Geemarc DALLAS 100 VM User manual

0
DALLAS 100 VM
AMPLIFIED TELEPHONE WITH
OUTGOING VOICE MODULATION
English

1
General Description
DESCRIPTION
Clip for wall
mounting
Line cord
socket*
Indirect
memory
button
Voice
meter
Quick Dial
locations,
M1, M2 and M3
Ringer
Volume
settings
Ringer
tone
setting
Sending
level
amplified
setting
Last
number
redial
Handset
Amplify
Memory
storing key
R button (for
private exchanges)
Handset tone
slide control
Handset volume
slide control
(*) Classified TNV-3 according to EN60950 standard.

2
Rear
Base
DESCRIPTION
Voice level
meter setting
Amplify
default
setting
Dialing
mode
setting
Flash
setting
Telephone
line socket
Thread the line cord
through this groove

3
1 - connecting telephone
1 - Connect the handset cord.
2 - Connect the line cord to the socket located at rear of
telephone then connect the PTT plug*.
2 - Ringer Volume Setting
A switch located on the right side allows the ringer to be
switched to HI, LOW or OFF
3 - Ringer tone setting
A switch located on the right side allows the melody to
be switched to HI, Middle or LOW.
4 - Wall mounting
To wall-mount your telephone, slide out the clip turn
around and slide back into the wall mounting position
(located in the base unit, just below the ear piece).This
will ensure that the handset stays firmly in position.
SETTING UP
(*) Classified TNV-3 according to EN60950 standard.
SETTING UP

4
Make 2 holes in the wall 85mm apart, insert the wall
plugs and the wall mounting screws. The screws should
protrude from wall by 6-7mm. Place the phone onto
the screw-heads and slide down to secure.
5 - Tone/pulse switch (t/p)**
The Tone/Pulse switch is factory pre-set to Tone
position (T).In the UK,all telephone exchanges now use
Tone dialing. If your phone does not dial out it is
probably being used from an older private switch board
(PBX). In this case, the Tone/Pulse switch must be
moved to Pulse (P).
** Please note that this switch is not to be moved after
setting.
SETTING UP

5
1 - Answering incoming call
- When an incoming call is received the phone will ring
and flash. To answer the call lift the handset and speak.
- On completion of the call, carefully replace the handset
in the cradle to release the line.
2 - Volume receiving adjustment
You can increase the volume according to your own
hearing requirements.
Use the button, located on the front side, to adjust
the level according to your own hearing requirements.
3 - Tone receiving adjustment
If the receiver volume has been amplified, the tone
control can also be adjusted. You can adjust and
increase the low frequency or high frequency sounds
with the tone slide control on the front edge of the unit.
USING THE PHONE
USING THE PHONE

6
Note: The tone adjustment function will not be effective
when the receiver volume is set to normal level.
4 - Making a call
- Lift the handset.
- Await the dial tone and dial required number.
- On completion of the call, carefully replace the handset
in the cradle.
5 - Sending level adjustment
If your voice is quiet or called parties have difficulty
hearing you, you can increase the sending level volume
with the switch located on the right side.
6 - Last number redial
- Lift the handset.
- Await the dial tone and press button.
- The previously dialled number will be automaticaly
redialled (not in use for memory numbers).
USING THE PHONE
0db
+4db

7
7 - R , * & # Buttons
These are used with the new services provided on
digital exchanges. For details please contact your
network operator.
8 - Storing telephone numbers
Your phone can store 3 direct and 10 indirect memories
(16 digits maximum for each memory).
- Lift the handset.
- Press button.
- Dial the telephone number you wish to store.
- Press button.
- Press one of the direct memory buttons, M1, M2, M3.
Or press M and any button 0 to 9 on the key pad under
which you wish to store the telephone number in indirect
memory.
- Replace the handset.
Note: Numbers will be lost if you disconnect your phone.
Entering a new number in memory will automatically
erase the previous number.
USING THE PHONE

8
9 - Dialling stored number
- Lift the handset and await the dial tone.
- Press appropriate direct memory button M1, M2, or M3.
The stored number will be dialled out automatically.
Or press the M button followed by the keypad 0 to 9
button under which the desired number is stored. The
stored number will be dialled out automatically.
To register your stored phones numbers, use the index
located on the base.
10 - Voice meter function
Push switch to adjust voice level meter ON
and OFF .
On mode:
When unit is off-hook, the voice meter LEDs inside the
memory card cover will indicate the outgoing voice level
on telephone line.
Off mode:
When unit is off-hook, the voice meter is turned off.
11 - Amplification setting
a. Set the AMPLIFY Switch located at rear side of
unit to ON position, the Amplification is auto on
when handset is lifted.
USING THE PHONE
USING THE PHONE

9
b.Set the AMPLIFY Switch to OFF position,
the Amplification is off when handset is lifted.
12 - Receive volume amplification
When unit is off-hook, press the button to toggle
the amplification On & Off
Amplification On:
When amplification is on, the corresponding LED on,
+15dB extra amplification is applied to the handset
receive volume control.
Amplification Off:
When amplification is off, the corresponding LED is off,
no extra amplification to the handset receive volume
control.
13 - Flash time setting
a.Set the flash Switch located at rear side of unit .set to
100ms position (for UK), the time is auto set in 100ms
mode when handset is lifted.
b.Set the flash Switch to 300ms position (for French),
the time is auto set in 300ms mode when handset is
lifted.
USING THE PHONE

10
General
Do not open the unit. Contact the helpline for all repairs.
The phone is capable of amplifying sounds to a loud volume. It is
important to instruct all potential users of its proper operation. It is
advised to adjust the volume control to its minimum level (Low)
when not in use and alert other users that hearing damage can
potentially result from misuse
Cleaning
Clean the telephone with a soft cloth. Never use polishes or
cleaning agents - they could damage the finish or the electrics
inside.
Environmental
Do not expose to direct sunlight.
Always ensure there is a free flow of air over the surfaces of the
telephone.
Do not place any part of your product in water and do not use it in
damp or humid conditions e.g. bathrooms.
Do not expose your product to fire or other hazardous conditions.
Unplug your phone from the telephone socket during
thunderstorms because it could damage your telephone. Your
guarantee does not cover thunderstorm damage.
The telephone is designed for working within a temperature range
of 5C to 45C.
SAFETY INFORMATION

11
From the moment your Geemarc product is purchased, Geemarc
guarantee it for the period of one year. During this time, all repairs
or replacements (at our discretion) are free of charge. Should you
experience a problem then contact our help line or visit our
website at www.geemarc.com. The guarantee does not cover
accidents, negligence or breakages to any parts. The product
must not be tampered with or taken apart by anyone who is not an
authorized Geemarc representative. The Geemarc guarantee in
no way limits your legal rights.
IMPORTANT: YOUR RECEIPT IS PART OF YOUR
GUARANTEE AND MUST BE RETAINED AND PRODUCED IN
THE EVENT OF A WARRANTY CLAIM.
DECLARATION: Geemarc Telecom SA hereby declares that this
product is in compliance with the essential requirements and other
relevant provisions of the Radio and Telecommunications
Terminal Equipment Directive 1999/5/EEC and in particular article
3 section 1a, 1b and section 2. The telephone does not operate if
the line current is lower than 18 mA.
The declaration of conformity may be consulted at www.geemarc.com
Telephone connection: Voltages present on the
telecommunication network are classified TNV-3
(Telecommunication Network Voltage) according to the EN60950
standard.
Please note: The guarantee applies to
the United Kingdom only
GUARANTEE
GUARANTEE

12
The WEEE (Waste Electrical and Electronic Equipment) has been
put in place for the products at the end of their useful life are
recycled in the best way.
When this product is finished with, please do not put it in your
domestic waste bin.
Please use one of the following disposal options:
- Remove the batteries and deposit them in an appropriate WEEE
skip. Deposit the product in an appropriate WEEE skip.
- Or, hand the old product to the retailer. If you purchase a new
one, they should accept it.
Thus if you respect these instructions you ensure human health
and environmental protection.
For product support and help visit our website at
www.geemarc.com
