GE PVB98STSS User manual

1
Installation
Instructions
Downdraft Vent Systems
PVB94
PVB98
ZVB30
ZVB36

2
Safety Information
WARNING: TO REDUCE THE RISK
OF FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING.
A. Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the
manufacturer.
B. Before service or cleaning unit, switch power
off at service panel and lock the service
disconnecting means to prevent power from
being switched on accidentally. When the service
disconnecting means cannot be locked, securely
fasten a prominent warning device, such as a tag,
to the service panel.
• Do not attempt to repair or replace any part of
WKHGRZQGUDIWV\VWHPXQOHVVLWLVVSHFL¿FDOO\
recommended in this book. All other servicing
VKRXOGEHSHUIRUPHGE\DTXDOL¿HGWHFKQLFLDQ
• For general ventilating use only. Do not use to
exhaust hazardous or explosive materials and
vapors.
• Installation work and electrical wiring must be
GRQHE\DTXDOL¿HGSHUVRQVLQDFFRUGDQFHZLWK
DOODSSOLFDEOHFRGHVDQGVWDQGDUGVLQFOXGLQJ¿UH
rated construction.
6XI¿FLHQWDLULVQHHGHGIRUSURSHUFRPEXVWLRQDQG
H[KDXVWLQJRIJDVHVWKURXJKWKHÀXHFKLPQH\RI
fuel burning equipment to prevent back drafting.
Follow the heating equipment manufacturer’s
guidelines and safety standards such as those
published by the National Fire Protection
$VVRFLDWLRQ1)3$DQGWKH$PHULFDQ6RFLHW\
for Heating, Refrigeration and Air Conditioning
(QJLQHHUV$6+5$(DQGWKHORFDOFRGHDXWKRULWLHV
:KHQDSSOLFDEOHLQVWDOODQ\PDNHXSUHSODFHPHQW
air system in accordance with local building code
requirements. Visit GEAppliances.com for available
makeup air solutions.
CAUTION: 7RUHGXFHWKHULVNRI¿UH
and to properly exhaust air, be sure to duct air
outdoors. Do not vent exhaust air into spaces
within walls or ceilings or into attics, crawl spaces
or garages.
BEFORE YOU BEGIN
Read these instructions completely and carefully.
•IMPORTANT– Save these instructions
for local inspector’s use.
•IMPORTANT– Observe all governing
codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the consumer.
• Note to Consumer – Keep these instructions
for future reference.
• Skill Level – Installation of these vents require
basic mechanical and electrical skills.
• Completion Time – 1 to 3 hours.
• Proper installation is the responsibility of the
installer. Product failure due to improper
installation is not covered under the warranty.
If you received a damaged vent, you should
immediately contact your dealer or builder.
For Monogram local service in your area,
1.800.444.1845.
For Monogram service in Canada,
1.800.561.3344.
For Monogram Parts and Accessories,
call 1.800.626.2002.
WARNING: SHOCK HAZARD
This appliance must be properly grounded.
WARNING:
TO REDUCE THE RISK OF FIRE, USE ONLY METAL
DUCTWORK.

3
Design Information
CONTENTS
Design Information
Product Dimensions................................................................3
Accessories..................................................................................3
Advance Planning ...............................................................4, 5
Installation Preparation
Clearances.............................................................................. 6, 7
Parts Supplied............................................................................7
Tools and Materials Required .............................................7
Remove Packaging..................................................................7
Power Supply .............................................................................8
Venting Options.........................................................................9
Ductwork
Duct Fittings............................................................................. 10
Installation Instructions
Step 1, Install Downdraft Vent......................................... 11
Step 2, Install the Ductwork.............................................. 11
Step 3, Install Remote Switch........................................... 12
Step 4, Connect Power........................................................ 13
Step 5, Install Filters, Check Operation........................ 13
Cleaning..................................................................................... 13
PRODUCT DIMENSIONS
A B
30"Models 30" "
36"Models 36" "
ACCESSORIES
JXRB67 – Optional accessory for indoor remote
ORFDWLRQRIWKHEORZHUPRWRUDVVHPEO\8VHWKLVNLW
when the blower and motor assembly will be located
RXWVLGHRIWKHFDELQHWVXFKDVEHORZWKHFDELQHWÀRRU

4
Design Information
ADVANCE PLANNING
Downdraft Vent and Cooktop Cutout
The installation of these downdraft vents with any GE
or Monogram cooktop requires careful consideration.
Before you begin, review the combination cutout
illustrations on page 6.
Countertop Requirements
7KHFRXQWHUWRSPXVWKDYHDGHHSÀDWVXUIDFHWR
accommodate the cooktop and the vent. Countertops
with a rolled front edge and backsplash may not provide
WKHÀDWVXUIDFHDUHDUHTXLUHG
Base Cabinet Requirements
Review the installation preparation on Page 6 to ensure
the base cabinet is deep enough to accommodate the
minimum clearance and that the side and back wall
locations allow the vent to be properly secured. Ensure
QRLQWHUQDOVWUXFWXUHHOHPHQWVVXFKDVFDELQHWFRUQHU
EUDFHVLQWHUIHUHZLWKWKHYHQWRUFRRNWRS
Before you begin, you must:
1. Review countertop dimension illustrations to be
VXUH\RXZLOOKDYHHQRXJKÀDWFRXQWHUWRSVXUIDFH
2. Check to be sure that the total countertop depth
UHTXLUHGLQFOXGLQJPLQLPXPFXWRXWWRIURQWHGJH
GHSWKDOORZVHQRXJKVSDFHIRUDEDFNVSODVK
3. Review the cabinet illustration. Check to be sure
the interior cabinet depth will house the cooktop
burner box, the vent and the cutout clearance from
the front.
4. When countertop and cabinet depth present a
problem, review Creative Solutions.
5. Read this book completely to accurately plan the
installation location, clearances and ductwork
requirements.
With careful planning, you can achieve a custom look
with minimal adjustments.
Creative Solutions
• When the kitchen
design calls for an
DJDLQVWWKHZDOO
installation, move
the base cabinet
forward 3" to 5".
Filler panels or
complementary
moldings can be
added to exposed
cabinet sides.
• In an island or
peninsula, use
DQH[WUDGHHS
countertop.
The countertop
overhang at
the front can be
adjusted to meet
setback to cutout
requirements.
• When the cutout to the front edge of the countertop
requirement is more than 2", add a bullnose trim to
the front edge of the countertop. Include the trim
thickness when measuring the front edge to cutout
requirement. By adding the trim, the cooktop can
Cover Panel
End
Panel
Countertop
Overhang
per Cooktop
Clearances
Must be
Maintained
Base
Cabinet
Filler Panel Base Sink
Filler Panel
Maintain Cutout Clearances
to Front Edge as Specified be moved forward, providing additional countertop
depth and interior cabinet space.
• When the distances between the vent and the
LQVLGHFDELQHWVLGHZDOOVDUHPRUHWKDQµDQG
RUWKHLQVLGHFDELQHWEDFNZDOOLVPRUHWKDQµ
false walls should be constructed inside the cabinet
for securing the vent with the stabilizing brackets
UHIHUWRCutouts and Clearances under Installation
Preparation.

5
Design Information
Clearances
• The downdraft system with blower, motor and
ductwork will occupy the cabinet below the
countertop and cooktop.
7KHEORZHUPRWRUDVVHPEO\FDQEHORFDWHG
EHORZWKHFDELQHWÀRRU7KHDVVHPEO\ZLOO¿W
EHWZHHQÀRRUMRLVWV2UGHU-;5%IRULQGRRU
remote locations.
5HIHUWR\RXUVSHFL¿FFRRNWRSLQVWDOODWLRQ
instruction for appropriate clearances.
• Installation must conform with local codes.
Ductwork
Prepare ductwork to vent to the outdoors.
• Use the shortest and straightest duct run possible.
• The maximum permissible equivalent length for
duct run is 100 feet.
5HIHUWR´'XFW)LWWLQJVµFKDUWWRFDOFXODWH
HTXLYDOHQWOHQJWKIRUYDULRXVGXFWFRQ¿JXUDWLRQV
• The downdraft blower system is designed to use
[GXFWZRUN,WFDQEHWUDQVLWLRQHGWR
round.
• Ductwork MUST be vented to the outside–never
into a crawl space, attic or other enclosed space.
• Determine the need for a wall cap or roof cap.
Order the cap in advance.
:KHQDSSOLFDEOHLQVWDOODQ\PDNHXSUHSODFHPHQW
air system in accordance with local building
code requirements. Visit GEAppliances.com for
available makeup air solutions.
Electrical and Gas Locations
Plan the placement of the electrical outlet and gas
FRQQHFWLRQVLIXVHGFDUHIXOO\(OHFWULFDORXWOHWVDQG
gas connections cannot be placed on the back wall
of the cabinet because it may interfere with the
downdraft plenum. Refer to POWER SUPPLY section
for information on location of electrical and gas
connections.
• Install a standard electrical outlet on the right side
RIWKHFDELQHWZLWKLQUHDFKRIWKHYHQW·VWZRIRRW
long power cord.
• The vent and a GE or Monogram gas cooktop
FRPELQDWLRQFDQRSHUDWHIURPWKHVDPHYROW
standard duplex outlet.
• Electric cooktops must operate from a separate
YROWMXQFWLRQER[
$HOERZQRWVXSSOLHGFDQEHLQVWDOOHGRQWR
the inlet of the gas cooktop and route the gas
connections to avoid interference when installed
with a downdraft vent or other cabinetry features.
• The hood must vent down or to the left when
installed with a GE or Monogram gas cooktop to
avoid interference with the inlet of the gas cook
top.

6
Installation Preparation
CUTOUTS AND CLEARANCES
• Measure carefully when cutting the countertop.
• Make sure sides of the opening are parallel and
rear and front cuts are exactly perpendicular
ULJKWDQJOHVWRWKHVLGHV
• Measure to be sure there is room for clearances
to the front edge of the countertop.
• Refer to cooktop installation instructions to be sure
WKDWPRGHOV¿WLQWRWKHEDVHFDELQHWVEHLQJXVHG
• Draw lines on the countertop to follow as a cutting
guide.
• Measure and mark cooktop and vent overlaps to be
VXUHWKHUHLVHQRXJKÀDWFRXQWHUWRSGHSWK
7KHFDELQHWVLGHZDOOVVKRXOGEHZLWKLQµRIWKH
vent body. The cabinet back wall should be within
µRIWKHYHQWERG\UHIHUWRCreative Solutions
• Measure the base cabinet width at the top and
bottom to ensure it meets the minimum width
requirements .
30" COOKTOP AND DOWNDRAFT
COMBINATION
The cooktop must be installed per manufacturer’s
installation instructions.
IMPORTANT: The countertop cutout depth requires
PLQLPXPÀDWFRXQWHUWRSVXUIDFHDQG
minimum total countertop depth.
NOTE: Before you begin, measure and mark depth
WRHQVXUHWKDWDGHTXDWHÀDWFRXQWHUWRSVXUIDFH
is available.
For cooktop and downdraft combination depth:
• Follow cooktop installation instructions for cooktop
and downdraft combination installation.
2WKHUZLVHDGGWRWKHFRRNWRSFXWRXWGHSWK
NOTE:$GGWRWKHFRRNWRSFXWRXWGHSWKIRU
-3DQG-3 *Required to maintain UL or CSA approvals

30"
0LQLPXP

0LQLPXPÀDWFRXQWHU
top behind cutout required
Side View: Installed Vent Front View: Installed Vent
Cooktop Cooktop
4-1/2” Max
5-1/2”
Max 5-1/2”
Max
“A”
Width
“A”
Width
MODEL “A” Minimum Width
PVB98
ZVB36 34”
PVB94
ZVB30 28-1/2”

7
36" COOKTOP AND DOWNDRAFT
COMBINATION
IMPORTANT: The countertop cutout depth requires
PLQLPXPÀDWFRXQWHUWRSVXUIDFHDQG
minimum total countertop depth.
NOTE: Before you begin, measure and mark depth
WRHQVXUHWKDWDGHTXDWHÀDWFRXQWHUWRSVXUIDFH
is available.
For cooktop and downdraft combination depth:
• Follow cooktop installation instructions for cooktop
and downdraft combination installation.
2WKHUZLVHDGGWRWKHFRRNWRSFXWRXWGHSWK
NOTE:$GGWRWKHFRRNWRSFXWRXWGHSWKIRU
-3DQG-3 *Required to maintain UL or CSA approvals

36"
0LQLPXP
34"
0LQLPXPÀDWFRXQWHU
top behind cutout required
Installation Preparation
PARTS SUPPLIED
Open the carton and remove parts package.
Check contents to be sure all pieces are present.
TOOLS AND MATERIALS REQUIRED
/DUJHÀDWEODGHVFUHZGULYHU
-LJVDZ
• Carpenter’s square
• Ductwork to suit the installation
• Level
REMOVE PACKAGING
• Remove the shipping materials and the carton;
set carton aside. The carton can be used as a pad
when changing or adjusting vent direction.
4 Stabilizing Brackets
With Screws
1 Remote Switch
2 Filters 1 Wire and White
Connector

8
Installation Preparation
IMPORTANT
(Please read carefully.)
The power cord of this appliance is equipped with
DWKUHHSURQJJURXQGLQJSOXJZKLFKPDWHVZLWK
DVWDQGDUGWKUHHSURQJJURXQGLQJZDOOUHFHSWDFOH
to minimize the possibility of electric shock. The
customer should have the wall receptacle and
FLUFXLWFKHFNHGE\DTXDOL¿HGHOHFWULFLDQWRPDNH
sure the receptacle is properly grounded and has
correct polarity.
:KHUHDVWDQGDUGWZRSURQJZDOOUHFHSWDFOHLV
encountered, it is the personal responsibility and
obligation of the customer to have it replaced
ZLWKDSURSHUO\JURXQGHGWKUHHSURQJZDOO
receptacle.
Do not, under any circumstances, cut or remove
the third (ground) prong from the power cord.
'212786($1(;7(16,21&25'
WARNING: SHOCK HAZARD
FOR PERSONAL SAFETY, THIS APPLIANCE MUST BE
PROPERLY GROUNDED.
Remove house fuse or open circuit breaker before
beginning installation.
Do not use an extension cord or adapter plug with
this appliance. Follow National Electrical Code or
prevailing local codes and ordinances.
This downdraft vent must be supplied with 120V,
60 Hz. and connected to an individual, properly
JURXQGHGEUDQFKFLUFXLWSURWHFWHGE\DRU
DPSHUHFLUFXLWEUHDNHURUWLPHGHOD\IXVH
$SURSHUO\JURXQGHGSURQJUHFHSWDFOHVKRXOGEH
ORFDWHGZLWKLQUHDFKRIWKHYHQW·VWZRIRRWSRZHU
cord.
• Gas Cooktops
If this vent is installed in combination with a GE or
Monogram gas cooktop, it may operate from the
same duplex outlet.
• Electric Cooktops
If this vent is installed in combination with a GE
or Monogram electric cooktop, the vent must
operate from a separate 120V outlet.
Locate the receptacle inside the cabinet on the right
VLGHZDOOVHHLOOXVWUDWLRQ7KHUHFHSWDFOHFDQQRWEH
placed on the back of the cabinet wall where it may
interfere with the downdraft plenum.
The downdraft vent power cord is to be routed
beneath the cooktop and routed away from heat
generated by the cooktop.
Ensure that the cooktop is installed per
manufacturer’s installation instructions.
POWER SUPPLY Locate the Gas or Electrical
Connection Only Within the
Shaded Area
DO NOT Locate
Gas or Electrical
Connections within
this Area
34" for 36" Models
IRU0RGHOV

12" Electrical
Outlet 12"
Above
Cabinet
Floor

9
Installation Preparation
VENTING OPTIONS
• The downdraft vent is shipped with the
discharge outlet pointing straight down
and can be changed to the left or right
side.
7KHEORZHURXWOHWLVVL]HGIRU[
and can be transitioned to 6" round.
2UGHU-;5%IRULQVWDOODWLRQRIWKH
EORZHUDQGPRWRUEHORZWKHÀRRU
Side-to-Side Adjustments:
The entire blower mounting plate can be
DGMXVWHGWRWKHOHIWRUULJKW7KLV
will help to align vent discharge to house
ductwork.
Discharge Direction
The blower assembly may be removed and turned
IRUDOHIWRUULJKWVLGHGLVFKDUJH
• A left or right 90° direction adjustment should be
performed before dropping into the countertop
opening.
• Flatten the shipping box to use as a pad.
• Lay the vent on its back and onto the pad.
To change to a left or right discharge:
• Remove the 4 screws holding the blower and the
mounting plate assembly to the downdraft vent.
Retain screws.
• Remove blower assembly; turn it over to access the
4 nuts holding the blower to the mounting plate.
Remove the nuts.
Discharge Down
$V6XSSOLHG
Loosen Screws
to Adjust
WR
Left or Right
IMPORTANT: Do not lift motor by the power cable.
• Turn the blower to the left or right discharge
direction and reinstall the 4 nuts.
• Reinstall blower and mounting plate with original
screws.

 

 
Discharge Down
$V6XSSOLHG
Discharge Left Discharge Right

10
Installation Preparation
DUCT
FITTINGS
8VH[
duct. It can
transition to 6"
round.
Total
Equivalent Quantity Equivalent
Duct Piece Dimensions Length* Used Length
1 ft.
  URXQG SHUIRRW
  VWUDLJKW OHQJWK
1 ft.
  ø[ SHUIRRW
  VWUDLJKW OHQJWK
6"
90° elbow 12 ft.
6"
45° elbow 7 ft.
  ø[
90° elbow 14 ft.
  ø[
45° elbow 8 ft.
  ø[
  ÀDWHOERZ IW
6" round
  WRø[
transition 2 ft.
  ø[
round to 6"
transition 2 ft.
6" round to
  ø[
transition
90° elbow 4 ft.
  ø[WR
round transition
90° elbow 4 ft.
6" round
wall cap
with damper 24 ft.
  ø[
wall cap
with damper 24 ft.
6" round
roof cap 33 ft.
Total Duct Run
Use this chart to
compute maximum
permissible lengths
for duct runs to
outdoors.
NOTE: Do not exceed
maximum permissible
equivalent lengths!
$FWXDOOHQJWKRIVWUDLJKWGXFWSOXVGXFW¿WWLQJ
equivalent. Equivalent length of duct pieces is based
on actual tests conducted by GE Evaluation Engineering
DQGUHÀHFWUHTXLUHPHQWVIRUJRRGYHQWLQJSHUIRUPDQFH
with any downdraft cooktop.
Downdraft Vent: 100' maximum
equivalent length
Flexible ducting:
,IÀH[LEOHPHWDOGXFWLQJLVXVHGDOOWKH
equivalent feet values in the table should
EHGRXEOHG7KHÀH[LEOHPHWDOGXFWVKRXOG
be straight and smooth and extended as
much as possible.
'2127XVHÀH[LEOHSODVWLFGXFWLQJ
NOTE: Any home ventilation system, such
as a cooktop with a downdraft exhaust
PHFKDQLVPPD\LQWHUUXSWWKHSURSHUÀRZ
of combustion air and exhaust required by
¿UHSODFHVJDVIXUQDFHVJDVZDWHUKHDWHUV
and other naturally vented systems. To
minimize the chance of interruption of such
naturally vented systems, follow the heating
equipment manufacturer’s guidelines and
safety standards such as those published
by NFPA and ASHRAE. When applicable,
LQVWDOODQ\PDNHXSUHSODFHPHQWDLUV\VWHP
in accordance with local building code
requirements. Visit GEAppliances.com for
available makeup air solutions.

11
1 INSTALL DOWNDRAFT VENT
ATwo stabilizing brackets must be installed on
each side of the downdraft vent.
• For right-side or straight-down blower
discharge, fasten the stabilizing brackets at
locations A, B, D and E.
• For left-side blower discharge, fasten the
stabilizing brackets at locations B, C, D and E.
BPlace the downdraft vent into the countertop
FXWRXWVRWKDWWKHEDFNÀDQJHRIWKHYHQWLV
sitting on top of the countertop.
Note: The downdraft vent may need to be
WXUQHGDWDQDQJOHWR¿WLQWRWKHFRXQWHUWRS
cutout.
CSecure the screws for the stabilizing brackets to
the cabinet back and side walls.
DCheck that the downdraft vent is vertically level.
Operate the vent 3 to 5 times to ensure proper
installation.
Installation Instructions
2 INSTALL DUCTWORK
• The downdraft blower system is designed for use
ZLWK[GXFWZRUN,WFDQEHWUDQVLWLRQHGWR
6" round.
'XFWZRUN0867EHYHQWHGWRWKHRXWVLGH³QHYHU
in a crawl space, attic or other enclosed space.
• 6" PVC duct should be used when installing under a
concrete slab.
NOTE: Local building code must be followed for
installation in specifying approved type and schedule
of PVC duct used.
'212786(ÀH[LEOHSODVWLFGXFWLQJ
• Always use appropriate roof or wall cap with damper.
/DXQGU\W\SHZDOOFDSVVKRXOGQHYHU
be used.
• Use the straightest duct run possible.
• For satisfactory performance, the duct run should
not exceed 100 ft. or its equivalent length when
EHQGVRUYDULRXV¿WWLQJVDUHXVHG5HIHUWRWKHWDEOH
of equivalent lengths to calculate your installation.
• Install ductwork so the piece of duct nearest the
downdraft unit slots INTO the next piece of the duct.
6HFXUHWKHMRLQWVZLWKVHOIWDSSLQJVFUHZVDQGDSSO\
duct tape around the joints to ensure an airtight seal.
Duct Tape
Over Seam and Screw
Screw
Air
Flow
Bracket
Cabinet Back
Wall
Downdraft Vent
Location A
TOP VIEW
A
C
EPlace Cooktop into the countertop cutout. There
should be a 1/8” minimum gap between the
front of the vent trim and the rear of the cooktop.
It may be necessary to readjust the cooktop and
repeat steps C and D.
A
D
CB
E
4 to 5” 4 to 5”
Top
Brackets
Bottom
Brackets
Level
Level

12
Installation Instructions
3 INSTALL REMOTE SWITCH
Connect Wire Lead to Control Box
• Connect the mating wire ends.
3ODFHWKHDGKHVLYHZLUHFODPSVSURYLGHGQHDU
the mating connector.
.HHSDSSUR[LPDWHO\ORQJZLUHDQGDWWDFK
the wire to the clamp with a wire tie. This will act
as a strain relief.
 'ULOODGLDKROHLQWRWKHGHVLUHGORFDWLRQ8VH
the mounting bracket as a template to locate the
hole accurately. Check for interference between
WKHVZLWFKFRYHUDGMDFHQWREMHFWVDQGFRRNWRS
vent overlaps.
• If switch is mounted into a tile surface, drill the
hole between tiles. Use locally approved caulking
to cover any gaps.
• If the remote switch is not installed on the coun
tertop, ensure that it is installed in a location that
meets local codes and is easily accessible.
Connect Remote Switch to Remote Harness
7KUHDGWKHUHPRWHKDUQHVVWKURXJKWKHGLD
hole and attach the harness connector to the
remote connector.
• Remove the paper backing on the remote switch
foam piece and mount the remote switch on the
countertop such that the switch connectors stay
ORFDWHGLQWKHGLDKROH
6WLFNDGKHVLYHZLUHFODPSQHDUWKHGLDKROH
and attach the loose wire with a wire tie.
WARNING: SHOCK HAZARD
Disconnect electrical power from unit before
beginning switch installation. Failure to do so could
result in personal injury or damage to the electrical
controls.
WARNING: BURN HAZARD
The remote switch must be located so that it can be
operated without reaching over the cooktop. Failure
to do so may result in ignition of clothing which could
cause serious injury or death.
Determine the location for the remote switch.
• The remote switch should be located so that the
YHUWLFDOGLVWDQFHIURPWKHÀRRUWRWKHUHPRWH
switch is less than 48" and more than 15".
• The remote switch harness is 68" long and should
be installed so that it is not pinched and is away
from moving parts.
Control
Box
'LD+ROH
'LD
Hole
Foam Piece With
Adhesive Mounting
Surface
Foam Piece With Adhesive
Mounting Surface
Remote Switch
Remote
Switch
Strain Relief
$GKHVLYHZLUHFODPS
ZLWKWLH
Remote
Harness
Remote Harness
Mating Connectors
Strain Relief
$GKHVLYHZLUH
FODPSZLWKWLH

13
Installation Instructions
4 CONNECT POWER
Plug power cord into properly grounded receptacle.
5 INSTALL FILTERS, CHECK OPERATION
3UHVVWKH212))SDGRQWKHFRQWURO
to raise the vent.
6OLS¿QJHUVLQWRWKHYHQWKROHV/LIWWKHYHQW
straight up and pull forward.
6OLGH¿OWHULQWRWKHUHWDLQHUVDQGFORVHWKHYHQW
• Press the Fan Speed HIGHER pad to start the
blower. Adjust the blower by pressing HIGHER or
LOWER.
• 7RORZHUWKHYHQWSUHVVWKH212))SDG
NOTE: It is not necessary to turn the fan OFF
before lowering the vent. The fan will automatically
turn off when the vent is lowered. When the fan
is not turned off before lowering the vent, it will
automatically come on at the previously set speed
when the vent is fully raised.
IMPORTANT: The vent can be activated by pressing
the pads on the switch. Do not use excessive force
or sharp objects to activate the switch. Damage
could occur and void the warranty.
Filter Tabs
Retainers

14
Notes

15
Notes

16
NOTE: While performing installations described in this book,
safety glasses or goggles should be worn.
NOTE: Product improvement is a continuing endeavor
at General Electric. Therefore, materials, appearance
DQGVSHFL¿FDWLRQVDUHVXEMHFWWRFKDQJHZLWKRXWQRWLFH

*(
