Geemarc VISO15-DCF User manual


123
UserManual
VISO15–DCF
(MainlandEurope–NotUK)
1.Features
‐EasytoReadandUnderstandTimedisplay
‐PerpetualCalendarUptoYear2099
‐Daysoftheweek&Monthin14differentlanguages
2.UnitAppearance





PartA‐LCD
A1: DayoftheWeek
A2:RadioControlIcon
A3:Time
A4:Periodoftheday
A5:AM/PM
A6:Date
A7:Month
A8:Year
PartB‐ButtonPartC‐Structure 
B1:“SET” Button
B2:“▲”Button
B3:“▼”Button
B4:Poweradaptor
C1:backlightsensor
C2:HangingHole
C3:BatteryCompartment
C4:Stand
3.Gettingstarted:
zPlugthepoweradaptorintothewallsocketandinto
thebackofyourclockin(B4)
zOpenthebatterycompartment(C3).
zInsert3xAAsizealkalinebatteriesobservingpolarity
[“+”and“–“marks].Youshouldherea“click”sound,it
indicatesthatyouhaveplacedthebatteriescorrectly.
zReplacethebatterycompartmentcover.
zThebatteriesareonlyusedincaseofpowerfailure.
zYoucanselectthelevelofbrightnessofthebacklightby
placingyourhandonthebacklightsensor(C1).Thereare
fourlevels(High,middle,lowandOFF).
InNIGHTmode,thebrightnessissetonLOWandthe
HIpositioncan’tbeselected.
4.Setting
4.1Automaticclocksetting
zWhenyouconnectyourpoweradaptorortheAlkaline
batteries,yourclockasksyoutoselectyourlanguage.
Youhavethechoicebetweenthefollowing14languages:
English,Français,Deutsch,Nederlands,Italiano,Espanol,
Portugues,Swenska,Norsk,Dansk,Suomi,Polski,Ceska
andMagyar.
zPressthe“▼”(B3)or“▲”(B2)buttontochooseyour
languageandthenpresstheSET(B1)button
zPressthe“▼”(B3)or“▲”(B2)buttontochooseyour
typeofdisplayandthenpresstheSET(B1)buttonto
exit.
Youcanchoosebetweenfourtypesofdisplay(seepictures)
a)DP1:Day+Periodoftheday+Time
b)DP2:Day+Date+Time
c)DP3:Day+Date+Year
d)DP4:Inthismode,youcanselectboth(DP1,DP2or
DP3)mode,theclockwillthenswitchbetweenthethird.
Bydefault,theswitchwillhappenevery5secondsbut
youhavethepossibilitytoincreasethetimeperiod
betweentwoswitches(upto60seconds).
zAfterhavingsetthelanguageandthetypeofdisplay,
theclockautomaticallystartstoscanfortheDCFtime
signal.TheRadioControlIcon“”(A2)willthen
appearonthescreen.
(A2)flashesIndicatesthattheclockisnow
receivingtheDCFsignal
(A2)stayson Indicatesthesignalhas
successfullybeenreceived
(A2)disappears Indicatesthereceptionofthe
signalhasfailed
zTheclockautomaticallysynchronizeswiththeDCFradio
signaleverydayat3.00amtomaintainaccuratetime
keeping.IfsynchronizationwiththeDCFradiosignal
fails,the“”iconwilldisappearfromthescreen.The
clockwillthenreattempttosynchronizewiththeDCF
radiosignalat4.00and5.00am.
zYoucanmaketheclockscanfortheradiosignalbyholding
the“▼”button(B3)for3seconds.Eachattemptsat
gettingthesignaltakesseveralminutes.Ifthereception
fails,thescanningstopsmomentarily(the“”icon
disappears)andthenstartsagainonthenextclockhour.
E.g.ifreceptionfailedat8:20a.m.theclockwillscan
againforthesignalat9:00a.m.
zTostopthescanningfortheDCFradiosignal,holdthe
“▼”button(B3)for3seconds.
Day
+
Periodof
theday
+
Time
Day
+
Date
+
Time
Day
+
Date
+
Year


456
4.2ManualclockSetting:
4.2.1:Settingoftheperiodoftheday
Note:
‐AllSettingmodeswillautomaticallyexitafter15seconds
ifnoadjustmentismade.
‐(Pressandholdthe“▼”(B3)or“▲”(B2)button,toreach
thedesiredvaluemorequickly).
zIftheperiodofthedayisnotindicatedonthescreen
(DP1),presstheSET(B1)buttononcetomakeitappear.
zSettingbydefault:
MORNING=7:01–12:00EVENING=17:01‐23:00
AFTERNOON=12:01–17:00NIGHT=23:01‐7:00
zPressandholdtheSET(B1)buttonuntiltheword
“MORNING”flashes.
zSetthecorrecthourforthisperiodbypressingthe“▼”
(B3)or“▲”(B2)buttonsthenpresstheSET(B1)button
tosave.
z“AFTERNOON”nowblinks,setthecorrecthourforthis
periodbypressingthe“▼”(B3)or“▲”(B2)buttons
thenpresstheSET(B1)buttontosave.
z“EVENING”nowblinks,setthecorrecthourforthis
periodbypressingthe“▼”(B3)or“▲”(B2)buttons
thenpresstheSET(B1)buttontosave.
z“NIGHT”nowblinks,setthecorrecthourforthisperiod
bypressingthe“▼”(B3)or“▲”(B2)buttonsthen
presstheSET(B1)buttontosaveandexit.
4.2.2:Settingthetimezoneandclock(date,year,
hourandmonth)
Ifthedayandtheyeararenotindicatedonthescreen
(DP3),presstheSET(B1)buttontomakethemappear.
zPressandholdSET(B1)buttonuntil00blinks.Pressthe
“▼”(B3)or“▲”(B2)buttonstoselectthecorrecttime
zonethenpressSET(B1)buttontosave.00bydefault.
zNowtheyearblinks.Pressthe“▼”(B3)or“▲”(B2)
buttonstoselectthecorrectyearthenpressSET(B1)
buttontosave.
zNowthemonthblinks.Pressthe“▼”(B3)or“▲”(B2)
buttonstoselectthecorrectmonththenpresstheSET
(B1)buttontosave.
zNowthedateblinks.Pressthe“▼”(B3)or“▲”(B2)
buttonstoselectthecorrectdatethenpresstheSET
(B1)buttontosave.
zNowthehour’sdigitsblink.Pressthe“▼”(B3)or“▲”
(B2)buttonstosetthehourthenpresstheSET(B1)
buttontosave.
zNowtheminutes’digitsblink.Pressthe“▼”(B3)or
“▲”(B2)buttonstosettheminutesthenpressSET(B1)
buttontosaveandexit.
4.1.3Settingthelanguageanddisplaytype
zInnormalsettingpattern,pressandholdthe“▲”(B2)
buttonuntilyouhavethelanguagesetblinkingPress“▼”
(B3)or“▲”(B2)buttontoselectthecorrectlanguage
thenpresstheSET(B1)buttontosave.
Note:Youhavethechoicebetweenthefollowing14languages:
English,Français,Deutsch,Nederlands,Italiano,Espanol,
Portugues,Swenska,Norsk,Dansk,Suomi,Polski,Ceska
andMagyar.
zPressthe“▼”(B3)and“▲”(B2)buttonstoselectyour
languagethenpresstheSET(B1)button
zPressthe“▼”(B3)and“▲”(B2)buttontoselectyour
displaytypethenpressSET(B1)buttontoexit
a)DP1:Day+Periodoftheday+Time
b)DP2:Day+Date+Time
c)DP3:Day+Date+Year
d)DP4:Inthismode,youcanselectboth(DP1,DP2or
DP3)mode,theclockwillthenswitchbetweenthethird.
Bydefault,theswitchwillhappenevery5secondsbutyou
havethepossibilitytoincreasethetimeperiodbetween
twoswitches(upto60seconds).
5.Precautions
zTheclocklosesitstimeinformationwhenthepower
adaptorisremovedandyouhavenotinsertedthealkaline
batteries.
zDonotexposeittodirectsunlight,heavyheat,cold,
highhumidityorwetenvironments
zNevercleanthedeviceusingabrasiveorcorrosive
materialsorproducts.Abrasivecleaningagentsmay
scratchplasticpartsandcorrodeelectroniccircuits.
6.Radiocontrolledtimereceptionrange:
upto1500kmfromDCF77transmitter.
7.Guarantee
FromthemomentyourGeemarcproductispurchased,
Geemarcguaranteeitfortheperiodoftwoyears.During
thistime,allrepairsorreplacements(atouroption)are
freeofcharge.Shouldyouexperienceaproblemthencontact
ourhelplineorvisitourwebsiteatwww.geemarc.com.
Theguaranteedoesnotcoveraccidents,negligenceor
breakagestoanyparts.Theproductmustnotbetampered
withortakenapartbyanyonewhoisnotanauthorised
Geemarcrepresentative.TheGeemarcguaranteeinnoway
limitsyourlegalrights.
IMPORTANT:YOURRECEIPTISPARTOFYOURGUARANTEE
ANDMUSTBERETAINEDANDPRODUCEDINTHEEVENTOF
AWARRANTYCLAIM.
CEDeclaration:Thedeclarationofconformitymaybe
consultedatwww.geemarc.com
8.Recyclingdirectives
TheWEEE(WasteElectricalandElectronicEquipment)has
beenputinplacefortheproductsinendoflifearerecycled
inthebestway.
Whenthisproductisoutoforder,pleasedonotputitin
yourdomesticwastebin.
Pleaseuseoneofthefollowingdisposaloptions:
‐Removethebatteriesanddeposittheminanappropriate
WEEEskip.
DeposittheproductininaappropriateWEEEskip.
‐Orhandtheoldproducttotheretailer.Ifyoupurchasea
newone,theyshouldacceptit.




Forproductsupportandhelpvisitourwebsiteat
www.geemarc.com
telephone01707387602






UGViso15_DCF(VDE)_En_A4_V1.0
