Geemarc T300 User manual

1
Telephone
CAUTION:THIS TELEPHONE PRODUCT IS
SPECIFICALLYDESIGNED FOR PEOPLE WITH HEARING
DIFFICULTIES AND IS PROVIDED WITH A HANDSET
EARPIECE WITH VOLUME CONTROL FOR INDIVIDUAL
REQUIREMENTS. DUE CARE MUST BE TAKEN BY ALL
USERS THAT THE HANDSET EARPIECE VOLUME
CONTROL IS SETTOTHE LOWEST LEVEL ACCEPTABLE
BYEACHRESPECTIVEUSER. CARESHOULDTHEREFORE
BE EXERCISED TO ENSURE THATANYNEW USERSARE
FAMILIAR WITH THIS REQUIREMENT.
ATTENTION:CETELEPHONE PEUTETRE DESTINE
AUXPERSONNESAYANTDESPROBLEMESD’AUDITION.
IL POSSEDE UN ECOUTEUR A VOLUME VARIABLE. A
LA PREMIERE UTILISATION, ASSUREZ VOUS QUE LE
BOUTONDE REGLAGE DUVOLUME SOIT POSITIONNE
SURLAPOSITIONVOLUME MINIMUM.LESPERSONNES
MALENTENDANTES POURRONT PAR LA SUITE
AUGMENTER LE VOLUME POUR L’ADAPTER A LEUR
AUDITION.
Ampli DECT300Ampli DECT300
Ampli DECT300Ampli DECT300
Ampli DECT300
User guide p.2
Notice d’utilisation p.31
GB
F

2
INDEX PAGE
DESCRIPTION
- Handset and base unit controls 4
GENERALSETTINGS
- How to connect the phone and set the batteries 8
-Charging the batteries 8
-Phonerange 9
-Clean thephone 9
BASESETTINGS
-Baseringer volume 10
HANDSETSETTINGS
- Menu access 11
- Settings icons displayed on the handset 11
-Handset registration 11
-Handsetderegistration 11
-Handset ringervolume, melody and shaker 12
- Earpiece volume setting and tone adjust 12
- Network features, Flash time, Dial pause 13
USINGTHEPHONE
- Making a call 14
- Answering a call 14
- Use the call back features 15
-Delete stored names and numbers 15
-Paging the handset 15
-Timer 15
PHONEBOOK
-Aboutthephone book 16
- Phone book handset ring tone settings 16
- Storing a number with a name 17
- Dialling using the phone book 18
- Modify a phone book entry 18
- Delete a phone book entry 18
-Transfer numbers and names intothe phone book 19
GB

3
ANSWERINGMACHINE
-Answeringmachineprogramming option 20
- How to use the answering machine 21
-Answering machine remote control 23
ADDITIONALHANDSETS
- General settings 24
- Using several handsets ( registration ) 24
- Deregister all additional handsets from the base 25
- Internal calls 25
-Call transfer to another registered handset 26
- Headset- Neck loop option 26
ADDITIONALBASEUNIT
-General settings 27
- How to add a base unit 27
TROUBLESHOOTING 28
GUARANTEE- NORMS 30

4
LCD display
Afficheur LCD
Keypad
Clavier
Amplifier switch
Interrupteur ampli
Shaker switch
Interrupteurvibreur
Speaker
Ecouteur
Microphone
Functionand
phonebookkeys
Touches de fonction et
de répertoire
Amplifierkey
Touche ampli
Tone adjustment
Réglage de la
tonalité
Flash Key
Touche flash
Pick up and hang up key
Touche de décroché et de
raccroché
HANDSET DESCRIPTION
DESCRIPTION DU COMBINE
Answering machine key
Toucherépondeur téléphonique
Ring/Messages light
indicator
Indicateurlumineux de
Sonnerie/Messages
DESCRIPTION
2.5mm socket
Prise jack 2.5mm
( CLA3 , CLA7 option )

5
Amplifier volume
button adjustment
Bouton de réglage
volume ampli
Belt clip
Clip ceinture
Batteries cover
Couvercle de batteries
HANDSET DESCRIPTION
DESCRIPTION DU COMBINE
DESCRIPTION

6
BASE CONTROLS
CONTROLES SUR LA BASE
Pagekey
Touche de pagination
Charge contacts
Contacts de charge
Handset cradle
Support combiné
Charging LED
Voyant de charge
DESCRIPTION

7
BASE CONNECTIONS
CONNECTIONS SUR LA BASE
Ringer volume setting switch
Interrupteurde réglage sonnerie
* Power adaptor socket
* Connecteur adaptateur
secteur
** Line socket
** Connecteur cordon de ligne
(*) Classified “hazardous voltage” according to EN60950 standard.
Classé “tension dangereuse” selon la norme EN60950.
(**) Classified TNV-3 according to EN60950 standard.
Classée TNT-3 selon la norme EN60950
DESCRIPTION

8
GENERAL SETTINGS
1 - HOW TO CONNECT THE PHONEAND SET THE BATTERIES
1 - Plug the adaptor in the power wall socket and the power plug in
the base socket (*).
2 - Connect the line cord plug to the base socket (**).
3 - Connect the line cord to the PTT socket.
4 - Insert the batteries with the correct polarity into the batteries
compartment and replace the battery cover.
5 - Place the handset on the base unit then a short beep will be heard
and the battery symbol will flash on the display, except if the
batteries are totally empty.
NOTE: Do not expose the base to electric equipment likeTV, radio, monitors,
sunlight, heat or other phones...to avoid any disturbances of your phone.
(**)ClassifiedTNV-3 accordingto EN60950standard.
(*)Classified “hazardousvoltage” accordingto EN60950standard
2 - CHARGING THE BATTERIES
The phone is supplied with NiMH rechargeable batteries. In standby mode,
batteries are fully charged around 170 hours and talk time is around 8 hours.
The battery charge icon will flash as long as the phone is being charged
and will stop when the charging process is complete. The phone has an
automaticcharging control to avoid excessive charging.
IMPORTANT: Batteries must be charged during 24 hours before using
the phone for the first time.
Battery charge icon:
Thehandsetdisplay shows whenthebatteries areflatand whena warning
signal is heard. If the phone does not have enough power or is not completly
recharged, it switches itself off automatically until it is returned to the base
unit.

9
GENERAL SETTINGS
3-PHONE RANGE
Thephone radio range can workup to 300 m andradio signal can be affected
by many factors like a wall, obstacles...The maximum range if there are no
obstacles between the phone and the base unit is around 300 m.
If the range is restricted by walls in a house or in the office, the base unit
should be in a slightly elevated position.
Awarningsignal (beep) willbeheard whenthehandset is outof range, thecall
will be stopped if the handset does not come nearer to the base unit.
4 - CLEAN THE PHONE
Cleanthe phonewithasoftcloth.Keepthebaseandhandsetchargingcontacts
clean.Neveruse polishesorcleaning agents-they coulddamage the finishor
the electrics inside.
Note: We advise you to place the telephone on a table cloth or similar, as
rubberfeet can mark some surfaces.
Thunderstorms: unplug your phone from the telephone socket during
thunderstorms because it could damage your phone. Your guarantee does
notcoverthunderstorm damage.

10
BASE SETTINGS
BASE RINGER VOLUME
The base ringer volume can be adjusted by using the slider switch located
on the base rear panel.
Thefollowingsettings are available:
Symbol Function
Off
Low
Normal
High
For product support and help visit our website at
www.geemarc.com
telephone [phone]
or fax [phone]

11
HANDSET SETTINGS
1 - MENU ACCESS
: To activate or deactivate the menu
: To move backward in the menu
: To move forward in the menu
: To confirm a selection
2 -SETTING ICONS DISPLAYED ON THE HANDSET
1 Answering Machine programmin
2 Set ring volume and melod
3 Handset programming
4 Network, flash time and dial
pause settings
5 Earpiece volume adjust
6 Battery charge level
7 CID numbers
8 Phone book Nbr 1
9 ON/OFF line
10 Calltransfer
11 Answering machine
12 Phone book Nbr 2
13 Incoming messag
14 Handset registered on the base
3-HANDSETREGISTRATION
The handset is already registered with the base ( factory setting) , the icon
must be fixed .
Ifthis one flashes that meansthe handsetis notlinked with the base andmust
be registered ( see P 24, “using several handset” )
4-HANDSETDEREGISTRATION
To deregister the handset from the base unit :
- Press key
- Press then key
- Enter the PIN code ( factory setting 1111 ), then press to confirm
The icon flashes , the handset is deregistered
1 2 3 4 5
6 7 8 9 10 11 12 13 14

12
5-HANDSET RINGER VOLUME, MELODY AND SHAKER
To set the volume and melody please follow instructions below:
1 - Press the key.
2 - Press the or the key to select the icon
3 - Press the key to select
4 - Now you can select one of the possibilities below:
Press the to scroll through the menu. If you want to modify entries
press and keys.
1/4++++ for the Ringer volume.
2/4 for the Normal calls ringer melody.
3/4 for the Phone book ringer melody.
4/4 for the Phone book ringer melody.
5 - Press the key to confirm the settings and exit to the menu.
6 - If you want to exit to the menu press .
7- In addition to the ring, you can use the shaker function with the switch
set to the position ( on the handset right side ) .
Note : The different melodies will be active only if you have subscribed
to a caller ID service
6- EARPIECE VOLUME SETTING AND TONE ADJUST
6-1Answeringmachinemode
To set the hearing volume from the earpiece to listen your messages :
- Press the key
- Press the key or to select the icon
- Press the key to confirm
1/1 : from +to ++++ ( low to high )
Select the level with or key
- Press to confirm
- Press the key to exit
HANDSET SETTINGS

13
6-2 Normallistening
Hearing volume can be adjusted in 4 steps on using the button on
the handset rear, press on it successively .
This will modify the setting done for the answering machine .
It also can be more amplified with the button ( on the right side ), set it on
, then press key: lit ( if not, you lose the amplification )
In both cases the button on the left side allows adjustment
to the tone Hi : treble , Lo : bass , but only for the earpiece.
7 - NETWORK FEATURES, FLASH TIME, DIALPAUSE
1 - Press the key.
2 - Press the or the key to select the icon
3 - Press the key to select
4 - You can choose from the menu below:
You can scroll into the menu by pressing the key. Press the or
the key to modify entries, press to confirm modification.
French menu UK menu Meaning
1/5 1/2 : 1 For UK, 2 for France (CID features).
2/5 Tone/Pulse for dialling must be set to Tone.
1/3 3/5 A,B,C,D (Telephone network settings; keep A)
2/3 4/5 Flash time (R key: *** for 100ms ; ****** for 300ms
3/3 5/5 Dial pause (*) : Yes/No
Flash time : France 300ms, other countries 100ms
(*) : To insert a 3 second pause after the first digit dialed ( Yes: activated ;
NO : de-activated ), then the rest is dialed normaly. Used when plugged in at
a private telephone exchange ( in an hotel, an office ...) .
5 - Press the key to exit the menu.
HANDSET SETTINGS

14
USING THE PHONE
1 - MAKING A CALL
From the keypad :
- Dial the phone number you want to call, you can press the key to
cancel an incorrect entry.
- Press the , the number is automatically dialled.
-On completionof thecall simplypress the againto releasethe lineor
put the handset on the base.
You may first press the keythen dial your number but the key
will be without effect .
From stored caller numbers :
Only if you subscrided to the “Caller ID” service
Your telephone saves the 10 last numbers of incoming calls . When the
memory is full , the oldest number is replaced by the latest .
- Press the key
- Use the or key to select the wanted number ( or the name ), if
you
press you can see also the date/time of his call .
- Press the key , the number is dialed
You may exit before dialing : press key
2 - ANSWERING A CALL
When an incoming call is received proceed by:
- Press the key to take the line and speak.
- On completion of the call simply press the again to release the line
or put the handset on the base.
Caller ID display
If you subscrided to the “Caller ID” service, the caller number or name will be
displayed.
Ifyousee ******** symbols,thatmeans yourcallerdoesn’t want tobe identified

15
USING THE PHONE
3 - USE THE CALLBACK FEATURES
You can display the last 5 numbers you dialed
- Press the key and scroll through the list by pressing the or
keys until you select the number you want.
- Press the key to dial the number.
: Exit
: Delete the displayed entry
4-DELETESTOREDNAMESANDNUMBERS
Only if you subscrided to the “Caller ID” service, otherwise the list will be
empty .
- Press the key.
- Select the desired number to delete by pressing the or key. Two
short beeps will be heard when you reach the end of the list.
- Press the key to delete the entry, a short beep will be heard .
- Do it again from step 2 for deleting other entries, otherwise exit on
pressing the key .
5 - PAGING THE HANDSET
If you wish to locate your handset on making it ring, simply follow the
instructions below ( if it is in a valid receiving area )
- Press the key on the base unit located on the base front side, all
the registered handsets paged will ring.
- Press the twice on the located handset to stop the paging mode.
Pressing the key on the base unit has the same effect.
6-TIMER
Atimer will be displayed on the screen after starting the call. You can check
the call length by using this function.

16
PHONE BOOK
(*) You must be subscrided to the “ Caller ID” service from your local
phone company to enjoy principal features of phone books.
1 - ABOUT THE PHONE BOOK
Names and phone numbers can be stored in both phone books. Each phone
numberstored in the phone bookscan becalled bypressing only few buttons.
Thenameandthenumberofthecallerwillbe displayed (*) duringtheincoming
call.The callername willbe displayedif ithas beenstored inone ofthe phone
books.
Each phone book may contain 10 entries.
The entries in both phone books are sorted out by using an alphabetic list.
Eachnamecan contain upto10 charactersandeach phone numbercan have
up to 25 digits.
2 - PHONE BOOK MELODIES SETTINGS
It is possible by a different bell to identify which phone book is being used (*)
by the setting you have done Page 12 .
Non stored numbers : Melody 2/4
Calls from numbers and names in the phone book : Melody 3/4.
Calls from numbers and names in the phone book : Melody 4/4
IMPORTANT :
Even if a caller is stored in a phone book, it can happen that only the normal
ring tone is triggered, in this case caller may have used his or her private
numberfunction.

17
PHONE BOOK
3 - STORING A NUMBER WITH A NAME
Follow instructions below to store new entries in the phone book:
- Enter the phone number you wish to set in the phone book.
- Select one of the two phone books by pressing the or key, a
beep will be heard and the phone book icon selected will flash.
-Enter the corresponding name and number by pressing the corresponding
number key once or twice to select the desired letter (see the table below).
Key Characters
1 [space] - 1
2 A B C 2
3 D E F 3
4 G H I 4
5 J K L 5
6 M N O 6
7 P Q R S 7
8 T U V 8
9 W X Y Z 9
00
* or # To confirm the key and go to another one
Example: forAB pressA*B
- Press the key to store the entry then a beep will be heard to
confirm.
Note: To leave the menupress and hold the key.

18
PHONE BOOK
4 - DIALLING USING THE PHONE BOOK
1 - Select the desired phone book by pressing the or .
2 - Select the desired entry in the list by using the or key .
3 - Press the key then the number will be automatically dialled.
Note: To leave the menu press the or key.
5 - MODIFY A PHONE BOOK ENTRY
1 - Select the desired phone book by pressing the or key.
2 - Select the desired number to modify by pressing the or keys.
3 - Press the key.
4 - The number will be displayed and can be deleted by pressing the
key.
5 - Enter the new number and press the key to store.
6 - DELETE A PHONE BOOK ENTRY
1 - Select the desired phone book by pressing the or key.
2 - Select the desired number to delete by pressing the or keys.
3 - Press the key.
4 - Press the key to delete the entry.
5 - Display will show OK?
5 - Press the to confirm then a beep will be heard, otherwise press
any key 0 to 9 to cancel.
6 - If OK press key or to exit .

19
PHONE BOOK
7 - STORE NUMBERS AND NAMES INTO THE PHONE BOOK
Onlyavailable if you subscrided to the “Callaer ID” service from your local
phone company, otherwise the list will be empty
1 - Press the key.
2 - Select the desired number to store in the phone book by pressing the
or keys. Two short beeps will be heard if you reach the end of the list.
3 - Select the desired phone book in which you want to store the number by
pressing the or key.
4 - Store the name as described Page 17 “ Store a number with a name .
5 - Press the to confirm the storage in the phone book.
For product support and help visit our website at www.geemarc.com
telephone[phone]
or fax [phone]

20
ANSWERING MACHINE
1 - ANSWERING MACHINE PROGRAMMING OPTIONS
To access to the menu press the key then press the key or
use the or keys to select . To set the answering machine
use the table below:
Function Programmable functions Select Default
Nbr
1/5 Modifies the system day List: 1 (Monday) to 7 1
(Sunday)
2/5 Modifies the system time Type value
(00:00 to 23:59) 00:00
3/5 Selects number of rings List: 2, 3, 4, 5, toll saver Toll
saver
4/5 Modifies remote control code Type value
(0000 to 9999) 1111
5/5 Modifies telephone answering List: ****A (top quality), A
machine recording quality ****B (standard quality)
Remotecontrolcode :confidentialIDcodetoactivate/deactivatetheanswering
machineor readyour messasge from another phone.
Toll Saver: this option allows the machine to answer your call after 3 rings if
new messages have been received instead of 5 in case of no new messages
Answering Machine general icons displayed:
- MessagesAnswering Machine icon , it will be displayed when the
answering machine is on.
- Icoming message icon , it will flashes when you have a message.
