JVB98SH – GE Profile™36" Telescopic Downdraft System
Specification Revised 5/09
220961
2-1/4
6-3/8
3-1/4
33-7/8
36
17-1/8
20-5/8
12-1/8
7-1/4
7-1/2
8-1/2
27
C
L
36" Unit
Overall Dimensions (in inches) Venting Options (in inches)
Installation Information: Before installing, consult installation instructions
packed with product for current dimensional data.
For answers to your Monogram,
® GE Profile™or
GE®appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
Through the Floor In Cabinet Discharge (Down)
In Cabinet Discharge (Right) In Cabinet Discharge (Left)
Listed by
Underwriters
Laboratories
Note: Telescopic downdraft vents are not recommended to be installed
with cooktops that are flush mounted.
Approved for use with the following GE Profile™and GE cooktops –
36" and 30" electric models, 36" and 30” gas sealed burner models and
36" and 30" induction models.
Not approved for use with standard burner gas cooktops.
Note: The countertop must be at least 26" deep with a flat surface
area of 23-1/2" or more, front to back. In addition, other clearances
to the front edge of the countertop must be considered.
Note: Dimensions shown are for reference only. Before cutting out
countertop, refer to instructions packed with downdraft and cooktop.
Note: Installation in cabinets/countertops against the wall
will not be possible in most applications. Against the wall
installations are limited to dimension requirements. Refer to
installation instructions packed with product for further details.
JXBC67 Outdoor Cover. Optional accessory may be ordered for
installation of motor and blower assembly on outside wall.
JXRB67 Indoor Remote Accessory. Optional accessory may be
ordered for installation of motor and blower assembly in an indoor
remote location.
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.

JVB98SH – GE Profile™36" Telescopic Downdraft System
DUCTWORK LENGTH AND DUCT FITTINGS
NOTE: Do not exceed 150 foot maximum permissible equivalent lengths!
Flexible ducting: If flexible metal ducting is used, all equivalent feet values in the table should be
doubled. The flexible metal duct should be straight and smooth and extended as much as possible.
DO NOT use flexible plastic ducting.
Add equivalent lengths for all duct pieces and transitions used to ensure that the duct run does not
exceed the maximum 150 feet.
Duct Equivalent Duct Equivalent Duct Equivalent
Pieces Length* Pieces Length* Pieces Length*
31⁄4″x 10″
to 6″Round
6″Round 1 ft. (per 31⁄4″x 10″Transition 4 ft.
Straight foot length) 45°Elbow 8 ft. 90°Elbow
6″Round
31⁄4″x 10″1 ft. (per 31⁄4″x 10″Wall Cap 24 ft.
Straight foot length) 90°Flat Elbow 33 ft. with Damper
6″Round 31⁄4″x 10″
6″12 ft. to 31⁄4″x 10″2 ft. Wall Cap 24 ft.
90°Elbow Transition with Damper
31⁄4″x 10″
6″to 6″Round 2 ft. 6″Round
45°Elbow 7 ft. Transition Roof Cap 33 ft.
6″Round
to 31⁄4″x 10″
31⁄4″x 10″Transition 4 ft.
90°Elbow 14 ft. 90°Elbow
SHOULD NOT EXCEED 150 EQUIVALENT FEET
*Equivalent lengths of duct pieces are based on actual tests conducted by GE Evaluation Engineering
and reflect requirements for good venting performance. See chart for CFM Duct Length.
Venting Duct Information
Plan the Ductwork
1. This downdraft blower system is designed for use with 3-1/4" x 10"
ductwork (can be transitioned to 6" round). Two different discharge
directions are available with side-to-side adjustment for the accurate
alignment of ductwork.
2. For best performance: choose the ducting option which allows the shortest
length of ductwork and a minimum number of elbows and transitions.
Check location of floor joists, wall joists, wall studs, electrical wiring or
plumbing for possible interference.
Left discharge
(as shipped)
Right 
discharge
Specification Revised 5/09
