Gefen EXT-DVI-141DLBP User manual

DVI DL Booster PLUS
Extend the range of your Dual-Link video -- with increased signal
robustness
Like our DVI DL Booster, the new DVI DL Booster Plus allows the extension of massive desktop
resolutions over dual-link digital video cable well beyond its default limit of a 15-foot distance.
Without such a device, sparkles or other objectionable mutations of the video signal can appear.
Such degradations are completely unacceptable, especially where computer applications are
concerned, where desktop images must be sharp, clear and bright for productive work to take
place.
The DVI DL Booster Plus uses a plug-in power supply which helps to extend sparkling clear video
images to great distances (up to 200 feet at 2560x1600). Rest assured that with this product, you
can enjoy your computer desktop as if the computer was in the same room as the display.
With the new Plus model, improved DDC signal robustness is added, giving robustness to electrical
signals that negotiate delicate resolution and frequency settings, for even greater precision than
ever before.
To go beyond the limited inherent DVI distance or if you'd like to use two or more cables, our
Boosters are a perfect option. They replicate digital video signals, enabling you to "daisy chain"
cables and Boosters as far as you need to go.
How It Works
This plug and play installation takes mere seconds. Simply place the DVI-DL Super Booster Plus in
the middle of two Dual-Link cables or at the end of a long DVI-DL cable extension. Make sure all
video cables are connected properly at the source and destination ends. Attach the power cable to
the DVI-DL Super Booster Plus. Power up (or restart) all equipment. You should now see flawless
video at your remote desktop. That's all there is to it!
Note: The DVI-DL Super Booster Plus is HDCP pass-through.
Features:
zPerfects video sent over long stretches of Dual-Link DVI cables
zExtends DVI Dual Link displays away up to 200 feet
zSupports resolutions up to 3840x2400 @ 60 Hz
zSupports DDWG standards for DVI compliant monitors
zDDC Signal is amplified for better robustness when interfacing
zHDCP compliant
Specifications:
zVideo Amplifier Bandwidth: 2 x 165 MHz
zInput Video Signal: 1.2 volts p-p
zInput DDC Signal: 5 volts p-p (TTL)
zDual Link Range: up to 3840x2400 @ 60 Hz
zDVI Connector: DVI-I (29 pin) female (digital only)
zPower Supply: 5V DC
zPower Consumption: 5 watts (max)
zDimensions: 1.75"W x 1"H x 1.875"D
zShipping Weight: 1 lb.
Package Includes:
z1x 5V DC power supply
z1x Users Manual
Dystrybucja i sprzedaż: Meditronik Sp. z o.o.
02-952 Warszawa, ul. Wiertnicza 129, tel. [phone], fax [phone]
http://www.meditronik.com.pl e-mail: [email protected]
EXT-DVI-141DLBP

www.gefen.com
DVI DL Super
Booster Plus
EXT-DVI-141DLBP
User Manual
www.gefen.com
DVI DL Super
Booster Plus
EXT-DVI-141DLBP
User Manual

Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
[email protected]
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any accompanying
documentation without prior written notice.
DVI DL Super Booster Plus is a trademark of Gefen Inc.
© 2008 Gefen Inc., All Rights Reserved
All trademarks are the property of their respective companies
Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
[email protected]
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any accompanying
documentation without prior written notice.
DVI DL Super Booster Plus is a trademark of Gefen Inc.
© 2008 Gefen Inc., All Rights Reserved
All trademarks are the property of their respective companies
ASKING FOR ASSISTANCE
ASKING FOR ASSISTANCE

CONTENTS
CONTENTS
1 Introduction
2 Features
3 Panel Layout
4 Connecting And Operating The DVI DL Super Booster Plus
5 Dip Switch Location
6 Specifications
7 Warranty
1 Introduction
2 Features
3 Panel Layout
4 Connecting And Operating The DVI DL Super Booster Plus
5 Dip Switch Location
6 Specifications
7 Warranty

1
1
INTRODUCTION
Congratulations on your purchase of the DVI DL Super Booster Plus. Your complete satisfaction is very
important to us.
Gefen
Gefen delivers innovative, progressive computer and electronics add-on solutions that harness
integration, extension, distribution and conversion technologies. Gefen’s reliable, plug-and-play products
supplement cross-platform computer systems, professional audio/video environments and HDTV
systems of all sizes with hard-working solutions that are easy to implement and simple to operate.
The Gefen DVI DL Super Booster Plus
The DVI DL Booster Plus uses a plug-in power supply which helps to extend sparkling clear video im-
ages to great distances (up to 200 feet at 2560x1600). Rest assured that with this product you can enjoy
your computer desktop as if the computer was in the same room as the display.
To go beyond the limited inherent DVI distance or if you’d like to use two or more cables, our Boosters
are a perfect option. They replicate digital video signals, enabling you to “daisy chain” cables and Boost-
ers as far as you need to go.
How It Works
This plug and play installation takes mere seconds. Simply place the DVI-DL Super Booster Plus in
the middle of two Dual-Link cables or at the end of a long DVI-DL cable extension. Make sure all video
cables are connected properly at the source and destination ends. Attach the power cable to the DVI-DL
Super Booster Plus. Power up (or restart) all equipment.
Congratulations on your purchase of the DVI DL Super Booster Plus. Your complete satisfaction is very
important to us.
Gefen
Gefen delivers innovative, progressive computer and electronics add-on solutions that harness
integration, extension, distribution and conversion technologies. Gefen’s reliable, plug-and-play products
supplement cross-platform computer systems, professional audio/video environments and HDTV
systems of all sizes with hard-working solutions that are easy to implement and simple to operate.
The Gefen DVI DL Super Booster Plus
The DVI DL Booster Plus uses a plug-in power supply which helps to extend sparkling clear video im-
ages to great distances (up to 200 feet at 2560x1600). Rest assured that with this product you can enjoy
your computer desktop as if the computer was in the same room as the display.
To go beyond the limited inherent DVI distance or if you’d like to use two or more cables, our Boosters
are a perfect option. They replicate digital video signals, enabling you to “daisy chain” cables and Boost-
ers as far as you need to go.
How It Works
This plug and play installation takes mere seconds. Simply place the DVI-DL Super Booster Plus in
the middle of two Dual-Link cables or at the end of a long DVI-DL cable extension. Make sure all video
cables are connected properly at the source and destination ends. Attach the power cable to the DVI-DL
Super Booster Plus. Power up (or restart) all equipment.
INTRODUCTION

2
2
FEATURES
Features
Perfects video sent over long stretches of Dual-Link DVI cables•
Extends DVI Dual Link displays away up to 200 feet•
Supports resolutions up to 3840x2400 @ 60 Hz•
Supports DDWG standards for DVI compliant monitors•
DDC Signal is amplified for better robustness when interfacing•
HDCP compliant•
Package Includes
(1) DVI DL Super Booster Plus
(1) 5V DC Power Suppy
(1) User’s Manual
Features
Perfects video sent over long stretches of Dual-Link DVI cables•
Extends DVI Dual Link displays away up to 200 feet•
Supports resolutions up to 3840x2400 @ 60 Hz•
Supports DDWG standards for DVI compliant monitors•
DDC Signal is amplified for better robustness when interfacing•
HDCP compliant•
Package Includes
(1) DVI DL Super Booster Plus
(1) 5V DC Power Suppy
(1) User’s Manual
FEATURES

3
3
PANEL LAYOUT
PANEL LAYOUT

4
4
CONNECTING AND OPERATING THE DVI DL SUPER BOOSTER PLUS
How to Connect the DVI DL Super Booster Plus
Connect the long DVI cable from the source into the “DVI In” on the front of the DVI DL Super1. Booster Plus. The DVI DL Super Booster Plus is placed next to your display to regenerate the DVI
signal.
Connect a short DVI cable from the “DVI Out” connection in the back of the DVI DL Super Booster2. Plus to your display or projector
Plug the 5V DC power supply into the DVI DL Super Booster Plus.3.
Plug the 5VDC wall mount power supply into the wall outlet.4.
Manual Equalization
There are service Dip Switches located on the underside of the unit. To access these Dip Switches
remove the metallic colored tape covering them. Dip Switch 1 relates to equalization and Dip Switch 2
is not used. By default, the DVI DL Super Booster Plus is set to auto equalization (Dip Switch 1 in the
OFF position). Use this setting for ease of setup as this mode will automatically tune out unwanted video
noise. No manual adjustments to the EQ can be made in this mode using the EQ Trim Pot on the front
of the unit. If video noise is present in automatic EQ mode, go to manual EQ mode by turning Dip Switch
1 to the ON position and manually tune the signal using the EQ Trim Pot on the front of the unit. Adjust
the EQ Trim Pot on the front of the unit to eliminate video noise by inserting a small flat-head tool into
the Trim Pot port. Turn the Trim Pot in very small increments to EQ the video signal until all video noise
is eliminated.
How to Connect the DVI DL Super Booster Plus
Connect the long DVI cable from the source into the “DVI In” on the front of the DVI DL Super1. Booster Plus. The DVI DL Super Booster Plus is placed next to your display to regenerate the DVI
signal.
Connect a short DVI cable from the “DVI Out” connection in the back of the DVI DL Super Booster2. Plus to your display or projector
Plug the 5V DC power supply into the DVI DL Super Booster Plus.3.
Plug the 5VDC wall mount power supply into the wall outlet.4.
Manual Equalization
There are service Dip Switches located on the underside of the unit. To access these Dip Switches
remove the metallic colored tape covering them. Dip Switch 1 relates to equalization and Dip Switch 2
is not used. By default, the DVI DL Super Booster Plus is set to auto equalization (Dip Switch 1 in the
OFF position). Use this setting for ease of setup as this mode will automatically tune out unwanted video
noise. No manual adjustments to the EQ can be made in this mode using the EQ Trim Pot on the front
of the unit. If video noise is present in automatic EQ mode, go to manual EQ mode by turning Dip Switch
1 to the ON position and manually tune the signal using the EQ Trim Pot on the front of the unit. Adjust
the EQ Trim Pot on the front of the unit to eliminate video noise by inserting a small flat-head tool into
the Trim Pot port. Turn the Trim Pot in very small increments to EQ the video signal until all video noise
is eliminated.
CONNECTING AND OPERATING THE DVI DL SUPER BOOSTER PLUS

DIP SWITCH LOCATION
DIP SWITCH LOCATION
5
5

6
6
SPECIFICATIONS
Video Amplifier Bandwidth .......................................................................................................2 x 165 MHz
Input Video Signal ................................................................................................................... 1.2 Volts p-p
Input DDC Signal .............................................................................................................. 5 volts p-p (TTL)
Maximum Dual Link Range .......................................................................................... 3840 x 2400 x 60hz
DVI Input/Output Connector Type ........................................................................................ DVI-D (29 pin)
Power Consumption .............................................................................................................. 5 Watts (max)
Power Supply…………………….. ..................................................................................................... 5V DC
Dimensions ..................................................................................................................... 2”W x 1”H x 2.5”D
Shipping Weight ................................................................................................................................. 2 Lbs
Video Amplifier Bandwidth .......................................................................................................2 x 165 MHz
Input Video Signal ................................................................................................................... 1.2 Volts p-p
Input DDC Signal .............................................................................................................. 5 volts p-p (TTL)
Maximum Dual Link Range .......................................................................................... 3840 x 2400 x 60hz
DVI Input/Output Connector Type ........................................................................................ DVI-D (29 pin)
Power Consumption .............................................................................................................. 5 Watts (max)
Power Supply…………………….. ..................................................................................................... 5V DC
Dimensions ..................................................................................................................... 2”W x 1”H x 2.5”D
Shipping Weight ................................................................................................................................. 2 Lbs
SPECIFICATIONS
