8
Step 2
Lay the top vertex on a at surface. The side
with the hexagonal groove being on bot-
tom. Slide short short V rail in the ank of
the vertex. (These should easily slide on due
to the screws being loose).
Using the M2.5 Allen Key fasten the screws
tightly from the inside. (As gure 1.4).
Figure 1.3
Figure 1.4
Step 3
Next, assemble the remaining top Vertexes
with the short V rail, similar to steps 1 & 2.
Attention: the bottom of the vertex is the
side with hexagonal grooves. (As gure 1.4)
Step 4
Sequence 3 assembled top Vertexes like
Figure 1.5, then put them together slowly.
Finally, tighten the remaining screws.
Figure 1.5
