Gembird BTSHS-001 User manual

Bluetooth stereo headset
BTSHS-001 Bluetooth stereo headset

Bluetooth stereo headset
Disclaimer
•We spared no efforts to make sure that the information in this manual is correct and
complete. However no liability is accepted for any errors or omissions. Gembird
Electronics reserves the right to change the specifications of the hardware and
software described in this manual without prior notice.
•No part of this manual may be reproduced transmitted or translated in any language
in any form by any means without the prior written permission of Gembird
Electronics Ltd.
•Gembird Electronics makes no warranties for damages resulting from corrupted or
lost data due to a mistaken operation or malfunction of the product the software
personal computers or peripheral devices.
Gembird® is a registered trademark of Gembird Europe.
Other names or products not mentioned above may be registered trademarks or
trademarks of their respective owners.
Copyright © 1997-2006 Gembird Electronics Ltd. All rights reserved.

Bluetooth stereo headset
Introduction
Thank you for buying our Bluetooth stereo headset! This manual
will help you install it properly.
Features
•Enjoy high-quality stereo music
•Voice dialling
•Last number redial
•Call answering and rejecting
•Clip-on comfortable case
Specifications
•Standard: Bluetooth v.1.2
•Chipset: BlueCore3 Multimedia single chip
•Compatibility: General headset and Bluetooth cell phones
BTSHS-001 User manual

Bluetooth stereo headset
•Radio performance: Class 2
•Carrier frequency: 2.4-2.480GHz
•Sensitivity: <= -75dBm
•Spread spectrum: 10 meters
•Profiles supported: A2DP headset hands free
•Charger: input 100-240VAC output 5VDC
•Battery: rechargeable Li-polymer 120mAh
•Charging time: up to 3hrs
•Talking time: up to 5hrs
•Standby time: up to 150hrs
•Weight: 17g (including battery)
•Dimensions (LxWxH): 50x23x19mm

Bluetooth stereo headset
Package contents
•Bluetooth stereo headset
•Stereo earphones
•Travel charger
•USB charge cable
•User manual
System requirements
Bluetooth enabled computer (with adapter and software driver
installed) or mobile phone:
•supporting "Headset" and "Hands free" Bluetooth profiles
•supporting "A2DP" Bluetooth profile for stereo sound

Bluetooth stereo headset
Buttons
Descrip
tions

Bluetooth stereo headset
Start use
Please use your headset according to the following simple
steps:
•Charge headset's battery
•Connect the headset with Bluetooth enabled mobile
phone
Charge headset
The headsets have a rechargeable battery inside it. Before
using the headset for the first time we suggest charging the
device thoroughly first. Plug the charger into the headset's
electronic socket. The red indicator will flash while charging.
•Charge headset's battery
•Connect the headset with Bluetooth function mobile
phones
The standard charging time: To charge the battery for the
first time it will generally take 3 hours. After recharging
completely the red indicator light will turn off. Unplug the

Bluetooth stereo headset
charger from the headset. Press down on the multi-function
button for 4 seconds will start the headset. Please read the
section of "Start and close headset"
Conversation, Id e and stereo broadcasts time: After
recharging the battery thoroughly it can run up to 5 hours
stay standby for 150 hours and has a stereo playing time up
to 5 hours.
When the battery power is weak: When the headset is
turned on and the power is weak a red indicator will flash and
send out a beeping sound once every minute. Please refresh
the battery according to the above mentioned step.
Start the headset
Press down multi-function button for 4 seconds. The blue
lights gleam quickly three times and it sends out a beeping
sound. A blue indicator will start flashing.
Attention: Start headset each time please press

Bluetooth stereo headset
multi-function button again once. Restart connecting with the
headset and mobile phone.
C ose the headset
Press down multi-function button for 8 seconds. The blue light
gleams quickly in two times and there will be a beeping
sound. Then the blue indicator will stop flashing.
Connecting headset and mobi e phone
Before the first use you need to pair the headset with the
Bluetooth function mobile phone:
1. Put the headset and the mobile phone within the
scope of one meter of each other.
2. Assure the headset is already closed.
3. Press down on the multi-function button for 5 seconds
a red/blue indicator of the headset will flash
alternatively.
4. Activate the Bluetooth function of the mobile phone

Bluetooth stereo headset
according to its user manual.
5. Roll over the menu and look for a screen showing
Bluetooth equipment and choose the headset.
6. Set the pairing key "0000" and press "OK". After
pairing successful a blue indicator will flash quickly
once. You will then hear a beeping sound.
7. Press "Return" menu on the mobile phone. The mobile
phone screen will show the headset diagram. You can
use the headset to dial a telephone number or answer
the phone call now.
Attention: When trying to pair the headset and the mobile
phone can not be completed in 2 minutes the blue indicator
of the headset will flash and then go into idle mode sending
out three beeps. The headset will then turn off. Please repeat
step 2-7.
Answer Ca ing
When you have an incoming call the headset will send out a

Bluetooth stereo headset
bell ring. Press the multi-function button: you will answer the
phone call such as using the mobile phone. While listening to
stereo music and you have an incoming phone call press the
multi-function key once: you can answer the call immediately.
After finishing the conversation the headset will continue to
play music.
Terminate Conversation
Press multi-function once to finish the conversation.
Ca Rejecting
If you want to refuse the phone call you just press down the
volume button for several seconds until hearing 2 beeps.
Latest ca re-dia ing
Press multi-function button for 3 seconds you can listen beep
sound at the same time your mobile phone will pop up the
last phone number dialled press the multi-function button
again for 1 second to call out.
Voice dia

Bluetooth stereo headset
If your mobile phone has the voice dial function you just
need to press the multi-function button of the headset a
when you hear one beeping sound you can then speak.
Attention: The above function is applicable to the mobile
phone having the Bluetooth function. If you want to acquire
more information please read you’re the user manual of your
mobile phone.
Adjust the headset vo ume
Taping the volume button and find your volume.
Troub e shooting
If you can not connect the headset and mobile phone please
try the following steps:
•Insure the headset has been started already and
power has been charged enough
•Insure the headset has been paired with the mobile
phone already

Bluetooth stereo headset
•The Bluetooth function in the mobile phone has been
activated already
•Insure the headset is used within the scope of 10
meters from the mobile phone and there is no
blockage such as a wall or other electronic equipment.
