GEA Fit R-300 Specification sheet

Fit R-300
Cable alley scraper
Operation Manual / Installation Instructions
(Original operating instructions)
2005-9015-009
01. August 2018
gea.com

2005-9015-009
01. August 2018
2 / 168
Contents
1 Preface 6.................................................................
1.1 About this manual 6.........................................................................
1.2 Manufacturer's address 7....................................................................
1.3 Customer service 7.........................................................................
1.4 GEA Farm Technologies Canada Inc. / Division GEA Houle - General equipment warranty 8..........
1.4.1 Limited warranty 8..........................................................................
1.4.2 Condition of the limited warranty 8............................................................
1.4.3 Extent of limited warranty 9..................................................................
1.4.4 Warranty limitations and exclusion 10...........................................................
1.4.5 General statements 10.......................................................................
1.5 Specific Limited Warranty for Fit R-300 Cable Alley Scraper 11.....................................
1.5.1 Extent of Specific Limited Warranty 11..........................................................
2 Safety 12...................................................................
2.1 Owner's obligation of care 12..................................................................
2.2 Explanation of safety symbols 13..............................................................
2.3 Basic safety instructions 14...................................................................
2.4 Personnel qualifications 15....................................................................
2.5 Protective devices 16........................................................................
2.6 Safety labels 16.............................................................................
3 Description 17..............................................................
3.1 Intended use 17.............................................................................
3.2 Product changes 18..........................................................................
3.3 Functional description 18.....................................................................
4 Technical data 19...........................................................
4.1 Acoustic emission 19.........................................................................
4.2 Operating temperature 19.....................................................................
4.3 Bolt torque chart 19..........................................................................
4.4 Lubricant specifications 19....................................................................
4.5 Motor specifications 20.......................................................................
4.6 Technical specifications 21....................................................................
4.6.1 2 Alleys with drop at one end - 2 scrapers (1 per alley) 21.........................................
4.6.2 2 Alleys with drop at one end - 3 scrapers (shuttle stroke in one alley) 22............................
4.6.3 3 Alleys with drop at one end - 3 scrapers (1 per alley) 23.........................................
4.6.4 3 Alleys with drop at one end - 4 Scrapers (shuttle stroke in one alley) 24............................
4.6.5 4 Alleys with drop at one end - 4 scrapers (1 per alley) 25.........................................
5 Geometric data 26..........................................................
5.1 Drive unit - 90° configuration - A 26............................................................
5.2 Drive unit - 90° configuration - B 28............................................................
5.3 Drive unit - 180° configuration 30..............................................................
5.4 Drive unit - 360° configuration 32..............................................................
5.5 16” (406 mm) corner wheel 34.................................................................
5.6 21” (533 mm) corner wheel 35.................................................................
5.7 Straight scraper 36...........................................................................
5.8 16° scraper 38..............................................................................
5.9 V-shape scraper 42..........................................................................

2005-9015-009
01. August 2018 3 / 168
6 Handling and installation 48.................................................
6.1 Special personnel qualification required for handling and installation 48..............................
6.2 Safety instructions for handling and installation 48................................................
6.3 Environment requirements 49.................................................................
6.4 Installation requirements 50...................................................................
6.4.1 Visual inspection 50..........................................................................
6.4.2 Necessary documents 50.....................................................................
6.4.3 Special tools 51.............................................................................
6.5 Packing material disposal 51..................................................................
6.6 Anchor bolt installation procedure 52...........................................................
6.7 Drive unit handling 53........................................................................
6.8 Drive unit frame anchoring 54.................................................................
6.9 Installation of air vents on gearboxes 57........................................................
6.10 Drive unit wheels installation 58................................................................
6.11 Corner wheels installation 60..................................................................
6.12 Proximity switches installation 64..............................................................
6.13 The cross gutter supports installation 65........................................................
6.14 Scraper handling 67..........................................................................
6.15 16° adjustable scraper with urethane blades assembly 68.........................................
6.16 16° adjustable scraper with steel blades assembly 70.............................................
6.17 16° scraper with urethane blades assembly 72...................................................
6.18 16° scraper with steel blades assembly 74......................................................
6.19 Straight scraper with urethane blades assembly 76...............................................
6.20 Straight scraper with steel blades assembly 78...................................................
6.21 V-shape scraper with urethane blades assembly 80..............................................
6.22 V-shape scraper with steel blades assembly 82..................................................
6.23 Urethane scraper blade adjustment 84..........................................................
6.24 Control panel installation 85...................................................................
6.25 Electric connections 86.......................................................................
6.25.1 Connecting the proximity switches 86...........................................................
6.25.2 Connecting electric motors 86.................................................................
6.26 Cable installation 87.........................................................................
6.26.1 Step 1: Positioning the scrapers 87.............................................................
6.26.2 Step 2: Linking the scrapers with cable 91.......................................................
6.26.3 Step 3: Link the scrapers to the drive unit with the combi-rope 93...................................
6.26.4 Step 4: Tensioning the cables 95..............................................................

2005-9015-009
01. August 2018
4 / 168
7 Programming 96............................................................
7.1 Special personnel qualification required for programming 96.......................................
7.2 Safety instructions for programming 96.........................................................
7.3 General settings 96..........................................................................
7.3.1 Programmable module 96.....................................................................
7.3.2 Language 98................................................................................
7.3.3 Clock / Date 98..............................................................................
7.3.4 Password 99................................................................................
7.3.5 Alarm buzzer 100.............................................................................
7.4 Motor initial settings 101.......................................................................
7.4.1 Overload relay setting 101.....................................................................
7.4.2 Volts 101....................................................................................
7.4.3 Amps 102...................................................................................
7.4.4 Nema nominal efficiency (%) 103...............................................................
7.4.5 Power factor (%) 104..........................................................................
7.4.6 Number of phases 105........................................................................
7.4.7 Motor capacity (HP) 106.......................................................................
7.4.8 Minimum load (HP) 107........................................................................
7.5 Motor capacity (HP) fine tuning 108..............................................................
7.6 Minimum load (HP) fine tuning 109..............................................................
7.7 Detection parameters 110......................................................................
7.7.1 Maximum load fluctuation (HP) 111..............................................................
7.7.2 Detection time 113............................................................................
7.7.3 Number of restarts 115........................................................................
7.8 Automatic cleaning mode using starting hours 116.................................................
7.9 Automatic cleaning mode using delay between cleanings 118.......................................
7.10 Scraper parking function 120...................................................................
7.11 Scraper withdrawal function 120................................................................
7.12 Gradual discharge mode 121...................................................................
7.13 Manure apron mode 121.......................................................................
7.14 External start signal mode 121..................................................................
7.15 Cold weather function 121.....................................................................
7.16 Manual parking function 122....................................................................
7.17 Instant start function 123.......................................................................
7.17.1 Number of strokes (Start Button) 123............................................................
7.18 Backup and recovery files 124..................................................................
7.19 Diagnosis 125................................................................................
7.20 Real time reading 126.........................................................................
7.21 Farm-access 127.............................................................................
7.21.1 Requirements 127............................................................................
7.21.2 Electric connection 127........................................................................
7.21.3 Wiring 128...................................................................................
7.21.4 Configuration 130.............................................................................
7.21.5 Mobile phone application 130...................................................................
7.21.6 Mobile phone notifications 130..................................................................
8 Starting for the first time 131.................................................
8.1 Special personnel qualification required for initial commissioning 131.................................
8.2 Safety instructions for initial commissioning 131...................................................
8.3 Initial commissioning checklist 132..............................................................
8.4 Checks after initial commissioning 134...........................................................
8.5 Handing over to the owner 134.................................................................
9 Operating 135...............................................................
9.1 Special qualification required for operating 135....................................................
9.2 Safety instructions for operation 135.............................................................
9.3 Requirements while operating 136..............................................................
9.3.1 Maintenance work in the free stall alleys 136......................................................
9.3.2 Control panel alarms 136......................................................................
9.3.3 Environment changes 136.....................................................................
9.4 Automatic mode operation 137.................................................................
9.5 Manual mode operation 137....................................................................

2005-9015-009
01. August 2018 5 / 168
10 Operating faults 138.........................................................
10.1 Special qualification required for troubleshooting 138...............................................
10.2 Safety instructions for troubleshooting 138........................................................
10.3 Troubleshooting possible faults 139.............................................................
10.4 FIO452 indicator lights 143.....................................................................
11 Maintenance 145............................................................
11.1 Special qualification required for maintenance work 145............................................
11.2 Safety instructions for maintenance 145..........................................................
11.3 Scheduled maintenance responsibilities 146......................................................
11.4 Check the tension of the rope / cable 147........................................................
11.5 Adjust the tension of the rope / cable 148.........................................................
11.6 Visual inspection 154..........................................................................
11.7 Check the bolts and anchor bolts torque 154......................................................
11.8 Grease the drive unit bearings 155..............................................................
11.9 Grease the drive unit wheels and the corner wheels 156............................................
11.10 Check and adjust the scraper blades 156........................................................
11.10.1 Steel blade 157...............................................................................
11.10.2 Urethane blade 157...........................................................................
11.11 Grease the scraper hinges 158.................................................................
11.12 Lubricate the threaded rod 159.................................................................
11.13 General cleaning 160..........................................................................
12 Decommissioning 161.......................................................
12.1 Safety instructions for decommissioning 161......................................................
12.2 Decommissioning/disposal 161.................................................................
13 Appendix 162...............................................................
13.1 IVR PRO / IVR PRO Max@ccess wiring diagram 162..............................................
13.2 Electric motor wiring diagram 163...............................................................
13.3 Safety labels and lubrication labels position 165...................................................
13.3.1 Drive unit 165................................................................................
13.3.2 Control panel 166.............................................................................
13.4 Abbreviations 167............................................................................

Preface
About this manual
2005-9015-009
01. August 2018
6 / 168
1 Preface
1.1 About this manual
The manufacturer reserves the right to make changes due to technical
developments in the data and illustrations in this manual.
Reproductions, translations and copies of any kind, including extracts, require
written authorization from the manufacturer.
This manual is supplied with the product.
● They should be kept close at hand and remain with the equipment even if
the equipment is sold.
● This manual is not subject to an amendment service. The most recent
version at any time can be obtained through the technical dealer or directly
from the manufacturer.
Pictograms used
This pictogram indicates information that will help towards better
understanding of a procedure or operation.
This pictogram indicates a special tool required for installation.
!A correction bar in the margin indicates changes to the previous
edition. The character string ”!!” in the search field of the PDF
document locates the correction bar.
This pictogram refers to another document or another section of this
manual.
If a manual number is given, the middle 4 figures indicate the language, as
follows:
Language Language Language
-9000- German -9013- Dutch -9032- Serbian
-9001- English (United
Kingdom)
-9015- English (North
American)
-9034- Slovak
-9002- French (France) -9016- Polish -9035- Chinese
-9003- Italian -9018- Japanese -9036- Lithuanian
-9004- Romanian -9021- Danish -9038- Portuguese (Brazil)
-9005- Spanish (Spain) -9022- Hungarian -9039- French (Canada)
-9007- Swedish -9023- Czech -9040- Latvian
-9008- Norwegian -9024- Finnish -9041- Estonian
-9009- Russian -9025- Croatian -9043- Spanish (Central
America)
-9010- Greek -9027- Bulgarian
-9012- Turkish -9029- Slovene
All of the above languages may not be available.

Preface
Customer service
2005-9015-009
01. August 2018 7 / 168
1.2 Manufacturer's address
GEA Farm Technologies Canada Inc. / Division GEA Houle
4591 boul. St-Joseph
Drummondville, Qc, J2A 0C6
+1 819 477 - 7444
+1 819 477 - 5565
[email protected]
www.gea.com
1.3 Customer service
Authorized Technical Dealer
If necessary, please contact your nearest dealer.
There is a comprehensive dealer Internet search function on our website at the
following address:
www.gea.com
European Contact Information:
GEA Farm Technologies GmbH
Siemensstraße 25-27
D-59199 Bönen
+49 (0) 2383 / 93-70
+49 (0) 2383 / 93-80
[email protected]
www.gea.com
US Contact Information:
GEA Farm Technologies, Inc.
1880 Country Farm Dr.
Naperville, IL 60563
+1 630 369 - 8100
+1 630 369 - 9875
[email protected]
www.gea.com

Preface
GEA Farm Technologies Canada Inc. / Division GEA Houle - General equipment warranty
2005-9015-009
01. August 2018
8 / 168
1.4 GEA Farm Technologies Canada Inc. / Division GEA Houle - General equipment
warranty
Important notice!
THIS GENERAL WARRANTY APPLIES TO ALL EQUIPMENT SOLD
UNDER THE HOULE TRADEMARK.
1.4.1 Limited warranty
GEA Farm Technologies Canada Inc. / Division GEA Houle (hereinafter
referred to as ”the Company”) warrants to the original buyer and end user
(hereinafter referred to as the ”Purchaser”) that the parts of all equipment sold
under the Company trademark are free from defects in material or workmanship
for a period of twelve (12) months from the date of delivery of the equipment to
the Purchaser. This written warranty takes precedence over any other written
warranty included in previous versions of the Company's manuals. Any
equipment used for commercial usage, commercial lease on one or more farms
is warranted for a reduced period of thirty (30) days only.
Components from third-party manufacturers that are not built by the Company,
and which are accessory to the equipment sold under the Company trademark
(including, without limitation, the motors and tires), are subject to such
third-party manufacturers' specific warranty coverage.
THIS WARRANTY EXTENDS ONLY TO THE PURCHASER AND DOES NOT
APPLY IN THE EVENT THAT THE EQUIPMENT IS SOLD OR OTHERWISE
TRANSFERRED.
1.4.2 Condition of the limited warranty
The Company, through its GEA authorized dealers only (hereinafter referred to
as ”Dealer”, reserves the right to either repair or replace all parts deemed
defective under the following conditions:
1. That the equipment is installed, operated and maintained in accordance with
the Company directives;
2. That the Purchaser uses the equipment in accordance with specific
instructions, under normal conditions, for the sole purpose for which the
equipment was designed;
3. That the Purchaser notifies in writing his Authorized Dealer or the Company
(whichever the case may be) of any defect of the equipment. In either case
the notification must be made within the twelve (12) months following the
date of the delivery to the Purchaser;
4. The Purchaser or the Authorized Dealer must keep the defective parts or
equipment for inspection by the Company and return such defective parts
or equipment prepaid to the Company, if requested;
5. That the Purchaser does not modify the equipment, nor attempts to repair
any equipment or parts without proper authorization from the Company;
6. Depending on the nature of the equipment involved and whether it is fixed
or transportable, the Company will repair or replace the defective parts of the
equipment free of charge where installed, or at the business place of the
Authorized Dealer or the Company, at its sole discretion.

Preface
GEA Farm Technologies Canada Inc. / Division GEA Houle - General equipment warranty
2005-9015-009
01. August 2018 9 / 168
1.4.3 Extent of limited warranty
This limited warranty DOES NOT cover:
● Defects caused by negligence of the Purchaser in the maintenance of the
equipment, improper use resulting from failure to adhere strictly to the
Company's manuals or non-compliance with prescribed maintenance
instructions provided by the Company (including, without limitation, lack of
lubrication of the equipment), as well as damages arising from
non-conforming installation of the equipment, or ambient temperature or
conditions of storage of the equipment that do not comply with the
Company's recommendations (including, without limitation, any damages
resulting from storage or operation of the equipment at a temperature equal
or below (5°C/41°F));
● Damages to equipment due to normal wear and tear or to external causes,
including issues of power or inadequate electrical conditions (including,
without limitation, inadequate tension (neutral/ground), abnormal
mechanical or environmental conditions (including, without limitation,
damages caused by fire, lightning, flood or other natural disaster), damages
caused by the use of sand litter or other abrasive or inadequate material
(including, without limitation, damages caused by solids in the manure, such
as stone, wood, iron, concrete, and strings), as well as damages caused by
ice or frozen manure blocking the evacuation line of the equipment or the
introduction of such solids in the equipment;
● Freight and shipping associated with repair or replacement of equipment
under this limited warranty, as well as all costs relating to removal or
replacement of any equipment that is welded or affixed permanently to the
ground or a building (including, without limitation, labor costs, and costs
related to concrete or excavation);
● Claims arising from repairs or replacements made by the Purchaser without
the prior written consent of the Company. The Purchaser shall not remove
or alter any safety device, guard, or warning sign.
If the Purchaser fails to comply with any of its obligations referred to in this
paragraph, the Purchaser agrees to save the Company and the Authorized
Dealer harmless in respect of any liability or obligation incurred by the Company
or the Authorized Dealer resulting from such failure of the Purchaser.

Preface
GEA Farm Technologies Canada Inc. / Division GEA Houle - General equipment warranty
2005-9015-009
01. August 2018
10 / 168
1.4.4 Warranty limitations and exclusion
NO WARRANTY, ORAL OR WRITTEN, EXPRESS OR IMPLIED, OTHER
THAN THE ABOVE WARRANTY IS PROVIDED IN RESPECT OF THE
EQUIPMENT SOLD.
Some states (or jurisdictions) do not allow the exclusion of implied warranties
so it is possible that this limitation may not apply.
THE COMPANY DISCLAIMS ALL IMPLIED WARRANTIES, INCLUDING THE
WARRANTIES OF MERCHANTABILITY, ADAPTABILITY OR OF
PERFORMANCE, PROVIDED THAT SUCH EXCLUSION OF LIABILITY
COMPLIES WITH THE LAWS HAVING APPLICABLE REGULATORY
JURISDICTION.
THE LIABILITY OF THE COMPANY AND ITS AUTHORIZED DEALERS
UNDER THIS WARRANTY IS LIMITED TO REPAIR OR REPLACEMENT OF
DEFECTIVE PARTS UP TO THE CONTRACT VALUE FOR THE
PURCHASED EQUIPMENT. IN NO EVENT SHALL THE COMPANY BE
LIABLE FOR ANY SPECIAL, INDIRECT, CONSEQUENTIAL, INCIDENTAL,
PUNITIVE OR EXEMPLARY DAMAGES IN ANY KIND OR CHARACTER,
INCLUDING INDIRECT COSTS, LOSS OF PRODUCTION, LOSS OF
REVENUES OR PROFITS, AND OTHER DISBURSEMENTS WHICH MAY
OCCUR.
Some states (or jurisdictions) do not allow the exclusion or limitation of
incidental or consequential damages and so it is possible that these limitations
or exclusions may not apply.
1.4.5 General statements
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY
ALSO HAVE OTHER RIGHTS THAT VARY BY JURISDICTION.
THE DEALER IS NOT AUTHORIZED TO MAKE ANY ADDITIONAL
REPRESENTATIONS OR PROMISES THAT DIFFER IN ANY WAY FROM
THE TERM OF THIS LIMITED WARRANTY, OR MODIFY THE PROVISIONS,
DURATION AND CONDITIONS OF THIS LIMITED WARRANTY. NO WAIVER
OR MODIFICATION OF THIS LIMITED WARRANTY IS VALID UNLESS
AGREED TO IN WRITING AND SIGNED BY THE AUTHORIZED
REPRESENTATIVES OF THE COMPANY.
IN THE EVENT OF ANY CONFLICT BETWEEN THE ENGLISH LANGUAGE
VERSION AND ANY OTHER TRANSLATED VERSION OF THIS LIMITED
WARRANTY (WITH THE EXCEPTION OF THE FRENCH LANGUAGE
VERSION) THE ENGLISH VERSION SHALL PREVAIL.

Preface
Specific Limited Warranty for Fit R-300 Cable Alley Scraper
2005-9015-009
01. August 2018 11 / 168
1.5 Specific Limited Warranty for Fit R-300 Cable Alley Scraper
This specific limited warranty extends to the Purchaser of all free stall cleaners
with cable (individually, the ”Cleaner System”) sold by the Company. All
conditions stated in this specific limited warranty are in addition to the General
Equipment Warranty that applies to all equipment sold by the Company (see
section 1.4 above).
1.5.1 Extent of Specific Limited Warranty
This specific limited warranty DOES NOT cover:
● Cable wear and tear and cable breaking that may arise after the installation.
Warranty on cable is limited to manufacturing defects detectable at the time
of installation;
● Wear and tear of corner wheels;
● Wear and tear of scrapers and all their components.

Safety
Owner's obligation of care
2005-9015-009
01. August 2018
12 / 168
2 Safety
2.1 Owner's obligation of care
This product is designed for agricultural purposes only. Make sure to follow the
local rules and regulations in relation with the use of this product.
This product is designed and constructed while taking into account a risk
assessment, a selection of harmonized standards and other technical
specifications to be complied with in order to guarantee a maximum level of
safety.
If component(s)/equipment not manufactured by GEA is/are added to this GEA
product, consider that new risk(s) may arise from this addition. Make sure the
equipment and the environment surrounding the equipment remain safe.
Since agitated manure produces heavy toxic gases, make sure to follow the
safety procedures for confined spaces before operating or servicing this
equipment in such environment. Look at the corresponding Web site below to
make sure the local safety procedures for confined spaces are followed.
Location Administrated by Web site
Canada Canadian Centre for
Occupational Health and
Safety
www.ccohs.ca
USA Occupational Safety and
Health Administration
www.osha.gov
European Union European Agency for
Safety and Health at Work
www.osha.europa.eu
Safety is achieved when the safety instructions are followed. It is part of the
owner's obligation of care to implement these safety measures and make sure
they are carried out at all times.
The owner must ensure a safe environment by providing:
● this instruction manual with this product. Everyone performing activities in
connection with this product must read this instruction manual and follow
those instructions;
● all required personal safety gear such as hearing, eye, feet protection, etc;
● adequate training for employee(s) working or performing activities in
connection with this product;
● the tools listed in this manual to perform activities in connection with this
product;
● locally purchased components and/or products that comply with the
technical requirements mentioned in section Technical data, if applicable;
● new parts to replace any defective, worn or damaged parts on this product;
● adequate lighting in all areas where activities in connection with this product
are performed.

Safety
Explanation of safety symbols
2005-9015-009
01. August 2018 13 / 168
2.2 Explanation of safety symbols
The safety symbols draw attention to the importance of the adjacent text.
The design of the notifications is based on ISO 3864-2 and ANSI535.6.
Safety symbols and key words
Danger!
The signal word ”Danger” indicates an immediate threat to the lives or
health of personnel.
Death or serious injury may result if the danger is not avoided.
Warning!
The indication ”Warning” signals danger to life or health of personnel.
Death or serious injury may result if the danger is not avoided.
Caution!
The indication ”Caution” signals a hazardous situation.
Minor or moderate injury may result if the danger is not avoided.
Attention!
The word ”Attention” indicates important information on risks for the
product or the environment.

Safety
Basic safety instructions
2005-9015-009
01. August 2018
14 / 168
2.3 Basic safety instructions
● Only trained personnel can operate this product to ensure safe operating
methods. Make sure the personnel performing activities in connection with
this product have the skills when special qualifications are required. Read
the section Safety - Personnel qualifications.
● Wear appropriate personal safety gear such as hearing, eye, feet
protection, etc. when performing activities in connection with this product.
Inspect the personal gear and replace if worn and/or defective.
● Familiarize yourself with the environment surrounding the working area.
Locate the elements that can be dangerous in order to avoid them.
● No one stands near this product unless they are performing instructions
included in this manual. When near this product, keep body parts such as
hands, feet, hair as well as clothing away from dangerous parts such as
rotating parts, articulated parts, sharp edges, etc.
● Use this product only when in perfect working condition. Do not use
damaged, worn or defective parts on this product, replace immediately to
avoid serious damages and injuries.
● The use of any tool or lubricant is subject to certain risks. Follow the
manufacturer's recommendations and wear appropriate personal safety
gear.
● Never remove the safety devices such as guards, covers, chains, labels, etc.
from this product to ensure safety unless otherwise indicated in this
instruction manual. Refer to section Safety - Protective devices. Read and
follow the instructions of the safety labels affixed on this product and make
sure the safety labels are legible at all times.

Safety
Personnel qualifications
2005-9015-009
01. August 2018 15 / 168
2.4 Personnel qualifications
The manufacturer intends to determine the difference between trained
personnel and qualified personnel.
Trained personnel
The operator was trained by the manufacturer or its legal representative to
follow all safety rules, cleaning method, general maintenance as well as the
operating methods.
It is the operator's responsibility to inform the farm workers of those rules,
maintenance and methods.
Qualified personnel
Qualified personnel refers to those having obtained the academic knowledge
of a specific field of work.
This personnel has followed a training and subsequently obtained a
certification, diploma or any other official document provided by a recognized
academic facility in the country of study.
An equivalence may be required when operating in other countries.
The special qualifications required will be specified in each section.
Everyone who performs work or activities in connection with the product must
carefully read and understand the manual and then act accordingly.

Safety
Safety labels
2005-9015-009
01. August 2018
16 / 168
2.5 Protective devices
This product is equipped with safety parts protecting the user against
dangerous elements.
Those parts must be in perfect working condition and remain in place at all
times.
Replace if damaged, worn and/or defective. Refer to the part number.
Safety guard for corner wheel
16” (406 mm) model (part no. 2005-7508-090)
21” (533 mm) model (part no.2005-7508-100)
Safety guard for scraper cable tensioner
Single tensioner (part no. 2005-2005-180)
Double tensioner (part no. 2005-2005-170)
Transformer finger safe device
Control panel emergency stop button
2.6 Safety labels
The labels affixed on this product inform the user of the potential dangers, the
prohibited manoeuvres, the proper procedures and applications when
performing activities in connection with this product.
The labels must remain in place and legible at all times.
Replace when damaged. Refer to the part number for the appropriate label.
Refer to section Appendix - Label position.

Description
Intended use
2005-9015-009
01. August 2018 17 / 168
3 Description
3.1 Intended use
The Fit R-300 system is exclusively designed to:
● Scrape manure in a free stall barn alleys;
● Scrape manure having limited quantity of bedding;
Note!
This product and its equipment are designed for agricultural purposes
only. Any applications not listed above are considered as improper
use.
Please note that the following is prohibited:
● Scraping other material than manure and/or waste water;
● Running over the cable with machinery;
● Repairing the cable using sharp or clinging fastener;
● Operating the cleaning system while the load fluctuation parameters are
deactivated;
● Operating the cleaning system while the load fluctuation parameters are
improperly set;
● Operating the cleaning system although the control panel continuously
triggers alarms.
The manufacturer is not liable for any resulting damages due to improper use
of this product. The user carries the risk. Proper use also includes reading and
following the instructions of this instruction manual.
● Original GEA Houle parts and accessories are specially designed for GEA
Houle products and equipment.
● The manufacturer expressly points out that only original parts and original
accessories supplied by GEA Houle are adapted, tested and authorized to
be used with this product or equipment. Do not use other supplier's parts or
equipment with GEA Houle product unless otherwise approved in writing by
GEA Houle.
● The manufacturer does not accept any liability toward injured people or
animals or damaged products and equipment caused by the use of other
manufacturers products.

Description
Functional description
2005-9015-009
01. August 2018
18 / 168
3.2 Product changes
Unauthorized product modifications can have a negative impact on the safety,
service life and functionality of the product.
Any modifications not described in the product documentation are deemed to
be prohibited.
For safety reasons, do not carry out any unauthorized changes!
Planned changes must be approved by the manufacturer in writing.
Any unauthorized modifications to the product will invalidate the warranty and
may invalidate the manufacturer's declaration or installation declaration
provided.
3.3 Functional description
The Fit R-300 system consists of a drive unit, corner wheels, scrapers, a cable
and a control panel.
The system operates by means of a control panel which powers the drive unit
motor(s) upon command. Subsequently, the scrapers move in the alleys as they
are linked together by a cable which ties to the drive unit drum. As the drive unit
operates, one scraper moves forward while the other moves backwards. When
a scraper reaches the cross gutter, the system operates in opposite motion.
1
7
2
3
4
6
5
5
8
3
Legend:
1Drive unit 5 Stalls
2Corner wheel 6Cable (nylon or steel)
3 Scraper 7 Feeding alley
4Cross gutter 8Control panel

Technical data
Lubricant specifications
2005-9015-009
01. August 2018 19 / 168
4 Technical data
4.1 Acoustic emission
Noise level Less than 65 dBA
4.2 Operating temperature
Operating temperature Over 5°C (41°F)
4.3 Bolt torque chart
Note!
Refer to the bolt torque chart below unless otherwise specified in this manual.
Bolt Mat.
Bolt diameter
1/4” 5/16” 3/8” 7/16” 1/2” 9/16” 5/8” 3/4” 7/8” 1”
SAE 2
LCS 6 ft-lb
8Nm
12ft-lb
16Nm
20ft-lb
27Nm
32ft-lb
44Nm
47ft-lb
64Nm
69ft-lb
94Nm
96ft-lb
130Nm
155ft-lb
210Nm
206ft-lb
279Nm
310ft-lb
420Nm
SAE 5 MCS
HT
10ft-lb
14Nm
19ft-lb
26Nm
33ft-lb
45Nm
54ft-lb
73Nm
78ft-lb
106Nm
114ft-lb
155Nm
154ft-lb
209Nm
257ft-lb
349Nm
382ft-lb
518Nm
587ft-lb
796Nm
SAE 8
MCAS 14ft-lb
19Nm
29ft-lb
39Nm
47ft-lb
64Nm
78ft-lb
106Nm
119ft-lb
161Nm
169ft-lb
229Nm
230ft-lb
312Nm
380ft-lb
515Nm
600ft-lb
814Nm
700ft-lb
949Nm
Socket
Head
Cap
Screw
AS
HT
16ft-lb
22Nm
33ft-lb
45Nm
54ft-lb
73Nm
84ft-lb
114Nm
125ft-lb
170Nm
180ft-lb
244Nm
250ft-lb
339Nm
400ft-lb
542Nm
640ft-lb
868Nm
970ft-lb
1315Nm
4.4 Lubricant specifications
Lubricant type Product name Grade Purpose
Grease*PRECISIONTM general purpose
EP2
NLGI 2
NLGI 3
● General lubrication of the
equipment
● To grease corner wheels
● To grease the bearings of the
drive unit
● Stroke limit threaded rod
● Threaded rod
● Scraper hinges
Gearbox oil Shell Omala S4 WE ISO
VG-320 ● To fill the gearbox.
* Must not contain Molybdenum disulfide.

Technical data
Motor specifications
2005-9015-009
01. August 2018
20 / 168
4.5 Motor specifications
Note!
GEA provides specifications and electric motor wiring diagram related
to Baldor motor(s). For any other motor brand, contact the
manufacturer.
Motor type General motor
Standard specifications NEMA IEC
Frame sizes required 56C -
Type of construction B3
Weight No special requirements
Frame material No special requirements
Degree of protection IP 55
Method of cooling TEFC, IC 411
(Totally Enclosed, Fan Cooled)
Vibration class No special requirements
Insulation 155(F) to 130(B)
Duty type S1(continuous operation)
Direction or rotation Bi-directional
Rated motor voltage As per local requirements
Frequency 60Hz
Rated motor power 0.75 HP (0.5kW)
Rated motor speed 60Hz@1725rpm
Rated motor torque
No special requirements
Rated motor current
Power factor
Efficiency min. 80%
