Gefen Composite Extender User manual

Composite
Extender
USER MANUAL
www.gefen.com

Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff Street
Chatsworth, CA 91311
www.gefen.com
[email protected]
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
Composite Extender is a trademark of Gefen Inc.
© 2007 Gefen Inc., All Rights Reserved
ASKING FOR ASSISTANCE

TABLE OF CONTENTS
INTRODUCTION
FEATURES
INSTALLATION INSTRUCTIONS
CAT5 WIRING DIAGRAM
WIRING DIAGRAM
SPECIFICATIONS
WARRANTY
1
2
3
4
5
6
7

Thank you for purchasing the Composite Extender by Gefen, Inc.
The Composite Extender allows users to extend Composite video signals beyond theA/V
rack. The Composite Extender Series can be used to extend a Composite signal to cover
the distances up to 330 feet. Industry standard Category 5e (CAT-5e) cable is used for
the extension.
HOW IT WORKS
The Composite Extender sender resides next to the TV source. With the supplied
Composite cable, the Composite Extender sender is connected to the source. The
Composite Extender receiver is then placed next to the monitor or projector. Industry
standard Category 5e (CAT-5e) cable is used to link the Composite Extender sender and
Composite Extender receiver together.
INTRODUCTION
1
READ THESE NOTES BEFORE INSTALLING
OR OPERATING THE COMPOSITE EXTENDER SYSTEM
• Use industry standard Category-5e (CAT-5e) cable to operate the Composite Extender
system. CAT-5e cable is preferred.
• Please connect all the cables between the source and the Composite Extender before
powering up the Composite Extender unit.
• The Composite Extender units are housed in a metal box for better RF shielding.
OPERATION NOTES

Features
• Extends Composite video up to 330 feet
• Power only required only on transmitter.
• Plug & Play installation.
• One CAT5 Cable for extension.
• No Loss of Quality.
Includes:
Composite Extender sender unit
Composite Extender receiver unit
5V DC power supply
2x VGA to Composite Cables (6 feet)
VGA F-F Adapter
User’s Manual
FEATURES
2

Use the included VGA to Composite Cable and VGA F-F Adapter to connect the
Composite output of your TV source to the VGAinput on the Composite
Extender Sender Unit.
Use the second VGA to Composite Cable to connect the Composite input of your
display or projector to the VGA output on the Composite Extender Receiver Unit.
Connect the CAT-5 cable between the Composite Extender sender and receiver’s
CAT-5 input.
Power on both the HDTV source and display
Plug the 5 volt power supply into the sender unit. The Composite Extender
receiver will draw power from the sender.
INSTALLATION INSTRUCTIONS
1.
2.
3.
4.
5.
3
Note: Any of the 3 RCA lines can be used for video and remaining two will be for audio.
Both ends will need to be matched for the signal to be passed through correctly.

White/Orange
Orange
White/Green
Blue
White/Blue
Green
White/Brown
Brown
RJ-45 Jack RJ-45 Jack
2 3 4 5
6
7 8 1
2 3 4 5
6
7 8 1
1818
CAT5 WIRING DIAGRAM
4

Video Amplifier Bandwidth .................................................................................. 350 MHz
Input Video Signal ......................................................................................... 1.2 Volts p-p
Video In .................................................................................................................. HD-15
Focus ............................................................................................................ 25 to 450 FT
Video out ............................................................................................................... HD-15
Link Connector ........................................................................................................ RJ-45
Power Consumption ............................................................................................... 1 Amp
Power Supply ......................................................................................................... 5V DC
Dimensions .................................................................................... 1.9”H x 1.6”W x 3.5”D
Shipping Weight ....................................................................................................... 2 lbs.
SPECIFICATIONS
6

Gefen Inc. warrants the equipment it manufactures to be free from defects in
material and workmanship.
If equipment fails because of such defects and Gefen Inc. is notified within one
(1) year from the date of shipment, Gefen System will, at its option, repair or replace
the equipment, provided that the equipment has not been subjected to mechanical,
electrical or other abuse or modifications.
Equipment that fails under conditions other than those covered will be repaired at the
current price of parts and labor in effect at the time of repair. Such repairs are warranted
for ninety (90) days from the day of shipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including without
limitation, any implied warranty or merchantability or fitness for any particular purpose,
all of which are expressly disclaimed.
The information in this manual has been carefully checked and is believed to be
accurate. However, Gefen Inc. assumes no responsibility for any inaccuracies that
may be contained in this manual. In no event will Gefen Inc., be liable for direct,
indirect, special, incidental, or consequential damages resulting from any defect
or omission in this manual, even if advised of the possibility of such damages. The
technical information contained herein regarding the Composite Extender features and
specifications is subject to change without notice.
WARRANTY
7
