GE
Lighting
Light Bar Retrot Kit Series
LuminationTM LED Luminaires
Installation Guide
BEFORE YOU BEGIN
Read these instructions completely and carefully.
WARNING AVERTISSEMENT
RISK OF FIRE OR ELECTRIC SHOCK
• Disconnect power before installation or maintenance.
• Luminaire wiring and electrical parts may be damaged when drilling for
installation of LED retrot kit. Check for enclosed wiring and components.
• LED Retrot Kit installation requires knowledge of luminaires electrical
systems. If not qualied, do not attempt installation. Contact a qualied
electrician.
• Install this kit only in luminaires that have the construction features and
dimensions shown in the photographs and/or drawings and where the
input rating of the retrot kit does not exceed the input rating of the
luminaire.
• Only those open holes indicated in the photographs and/or drawings
may be made or altered as a result of kit installation. Do not leave any
other open holes in an enclosure of wiring or electrical components.
• To prevent wiring damage or abrasion, do not expose wiring to edges of
sheet metal or other sharp objects.
RISQUE D’INCENDIE OU D’ELECTROCUTION
• Débrancher l’alimentation avant l’installation ou la maintenance.
• Le câblage du luminaire ainsi que ses composantes électriques peuvent
être endommagés lors du perçage requis pour l’installation de l’ensemble
de mise à niveau à DEL. Vériez le câblage et les composants.
• L’installation de l’ensemble de mise à niveau à DEL requiert des
connaissances en système électrique d’éclairage. Si vous n’avez pas les
qualications adéquates, ne procédez pas à l’installation et contactez un
électricien qualié.
• N’installez cet ensemble de mise à niveau à DEL que sur des luminaires
ayant une construction et des dimensions indiquées sur les photos et
dessins et ce, seulement dans la mesure où les spécications d’entrées
de l’ensemble de mise à niveau à DEL n’excède pas les spécications
d’entrée du Luminaires dans lequel il sera installé.
• Seules les ouvertures indiquées sur les photos et dessins peuvent être
faites ou modiées lors de l’installation de l’ensemble de mise à niveau à
DEL. Ne laissez aucune ouverture dans le boitier ou le compartiment où
se trouvent les composants électriques.
• An de prévenir tout dommage ou abrasion aux ls électriques, évitez
que ceux-ci ne viennent en contact avec les bordures métalliques ou
d’autres ojets pointus.
CAUTION! ATTENTION!
• The Light Bar may fall down if not installed properly, follow installation
instructions.
• Wear safety glasses and proper aid during installation and maintenance.
• Les barres lumineuses peuvent tomber s’il ne sont pas installés
correctement. Suivre les instructions d’installations.
• Portez des lunettes protectrices ainsi que tout autre protection
nécessaire durant l’installation et la maintenance.
Tools Required
• Screwdriver Philips #2
• Portable drill with Philips #2 bit
• Wire cutter
Save These Instructions
These instructions do not purport to cover all details or variations in components nor to provide for every possible contingency to be met in
connection with installation, operation or maintenance. Should further information be desired or should particular problem arise which are
not covered sufciently for the purchaser’s purpose, the matter should be referred to General Electric Company. GE Lighting does not claim
liability for any installation not performed according to this guide or not by a qualied electrician.
• Installation to be performed by factory trained or qualied personnel.
Ensure this manual is provided to the installers and users.
• Use this product only in the manner intended by the manufacturer. If there
are any questions or concerns, contact the manufacturer.
For Your Safety
Read and observe all CAUTIONS and WARNINGS shown throughout
these instructions.
imagination at work

Table 1: Light Bar Retrot Kit Contents
Item Quantity
Lens assembly 1
Light engines assembly 1
Retrot kit accessory bag 1
Mounting brackets 2 or 3
Drill point screws 5
T8/T5 socket hole cover 4 or 8
T8 HO socket hole covers 0, 4 or 8
5/16” white plastic bushing 1
White wire 18 AWG 1.5” / 4cm 3
White wire 18 AWG 23.6” / 60cm** 0 or 1
Black wire 18 AWG 23.6” / 60cm** 0 or 1
Green-yellow wire 18 AWG 23.6” / 60cm** 0 or 1
Red wire 18 AWG 23.6” / 60cm** 0 or 1
Blue wire 18 AWG 23.6” / 60cm** 0 or 1
Violet wire 18 AWG 11.8” / 30cm** 0 or 1
Gray wire 18 AWG 11.8” / 30cm** 0 or 1
**Depending on conguration. See Table 2.
Note: See Table 2 for Light Bar Retrot Kit components required and required xture dimensions.
Note: The assembly of the light engine(s) + lens is called a “light bar”.
Recessed Fixture Retrotting
Surface Mounted Fixture Retrotting
Before
Before
After
After
The pictures below show some typical xtures before and after installation of the Light Bar Retrot Kit for recessed and
surface mounted applications.

Retrot Kit Model LB96-UNV-840-A-P (8ft) LB48-UNV-840-A-P (4ft)
Light Bar Model/Qty
LB Interconnection Wires Needed
2x
LB-LE-40K-4FT-A (4ft)
2x
Interconnect wires
1x
LB-LE-40K-4FT-A (4ft)
Nominal Input Power 82W 41W
Driver 1x driver prog. at 2A output
(Wiring Diagram A)
1x driver prog. at 1A output
(Wiring Diagram B)
Retrot Kit Accessories LBACCP8 LBACCG
LBACCG8
Lens LENS-RFITA-8 LENS-RFITA-4
Min Fixture Length 96”
(2438mm)
48”
(1219mm)
Min Fixture Mounting Flat width &
Min Fixture Driver Compartment Size
Min. at width:
2-1/2” (64mm)
Minimum driver compartment size:
4” x 1-13/16”x 47”
(101 x 46 x 1194mm)
Min. at width:
2-1/2” (64mm)
Minimum driver compartment size:
2-3/4” x 1-13/16” x 48”
(70 x 46 x 1219mm)
Mounting Brackets Qty and
Mounting
2x from light bar edges:
3” (76mm)
1x in center: 48” (1219mm)
2x from light bar edges:
3” (76mm)
Table 2: Required Driver Accessory Kit and Dimensions for Fixture Installation
The table below lists:
• Light Bar Retrot Kit nominal input power.
• Light engine model/length required and number of light engine interconnection wires required (provided).
• Required driver needed vs. light bar retrot kit type.
• Required lens assembly.
• Fixture dimensions (minimum at mounting surface width and minimum driver compartment dimensions).
• Number of mounting brackets and installation notes.
Fixtures need to be within the below specications and measured before installation.
Retrot Kit can be installed in recessed or surface mounted uorescent xtures.

Turn of power.
Remove the existing uorescent tube sockets
and wiring.
Mount the Retrot Kit LED driver in the location occupied by the original uorescent ballast and using the original
mounting screw. In the case where original ballast mounting holes are not used to mount the LED driver, leave the
ballast mounting screws in their original holes in the enclosure.
Open the ballast compartment cover. Remove
the existing ballast and save the ballast
mounting screw(s).
Install uorescent tube socket covers provided
(two models are included in accessories bag).
1
3
5
2
4
Light Bar Retrot Kit Installation Steps
(48” xture)
AC line
(96” xture)
(not to scale)

Line
Neutral
Ground
GND screw
AC Input
Out (+)
Out (-)
0-10V (+)
0-10V (-)
LED Driver
(Class 2)
(-)
(+)
(-)
(+)
Retrot Kit Light Bar
(4ft)
Retrot Kit Light Bar
(4ft)
Dimming
Wires
AC Input
Out (+)
Out (-)
0-10V (+)
0-10V (-)
LED Driver
(Class 2)
Line
Neutral
Ground GND screw
Retrot Kit Light Bar
(4ft)
Dimming
Wires
(-)
(+)
For LB96 Kit provided with one XI075C200V054BPT1 driver only:
• Install the 23.5”/60cm black, white and yellow-green wires provided in accessories kit to the driver input push-in connectors.
• Install the 23.5”/60cm red and blue wires provided in accessories kit to the driver output push-in connectors.
Optional:
• If 0-10V dimming wires are present in the retrotted xture, connect 0-10V dimming wires to the driver dimming
wires or to dimming push-in connectors whichever is present. Connect violet (+) dimming wire to driver violet
dimming wire/push-in connector. Connect gray (-) dimming wire to driver gray dimming wire/push-in connector.
If ferrite bead is present on AC/Dimming wires provided, do not remove. Make connections to the driver on the end
where ferrite is placed.
6A
Wiring Diagram A
8ft Conguration (1 Driver)
4ft congurations:
Connect led driver(s) to AC main using UL listed wire connectors. Refer to Table 2.
6B
Wiring Diagram B
4ft Conguration

Drill one 5/16” hole in the driver compartment’s
cover towards the end closest to the driver and
install the white snap bushing into the hole.
Use drill point screws to install one mounting
bracket on each end of the troffer xture. If a third
mounting bracket is present, install it in the center of
the troffer. Make sure all the mounting brackets’ tab
is in the same orientations.
Care should be taken to install the mounting bracket
in the center (vs. width) of the troffer. The brackets
feature an oval hole to help in the alignment process.
Pass the red and blue driver output wires through
the bushing and replace the driver cover. Make
sure that all components needed for xture’s driver
enclosure cover securing are properly re-installed.
Snap the light engines into the mounting brackets.
If two light engines are included in the kit, the
center mounting bracket serves to hold the two
light engines in the center of the troffer.
7
9
8
10
8ft Fixture Mounting Brackets Installation
4ft Fixtures Mounting Brackets Installation
Install bushing
3” (76mm)
3” (76mm) 3” (76mm)
3” (76mm)
49” (1219mm)
Red and blue
output wires
Snap into mounting brackets
Drill hole
If two light engines are included in the kit and
there is only one driver, install two jumper wires
between the 4ft. light engines.
Connect the red wire to the (+) terminal and
the blue wire to the (-) terminal of the push-in
connector on the end of the light engine.
1211

Install the lens over the light engine(s) and make
sure it snaps in place.
13
Contact qualied electrician for maintenance service.
Order any replacement parts individually with the exact same model number. For any questions or concerns contact the
manufacturer.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This Class
[A] RFLD complies with the Canadian standard ICES-003. Ce DEFR de la classe [ A ] est conforme à la NMB-003 du Canada.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his own expense.
Maintenance/Lamp Replacement
www.gelighting.com
GE and the GE Monogram are trademarks of the General Electric Company. All other trademarks are the property of their respective owners. Information provided is subject to
change without notice. All values are design or typical values when measured under laboratory conditions. GE Lighting is a business of the General Electric Company. © 2016 GE.
IND147 (Rev 03/07/16)
