GE Tetra miniMAX MS Manual

Tetra®miniMAX MS
LED Lighting System
GEMS2471-W1, GEMS2465-W1, GEMS2457-W1, GEMS2450-W1,
GEMS2441-W1, GEMS2432-W1
BEFORE YOU BEGIN
Read these instructions completely and carefully.
RETROFIT SIGN CONVERSION LED KIT FOR USE ONLY IN
ACCORDANCE WITH KIT INSTRUCTIONS.
KIT IS COMPLETE ONLY WHEN ALL PARTS REQUIRED BY
THE INSTRUCTIONS ARE PRESENT.
TROUSSE DE CONVERSION À DEL POUR LA
MODERNISATION DES ENSEIGNES
À UTILISER CONFORMÉMENT AU GUIDE D’INSTALLATION.
Prepare Electrical Wiring
Electrical Requirements
• Acceptable for use in dry, damp and wet locations.
• The grounding and bonding of the LED Driver shall be done in
accordance with National Electric Code (NEC) Article 600.
• Follow all National Electric Codes (NEC) and local codes.
• These products are only suitable for connection to a circuit
from a Class 2 power source.
• These products have not been evaluated for use when connected to a
power source that does not comply with Class 2 voltage and energy
limited supplies.
Save These Instructions
Use only in the manner intended by the manufacturer.
If you have any questions, contact the manufacturer.
24
Volt
EN Instruction Guide
For the latest North American install guides for your product go to: https://products.currentbyge.com/led-signage-lighting
For the latest European install guides for your product go to: https://products.currentbyge.com/eu
FOR UL ONLY
BG Българската версия на инструкциите за инсталаця
и информация за безопасност могат да бъдат
намерени на следния адрес: https://products.
currentbyge.com/eu
CS Návod k montáží a bezpečnostní informace v češtině
najdete zde: https://products.currentbyge.com/eu
DA Den danske version af installationsvejledningen
og sikkerhedsoplysninger kan findes på følgende
placering: https://products.currentbyge.com/eu
DE Die deutsche Version der Installationsanleitung und
Sicherheitsinformationen finden Sie in folgendem
Verzeic: https://products.currentbyge.com/eu
EL Μπορείτε να βρείτε την ελληνική εκδχή των οδηγιών
νγκατάστασης και των πληροφοριών ασφάλειας στην
εξής τοποθεσία: https://products.currentbyge.com/eu
ES La versión española de las instrucciones de instalación
y la información sobre seguridad puede encontrarse
en la siguiente ubicación: https://products.
currentbyge.com/eu
ET Eestikeelse paigaldusjuhendi ja ohutusnñuded leiate
aadressilt: https://products.currentbyge.com/eu
FI Asennusohjeiden ja turvallisuustietojen
suomenkielinen versio löytyy seuraavasta paikasta:
https://products.currentbyge.com/eu
FR La version française des instructions d’installations
et information de sécurité est disponible à l’adresse
suivante: https://products.currentbyge.com/eu
HR Hrvatska verzija priručnika za ugradnju i sigurnosnih
informacija nalazi se na sljedečoj lokaciji: https://
products.currentbyge.com/eu
HU A telepítési útmutató és a biztnosági információk
magyar nyelvű változata az alábbi címen található:
https://products.currentbyge.com/eu
IT La versione italiana del manuale di installazione e
sicurezza può essere reperita nella seguente sezione:
https://products.currentbyge.com/eu
LT Lietuvišką diegimo instrukcijos ir saugos informacijos
versiją galima rasti šioje vietoje: https://products.
currentbyge.com/eu
LV Uzstādīšanas instrukciju un drošības informāciju
latviešu valodā var atrast šeit: https://products.
currentbyge.com/eu
NL De Nederlandse versie van de installatie-instructies
en veiligheidsinformatie kan op de volgende locatie
worden gevonden: https://products.currentbyge.
com/eu
PL Polską wersję instrukcji instalacji oraz informacje
dotyczące bezpieczeństwa można znaleźć w
następującej lokalizacji: https://products.currentbyge.
com/eu
PT A versão em Português das instruções de instalação e
das informações de segurança pode ser encontrada
na seguinte localização: https://products.currentbyge.
com/eu
RO Versiunea în limba română a instrucţiunilor de
instalare şi a informaţiilor de siguranţă pot fi găsite la:
https://products.currentbyge.com/eu
SV Ni hittar den svenska versionen av
installationsanvisningarna och säkerhetsinformationen
på följande plats: https://products.currentbyge.com/eu
SL Previdnostna opozorila in varnostne informacije so na
zadnji strani vodnika za namestitev. Pred začetkom
namestitve izdelka jih skrbno preberite: https://
products.currentbyge.com/eu
SK Slovenskú verziu montažnej príručky a
bezpečnostnŷch instrukcií nájdete na nasledujúcej
lokalite: https://products.currentbyge.com/eu
1

WARNING/AVERTISSEMENT
RISK OF ELECTRIC SHOCK
∙Turn power off before inspection, installation or removal.
∙Properly ground GE power supply enclosure.
RISK OF FIRE
∙Use only suitably approved wire for input/output
connections. Minimum size 18 AWG (0.82mm2)
∙Follow all local codes.
∙Not to be submerged or used in a marine environment.
RISQUES DE DÉCHARGES ÉLECTRIQUES
∙Coupez l’alimentation avant l’inspection, l’installation ou le déplacement.
∙Assurez-vous de correctement mettre à terre l’alimentation électrique GE.
RISQUES D’INCENDIE
∙N’utilisez que des ls approuvés par UL pour les entrées/sorties de connexion.
Taille minimum 18 AWG (0.82mm2)
∙Respectez tous les codes locaux.
∙Ne pas submerger ou installer dans un environnement marin.
UL WARNING/AVERTISSEMENT UL
RISK OF FIRE OR ELECTRIC SHOCK
∙LED Retrot Kit installation requires knowledge of sign
electrical systems. If not qualied, do not attempt
installation. Contact a qualied electrician.
∙Install this kit only in host signs that have been identied in
the installation instructions and where the input rating of
the retrot kit does not exceed the input rating of the sign.
∙Installation of this LED retrot kit may involve drilling or
punching of holes into the structure of the sign. Check
for enclosed wiring and components to avoid damage
to wiring and electrical parts.
∙Do not make or alter any open holes in an enclosure of
wiring or electrical components during kit installation.
RISQUE D’INCENDIE OU DE CHOC ÉLECTRIQUE
∙L’installation de l’équipement de remplacement DEL exige Ia connaissance des
systèmes électriques pour enseignes. Si non qualié, ne tentez pas d’installation.
Veuillez contacter un électricien qualié.
∙Risque d’incendie ou de choc électrique. Installez cet ensemble seulement dans des
enseignes hôtes qui ont été identiés dans les instructions d’installation et dont la
capacité d’entrée de l’ensemble ne dépasse pas la capacité d’entrée de l’enseigne.
∙L’installation de cet équipement de remplacement DEL peut impliquer le perçage
ou le poinçonnage de trous dans la structure du panneau Vériez le câblage et les
composants inclus pour éviter d’endommager le câblage et les composants électriques.
∙Ne pas faire ou modier les trous ouverts dans une enceinte de câblage
ou de composants électriques pendant l’installation de cet équipement de
remplacement DEL.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
This Class [A] RFLD complies with the Canadian standard ICES-005. Ce DEFR de la classe [A] est conforme à la NMB-005 du Canada.
1
2
3
4
5
66
Components
TCMeasure Point
1 2 3
5
4
This product is intended solely for the use of non-residential signage lighting and is not intended for use in any other applications.
Conforms to the following standards:
III
UL approved 18 AWG (0.82 mm2) supply wire
UL approved 22-14 AWG (0.33-2.08 mm2) wire connectors or
22-18 AWG (0.33-0.82 mm2) in-line/IDC connectors
Weather box GEXNWB2 (optional)
Tetra®24 Volt Power Supply
Tetra® miniMAX MS LED modules
Electrical grade RTV silicone:
• Momentive RTV 6700 Series Silicone Rubber Adhesive Sealant
• Momentive White Blanc RTV 162 Silicone Rubber Adhesive
Sealant-Electrical Grade
• Dow Corning 3140 - Non-Corrosive Flowable (clear)
• Dow Corning 3145 - Non-Corrosive Nonowable (clear or gray)
• Dow Corning RTV 748 Non-Corrosive Sealant-White
2

Measure and cut Tetra LED
strip to the appropriate length
for each letter. Cuts can be
made between any of the
modules.
2
Use the double stick tape or
electrical grade RTV silicone
to x LED module within the
channel letter.
4Drill a 1/4-inch (6.4 mm)
hole near the LED strip and
grommet the hole for supply
wire access.
5 6 Remove all the debris from the
inside of the channel letter and
replace the sign face.
NOTE: For halo-lit applications LED modules should be mounted on UL
recognized clear acrylic or polycarbonate. The light output from the LED
system should be directed back into the sign enclosure. This will allow for
uniform backlighting of the sign and will provide simple mounting.
Before you begin, clean
surfaces and remove all debris
from the inside of the channel
letter.Clean the surfaces with
a 50:50 mixture of isopropyl
alcohol (IPA) and water and let
dry.
1
Layout Modules
Remove tape backing and stick
LED modules into place. When
using tape apply approximately
15 psi pressure on the module
(avoid the lens dome surface) for
5 seconds, full bonding strength
after 24 hours. Continue until you
have reached the end of the strip.
3
Do not
press lens
Electrical Connections
NOTE: Do not use connectors pre-lled with silicone grease/mineral base protective grease or use silicone grease to seal connections.
Cap wires Optional: Cut wires ush
Must cap all exposed wires with appropriate wire
connectors and seal with electrical grade RTV silicone.
Optional: Cut wires ush to the module and seal with
electrical grade RTV silicone.
2
Connect LED strips using in-line (IDC) connectors or
twist-on wire connectors.
NOTE: Seal all connections in wet locations with
electrical grade RTV silicone.
1
Red stripe (+)
White (-)
Seal all connections in wet locations
with electrical grade RTV silicone
3

Run a wire from the LED power supply to the LED module
and connect.
NOTE: Must be used with Tetra®24 Volt Power Supplies.
NOTE: Refer to Maximum Loading & Remote Mounting
Specications on page 4.
3
LED
Power
Supply
To Tetra LED System
Red (+)
Black or blue (-)
To LED
power
supply
Red (+)
Black or
blue (-)
Red Stripe (+)
Connect the red stripe wire (+) of the LED strip to the red
wire (+) of the power supply. Connect the white wire (-)
of the LED strip to the black or blue wire (-) of the LED
power supply.
NOTE: All electrical connections should be suitably
protected from mechanical damage and the
environment. Seal all connections in wet locations with
electrical grade RTV silicone.
4
White (-)
Seal all connections in wet locations
with electrical grade RTV silicone
OPTIONAL
A Weather Box (GEXNWB2) may be used to house
and seal Class 2 connections as described below:
A) Insert wire connectors into weather box. Fill
with electrical grade silicone and close box.
B) Secure the weather box using a #6 or #8 (M2
or M3) screw.
Weather box
can be painted
Light engine
A B
Retrot Instructions
1. (Existing Signs Only) Prior to installation, survey the site for information regarding power and accessibility inside and outside the building. Ensure
that the branch circuit supplying the existing transformer or ballast will be within the voltage ratings of the new LED power supply, and have a
current rating not exceeding 20A, or that permitted by applicable local, state, or country electrical codes (whichever is less).
2. (Existing Signs Only) Remove the existing lighting equipment to be replaced, such as neon tubing or uorescent tubes; and associated
transformers and ballasts. Care should be taken not to break the existing neon or uorescent tubes. NOTE: Follow all federal and local regulations
when disposing of neon tubing, uorescent tubes, transformers and ballasts.
3. (Existing Signs Only) If removal of the existing lighting equipment eliminates the disconnect switch, as required by applicable local, state, or
country electrical codes; a new disconnect switch must be installed.
4. (Existing Signs Only) Repair and seal any unused openings in the electrical enclosure. Openings greater than 12.7-mm (1/2-in) diameter require a
metal patch secured by screws or rivets and caulked with non-hardening caulk. Smaller openings may be sealed with non-hardening caulk.
5. (Existing Signs Only) A clean and dry mounting surface ensures optimum adhesion if the self-adhesive method of mounting is chosen. Follow
the manufacturer’s directions when using a non-oil based solvent, such as rubbing alcohol to clean the surface area where you intend to mount
the module. Before installing, ensure the surface is dry.
6. Using the layout guidelines above, determine required number of LED modules required to illuminate the sign.
7. A Tetra® 24VDC Class 2 Power Supply, as listed below, must be used with this retrot kit. Using the Maximum Loading chart below, determine the
number of Tetra®Class 2 Power Supplies required to power the number of LED modules required to illuminate the sign, so as not to overload the
Tetra®Class 2 Power Supply chosen.
8. Follow the instructions above to properly mount the LED modules.
9. Connect the DC output of the power supply to the LED modules using the Electrical Connections instructions above.
10. Connect the power unit to the supply in accordance with the applicable local, state, and country electrical codes, and the instructions found in the
power supply installation guide.
11. If required, the disconnect switch shall be installed by qualied personnel, in accordance with applicable local, state, and country electrical codes.
FOR UL ONLY
4

Specications
Maximum Loading per Tetra 24V DC Power Supply
SKU Rating
25W
Power Supply
Note: Load shall
not exceed 1.04A
80W
Power Supply
Note: Load shall
not exceed 3.3A
100W
Power Supply
Note: Load shall
not exceed 4.0A
180W Power Supply
Note: Load shall
not exceed 3.8A
per each (of 2)
output channels
300W Power Supply
Note: Load shall
not exceed 4A
per each (of 3)
output channels
GEMS2471-W1
GEMS2465-W1
GEMS2457-W1
GEMS2450-W1
GEMS2441-W1
GEMS2432-W1
24V DC,
9.9mA/module
0.24W/module
90 modules/
22.5 ft. (6.86 m) 282 modules/
70.5 ft. (21.49 m)
340 modules/
85 ft. (25.91 m)
320 modules/
80 ft. (24.38 m)
per output channel
640 modules/
160 ft. (48.76 m)
per power supply
340 modules/
85 ft. (25.91 m)
per output channel
1020 modules/
255 ft. (77.72 m)
per power supply
Maximum Remote Mounting Distance from Driver Output
18 AWG/0.82 mm2
Supply Wire 16 AWG/1.31 mm2 Supply Wire 14 AWG/2.08 mm2 Supply Wire 12 AWG/3.31 mm2 Supply Wire
25W Power Supply 120 ft./36.6 m - - -
80W Power Supply 20 ft./6.1 m 25 ft./7.6 m 35 ft./10.6 m 40 ft./12.1 m
100W Power Supply 20 ft./6.1 m 25 ft./7.6 m 35 ft./10.6 m 40 ft./12.1 m
180W Power Supply 20 ft./6.1 m 25 ft./7.6 m 35 ft./10.6 m 40 ft./12.1 m
300W Power Supply 20 ft./6.1 m 25 ft./7.6 m 35 ft./10.6 m 40 ft./12.1 m
NOTE: The maximum loading claimed in the table is at ambient temperature 25°C (77°F).
For linear long runs, center connection to the LED strip is recommended to minimize voltage drop.
Tips
• For optimal light uniformity in halo-lit applications the Tetra®LED modules should be mounted on UL recognized plastic and the
light output from the Tetra® LED system should be directed back into the sign enclosure. This will allow for uniform backlighting of
the sign and will provide simple mounting for the Tetra®LED system.
• A best practice for the supply wire at the point at which it is brought into the sign is to have a drip loop on the inside of the letter to
keep water from collecting on the Tetra®LED strip.
• These products are not required to be enclosed or protected from weather.
Troubleshooting
Symptom Solution
All letters are OFF • Check AC input connection and/or check circuit breaker.
• Check wire connection(s) at the Tetra® LED System and power supply for improper termination(s) or short
circuits. Properly terminate or replace the wire connection(s).
• Check that connections are the red striped wire (+) of the LED strip to the red wire (+) of the power supply and
the white wire (-) of the LED strip to the black or blue wire (-) of the power supply.
Some LEDs
appear dim
• Ensure the overall length of the Tetra® LED System does not exceed the maximum load.
• Ensure the length of supply wire is equal to or below the recommended remote mounting distance.
• Ensure the overall length of the Tetra® LED System does not exceed the maximum load.
Some of the letters are
not illuminated
• Check wire connection(s) at the Tetra® LED System and power supply for improper termination(s) or short
circuits. Properly terminate or replace the wire connection(s).
• Check that connections are the red striped wire (+) of the LED strip to the red wire (+) of the power supply
and the white wire (-) of the LED strip to the black or blue wire (-) of the power supply.
Shadows • Re-route supply wire and secure to the back of the can with electrical grade RTV silicone. Adjust wire
connector orientation so that it does not cover any LEDs.
• Adjust LED layout to ensure uniformity of illumination on the face of the letter.
All trademarks are the property of their respective owners. Information provided is subject to
change without notice. All values are design or typical values when measured under laboratory
conditions. Current, powered by GE is a business of the General Electric Company.
© 2019 GE.
www.currentbyge.com SIGN161 (Rev 06/22/19) GE2031-1384
