We bring good things to life.
900MHz SPACEMAKER® Under the
Counter Call Waiting Caller ID Cordless
Speakerphone/Answering System with
Digital AM/FM Radio andTimer
User’s Guide
26976

2
EQUIPMENT APPROVAL INFORMATION
Your telephone equipment is approved for connection to the Public SwitchedTelephone Network and is in
compliance with parts 15 and 68, FCC Rules and Regulations and theTechnical Requirements forTelephone
Terminal Equipment published by ACTA.
1Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other information, the US number and Ringer
Equivalence Number (REN) for the equipment.You must, upon request, provide this information to your
telephone company.
The REN is useful in determining the number of devices you may connect to your telephone line and
still have all of these devices ring when your telephone number is called. In most (but not all) areas, the
sum of the RENs of all devices connected to one line should not exceed 5.To be certain of the number of
devices you may connect to your line as determined by the REN, you should contact your local
telephone company.
A plug and jack used to connect this equipment to the premises wiring and telephone network must
comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant
telephone cord and modular plug is provided with this product. It is designed to be connected to a
compatible modular jack that is also compliant. See installation instructions for details.
Notes
•This equipment may not be used on coin service provided by the telephone company.
•Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone
equipment if you are on a party line. Check with your local telephone company.
•Notice must be given to the telephone company upon permanent disconnection of your telephone
from your line.
•If your home has specially wired alarm equipment connected to the telephone line, ensure the
installation of this product does not disable your alarm equipment. If you have questions about what
will disable alarm equipment, consult your telephone company or a qualified installer.
2Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the telephone network, the telephone
company shall, where practicable, notify you that temporary discontinuance of service may be required.
Where prior notice is not practicable and the circumstances warrant such action, the telephone company may
temporarily discontinue service immediately. In case of such temporary discontinuance, the telephone
company must: (1) promptly notify you of such temporary discontinuance; (2) afford you the opportunity to
correct the situation; and (3) inform you of your right to bring a complaint to the Commission pursuant to
procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.
The telephone company may make changes in its communications facilities, equipment, operations or
procedures where such action is required in the operation of its business and not inconsistent with FCC Rules
and Regulations. If these changes are expected to affect the use or performance of your telephone equipment,
the telephone company must give you adequate notice, in writing, to allow you to maintain uninterrupted service.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING:TO
PREVENT FIRE OR
ELECTRICAL SHOCK
HAZARD, DO NOT
EXPOSETHIS
PRODUCT TO RAIN
OR MOISTURE.
THE LIGHTNING
FLASH AND ARROW
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
“DANGEROUS
VOLTAGE” INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR
BACK). NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
CAUTION:

3
INTERFERENCE INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference; and (2)This device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna (that is, the antenna for radio or television that is “receiving”
the interference).
•Reorient or relocate and increase the separation between the telecommunications equipment and
receiving antenna.
•Connect the telecommunications equipment into an outlet on a circuit different from that to which the
receiving antenna is connected.
If these measures do not eliminate the interference, please consult your dealer or an experienced radio/television
technician for additional suggestions. Also, the Federal Communications Commission has prepared a helpful
booklet, “HowTo Identify and Resolve Radio/TV Interference Problems.”This booklet is available from the U.S.
Government Printing Office, Washington, D.C. 20402. Please specify stock number 004-000-00345-4 when
ordering copies.
HEARING AID COMPATIBILITY
This telephone system meets FCC standards for Hearing Aid Compatibility.
FCC NUMBER IS LOCATED ONTHE CABINET BOTTOM
REN NUMBER IS LOCATED ONTHE CABINET BOTTOM
Attachments: Do not use attachments not recommended by the product manufacturer as they may
cause hazards.
Lightning: For added protection for this product during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall and disconnect the antenna or cable system. Doing
so prevents damage to the product due to lightning and power-line surges.
Replacement Parts: When replacement parts are required, be sure the service technician uses manufacturer
specified replacement parts or parts with the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock or other hazards.
Safety Check: Upon completion of any service or repairs to the product, ask the service technician to
perform safety checks to determine that the product is in proper operating condition.
Wall or Ceiling Mounting:The product should be mounted to a wall or ceiling only as recommended by
the manufacturer.

4
(Table of Contents continued on
the following page.)
TABLE OF CONTENTS
EQUIPMENT APPROVAL INFORMATION ......... 2
INTERFERENCE INFORMATION .................... 3
HEARING AID COMPATIBILITY .................... 3
INTRODUCTION ...................................... 6
DIGITAL SECURITY SYSTEM ................. 7
BEFORE Y OU BEGIN ............................... 7
PARTS CHECKLIST .............................. 7
IMPORTANT INSTALLATION GUIDELINES ....... 7
SAFETY PRECAUTIONS ........................ 7
INSTALLATION GUIDELINES ....................... 8
TELEPHONE JACK REQUIREMENTS ......... 8
INSTALLING THE PHONE ........................... 8
WALL BASE UNIT ............................. 8
CONNECTING THET ELEPHONE LINE ........ 9
CONNECTING THE AC (ELECTRICAL)
POWER ................................ 9
HANDSET .................................... 9
SPACEMAKER® UNIT ........................... 10
CONNECTING THE AC (ELECTRICAL)
POWER .............................. 10
CHARGING THE HANDSET BATTERY ..... 10
UNDER CABINET MOUNTING ................. 10
TOOLS REQUIRED ............................ 10
MOUNTING HARDWARE PACKED WITH
YOUR UNIT ........................ 11
BEFORE MOUNTING ......................... 11
MOUNTING PROCEDURE .................... 12
HANDSET AND W ALL BASE UNIT
LAYOUT ........................................... 15
SPACEMAKER® UNIT LAYOUT ................ 15
SPACEMAKER® UNIT SETUP ................. 16
DAY/TIME SETUP ............................ 16
RINGER SETUP ................................ 16
SYSTEM SETUP ............................... 16
LANGUAGE ..................................... 16
LOCAL AREA CODE .......................... 17
TONE/PULSE DIALING ...................... 17
DISPLAY CONTRAST ......................... 18
ANSWERING SYSTEM ON/OFF ......... 18
SETTING THE RINGS TO ANSWER ........ 18
SETTING THE SECURITY CODE FOR
REMOTE ACCESS ................. 19
SPACEMAKER® UNIT ....................... 19
DEFAULT SETTINGS .......................... 19
HANDSET SETUP ................................. 20
RINGER SETUP ................................ 20
SYSTEM SETUP ............................... 21
LANGUAGE ..................................... 21
LOCAL AREA CODE .......................... 22
TONE /PULSE DIALING ..................... 22
DEFAULT SETTINGS .......................... 22
HANDSET OPERATION ........................... 22
REGISTRATION ................................. 22
RECEIVING ACALL ........................... 23
MAKING ACALL .............................. 23
LINE IN USE ................................... 23
3-WAY CONFERENCING .................... 23
CALLT RANSFER ............................... 24
LAST NUMBER REDIAL ..................... 24
FLASH ........................................... 24
INUSE INDICATOR LIGHT .................. 24
AUTO STANDBY .............................. 24
CHANNEL BUTTON ........................... 24
TEMPORARY T ONE ............................ 25
EXIT .............................................. 25
FINDING THE HANDSET ..................... 25
RINGER .......................................... 25
VOLUME ........................................ 25

5
CALLT IMER .................................... 25
SPEAKERPHONE OPERATION ................... 26
SPEAKERPHONE LOCATION ................. 26
SPEAKERPHONE GUIDELINES .............. 26
REGISTRATION ................................. 26
RECEIVING ACALL ........................... 27
MAKING ACALL .............................. 27
LINE IN USE ................................... 27
3-WAY CONFERENCING .................... 27
CALLT RANSFER ............................... 27
FLASH ........................................... 27
SPEAKER INDICATOR LIGHT ................ 27
CHARGE INDICATOR LIGHT ................. 28
EXIT .............................................. 28
DISPLAY BACKLIGHT ......................... 28
CHANNEL BUTTON ........................... 28
SPEAKERPHONE VOLUME ................... 28
MIC MUTE .................................... 28
CALLT IMER .................................... 29
ANSWERING SYSTEM OPERATION ........... 29
VOICE INSTRUCTIONS ....................... 29
RECORDING THE OUTGOING
ANNOUNCEMENT ................. 29
REVIEWING ANNOUNCEMENT ............. 29
MESSAGES INDICATOR ...................... 29
SCREENING CALLS FROM THE
SPACEMAKER®................... 30
MESSAGE PLAYBACK ........................ 30
ANSWERING SYSTEM MEMORY FULL .. 30
ERASING MESSAGES ........................ 30
LEAVING AMEMO ........................... 31
REMOTE ACCESS ............................. 31
CALLER ID (CID) ................................ 32
CALL WAITING CALLER ID ................ 32
RECEIVING AND STORING CALLS ......... 32
REVIEWING CID RECORDS ................ 33
TRANSFERRING CID RECORDS TO
MEMORY ........................... 33
DELETING THE CID RECORD
SHOWING IN THE DISPLAY ..... 33
DELETING ALL CID RECORDS ............ 34
DIALING ACID NUMBER .................. 34
CHANGING THE CID NUMBER
FORMAT ............................. 34
RADIO OPERATION ............................... 34
AM ANTENNA ................................ 34
FM ANTENNA ................................ 35
TURNING ON THE RADIO ................... 35
BAND ............................................ 35
RADIO VOLUME ............................... 35
CHANGING STATIONS ....................... 35
STORING PRESET STATIONS .............. 35
USING PRESET STATIONS ................. 35
CLOCK ........................................... 35
MEMORY ............................................ 35
STORING ANAME AND NUMBER IN
MEMORY ........................... 36
CHANGING ASTORED NUMBER .......... 36
STORING AREDIAL NUMBER ............. 36
DIALING ASTORED NUMBER ............. 37
INSERTING APAUSE IN THE DIALING
SEQUENCE ......................... 37
REVIEWING AND DELETING STORED
NUMBERS .......................... 38
CHAIN DIALING FROM MEMORY .... 38
PROGRAMMABLE T IMER ......................... 38
SETTING THET IMER .......................... 39
STARTING THET IMER ........................ 39
STOPPING THET IMER ........................ 39
PAUSING THET IMER ......................... 40
USING THET IMER WITH OTHER
MODES ............................. 40
TALK MODE ................................. 40
CHANGING THE BATTERY ....................... 40
DISPLAY MESSAGES ............................. 41
HANDSET SOUND SIGNALS ................... 42
HEADSET AND BELT CLIP OPERATION ...... 42
CONNECTING AN OPTIONAL
HEADSET TO THE HANDSET .... 42
CONNECTING THE BELT CLIP .............. 43
TROUBLESHOOTING T IPS ........................ 43
CALLER ID ................................ 43
TELEPHONE ............................... 43
SERVICE ............................................. 46
INDEX ................................................ 47
ACCESSORY ORDER FORM .................... 49
LIMITED WARRANTY ............................. 50

6
INTRODUCTION
CAUTION: When using telephone equipment, there are basic
safety instructions that should always be followed. Refer to the
IMPORTANT SAFETY INSTRUCTIONS provided with this
product and save them for future reference.
Your Caller ID phone stores and displays specific information, provided
by your local telephone company, to subscribers of Caller ID or similar
caller identification services.
Your Caller ID phone enables you to:
•Identify callers before you answer the phone.
•View the time and date of each incoming call.
•Record up to 40 Caller ID messages sequentially.
•Know who called while you were away or on the phone.
To get the most from your new phone, we suggest that you take a few
minutes right now to read through this user’s guide.
IMPORTANT: In order to use all of the Caller ID features of this
phone, you must subscribe to either the standard Name/Number
Caller ID Service or Call Waiting Caller ID Service. To know who is
calling while you are on the phone, you must subscribe to Call
Waiting Caller ID Service.
IMPORTANT: Because cordless phones operate on electricity, you
should have at least one phone in your home that isn’t cordless, in
case the power in your home goes out.
INSTALLATION NOTE: Some cordless telephones operate at
frequencies that may cause interference to nearby TVs, microwave
ovens, and VCRs. To minimize or prevent such interference, the base
of the cordless telephone should not be placed near or on top of a
TV, microwave ovens, or VCR. If such interference continues, move
the cordless telephone farther away from these appliances.

7
DIGITAL SECURITY SYSTEM
Your cordless phone uses a digital security system to provide protection
against false ringing, unauthorized access, and charges to your phone line.
BEFORE YOU BEGIN
PARTS CHECKLIST
Make sure your package includes the items shown here.
In addition, your package also includes some mounting hardware, please
refer to the Under Cabinet Mounting section for details.
IMPORTANT INSTALLATION GUIDELINES
SAFETY PRECAUTIONS
CAUTION: To reduce the risk of fire, do not place any heating
or cooking product beneath this unit.
•Never install telephone wiring during a lightning storm.
•Never install telephone jacks in wet locations unless the jack is
specifically designed for wet locations.
•Never touch non-insulated telephone wires or terminals, unless the
telephone line has been disconnected at the network interface.
•Use caution when installing or modifying telephone lines.
•Temporarily disconnect any equipment connected to the phone such
as faxes, other phones, or modems.
Wall base unit
Telephone
line cord AC Power converter for Spacemaker® Unit
Spacemaker® Unit Handset
Handset battery pack Belt Clip
page
+
-
skip
tune/seek
review
radio
on•off
am•fm
radio controls
radio
presets
format
flash
prog
exit
speaker
+
-
CID
VOL
delete
cid
erase play
stop
memo message
answerer controls
channel
a
a
n
n
o
u
n
c
e
timer
m
u
t
e
m
i
c
mic
T
A
L
K
C
A
L
L
B
A
C
K
c
h
a
r
g
e
MIN HOUR DAY/TIMECHECK
press to check/hold to change
RINGER HI LO OFF
F
M
TAL K
+ -
FORMATREDIAL CID/VOL
timer mem
9
WXYZ
6
MNO
3
DEF
8
TUV
5
JKL
2
ABC
7
PQRS
4
GHI
1
9
PAUSE
0
OPER
*
TONE
delete program
ringer
CHAN FLASH
HI
OFF
LO
mic
C
A
L
L
B
A
C
K
exit

8
INSTALLATION GUIDELINES
•Install the wall base unit near both a telephone (modular) jack and an
electrical power outlet.
•The Spacemaker® unit is a cordless speakerphone with radio and
answering machine. Before mounting it under a cabinet, check if the
cordless speakerphone and the radio work well at the selected
location first, also check the orientation of the power converter cord
for the best FM radio reception.
•Avoid sources of noise, such as a window by a busy street, and electrical
noise, such as motors, microwave ovens and fluorescent lighting.
•Avoid heat sources, such as heating air ducts, heating appliances,
radiators, and direct sunlight.
• Avoid areas of excessive moisture or extremely low temperature.
• Avoid dusty locations.
• Avoid other cordless telephones or personal computers.
TELEPHONE JACK REQUIREMENTS
To use this phone, you need an RJ11C type modular
telephone jack, which might look like the one
pictured here, installed in your home. If you don ’t
have a modular jack, call your local phone company
to find out how to get one installed.
INSTALLING THE PHONE
Choose the best location to install your wall base unit and Spacemaker®
unit.Your wall base unit should be plugged into an electrical outlet with a
phone jack nearby, while your Spacemaker® unit should be mounted
under the counter, or you may place it on a level surface such as a desk
or table top.
WALL BASE UNIT
Modular
telephone
line jack
Wall plate

9
CONNECTING THE TELEPHONE LINE
1. Connect one end of the telephone line cord to the LINE jack on the
bottom of the wall base unit.
2. Connect the other end of the telephone line cord to a telephone jack
on the wall.
3. Raise the antenna on the base.
CONNECTING THE AC (ELECTRICAL) POWER
1. Plug the wall base unit into an electrical outlet.
2. Make sure that its pins are inserted fully into the outlet and it is firmly
installed. If not, choose another electrical outlet to plug into.
HANDSET
NOTE: The handset battery compartment cover are
packaged together.
1. Connect the battery to the jack located inside the battery compartment.
NOTE: It is important to maintain the polarity (black and red wires)
to the jack inside the compartment as shown in the illustration.
2. Close the battery compartments by pushing the cover up until it snaps
into place.
page
Insert another phone
RED
WIRE
PRESS DOWN
FIRMLY
CHARGE FOR 12 HOURS
CONNECT BATTERY AND
INSTALL COVER
PRIOR TO USE
BLACK WIRE
BATTERY
