150˚ Door Swing
90˚ Door Swing 24-5/8"
19-1/16"
Adjustable Pin
Leveling
Leg

Slide the control all the way to the HIGH setting
to provide high humidity recommended for most
vegetables.
Slide the control all the way to the LOW setting
to provide lower humidity levels recommended
for most fruits.
16
Crispers and Pans
Stainless Steel Refrigerator
Excess water that may accumulate in the bottom
of the drawers should be wiped dry.
Fruit and
vegetable
crispers
Adjustable
humidity
crispers
The convertible meat pan has its own cold air
duct to allow a stream of cold air from the freezer
compartment to flow to the pan.
The variable temperature control regulates
the air flow from the Climate Keeper.
Set the control to the coldest setting to store
fresh meats.
Set the control to Cold to convert the pan
to normal refrigerator temperature and provide
extra vegetable storage space. The cold air duct
is turned off. Variable settings between these
extremes can be selected.
Convertible
meat pan
To remove:
1Remove the fruit and vegetable drawers.
2Pull the drawer out to the stop position.
3Lift the lid to access the 4 swing locks.
4Rotate all four swing locks to the unlock
position.
5Lift the front of the drawer up and out.
To replace:
1Make sure all four swing locks are in the unlock
position.
2Place the sides of the drawer into the drawer
supports, making sure the swing locks fit
on the drawer slots.
3Lock all four swing locks by rotating them
to the lock position.
4Lower the lid and slide in the drawer.
5Replace the fruit and vegetable drawers.
Deli pan
removal
Swing Locks –
Unlock Position
Swing Locks –
Lock Position

Automatic Icemaker
Stainless Steel Refrigerator
Automatic
icemaker
N TE: A newly installed refrigerator may take 12 to 24 hours to begin making ice.
The icemaker will produce seven cubes
per cycle—approximately 100–130 cubes
in a 24-hour period, depending on freezer
compartment temperature, room temperature,
number of door openings and other use
conditions.
See below for how to access ice and reach
the power switch.
If the refrigerator is operated before
the water connection is made to the icemaker,
set the power switch in the (off) position.
When the refrigerator has been connected
to the water supply, set the power switch
to the l (on) position. The icemaker power light
will turn green when the freezer light switch is
pressed in or when the freezer door is closed.
The icemaker will fill with water when it cools to
15°F (–10°C). A newly installed refrigerator may
take 12 to 24 hours to begin making ice cubes.
You will hear a buzzing sound each time
the icemaker fills with water.
Throw away the first few batches of ice to allow
the water line to clear.
Be sure nothing interferes with the sweep
of the feeler arm.
When the bin fills to the level of the feeler arm,
the icemaker will stop producing ice. It is normal
for several cubes to be joined together.
If ice is not used frequently, old ice cubes will
become cloudy, taste stale and shrink.
N TE: In homes with lower-than-average water
pressure, you may hear the icemaker cycle
multiple times when making one batch of ice.
N TE: Set the power switch to the (off) position
if the water supply is shut off.
Icemaker
Feeler Arm
Power
Switch
Green
Power Light
To reach the icemaker power switch, open the top
freezer drawer and remove the full-width basket.
Always be sure to replace the basket.
To access ice, simply open the bottom freezer
drawer and slide out the full-width basket to expose
the ice bucket.
Accessing ice
and reaching
the power
switch
To access ice.
Ice
B cket
To reach the power switch.
17

18
Care and Cleaning
Stainless Steel Refrigerator
The stainless steel panels and handles can be
cleaned with a commercially available stainless
steel cleaner such as Stainless Steel Magic™.
Stainless Steel Magic is available at Ace, True
Value, Servistar, HWI and other leading stores.
It is also available through GE Parts and
Accessories, 800.626.2002. Order part number
WX10X15.
Do not use appliance wax or polish
on the stainless steel.
Cleaning
the outside
To help prevent odors, leave an open box
of baking soda in the fresh food and freezer
compartments.
Unplug the refrigerator before cleaning.
If this is not practical, wring excess moisture
out of sponge or cloth when cleaning around
switches, lights or controls.
Use warm water and baking soda solution—
about a tablespoon (15 ml) of baking soda to
a quart (1 liter) of water. This both cleans and
neutralizes odors. Rinse and wipe dry.
Use of any cleaning solution other than
that which is recommended, especially those
that contain petroleum distillates, can crack
or damage the interior of the refrigerator.
Avoid cleaning cold glass shelves with hot
water because the extreme temperature
difference may cause them to break. Handle
glass shelves carefully. Bumping tempered
glass can cause it to shatter.
Do not wash any plastic refrigerator parts
in the dishwasher.
Cleaning
the inside
Be careful when moving the refrigerator away
from the wall. All types of floor coverings can be
damaged, particularly cushioned coverings and
those with embossed surfaces.
Pull the refrigerator straight out and return it
to position by pushing it straight in. Moving
the refrigerator in a side direction may result
in damage to the floor covering or refrigerator.
When pushing the refrigerator back, make sure
you don’t roll over the power cord or icemaker
supply line.
Behind the
refrigerator
For long vacations or absences, remove food
and unplug the refrigerator. Clean the interior
with a baking soda solution of one tablespoon
(15 ml) of baking soda to one quart (1 liter)
of water. Leave the doors open.
Set the icemaker power switch to the (off)
position and shut off the water supply to
the refrigerator.
If the temperature can drop below freezing,
have a qualified servicer drain the water supply
system to prevent serious property damage due
to flooding.
Preparing
for vacation
Secure all loose items such as shelves and
drawers by taping them securely in place
to prevent damage.
When using a hand truck to move the refrigerator,
do not rest the front or back of the refrigerator
against the hand truck. This could damage
the refrigerator. Handle only from the sides
of the refrigerator.
Be sure the refrigerator stays in an upright
position during moving.
Preparing
to move

CAUTI N: Light bulbs may be hot.
Setting the controls to OFF does not remove
power to the light circuit.
1Unplug the refrigerator.
2Remove the freezer basket for access. The bulb is
located at the rear of the freezer inside a light
shield.
3To remove, grasp the shield at the top and pull out
to release the tabs at the bottom.
4After replacing with an appliance bulb of the
same or lower wattage, replace
the shield and freezer basket.
5Plug the refrigerator back in.
19
Replacing the Light Bulbs
Stainless Steel Refrigerator
Setting the controls to OFF does not remove
power to the light circuit.
1Unplug the refrigerator.
2The bulbs are located at the top
of the compartment, inside the light shield.
3To remove the light shield, pull forward
on the shield to disengage the tabs at the back
of the shield. Pull down to remove the light
shield.
4After replacing the bulbs with appliance
bulbs of the same or lower wattage, replace
the light shield. When replacing the light shield,
set the front tabs into the appropriate slots
in the front of the shield housing and pull
forward to seat the tabs at the back
of the shield into the housing.
5Plug the refrigerator back in.
Fresh food
compartment—
upper light
Tabs
Appearance may vary
Light
Shield
Freezer light

•You may hear cracking or popping sounds
when the refrigerator is first plugged in.
This happens as the refrigerator cools
to the correct temperature.
•Electronic dampers click open and closed to
provide optimal cooling and energy savings.
•The compressor may cause a clicking or
chirping sound when attempting to restart
(this could take up to 5 minutes).
•The electronic control board may cause
a clicking sound when relays activate
to control refrigerator components.
•Expansion and contraction of cooling coils
during and after defrost can cause a cracking
or popping sound.
•After an icemaking cycle, you may hear
the ice cubes dropping into the ice bucket.
•The flow of refrigerant through the freezer
cooling coils may make a gurgling noise like
boiling water.
•Water dropping on the defrost heater can
cause a sizzling, popping or buzzing sound
during the defrost cycle.
•A water dripping noise may occur
during the defrost cycle as ice melts from
the evaporator and flows into the drain pan.
•Closing the door may cause a gurgling sound
due to pressure equalization.
20
Normal
operating
sounds
Newer refrigerators sound different from older refrigerators. Modern refrigerators have more
features and use newer technology.
HUMMM...
WH SH...
CLICKS, O S,
CRACKS and CHIR S
WATER SOUNDS
Do you hear what I hear? These sounds are normal.
For additional information on normal
icemaker and dispenser operating
sounds, see the Automatic Icemaker
and Internal Water Dispenser
sections.
•The new high efficiency compressor may run
faster and longer than your old refrigerator
and you may hear a high-pitched hum or
pulsating sound while it is operating.
•Sometimes the refrigerator runs for an
extended period, especially when the doors
are opened frequently. This means that
the Frost Guard™feature is working
to prevent freezer burn and improve
food preservation.
•You may hear a whooshing sound when
the doors close. This is due to pressure
equalizing within the refrigerator.
•You may hear the fans spinning at high
speeds. This happens when the refrigerator
is first plugged in, when the doors are opened
frequently or when a large amount of food
is added to the refrigerator or freezer
compartments. The fans are helping
to maintain the correct temperatures.
•If either door is open for over 3 minutes,
you may hear the fans come on in order
to cool the light bulbs.
•The fans change speeds in order to provide
optimal cooling and energy savings.
The Problem Solver
Stainless Steel Refrigerator
