GEMMA TECHNICAL HELIOS STELLAR User manual

BUOYANCY COMPENSATOR
STELLAR
USER’S MANUAL
사용자 메뉴얼
使用
说明书

2| GEMMA TECHNICAL
© 2015 Gemma Technical Co., Ltd. All rights reserved.
This document is copyright and contains confidential information that is the property of Gemma Technical
Company Limited. Any reproduction, retransmission, republication, stored in a retrieval system, translated
into any language in any form by any means, or other use of all or part of this document is expressly
prohibited, without prior written consent from Gemma Technical Co., Ltd.
Helios is a registered trademark of Gemma Technical Co., Ltd.
본매뉴얼은 대한민국 저작권법에 의해 보호를 받는 저작물이므로 이를 무단 이용하는 경우 저작권법
등에 따라 법적 책임을 질수있습니다. 무단전재와 무단 복제를 엄금합니다.
本说明书受著作法律保护，擅自使用会依法追究法律责任，严禁擅自转载和复制。
Legal Disclaimer
Gemma Technical Co., Ltd. aims to make the information on this document as accurate as possible.
Gemma Technical Co., Ltd. does not make any claims, promises or guarantees about the accuracy,
completeness, or adequacy of the contents of this document, and expressly disclaims liability for errors and
omissions in its contents. Information in this document is for general information purposes only. Gemma
Technical Co., Ltd. disclaims and excludes any liability for incidental or consequential damages.
본매뉴얼에 포함된 내용은 일반적인 안내를 위한 것입니다. 제공되는 모든 내용은 완성도, 정확도
또는 이정보를 사용하여 발생하는 결과, 우발적 손해 또는 결과적 손해에 대하여 (주) 젬마테크니칼은
어떠한 보증도 책임도 제공하지 못합니다.
本说明书所包含的内容是为了说明一般情况，所提供的内容完成度，精准度，以及根据这些信息操作时产生
的结果及偶发性损害，我公司不负担任何责任。

3| HELIOS
PREFACE
머리말 绪论
HELIOS Backplate & Wing (BP&W) System Buoyancy Compensators are designed to provide
sufficient buoyancy to float at the surface and help you maintain neutral buoyancy in a face-
down horizontal position underwater. HELIOS Backplate & Wing System Buoyancy
Compensators are designed to provide comfort in recreational scuba diving. Our BCs have
been constructed from high quality rugged materials for best performance and reliability.
헬리오스 백플레이트 + 윙부력조절장치는 다이버가 수중에서는 균형감 있는 자세로 중성
부력을 유지하고, 수면에서는 충분한 부력으로 떠있을 수있도록 도움을 드리고자 설계된
제품입니다. 간결하면서 안정감을 더해주는 디자인으로 레크레이션 다이빙을 더욱
편안하게 즐길 수있습니다. 최고의 성능과 신뢰성을 위해 헬리오스 백플레이트+윙
부력조절장치는 내구성이 뛰어나고 강한 고품질 재질로 견고하게 만들어 졌습니다
HELIOS 浮力调整器能使潜水员在水中保持平衡的中性浮力的姿势，也可帮助潜水员在水面上
浮起。简单及安全的设计使您能更好的享受休闲潜水带来的快乐。为了最高的性能和信赖性，
HELIOS 浮力调整器使用高强度的材料制成，坚固耐用。
PLEASE CAREFULLY READ ALL CONTENTS OF THIS USER MANUAL BEFORE USING
THIS BUOYANCY COMPENSATOR.
제품을 사용하기 전에 메뉴얼을 읽고 올바르게 사용해 주십시오
在使用本产品前，请仔细阅读本说明书，并正确使用。
DO NOT USE THIS BUOYANCY COMPENSATOR UNLESS YOU ARE A CERTIFIED
SCUBA DIVER AND HAVE SUCCESSFULLY COMPLETED TRAINING COURSES BY
RECOGNIZED TRAINING & CERTIFICATION AGENCIES.
전문 스쿠버 다이빙 교육기관으로부터 올바른 교육과정을 이수한 자격증 취득자만
헬리오스 백플레이트 + 윙부력장치 를사용하실 수있습니다
只有从专门的潜水教育机构正确的学习并取得资格证的人才能使用 HELIOS 浮力调整器。

4| GEMMA TECHNICAL
For further questions regarding HELIOS Buoyancy Compensators and other HELIOS products,
please contact us below:
헬리오스 백플레이트 + 윙부력장치 또는 기타제품관련 추가 문의사항은 아래로 연락
주시기 바랍니다
关于 HELIOS 浮力调整器货其他产品相关的问题，请与以下地址联系。
International
GEMMA TECHNICAL CO., LTD
Helios Scuba Division
1585 Seohaean-Ro, Siheung-si
Gyeonggi-Do, Korea 14902
Tel: [phone]
[e-mail]
한국어
(주)젬마테크니칼
헬리오스 스쿠버 사업부
경기도 시흥시 서해안로 1585
대한민국 (우편번호: 14902)
전화: [phone]
[e-mail]
中文
HELIOS 潜水设备中国部
山东省烟台市芝罘区黄务街道办事处东里村基督大街 99 号
Tel: [phone]
www.helios-scuba.com.cn

5| HELIOS
TABLE OF CONTENTS
목차
目录
Important Safety Instructions, Warnings, and Precautions 6
STELLAR A1 Backplate & Wing Full System Configuration
8
A1 Harness Assembly Guide 10
Crotch Strap Mounting Guide
16
STELLAR Backplate & Wing Assembly Guide
17
How to Use the Power Inflator
22
Care & Maintenance
24
Frequently Asked Questions
25
Warranty
26
Service & Maintenance Records 71
Product Registration
72
Product Registration Form
75
주요 안전 지침, 경고 및주의사항 28
스텔라 A1 시스템 백플레이트 + 윙구성도 30
A1 하네스와 백플레이트 설치 가이드 32
크로치 스트랩 설치 가이드 38
스텔라 백플레이트 + 윙시스템 조립 가이드 39
파워 인플레이터 사용 방법 44
제품의 유지 관리 46
자주 묻는 질문 47
제품 품질보증서 48
유지 보수 기록 71
제품 등록 72
제품 등록서 75
主要安全指南及注意事项
50
STELLAR A1 装备构成介绍 52
STELLAR A1 织带安装指导 54
胯下带安装织带 60
STELLAR A1 装备组装指导
61
POWER INFLATOR 使用方法 66
产品的维护管理 68
常见问题及解答 69
产品品质保证书
70
保养及维修记录 71
产品登录 72
产品登录表 75

6| GEMMA TECHNICAL
IMPORTANT SAFETY INSTRUCTIONS, WARNINGS, & PRECAUTIONS
WARNING
READ THIS OWNER’S MANUAL COMPLETELYAND UNDERSTAND ENTIRELY PRIOR TO
USING THIS BUOYANCY COMPENSATOR (BC).
WARNING
THIS MANUAL MAY PROVIDE BASIC GUIDELINES FOR BUOYANCY CONTROL
TECHNIQUES, BUT IS NOT A SUBSTITUTE FOR PROPER TRAINING FROM A CERTIFIED
PROFESSIONAL DIVING INSTRUCTOR.
WARNING
IMPROPER USEAND/OR MISUSE OF THIS BOUYANCY COMPENSATOR (BC) MAY
CAUSE SERIOUS INJURY OR DEATH
WARNING
DO NOT USE THIS BUOYANCY COMPENSATOR (BC) IF YOU HAVE NOT BEEN
PROPERLY TRAINED AND HAVE NOT SUCCESSFULLY COMPLETED A SCUBA DIVING
COURSE BYARECOGNIZED TRAINING & CERTIFICATIONAGENCY. USE OF THIS BC BY
UNTRAINED & UNCERTIFIED PERSON(S) IS EXTREMELY DANGEROUS AND CAN
CAUSE SERIOUS INJURY OR DEATH
WARNING
THIS BUOYANCY COMPENSATOR (BC) IS NOTALIFE JACKET. INAN EMERGENCY, THIS
BUOYANCY COMPENSATOR MAY NOT PROVIDEA FACE UP POSITION OR FLOATATION
OF THE WEARER AT THE SURFACE IN ALL CONDITIONS. IF THE WEARER BECOMES
UNCONSCIOUS IN THE WATER, WITHOUT A BUDDY PRESENT TO PROVIDE IMMEDIATE
ASSISTANCE, THE WEARER MAY SUFFER SERIOUS INJURY OR DEATH.
WARNING
DO NOT BREATHE FROM OR INHALE FROM THE ORAL INFLATION MOUTHPIECE OR
AND/OR BUOYANCY COMPENSATOR (BC). THE INNER BLADDER OR BC MAY CONTAIN
HARMFUL GASES, RESIDUE, LIQUID, OR CONTAMINANTS WHICH COULD CAUSE
SERIOUS INJURY, SUFFOCATION, OR DEATH.
WARNING
ALWAYS PERFORM PRE-DIVE INSPECTIONS OF THIS BUOYANCY COMPENSATOR (BC)
DESCRIBED IN THIS MANUAL TO ENSURE: ALL BOLTS & ATTACHMENTS ARE
SECURELY CONNECTED, ALL COMPONENTS ARE FUNCTIONING PROPERLY, AND
THERE ARE NOT SIGNS OF LEAKS OR DAMAGES.
WARNING
DO NOT USE THIS BUOYANCY COMPENSATOR (BC) IF YOU CAN HEAR ANY LEAKAGE,
OR IF THE BLADDER BEGINS DEFLATE WITHIN 5 TO 10 MINUTES.

7| HELIOS
WARNING
TOTAL WEIGHT CARRIED BY THE WEARER OF THIS BUOYANCY COMPENSATOR MUST
BE PROPERLY CALCULATED AND TESTED FOR OPTIMUM BUOYANCY PRIOR TO
DIVING UNDERWATER. FAILURE TO PROPERLY WEIGHT YOURSELF MAY CREATE
HAZARDOUS CONDITIONS WHICH COULD RESULT IN SERIOUS INJURY OR DEATH
WARNING
ALWAYS WET THE TANK/CYLINDER ADAPTER STRAPS (HARNESS WEBBING) PRIOR TO
CONNECTING & SECURING THE TANK/ CYLINDER TO THE BC (ADAPTER). THE
TANK/CYLINDER ADAPTER STRAPS (HARNESS WEBBING) MAY STRETCH & LOOSEN;
WHICH MAY CAUSE THE TANK/ CYLINDER STRAPS TO FALL OUT. VERIFY THE TENSION
OF THE CYLINDER CONNECTION PRIOR TO EVERY DIVE.
WARNING
THIS BUOYANCY COMPENSATOR IS DESIGNED FOR SINGLE TANK / CYLINDER
ATTACHMENT ONLY AND NOT INTENDED TO BE USED WITH TWIN TANKS/CYLINDERS.
THIS BUOYANCY COMPENSATOR / WING COMES IN LIFT CAPACITY OF 21lbs (9kg)
WARNING
DO NOT OVERINFLATE THIS BUOYANCY COMPENSATOR (BC). IMMEDIATELY BEGIN
VENT/RELEASE AIR FROM THIS BC USING THE DEFLATE BUTTON ON THE POWER
INFLATOR OR PULLING THE CORD OF THE DUMP (OVERPRESSURE) VALVE.
CONTINUE VENT / RELEASE AIR TO SLOW YOUR ASCENT RATE. AN UNCONTROLLED
RAPIDASCENT MAY CAUSE DECOMPRESSION SICKNESS ORARTERIAL GAS
EMBOLISM WHICH MAY LEAD TO SERIOUS INJURY OR DEATH
WARNING
TEMPERATURE LIMITATIONS MUST BE ADHERED: THIS BUOYANCY COMPENSATOR
SHOULD BE USED IN TEMPERATURES NO LOWER THAN 1 DEGREE CELSIUS (40°F)
AND NOT HIGHER THAN 34 DEGREES CELSIUS (104°F)
WARNING
IF YOU ARE NOT A FACTORY TRAINED, HELIOS AUTHORIZED TECHNICIAN, DO NOT
ATTEMPT TO PERFORM REPAIRS, NON PRESCRIBED DISASSEMBLIES, LUBRICATIONS,
OR SERVICING TO THIS BUOYANCY COMPENSATOR (BC). UNAUTHORIZED SERVICE(S)
TO THIS BC WILLVOID & NULLALLAND ANYWARRANTIES.
WARNING
DO NOT RELY SOLELY ON THE POWER INFLATOR TO INFLATE THIS BUOYANCY
COMPENSATOR. PRACTICE THE TECHNIQUE OF ORALLY INFLATING YOUR BC.
WARNING
FAMILIARIZE YOURSELF WITH THIS BC, ITS ADJUSTMENTS, AND ITS FEATURES IN A
CONTROLLED ENVIRONMENT SUCH AS A SWIMMING POOL PRIOR TO USING THIS BC
IN DEEPER WATERS

8| GEMMA TECHNICAL
STELLAR A1 BP&W FULL SYSTEM CONFIGURATION
FRONT
A
1680 DEN Nylon Wing
J
Rubber round ring
B
Shoulder Pads
K
HELIOS Quick-Pull webbing buckle
C
Aluminum Back Plate
L
2” S/S D-Ring
D
Back Plate Pad Pouch
M
2” Webbing Harness
E
2” S/S Bent D-Ring
N
Plastic Webbing Clip
F
2” S/S Tri-glide with Chest strap
O
S/S Waist buckle
G
Chest strap QR Buckle
P
Over Pressure Valve [Exhaust Valve]
H 13.3 In [34cm] Corrugated Hose Q Pull Cord
I
X01 Tech Power Inflator
R
5lb [2kg] Weight Pocket

9| HELIOS
BACK
S
Inflator Elbow [pipe] connection
V
Tank Cradle
T
Inflator Elbow [pipe] housing
W
Nylon Plastic CAM buckle for Tank strap
U
Tank / Cylinder Strap with Friction pads

10 | GEMMA TECHNICAL
A1 HARNESS SYSTEM ASSEMBLY GUIDE
HELIOS A1 harness is a front adjustable harness system consisting of 3 main webbings and a crotch strap.
1
Shoulder webbing: 2” nylon webbing with center grommet
150cm
2
Left waist webbing: 2” nylon with integrated D-ring handle
135cm
3
Right waist webbing: 2” nylon with integrated D-ring handle
110cm
4
Crotch strap with integrated D-ring
110cm
A1 harness is threaded through a total of 9 slots on the back plate which includes 1 slot to install the crotch
strap
Top
This side UP / FRONT
Insert the shoulder webbing into slot R1 front of the back plate
Flip the backplate to the back side
Pull the webbing and insert to slot L1 from back side of backplate
Flip the backplate to its front side. Pull the webbing until centered by aligning the center grommet to
the third hole from top of the backplate.
Insert the left end of the webbing to slot L2 and right end of the webbing to slot R2
Shoulder webbing both right and left will come over top edge of backplate
SLOT R2
SLOT R1
SLOT L2
SLOT L1
SLOT L3
SLOT L4
SLOT R3
SLOT R4
SLOT C1

11 | HELIOS
A1 WEBBING HARDWARE FOR STELLAR
Hardware
Usage
Qty
Rubber Round Ring
Inflator hose guide
1
Webbing rubber band
Securing excess webbing
4
2” S/S Bent D-rings
2
2” S/S Straight/ standard D-rings
Not including integrated D-rings
3
2” tri-glides
8
2” tri-glides 3 slots (chest strap tri-glide)
Each end of the chest strap pre-installed
2
Plastic webbing clip
Used for excess belt webbing
1
Helios Quick Pull webbing buckle
Front adjustment
2
S/S Waist buckle
On the left shoulder webbing insert/loop a tri-glide with the
Rubber Round ring. Thread the webbing in the tri-glide as
per illustration. This rubber round ring is used to guide the
inflator corrugated hose.
Insert/ loop a tri-glide and a bent D-ring on both of the left
and right shoulder webbing. Make sure the curve of the
bent D-ring is pointing outward.
These upper-chest bent D-rings should be positioned so
you may comfortable attach and detach items using the
same side hand. (While folding your arms parallel to the
ground your thumb should fold around the center of the
bent D-ring when properly positioned)
Insert a webbing rubber band (snoopy loop) to the webbing
Thread the Chest Strap Tri-glide to the left and right
shoulder webbing. (The adjustable chest strap should face
outward)
Loop each end of shoulder webbing through the top slot of
the Quick pull webbing buckle. (See below illustration of the
quick pull)
Thread the remaining webbing back into the Chest strap tri-glide
Allow sufficient space between the Chest strap Tri-glide and the Quick pull webbing buckle to install
the shoulder pad Velcro tabs
Finally insert the excess webbing in the rubber band
Left
shoulder
Webbing
Right
shoulder
Webbing
Quick Pull
Top slot
Quick Pull
Bottom slot

12 | GEMMA TECHNICAL
The image on the right shows a completed shoulder webbing
installation including shoulder pads
Allow sufficient room between the stainless steel hardware to
install the shoulder pad Velcro tabs
The position of the Chest Strap tri-glides and the Quick Pull
webbing buckles must be parallel on both the left and right
shoulder webbings.
Lengths of the left and right shoulder webbings must be even
Adjust the lengths of the shoulder webbings for a perfect fit
INSTALLING THE SHOULDER PADS
Open the adjustable Velcro straps located on the end of the shoulder pad
Insert the Velcro straps facing up to slots R2 and L2 the close the Velcro to the desired lengths
Shoulder pads are always positioned between your shoulder and the shoulder webbing. The webbing
is on the outside of the pad
Open the Velcro tabs located on each of the pads. Line up the shoulder pads with the webbing
Adjust the length of the shoulder pad or the position of the tri-glides so that there is room between
the tabs and the tri-glides
Note: Number of and design of Velcro straps and tabs may vary on different Shoulder pads
CAUTION: The tri-glides may damage the tabs on the shoulder pads when improperly installed

13 | HELIOS
INSTALLING THE LEFT & RIGHT WAIST WEBBING
The right waist webbing is shorter than the left
waist webbing
Hold the belt webbing by the D-ring end so
that the seam faces down. Insert the end of
the waist webbing (opposite side of the
integrated D-ring) in to the Quick pull webbing
buckle. Start from the bottom then loop over
the center moving bar of the Quick pull
webbing buckle
Pull the waist webbing all the way down until
the D-ring stops at the Quick Pull webbing
buckle
An elastic nylon band is installed on the cross
section seam where the nylon and polyester
webbing connects
Insert the right waist webbing into SLOT L4
from the front of the back plate
Note: the shoulder webbing and the belt
webbing should face forward when inserting the
waist webbing into SLOT L4
Pull the webbing from the back until the cross
section is approximately 10~15cm from SLOT
L4
Flip the back plate to the back side
Insert a tri-glide then insert the waist webbing
into SLOT L3
Turn the backplate to the front and pull the
webbing fully
Install the weight pocket (diver preference)
Thread a tri-glide and D-ring. This D-ring should be located on the hip or directly above.
Note: D-rings on hip are used to attach secondary regulator (octopus) hose clips, pressure gauge, or
other tools during your dive

14 | GEMMA TECHNICAL
Repeat the above steps for the left waist webbing but using SLOT R4 then R3 on the back plate
Insert the plastic webbing clip to the left waist webbing
Insert a webbing rubber band which will be used later to secure excess webbing
FITTING YOUR STELLAR BC
Before you install the waist buckle, adjust the lengths of the shoulder
webbings and waist webbings for a comfortable fit
A good fit is a comfortable and safe fit
First try on the A1 harness system which you have installed so far
The Quick Pull webbing buckle should be located either on the chest
or under the chest most comfortable for the individual diver.Adjust
the shoulder webbing accordingly
Pull down the integrated D-rings looped around the Quick Pull
webbing buckle. See Illustration
When fit snug the D-rings should drop approximately 10cm. If longer
or too short, loosen the tri-glides on the back of the backplate and
adjust the length.
Once the fit of the harness has been adjusted, extend your right hand
over your shoulder and try reaching the top edge of the backplate. If
your fingers touch the backplate, you have adjusted the harness
properly.

15 | HELIOS
ATTACHING THE WAIST BUCKLE
You are now ready to install the waist buckle
The waist buckle will installed on the left waist webbing and will be positioned on the right not the
center. This is to prevent the crotch strap from accidentally opening the waist buckle.
Open the buckle and thread the open end of the left waist webbing into slot A from the front. Thread
through Slot B, then Slot C, and finally insert back into Slot A. (Tip: Slot Ais slightly larger than other
slots. Fold the inserted webbing back to reveal space to insert the open end webbing.)
Pull the webbing fully and secure excess webbing in to the rubber band.
Cut excess webbing if desired, burn & seal the webbing end to prevent fraying
B
A
C

16 | GEMMA TECHNICAL
CROTCH STRAP MOUNTING GUIDE
The front and top side of the crotch strap has an integrated (sewn in) D-ring pointing outward and looped
webbing. The waist webbing belt will run through the looped webbing of the crotch strap.
Insert a webbing rubber band (snoopy loop) into the back end of the crotch strap
Thread a tri-glide and D-ring pointing outward (when worn)
Insert the crotch strap webbing to SLOT C starting from the back of the backplate
Pull and thread back into the tri-glide. See illustration
The back D-ring should be positioned approximately a width of 4 fingers. See illustration
Adjust the length of the crotch strap for a comfortable fit.
Secure excess strap webbing into the rubber band (and through the crotch strap pad)
Cut off excess strap webbing when too long

17 | HELIOS
STELLAR BACKPLATE & WING ASSEMBLY GUIDE
Mounting Hardware
NO. ITEM MATERIAL QTY PICTURE
1 30mm Carriage bolt with
slotted round head (metric
thread)
Stainless Steel 1
2 22mm Carriage bolt with
slotted round head (metric
thread)
Stainless Steel 1
3 Flat Washer 23.6mm
(large flat washer)
Stainless Steel 2
4 Lock Washer 14.6mm
(lock washer)
Stainless Steel 2
5 Flat Washer 15.7mm
(thin flat washer)
Stainless Steel 1
6 31mm T-handle
(T-handle)
Thermoplastic
1
7 Hex lock nut
(hex nut)
Stainless Steel 1
WARNING
STELLAR WINGS MUST BE ATTACHED TO THE BACKPLATE USING TWO BOLTS
TIGHTENED SECURELY. FAILURE TO USE TWO BOLTS AS INSTRUCTED IN THIS
MANUAL MAY LEAD TO PRODUCT DAMAGE AND COULD LEAD TO SERIOUS INJURY
Insert the 30mm carriage bolt from
the back of the Stellar Wing to the top
grommet/ eyelet located in the spine
of the wing

18 | GEMMA TECHNICAL
Flip the wing to the front. Make sure
you are holding the carriage bolt
pushed in the top grommet
Align the third hole from top of the
Backplate center spine together with
carriage bolt threaded end
Push the carriage bolt threaded end
out from the backplate third hole then
insert a large flat washer first, then a
lock washer, then insert a thin
(15.7mm) flat washer
Fasten in the T-handle (thermoplastic)
to the carriage bolt threaded end
Using a flat head screw driver on the
slotted round head of the carriage bolt,
tighten securely
CAUTION: Make sure the bolt threaded end passes through the grommet on the webbing
You are now ready to mount the
bottom bolt to the bottom
grommet/eyelet
Insert the 22mm carriage bolt from
the back of the Stellar Wing to the
bottom most grommet/ eyelet located
in the spine of the wing.
If the backplate is properly centered
horizontally, then bolt would pass
through the center of the oval bolt slot
of the backplate.
Flip the wing to the front.
Insert a large washer, then a lock
washer to the threaded end of the
carriage bolt
Fasten the hex nut to the bolt using a
spanner and a flat head screw-driver
Tighten securely

19 | HELIOS
THREADING THE TANK/ CYLINDER STRAPS
Place the tank strap flat so that the HELIOS
logo is facing up. The Velcro end should be
facing down on the left and the CAM buckle
should be to your right
Loop one end of the friction pad. Slide the
friction pad (with one end looped) close
towards the CAM buckle. Note the wide center
of the friction pad should be facing up
You are now ready to thread the tank strap to the Wing & backplate assembly. Turn the Wing to the
back.
Starting with the top right oval slot, insert the Velcro end of the strap. Remember the Velcro end
should be facing down
Push in the strap through the backplate slot
Flip the wing to the front. Pull the tank strap and insert the Velcro end to the right adjacent tank strap
slot on the backplate
Flip the wing to the back. Pull out the tank strap from the left oval slot of the wing
Loop the remaining end of the friction pad and center the friction pad to the spine of the wing
Repeat above steps for the lower slots of the wing
CAUTION: STELLAR Buoyancy compensators are designed to use two tank / cylinder straps securely
tightened to the tank/ cylinder.

20 | GEMMA TECHNICAL
TANK CRADLE / STABILIZER
STELLAR Wings are equipped with a tank cradle sometimes called stabilizer bars.
The tank cradle is located in the back side center of the wing
Remove the tank cradle when mounting a single tank adapter
Open the Velcro straps to remove
MOUNTING STELLAR BC TO THE SINGLE SCUBA TANK / CYLINDER
WARNING
ALWAYS WET THE TANK/ CYLINDER STRAPS PRIOR TO MOUNTING TO THE TANK/
CYLINDER FORAT LEAST 20 MINUTES. THE TANK STRAPS MAY STRETCH & LOOSEN;
WHICH MAY CAUSE THE TANK/ CYLINDER TO FALL OUT OR BECOME DETACHED.
VERIFY THE TENSION OF THE TANK CONNECTION PRIOR TO EVERY DIVE
First wet the tank straps. STELLAR buoyancy compensator assemblies can be wet together
NOTE: Partially threading the tank strap ends to the CAM buckle may provide an easier setup when
mounting the BCD and tank in an upright position
Slots on the CAM buckle are numbered in the order of inserting the strap
