GE GFWN1000 Operating instructions

GEAppliances.com
Safety Instructions .............. 2,3
Operating Instructions
Control Panels ...................... 4, S
Control Settings ..................... 6, 7
Features ........................... 8-10
Loading and Using the Washer .... 10, 11
Cleaning the Washer .............. 12-14
Installation Instructions ...... 15-2o
Preparing to Install Your Washer ...... 1S
Rough-In Dimensions ................. 16
Locution of Your Washer ............. 16
Unpacking Your Washer .............. 17
Drain Requirements .................. 18
Electrical Requirements .............. 18
Water Supply Requirements .......... 18
Installing the Washer .............. 19, 20
Replacement Parts ................... 20
Troubleshooting Tips ......... 21-24
Consumer Support
Warranty ............................ 25
Service Telephone Numbers .......... 26
GFWN 1000
GFWNllO0
WBVH5200
WBVH5300
WCVH6400
WCVH6800
WHDVH680
ENERGYSTAR
As an ENERGYSTAR@partner,
GEhas determined that this
product meets the ENERGYSTAR@
guidelines for energy efficiency.
Write the model and serial
numbers here:
Model #
Serial #
Youcan find them on a label on the
sideof the washer. 49-90392-2 09-ii GE

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
AWARNING! h ,n o mo ,onmonuo,
of fire or explosion, electric shock, or to prevent propertg damage, personal injurg or
loss of life.
The instructions in this manual and all other literature included with this washer are
not meant to cover everg possible condition and situation that mag occur. Good, safe
practices and caution MUSTbe applied when installing, operating and maintaining
ang appliance.
WATER HEATERSAFETY
Undercertain conditions, hydrogen gas may be produced in a water heater that has not been usedfor two
weeks
or more. Hydrogen gas can be explosiveunder these circumstances.
Ifthe hotwater hasnot been usedfor two weeksor more, prevent the possibilityof damage or injury by
turning on all hot water faucets and allowing them to run for several minutes. Dothis before using anyelectrical
appliance which isconnected to the hot water system.Thissimple procedurewill allow any built-up hydrogen
gas to escape.Sincethe gas isflammable, do not smokeor usean open flame or appliance during this process.
PROPERINSTALLATION
Thiswasher must beproperlg installedand located in accordancewith the InstallationInstructions beforeit is used.
• Installor storewhere itwill not be exposed • Properlyground washerto conform with allgoverning
to temperatures belowfreezingor exposed codesand ordinances.Followdetailsin Installation
to the weather,which couldcause permanent Instructions.
damage and invalidatethe warranty.
YOURLAUNDRYAREA
• Keepthe area underneath and around your
appliances free of combustible materials such as
lint, paper, ragsand chemicals.
• Do not leavethe washer door open.An open door
could entice children to hang on the door or crawl
insidethe washer.
• Closesupervisionis necessaryif this appliance is
used by or near children. Do not allow children to
play on,with or insidethis or any other appliance.
2

GEAppliances.com
Usethis
appliance
onlyfor its
intended
purposeas
describedin
this Owner's
Manual.
WHEN USINGTHEWASHER
Never reach into washer while it is moving.
Wait until the machine has completely stopped
before opening the door.
Donot mix chlorine bleach with ammonia
or acids such as vinegar and/or rust remover.
Mixing different chemicals can produce a toxic
gas which may cause death.
Donot wash or dry articles that have been
cleaned in, washed in, soaked in or spotted
with combustible or explosive substances (such
as wax, oil, paint, gasoline, degreasers, dry-
cleaning solvents, kerosene, etc.)which may ignite
or explode. Do not add these substances to the
wash water. Do not use or place these substances
around your washer or dryer during operation.
The laundry process can reduce the flame
retardancy of fabrics. To avoid such a result,
carefully follow the garment manufacturer's
wash and care instructions.
Never attempt to operate this appliance
if it isdamaged, malfunctioning, partially
disassembled, or has missing or broken parts,
including a damaged cord or plug.
Do not slam the washer door closed. Do not try
to force the door open when locked (LOCKED
indicator ON).This could result in damage to
the washer.
The washer is equipped with an electrical
overload protector. The motor will stop
if it becomes overheated. The washer will
automatically restart after a cool-down
period of up to 2 hours, if the washer
has not been manually turned off
during this time.
To minimize the possibility of electric shock,
unplug this appliance from the power supply
or disconnect the washer at the building's
distribution panel by removing the fuse or
switching off the circuit breaker before attempting
any maintenance or cleaning. NOTE:Pressing the
power button does NOT disconnect the appliance
from the power supply.
WHEN NOT IN USE
•Turn off water faucets to relieve pressure on
hoses and valves and to minimize leakage if
a break or rupture should occur. Check the
condition of the fill hoses; GErecommends
changing the hoses every S years.
•Before discarding a washer, or removing it
from service, remove the washer door to prevent
children from hiding inside.
•Do not attempt to repair or replace any part of
this appliance unless specifically recommended
in this Owner's Manual, or in published user-repair
instructions that you understand and have the
skillsto carry out.
•Do not tamper with controls.
READAND FOLLOWTHISSAFETYINFORMATIONCAREFULLY.
SAVE THESE INSTRUCTIONS

About the washer control panel.
Find the illustration that closely matches your model and see the cycle descriptions starting on page 6 for details.
EXTRA
RFNSE
(Onsome
models)
4

GEAppliances.com
J
J
J
_'SlGNA_ (
)

About the washer control panel.
0Po we r
Pressto "wake up" the display. If the display is active, press to put the washer into standby mode.
NOTE:Pressing POWERdoes not disconnect the appliance from the power supply.
0Wash Cycles
The wash cycles are optimized for specific types of wash loads. The chart below will help you match
the wash setting with the loads. The GentleCleanT"lifters lightly tumble the clothes into the water and
detergent solution to clean the load.
WHITES For heavily to lightly soiled white cottons, household linens, work and play clothes.
COLORS/NORMAL For heavy to lightly soiled colorfast cottons, household linens, work and play
clothes.
STAINWASH For heavy soiled colorfast cottons, household linens, work and play clothes.
EASYCARE For wrinkle-free and permanent press items.
(PERMAPRESS)
(some models)
ACTIVEWEAR For active sports, exercise and some casual wear clothes. Fabrics include modern
(some models) technology finishes and fibers such as spandex, stretch and micro-fibers.
DELICATES For lingerie and special-care fabrics with light to normal soil. Provides gentle
(some models) tumbling and soak during wash and rinse.
HANDWASH For items labeled hand-washable with light soils. Provides gentle rocking to mimic
the handwashing action.
WASHABLE For the washing of machine washable wool products, provided that they are
WOOLS washed according to the instructions on the garment label. When selecting this
(some models) cycle, you must use a detergent suitable for washing wool.
MYCYCLE Pressto use, create or modify custom wash cycles.
(some models)
SPEEDWASH For lightly soiled items that are needed in a hurry. Cycle time is approximately
:30minutes, depending on selected options.
DRAIN & SPIN Drain and spin at any time.
RINSE& SPIN To quickly rinse out any items at any time.
(some models)
6

@GEAppliances.com
Soil Level
Changing the SOILLEVELincreGses or decreases the wGsh time to remove different amounts of soil.
To chGnge the SOILLEVEL,press the SOILLEVELbutton until you hGvereGched the desired setting.
0Spin Speed
ChGnging the SPINSPEEDchanges the final spin speed of the cycles. AIwGys follow the fGbric
manufacturer's care label when changing the SPINSPEED.
To change the SPINSPEED,press the SPIN SPEEDbutton until you have reGched the desired setting.
Higher spin speeds Grenot avGilable on certGin cycles, such as Delicates.
Higher spin speeds remove more water from the clothes Gnd will help reduce dry time, but mGy Glso
increGse the possibility of setting wrinkles on some fGbrics.
Oash Temp
Adjust to select the proper water temperature for the wash cycle. The prewash and rinse water is
always cold to help reduce energy usage and reduce setting of stains and wrinkles.
Follow the fabric manufacturer's care label when selecting the wash temperature.
To change the wash temperature, press the WASH TENP button until you have reached the desired
setting. The Sanitized wash temperature is not available on certain cycles, such as Delicates.
O
When selecting the Sanitize wash temperature (on some models), the washer increases the water
temperature to sanitize and kill more than 99% of many common bacteria found in home laundry. The
sanitize wash temperature is only available on Stain Wash and Whites wash cycles. For best results,
select
the heavy soil setting when using the Sanitize wash temperature setting.
NOTE:The first 10 seconds of the wash fill is always cold. This feature assists in conditioning the fabric
and preventing stains from setting on garments.
START/PAUSE
Pressto start a wash cycle. If the washer is running, pressing it once will pause the washer and unlock
the door. Press again to restart the wash cycle.
NOTE:If the washer is paused and the cycle isnot restarted within 2 hours, the current wash cycle will
be cancelled.
NOTE:The washer performs automatic system checks after pressing the STARTbutton. Water will flow
in 45 seconds or less.You may hear the door lock and unlock before water flows; this is normal.
7

About the washer features.
NOTE:Features may not be available on all washer models.
0
0
Cycle Signal
Usethe SIGNALbutton to change
the volume ofthe end ofcyclesignal.
Pressthe button until you reach
the desiredvolume.
Prewash (onsomemodels)
Prewash isan extra wash before
the main wash. Use itfor heavily soiled
clothesor for clothes with a care label
that recommends prewashing before
washing. Besureto add high-efficiency
detergent, or the proper wash additive
to the prewash dispenser.
NOTE:When selecting prewash,
it is recommended to use powder
detergent in the main wash (detergent)
compartment.
0
@
®
®
Extra Rinse
Usean extra rinsewhen additional rinsing
isdesiredto remove excessdirt and
detergent from soiled loads.
Delag Start (on some models)
Youcan delaythe startof a wash cycle
for 10-18 hours,depending on the model.
Pressthe DELAYSTARTbutton to choose
the number of hoursyou want to delay
the start of the cycle,then presstheSTART
button.Themachine will count down and
startautomatically at the correcttime.
NOTE:Ifgou forget to fullg dosethe door,
a remindersignal will beepreminding gou
to do so.
NOTE:Ifgou open thedoor when the delog
iscounting down, the machine will enter
thepausestate. Youmust closethedoor
and pressSTARTagain in order to restart
thecountdown.
Lock
You can lock the controls to prevent any
selectionsfrom being made. Oryou can
lock the controls after you have started
a cycle.
Children cannot accidentally start
the washer by touching pads with
this option selected.
Tolock the washer, pressand hold
the DELAVSTARTbutton for 3 seconds
(onsome models useSIGNALbutton).
Tounlock the washer controls, press
and hold the DELAVSTARTbutton for
3 seconds.
Thecontrol lock icon on the display will
light up when it ison.
NOTE:ThePOWERbutton can still be
used when the machine is locked.
HY CYCLE (onsome models)
Tosavea favoritecycle,setthe desired
settingsforwash cycle,soillevel,spinspeed
andwash temp settingsand hold downthe
MYCYCLEbuttonfor 3 seconds.A beepwill
soundto indicatethe cyclehasbeensaved.
To use your custom cycle, press the
MY CYCLE button before washing a load.
Tochange the saved cycle, set the desired
settings and hold down the MYCYCLE
button for 3 seconds.
NOTE:When using MY CYCLE,wash
options cannot be modified after the
cgcle has been started.
NOTE:If gou change wash options with
MYCYCLEbefore starting the cgcle,the
MYCYCLElight will turn off and gou will
be returned to the base cgcle.
@
8
BASKET CLEAN
BasketClean isa cyclethat freshens
up the insideofyour washer. Thecycle
usesbleach or other available washing
machine cleaners and more water to
refreshyour washer. UseBasketClean
once every month to reduce odor and
residuebuildup insidethe washer.
Formore information on BasketClean,
referto the Careand Cleaningsection
on page 12.

GEAppliances.com
The Dispenser Drawer
Slowlyopen the dispenser drawer by pulling
itout untilitstops.
After adding laundryproducts,slowlyclose
the dispenserdrawer.Closingthe drawertoo
quicklycould resultin earlydispensingof the
bleach,fabric softeneror detergent.
Youmay seewater inthe bleachand fabric
softenercompartmentsat the end of thecycle.
Thisisa resultof the flushing/siphoningaction
and is part ofthe normaloperationof the
washer.
The Prewash Compartment (onsomemodels)
• Onlyusethe PrewashCompartmentifyou
areselectingthe Prewashcyclefor heavily
soiledclothes.Add measureddetergent or
prewashadditiveto the back left prewash
compartmentof thedispenserdrawer.
• Detergentor prewashadditive isflushed
from the dispenserinthe prewashcycle
(ifselected).
NOTE:Liquiddetergentwill drain into the
washerdrum asit isadded.
• Detergentusagemay needto beadjustedfor
water temperature,water hardness,sizeand
soillevelof the load.Avoidusingtoo much
detergent inyour washer asit canlead to
oversudsingand detergent residuebeingleft
on the clothes.
iiii! il!¸i iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiilililili i!
iiiiiil)ili!ii!_iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii!ii!!!!i_!_i
i,! ii!i iii!ii!! iiiii!iiiii i!i'ii'i]
Bet_rg_:
ett
Appearancemayvary
Onsomemodels,theLiquidBleach
The Detergent Compartment
•High-efficiency detergent isrequired for this
washer.Usethe detergent manufacturer's
recommendedamount.
Thedetergentselectioninsertmustbe placedin
the detergent compartmentin a specificposition
accordingto what type of detergentyou are
using.
•Powder Detergent- Placethe insert oooo
inthe rear position.ThePowderIconsoooo....
mustline up on centerwhenthe
insertisin the powderposition.
•Liquid Detergent - Youwill needto adjust
the insert accordingto the type of Liquid
Detergentyou ore using.TheIconson the side
ofthe detergent compartmentmust line upon
the center whenthe insertisin position.
NOTE:Not allmodels have the 2x and 3x
detergent settings. Some have only regular
HEdetergent settings. You must reduce the
amount of detergent for2x or 3x detergent
per bottle instructions.
Hovethe insert by pullingit up and replace
it byslidingit down betweeneitherthe rear
or front detergentcompartment moldedrails,as
desired,for powderor liquid detergent.
• Add measureddetergentto the front left
detergentcompartment ofthe dispenser
drawer.
Detergentisflushedfrom thedispenser
at the beginningofthe wash cycle.Either
powderedor liquiddetergent can beused.
Detergentusagemay needto be adjustedfor
water temperature,water hardness,
sizeand soillevelofthe load.Avoidusingtoo
much detergentin yourwasher asit con lead
to oversudsingand detergent residuebeing
left on the clothes.
• Usingmoredetergentthan the recommended
quantity cancauseresiduebuildup onyour
washer.
Compartmentisinthecenter.
The Liquid Bleach Compartment
IMPORTANT:The bleach compartment
position varies bg model. Be sure to identifg
the correct compartment for bleach before
using.
Ifdesired, measure out the recommended
amount of liquidbleach, not to exceed
:1/3cup (80 ml),and pour into the center
compartment labeled "LIQUIDBLEACH"
marked with this symbol ,/_.
Donot exceedthemaximum fill line.Overfilling
cancauseearltddispensingof thebleachwhich
couldresultin damagedclothes.
NOTE:Donot usepowderedbleachin the
dispenser.
Onsomemodels,theLiquidBleach
Compartmentisontheright. 9

About the washer features.
Onsomemodels,theFabricSoftener
Compartmentisontheright,
The Fabric Softener Compartment
IMPORTANT:Thefabric softener compartment
position varies bUmodel. Besure to identifU
the correctcompartmentfor fabric softener
before using.
If desired,pourthe recommendedamount
of liquidfabric softenerintothe compartment
labeled"FABRICSOFTENER."
Useonly liquid fabricsoftenerin thedispenser.
Dilutewith water to themaximumfill line.
Donot exceedthemaximum fill line.Overfilling
cancauseearltjdispensingof thefabricsoftener
which couldstainclothes.
NOTE:Donotpour fabricsoftenerdirectltj
on the washload.
Onsomemodels,theFabricSoftener
Compartmentisinthecenter.
Loading and using the washer.
Alwags follow fabric manufacturer's care label when laundering.
Sorting Wash Loads
Sort laundry into loads that can be washed together.
Colors Soil Fabric Lint
Whites Heavy Delicotes Lint Producers
Lights Normal Easy Care Lint Collectors
Dorks Light Sturdy Cottons
10
•Combine large and small items in a load. Load large items first. Large items should not be more than
half the total wash load.
• Washing single items is not recommended. This may cause an out-of-balance load. Add one or two
similar items.
• Pillows and comforters should not be mixed with other items. This mag cause an out-of-balance load.
Preparing Clothes
• Toavoid snags during washing.
Follow these steps to maximize garment care.
•Closegarmentzippers,snaps,buttonsand hooks.
• Mendseams,hems,tears.
• Emptgall itemsfrompockets.
°Removenonwashablegarment accessoriessuchasornamentsand nonwashabletrim materials.
• TOavoid tangling, tie strings, draw ties and belt-like materials.
• Brush awag surface dirt and lint; treat spots and stains.
• Promptlg wash wet or stained garments to maximize results.
•Mix garments using recommended maximum load sizes on page 11.
• Use nglon mesh garment bags to wash small items.
• Wash multiple garments at one time for best results.

GEAppliances.com
Loading the Washer
Wash drum may be fully loaded with loosely added
items. Do not wash fabrics containing flammable
materials (waxes, cleaning fluids, etc.).
To add items after washer has started, press
START/PAUSEand wait until the door is unlatched.
Thewasher may take up to 30 seconds to unlock
the door after pressing START/PAUSEdepending
on the machine conditions. Donot try to force open
the door when it is locked. After the door unlocks,
open gently. Add items, close the door and press
START/PAUSEto restart.
Maximum Loading Sizes*
WORKWEAR
4 Jeans
5 Workwear Shirts
5 Workwear Pants
LINENS
2 Bath Sheets
10 Bath Towels/
12 Washcloths
7 Hand Towels/
2 Terrycloth
BathMats
OR
2 Flat Queen-Sized
Sheets
MIXED LOAD
4 Pillowcases
2 Hand Towels
2 Flat Sheets/
2 Fitted Sheets
2 Bath Towels/
4 Washcloths
OR
DELICATES**
7 Bras
7 Panties
2 Fitted
Queen-Sized
Sheets
4 Pillowcases
6 Shirts (Men's
or Women's)
4 Pair Pants
(Khakis
or Twills)
5 T-Shirts
7 Pairs of Boxers
4 Pairs of Shorts
OR
6 T-Shirts
4 Pairs of
Sweatpants
4 Sweatshirts
2 Hoodies
7 Pairs of Socks
3 Slips
2 Camisoles
4 Nightgowns
SPEEDWASH
(2-4 GARMENTS)
2 Casual Wear
Work Shirts
1 Pair Casual Wear
Work Pants
OR
3Soccer Uniforms
*Exceeding maximum recommended load sizes may affect cleaning performance and garment care.
**Using a nylon mesh bag for small items is recommended.
ll

Cleaning the washer.
Care and Cleaning
Exterion Immediately wipe off any spills. Wipe with damp cloth. Do not hit surface with sharp objects.
Moving and Storage: Ask the service technician to remove water from drain pump and hoses.
Do not store the washer where it will be exposed to the weather. When moving the washer,
the tub should be kept stationary by using the shipping bolts removed during installation.
See Installation Instructions in this book. Ifthese parts are not available, they can be ordered
by visiting our Website at GEAppliances.com or by calling 800.GE.CARES.
Long Vacations: Be sure the water supply is shut off at the faucets. Drain all water from the hoses ifthe
weather will be below freezing.
Cleaning the Interior
of the Washer
To clean the interior of the washer, select
the BasketClean feature on the control
panel. The cycle will use more water,
in addition to bleach, to refresh your
washer.
NOTE:Readthe instructions below
completely before starting the
BasketClean cycle.
1. Remove any garments or objects from
the washer and ensure the washer
basket is empty.
2. Open the washer door and pour
one cup or 250 ml of liquid bleach
or other washing machine cleaner
into the basket.
3o Close the door and select the
BasketClean cycle. Push the START
button.
4. When the BasketClean cycle is
working, you will see CLn on the
display. The cycle will complete in
about 90 minutes. Do not interrupt
the cycle.
5. After the cycle is complete, leave
the door open slightly for better
ventilation.
If for any reason the cycle needs to
be interrupted, the door will not open
immediately. Forcing open the door at
this stage may cause water to flood.
The door will open after the water is
drained to a level where it would not
flood the floor.
BasketClean may be interrupted
by pressing the START/PAUSE button
in between cycles. A power outage in
the house might also interrupt the cycle.
When the power supply is back, the
BusketCleun cycle resumes where it had
stopped. When interrupted, be sure to
run a complete BusketCleun cycle before
using the washer. Ifthe POWER button
is pressed during BusketCleun, the cycle
will be lost.
IMPORTANT:
•Run BasketClean with J_Cup
(250 ml) of bleach once a month.
•After the completion of a BusketCleun
cycle, the interior of your washer may
have a bleach smell.
• It is recommended to run a light color
load after the BasketClean cycle.
12

Pour
spout
Cleaning the Pump Filter
Due to the nature of the front-load washer
it issometimes possible for small articles
to pass to the pump. The washer has a
filter to capture lost items so they are not
dumped to the drain. To retrieve lost items,
clean out the pump filter.
1. Using a coin or flat screwdriver
in the notch on the door, open
the access door.
2. Place a shallow pan or dish under
the pump access door and towels
on the floor in front of the washer to
GEAppliances.com
protect the floor. It is normal to catch
about a cup of water when the filter
is removed.
3. Pull down the pour spout.
5°
6.
Turn the pump filter counterclockwise
and remove the filter. Open slowly to
allow the water to drain.
Clean the debris from the filter.
Replace the filter and turn clockwise.
Tighten securely.
Z. Flip up the pour spout.
8. Close the access door.
L ..........
[[[[[[[[[[[i)iiii /iiiiiiiiiiiii
!!!!!!!!!!!!!!
iiiiiiiiiiiiii
iiiiiiiiiiiiii
jJiiiiiiiiiiiiii
i iiiiiiiiiiiiii
i[i!iii!i!_iiiiiiiiiiiiii_!!iill
!!!!!!!!!!!!!
Cleaning the Door Gasket
Open the washer door. Using both hands,
press down the door gasket. Remove any
foreign objects if found trapped inside
the gasket. Make sure there is nothing
blocking the holes behind the gasket.
While holding down the door gasket,
inspect the interior gasket by pulling it
down with your fingers. Remove any
foreign objects if found trapped inside
this gasket. Make sure there is nothing
blocking the holes behind the gasket.
When you are finished cleaning
the door gasket, remove your
hands and the gasket will return
to the operating position.
13

Cleaning the washer.
Locktab isvisible onlyafter drawer
hasbeenpulled out
Dispenser Drawer Area: Detergent and fabric softener may build up
in the dispenser drawer. Residue should be removed once or twice a month.
• Remove the drawer by first pulling it out until it stops. Then reach back into
the left rear corner of the drawer cavity and press down firmly on the lock
tab, pulling out the drawer.
• Remove the inserts from the bleach and fabric softener compartments and
the detergent insert. Rinsethe inserts and the drawer with hot water to
remove traces of accumulated laundry products.
• To clean the drawer opening, use a small brush to clean the recess. Remove
all residue from the upper and lower parts of the recess.
• Return inserts to the proper compartments. Replace the dispenser drawer.
14

Installation
Instructions Washer
IIf you have any questions, call 800.GE.CARES(800.432.2737)or visit ourWebsiteat:6EAppliances.com I
BEFORE YOU BEGIN
Read these instructions completelg and carefullg.
• IMPORTANT - Savetheseinstructions
for Iocol inspector's use.
• IMPORTANT - Observeallgoverning
codes and ordinances.
• Note to Instoller - Be sure to leave these
instructions with the Consumer.
• Note to Consumer - Keepthese instructions
for future reference.
• Skill level - Installation of this appliance requires
basic mechanical and electrical skills.
• Completion time - 1-3 hours
• Proper installation isthe responsibility of the installer.
• Product failure due to improper installation is not
covered under the Warranty.
FOR YOUR SAFETY:
AWARNING
• This appliance must be properly grounded and
installed as described in these Installation Instructions.
• Do not install or store the appliance in an area where
it will be exposed to water/weather. See the Location
of Your Washer section.
NOTE:This appliance must be properlg
grounded, and electrical service to the washer
must conform with local codes and ordinances
and the latest edition of the National Electrical
Code, ANSI/NFPA 70.
TOOLS REQUIRED FOR
WASHER INSTALLATION
[] 1/4" nut driver
[] 3/8" socket with ratchet
[] 3/8" open-end wrench
[] Adjustable wrench or 7/16" socket with ratchet
[] Adjustable wrench or 9/16" open-end wrench
[] Channel-lock adjustable pliers
[] Carpenter's level
PARTS SUPPLIED
[] CableTie
[] Water Hoses(2)
[] HoseGuide
STACK BRACKET KIT
A stack bracket kit isavailable at additional cost.
It can be ordered in the United States by visiting
our website at GEAppliances.com or calling 800.
GE.CARES.Order kit #WE25X10018 or GEFLSTACK.
15

Installation Instructions
LOCATION OF YOUR WASHER
Do Not Install the Washer:
1.In an area exposed to dripping water or outside
weather conditions. The ambient temperature should
never be below 60°F (15.6°0 for proper washer
operation.
2.In an area where it will come in contact with curtains
or drapes.
3.On carpet. The floor MUST be a hard surface with
a maximum slope of 1/2" per foot (1.27cm per
30 cm). To make sure the washer does not vibrate
or move, you may have to reinforce the floor.
NOTE:If floor is in poor condition, use 3/4" impregnated
plywood sheet solidly attached to the existing floor
covering.
IMPORTANT:
Minimum Installation Clearances
• When installed in alcove: Sides, Rear,
Top = 0" (0 cm)
• When installed in closet: Sides, Rear,
Top = 0" (0 cm), Front = r' (2.54 cm)
• Closet door ventilation openings required:
2 louvers each 60 square in. (387 cm), located 3"
(7.6cm) from top and bottom of door
ROUGH-IN DIMENSIONS
FRONT
27.0" 2.2"
(68.6cm) _- (5.6cm)
I_ 20.4"(51.9cm) _ I
I- ELECTRONICTRANSPARENTVISORr I
o iooo t
SIDE
1.6"
30.6" (3.9 cm)
(77.7cm)
(9_!2m)
*NOTE:With pedestal,52.6"
Stacked,84"
16

Installation Instructions
UNPACKING THE WASHER
;k WARNING: Recycleordestroythecarton
and plastic bags after the washer is unpacked. Make
materials inaccessibleto children. Children might use
them for play. Cartonscovered with rugs, bedspreads
or plastic sheetscan become airtight chambers causing
suffocation.
1. Cut and remove the top and bottom packaging straps.
2. While it isin the carton, carefully lay the washer on its
side. DONOTlay the washer on its front or back.
3. Turndown the bottom flaps-remove all base packaging,
including the cardboard, styrofoam base and styrofoam
tub support (insertedin center of base).
NOTE:If gou are installing a pedestal, proceed to
the installation instructions that come with the pedestal.
4. Carefullyreturn the washer to an upright position and
remove the carton.
5. Carefullymove the washer to within 4 feet (122cm)
of the final location.
6. Removethe following from the back sideof the washer:
4 bolts
4 plasticspacers (includingrubber grommets)
4 power cord retainers
//
/
NOTE:Failureto remove the shipping braces can cause
the washer to become severelyunbalanced.
Saveall bolts for future use.
NOTE:If you must transport the washer at a later date,
you must reinstall the shipping support hardware to prevent
shipping damage. Keepthe hardware in the plastic bag
provided.
In case gou misplacegour shipping bolts, replacements
are available at additional cost.Thegcan beordered in the
United States bg visiting our website at GEAppliances.com
or calling 800.GE.CARES.Order kit #WH49×10039.
17

Installation Instructions
ELECTRICAL REQUIREMENTS
Read these instructions completely
and carefully.
A WARNING: ToREDUCETHERISKOF
FIRE,ELECTRICALSHOCKAND PERSONALINJURY:
• DONOTUSEAN EXTENSIONCORDORAN ADAPTER
PLUGWITHTHISAPPLIANCE.
Washer must be electricallg grounded in accordance
with local codes and ordinances, or in the absence
of local codes, in accordance with the NATIONAL
ELECTRICALCODE,ANSI/NFPANO. 70.
CIRCUIT- Individual,properly polarizedand grounded
Z5-amp branch circuit fused with Z5-amp time-delay fuse
or circuit breaker.
POWERSUPPLY- 2-wire, with ground, 120-volt,
single-phase, 60-Hz,alternating current.
OUTLETRECEPTACLE-Properly _
grounded 3-prong receptacle to be
located so the power supply cord
isaccessiblewhen the washer is
in an installed position.
GROUNDING REQUIREMENTS
WARNING: ,mproperconnectionofthe
equipment grounding conductor can result in a risk
of electricalshock.Checkwith a licensedelectrician
ifyou are in doubt as to whether the appliance is
properlygrounded.
1. The washer MUST be grounded. In the event of
malfunction or breakdown, grounding will reduce
the risk of electrical shock by providing a path of least
resistance for electrical current.
2. Sinceyour washer isequipped with a power supply
cord having an equipment-grounding conductor and
a grounding plug,the plug MUSTbe plugged into an
appropriate, copper-wired receptacle that is properly
installedand grounded in accordance with all local
codes and ordinances or in the absence of localcodes,
with the National ElectricalCodes,ANSI/NFPA70 (latest
edition).If in doubt, call a licensedelectrician.DONOT
cut off or alter the grounding prong on the power
supply cord. Insituations where a two-slot receptacle is
present,it isthe owner's responsibilityto have a licensed
electrician replace itwith a properly grounded
three-prong grounding-type receptacle.
WATER SUPPLY REQUIREMENTS
Hot and cold water faucets MUSTbe installed within
42 inches (107 cm) ofyour washer's water inlet. Thefaucets
MUSTbe 3/4" (1.9cm) garden hose-type so inlet hoses can
be connected. Water pressure MUSTbe between 10 and 120
pounds per square inch.Your water department can advise
you of your water pressure.The hot water temperature
should be set to deliverwater at 120° to Z40°F(48°-60°C).
DRAIN REQUIREMENTS
1. Drain capable of eliminating 17 gals(64.3L)
per minute.
2. Astandpipe diameter of 1-1/4" (3.18cm) minimum.
3. Thestandpipe height above the floor should be:
Minimum height: 24" (61 cm)
Maximum height: 96"(244cm)
BACK
f96 in.
(244 cm)
Max.
NOTE:The drain hoseattached to the washer can reach
a 58"(147cm) high standpipe. Fora higher standpipe,
contact an authorized parts distributor.
18

Installation Instructions
INSTALLING THE WASHER
1. Runsome water from the hot and cold faucets to flush
the water linesand remove particles that might clog up
the inlethose and water valve screens.
2. Removethe inlet hosesfrom the plastic bag.
3. (90°elbow end) Ensurethere
isa rubber washer in the -.................. _
90° elbow end of the HOT
and COLDhoses.Reinstall
the rubber washer into the
hosefitting if it hasfallen out
during shipment. Carefully
connect the inlet hose
marked HOTto the outside (_ _
"H" outlet of the water valve.
Tighten by hand, then tighten another 2/3 turn with pliers.
Carefullyconnect the other inlet hoseto the inside"C"
outlet of the water valve.Tighten by hand; then tighten
another 2/3 turn with pliers.Do not crossthreed or over-
tighten these connections.
4. If the inlet hosescreen washers (ifsuppliedwith your
model)have fallen out during shipment, reinstallthe
screen washers by inserting them into the free endsof
the HOTand COLDinlet hoseswith protruded sidefacing
the faucet.
JWashers
5. Connectthe inlet hoseends to the HOTand COLDwater
faucets tightly by hand,then tighten another 2/3 turn
with pliers.Turnthe water on and check for leaks.
.Carefully move the washer to its final location.Gently rock
the washer into position. It isimportant not to damage
the rubber levelinglegswhen moving your washer
to its final location. Damaged legscan increase washer
vibration. It may be helpfulto spray window cleaner on
the floor to help move your washer into its final position.
NOTE:To reduce vibration, ensurethat all four rubber
levelinglegsare firmly touching the floor. Pushand
pull on the back right and then back left ofyour washer.
NOTE:Do not usethe dispenser drawer or door to lift
the washer.
NOTE:If you are installing into a drain pan,you can use
a 24-inch long 2x4 to lever the washer into place.
7. With the washer in its final position, place a level
on top of the washer
(if the washer is installed
under a counter,
the washer should not
be able to rock). Adjust
the front leveling legs
up or down to ensure
the washer is resting
solid. Turn the lock nuts
on each leg up towards
.................z /
the base of the washer and snug with a wrench.
NOTE:Keepthe leg extension at a minimum to prevent
excessivevibration. Thefarther out the legsare extended,
the more the washer will vibrate.
Ifthe floor isnot levelor isdamaged, you may have
to extend the rear levelinglegs.
19

Installation Instructions
INSTALLING THE WASHER Icont.}
8. Attach the U-shaped hose guide to the end of
the drain hose. Place the hose in a laundry tub or
standpipe and secure it with the cable tie provided in
the enclosure package.
NOTE:Placingthe drain hosetoo far down the drain pipe
can cause a siphoning action. Nomore than 7 inches of
hoseshould be in the drain pipe.There must be an air
gap around the drain hose.Asnug fit can alsocause a
siphoning action.
CableTie7
q
CableTie-''_ _
1
CableTie
.Plug the power cord into a grounded outlet.
NOTE:Check to be sure the power isoff at the circuit
breaker/fuse box before plugging the power cord into
an outlet.
10. Turn on the power at the circuit breaker/fuse box.
11. Readthe rest of this Owner's Manual. It contains
valuable and helpful information that will save you
time and money.
12. Before sterting the washer, check to make sure:
[] Main power isturned on.
[] Thewasher isplugged in.
[] Thewater faucets are turned on.
[] Theunit is leveland allfour leveling legsare firmly
on the floor.
[] Theshipping support hardware isremoved
and saved.
[] Thedrain hoseis properly tied up.
[] Thereare no leaks at the faucet, drain line
or washer.
13. Runthe washer through a complete cycle.
Check for water leaks and proper operation.
14. Ifyour washer does not operate, please review
the BeforeYouCoilForServicesection before
calling for service.
15. Placethese instructions in a location near the washer
for future reference.
REPLACEMENT PARTS
If replacement parts are needed for your washer,they
con be ordered in the United States by visiting our
Website at GEAppliances.com or by calling 800.GE.CARES.
20
