The GRSE Series Environmental Monitoring Units provide remote environmental monitoring and
alarming capability needed to detect climate conditions in data centers. The GRSE Series
environmental monitoring units are equipped with a built-in web server. Web pages, including
graphs, are generated by the unit to monitor environmental conditions within the cabinet. No
software other than a web browser is required for operation and several data formats are
available. In GRSE Series units, built-in sensors monitor Temperature, Relative Humidity,
Airflow, Light Level and Sound Level. Optional external sensors and network cameras are also
available. The GRSE Series is available in two different versions; the GRSE2X16 and GRSE-B.
The GRSE2X16 and GRSE-B are identical except for the scrolling LCD display and alarm buzzer
features of the GRSE2X16.
Environmental
Temperature
Operating: 10°C (50°F) min 45°C (104°F) max
Storage: -25°C (-13°F) min 65°C (149°F) max
Humidity
Operating: 5% min 95% max (non-condensing)
Storage: 5% min 95% max (non-condensing)
Elevation
Operating: 0 m (0 ft) min 2000 m (6561 ft) max
Storage: 0 m (0 ft) min 15240 m (50000 ft) max
Electrical
6-12 Volts DC, 2 Amps
Networking
Protocols
HTTP, HTTPS (SSL/TLS), SMTP, POP3, ICMP, DHCP, TCP/IP, NTP, Telnet, Syslog
Ethernet Link Speed
10 Mbit; half-duplex
Data Formats
HTML, SNMP, CSV/Plain Text, XML

GM1089
4
Revision Date: 5/8/2012
EMC Verification
This Class A device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired
operation.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
Warning: Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.

GM1089
5
Revision Date: 5/8/2012
Installation
Guidelines
If the Environmental Monitoring Unit is installed in a cabinet the ambient temperature of the
rack should be no greater than 45C.
Install the Environmental Monitoring Unit such that the amount of airflow required for safe
operation of equipment is not compromised.
Mount the Environmental Monitoring Unit so that a hazardous condition is not achieved due
to uneven mechanical loading.

GM1089
6
Revision Date: 5/8/2012
Mounting
Figure 1: 19" Horizontal/Panel Mount Brackets (7938)
Using the 19” horizontal/panel mount brackets, attach Environmental Monitoring Unit to rack as
shown

GM1089
7
Revision Date: 5/8/2012
Network Overview
This product comes preconfigured with a default IP address set. Simply connect to the
Environmental Monitoring Unit and access the web page with your browser.
Default IP Address
GRSE Series units have a default IP address for initial setup and access to the unit if the
assigned address is lost or forgotten. Once an IP address is assigned to a unit, the default IP
address is no longer active. To restore the default IP address, press the reset button located
below the network connector and hold for approximately 20 seconds. The idle and activity
lights on the network connector will both light up when the IP address has been reset. The
reset button is accessed through the white, circular hole located below the Ethernet jack.
Note: Pressing the reset button under the network connector will restore the default IP address
and will also clear all password settings.
The Configuration page allows you to assign the network properties or use DHCP to connect to
your network. Access to the unit requires the IP address to be known, so use of a Static IP or
reserved DHCP is recommended. The default address is shown on the front of the unit:
IP Address: 192.168.123.123
Subnet Mask: 255.255.255.0
Gateway: 192.168.123.1
Initial Setup
Connect the GRSE Series unit to your computer using a crossover cable or hub/switch.
Windows XP
On your computer, go to “Start > Settings > Control Panel > Network and Dial Up
Connections”
Right click on “Local Area Connection” and select “Properties”
Select “Use the following IP address”. Use these settings:
IP Address: 192.168.123.1
Subnet Mask: 255.255.255.0
Gateway: Leave blank
Click “OK” twice.
The unit should now be accessible in a web browser via the unit’s permanent IP address:
http://192.168.123.123/. See Unit Configuration (page 21) for details.

GM1089
8
Revision Date: 5/8/2012
Figure 2: Network settings for initial setup.
MacOS X Leopard
Open System Preferences via the Dock or the Apple menu.
Select “Network” under “Internet & Network.”
Select “Ethernet” from the list on the left side of the window and enter these settings on the
right side of the window:
Configure: Manually
IP Address: 192.168.123.1
Subnet Mask: 255.255.255.0
Router: Leave blank
Hit “Apply” and confirm the changes.
The unit should now be accessible in a web browser via the unit’s permanent IP address:
http://192.168.123.123/. See Unit Configuration (page 21) for details.

GM1089
9
Revision Date: 5/8/2012
Figure 3: MacOS X network settings for initial setup

GM1089
10
Revision Date: 5/8/2012
Web Interface
Overview
The unit is accessible via a standard, unencrypted HTTP connection as well as an encrypted
HTTPS (SSL) connection. The following web pages are available:
Sensors Page
The front page, Sensors, gives both instantaneous and historical views of the unit’s data. Real
time readings are provided for all sensor data next to historical graphs.
Optional cameras may be added and their live snapshots are shown on this page. Plug-and-
play sensors appear below the internal sensors when attached.
The menu bar allows access to the rest of the Environmental Monitoring Unit’s functionality.
Figure 4: Sensors Page –Power Strip Circuit Data

GM1089
11
Revision Date: 5/8/2012
Figure 5: Sensors Page –Group and Sensor Data

GM1089
12
Revision Date: 5/8/2012
Logging Page
The Logging page allows the user to access the historical data by selecting the desired sensors
and time range to be graphed. Selected sensor values are logged into the data file at a rate of
one point per minute. Please note that although data is logged once per minute, all sensor data
used in the real time display and alarm functions is read at least once every 5 seconds for
internal sensors and once every 30 seconds for external sensors. On GRSE2X16 units only,
checked readings are displayed on the LCD module. Recorded data is available for download in
a comma-separated values (CSV) file.
Figure 6: Logging Page

GM1089
13
Revision Date: 5/8/2012
Display Page
The Display page allows the user to assign friendly names to internal and attached sensors as
well as change the default temperature unit of measure for sensors. The display page also
allows the user to select between the default and classic web page layouts. The default
interface displays a vertical menu bar to the left of the main window, while the classic interface
displays a horizontal menu bar across the top of the screen.
Figure 7: Display Page

GM1089
14
Revision Date: 5/8/2012
Alarms Page
The Alarms page allows the user to establish alarm conditions for each sensor reading. Alarm
conditions can be established with either high or low trip thresholds. The alarms are displayed
in different sections based on the device the alarm is associated with. Alarm options include a
local Buzzer (GRSE2X16 units only), Email and SNMP Trap. See Alarms (page 27) for details.
Figure 8: Alarms Page

GM1089
15
Revision Date: 5/8/2012
Configuration Page
The Configuration page has five sub-tabs; Network, Monitoring, Diagnostics, Event Log, and
Admin. See Unit Configuration (page 21) for details.
Configuration Network Tab
The user can enter and update the network settings on the Network tab of the Configuration
page. See Unit Configuration section for details.
Figure 9: Configuration Network Tab

GM1089
16
Revision Date: 5/8/2012
Configuration Monitoring Tab
The user can enter and update the email alert, SNMP, and camera settings on the
Monitoring tab of the Configuration page. See Unit Configuration section for details.
Figure 10: Configuration Monitoring Tab

GM1089
17
Revision Date: 5/8/2012
Configuration Diagnostics Tab
The user can update the Syslog settings on the Diagnostics tab of the Configuration page.
Figure 11: Configuration Diagnostics Tab

GM1089
18
Revision Date: 5/8/2012
Configuration Event Log Tab
The user can view the Event Log and update the Memory Syslog settings on the Event Log
tab of the Configuration page.

GM1089
19
Revision Date: 5/8/2012
Figure 12: Configuration Event Log Tab

GM1089
20
Revision Date: 5/8/2012
Configuration Admin Tab
The user can set the system clock and administrative information on this tab. Additionally
the user can set administrator and account passwords. See Unit Configuration section for
details.
Figure 13: Configuration Admin Tab
