Owner’s Manual
50 Hz Air-Cooled Generators
8 / 10 / 13 kVA
SAVE THIS MANUAL FOR FUTURE REFERENCE
This manual must be used in conjunction with the appropriate Installation Manual.
Register your Generac product at:
WWW.GENERAC.COM
1-888-GENERAC
(1-888-436-3722)
Para español , visita: http://www.generac.com/service-support/product-support-lookup
Найти версию на русском языке: http://www.generac.com/service-support/product-support-lookup
000918
(000209a)
WARNING
This product is not intended to be used in
a critical life support application. Failure to
adhere to this warning could result in
death or serious injury.

Owner’s Manual for 50 Hz Air-cooled Generators
Use this page to record important information about your generator set.
Record the information found on your unit data label on this
page. For the location of the unit data label, see General
Information. The unit has a label plate affixed to the inside
partition, to the left of the control panel console as shown in
Figure 2-1 and Figure 2-2. For directions on how to open
the top lid and remove the front panel, see Operation.
When contacting an Independent Authorized Service Dealer
about parts and service, always supply the complete model
number and serial number of the unit.
Operation and Maintenance: Proper maintenance and care
of the generator ensures a minimum number of problems
and keeps operating expenses at a minimum. It is the
operator’s responsibility to perform all safety checks, to
make sure that all maintenance for safe operation is
performed promptly, and to have the equipment checked
periodically by an Independent Authorized Service Dealer.
Normal maintenance, service and replacement of parts are
the responsibility of the owner/operator and, as such, are not
considered defects in materials or workmanship within the
terms of the warranty. Individual operating habits and usage
may contribute to the need for additional maintenance or
service.
When the generator requires servicing or repairs, contact an
Independent Authorized Service Dealer for assistance.
Authorized service technicians are factory-trained and are
capable of handling all service needs.To locate the nearest
Independent Authorized Service Dealer, please visit the
dealer locator at:
www.generac.com/Service/DealerLocator/.
Model:
Serial:
Prod Date Week:
Volts:
LPV AMPS:
NG AMPS:
HZ:
Phase:
Controller P/N:
(000005)
WARNING
California Proposition 65. This product contains or
emits chemicals known to the state of California to
cause cancer, birth defects, and other reproductive
harm.
(000004)
WARNING
California Proposition 65. Engine exhaust and some
of its constituents are known to the state of California
to cause cancer, birth defects, and other reproductive
harm.

Owner’s Manual for 50 Hz Air-cooled Generators iii
Section 1: Safety Rules & General
Information
Introduction...........................................................1
Read This Manual Thoroughly ....................................1
How to Obtain Service .................................................1
Safety Rules ..........................................................2
General Hazards .........................................................2
Exhaust Hazards .........................................................3
Electrical Hazards .......................................................3
Fire Hazards ................................................................4
Explosion Hazards ......................................................4
Section 2: General Information
The Generator .......................................................5
Specifications .......................................................6
Generator ....................................................................6
Engine .........................................................................6
Protection Systems ..............................................7
Emission Information ...........................................7
Fuel Requirements ...............................................7
Battery Requirements ..........................................7
Battery Charger.....................................................7
Engine Oil Requirements .....................................7
Replacement Parts ...............................................8
Accessories...........................................................8
Section 3: Operation
Site Prep Verification............................................9
Side Compartment................................................9
Main Circuit Breaker (Generator Disconnect) ..............9
LED Indicator Lights ....................................................9
Generator Enclosure ............................................9
Control Panel Interface ......................................11
Using the Auto/Off/Manual Buttons ..................11
Interface Menu Displays.....................................11
The LCD Display .......................................................11
Menu System Navigation ..........................................11
Battery Charger...................................................14
Manual Transfer Operation................................ 14
Transfer to Generator Power Source ........................14
Transfer Back to Utility Power Source .......................15
Automatic Transfer Operation .......................... 15
Automatic Sequence of Operation ................... 15
Utility Failure ..............................................................15
Cranking ....................................................................15
Cold Smart Start ........................................................15
Load Transfer ............................................................15
Shutting Generator Down While Under Load .. 16
Section 4: Maintenance
Performing Scheduled Maintenance ................ 17
Before Servicing................................................. 17
Maintenance Kits................................................ 17
Service Schedule................................................ 18
Maintenance Log .......................................................18
Checking Engine Oil Level ................................ 19
Engine Oil Recommendations ...................................19
Changing the Oil and Oil Filter.......................... 19
Changing the Engine Air Filter.......................... 20
Spark Plugs......................................................... 20
Valve Clearance Adjustment ............................. 20
Battery Maintenance .......................................... 21
Attention After Submersion .............................. 22
Corrosion Protection ......................................... 22
Out of Service Procedure .................................. 22
Removal From Service ..............................................22
Return to Service .......................................................22
Section 5: Troubleshooting / Quick
Reference Guide
Troubleshooting ................................................. 23
Quick Reference Guide...................................... 24
Table of Contents

Table of Contents
iv Owner’s Manual for 50 Hz Air-cooled Generators
This page intentionally left blank.

Safety Rules & General Information
Owner’s Manual for 50 Hz Air-Cooled Generators 1
Section 1: Safety Rules & General Information
Introduction
Thank you for purchasing this compact, high
performance, air-cooled, engine-driven generator. It is
designed to automatically supply electrical power to
operate critical loads during a utility power failure.
This unit is factory installed in an all-weather, metal
enclosure that is intended exclusively for outdoor
installation. This generator will operate using either vapor
withdrawn liquid propane (LP) or natural gas (NG).
NOTE: When sized properly, this generator is suitable for
supplying typical residential loads such as induction
motors (sump pumps, refrigerators, air conditioners,
furnaces, etc.), electronic components (computer,
monitor, TV, etc.), lighting loads and microwaves.
Read This Manual Thoroughly
If any portion of this manual is not understood, contact
the nearest Independent Authorized Service Dealer for
starting, operating and servicing procedures.
This manual must be used in conjunction with the
appropriate Installation Manual.
SAVE THESE INSTRUCTIONS: The manufacturer
suggests that this manual and the rules for safe operation
be copied and posted near the unit installation site.
Safety should be stressed to all operators and potential
operators of this equipment.
Throughout this publication and on tags and decals
affixed to the generator, DANGER, WARNING, CAUTION
and NOTE blocks are used to alert personnel to special
instructions about a particular operation that may be
hazardous if performed incorrectly or carelessly. Observe
them carefully. Their definitions are as follows:
NOTE: Notes provide additional information important to
a procedure or component.
These safety warnings cannot eliminate the hazards they
indicate. Observing safety precautions and strict
compliance with the special instructions while performing
the action or service are essential to preventing accidents.
The operator is responsible for proper and safe use of
the equipment. The manufacturer strongly recommends
that if the operator is also the owner, to read the Owner’s
Manual and thoroughly understand all instructions before
using this equipment. The manufacturer also strongly
recommends instructing other users to properly start and
operate the unit. This prepares them if they need to
operate the equipment in an emergency.
How to Obtain Service
When the generator requires servicing or repairs, contact
an Independent Authorized Service Dealer for
assistance. Service technicians are factory-trained and
are capable of handling all service needs. For assistance
locating a dealer, go to www.generac.com/Service/
DealerLocator/.
When contacting a dealer about parts and service,
always supply the complete model number and serial
number of the unit as given on its data decal, which is
located on the generator. See The Generator for decal
location.
(000100a)
WARNING
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
(000001)
DANGER
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
(000002)
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
(000003)
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.

Safety Rules & General Information
2Owner’s Manual for 50 Hz Air-Cooled Generators
Safety Rules
Study these SAFETY RULES carefully before installing,
operating or servicing this equipment. Become familiar
with this Owner’s Manual and with the unit. The
generator can operate safely, efficiently and reliably only
if it is properly installed, operated and maintained. Many
accidents are caused by failing to follow simple and
fundamental rules or precautions.
The manufacturer cannot anticipate every possible
circumstance that might involve a hazard. The warnings in
this manual and on tags and decals affixed to the unit are,
therefore, not all-inclusive. If using a procedure, work
method, or operating technique the manufacturer does not
specifically recommend, verify that it is safe for others.
Also, make sure the procedure, work method or operating
technique utilized does not render the generator unsafe.
General Hazards
Inspect the generator regularly, and contact the nearest
Independent Authorized Service Dealer for parts needing
repair or replacement.
(000190)
DANGER
Loss of life. Property damage. Installation must always
comply with applicable codes, standards, laws and
regulations. Failure to do so will result in death
or serious injury.
Automatic start-up. Disconnect utility power and
render unit inoperable before working on unit.
Failure to do so will result in death or serious injury.
(000191)
DANGER
(000187)
WARNING
(000130)
WARNING
Accidental Start-up. Disconnect the negative battery
cable, then the positive battery cable when working
on unit. Failure to do so could result in death
or serious injury.
(000182)
WARNING
(000155)
WARNING
Only a trained and licensed electrician should perform
wiring and connections to unit. Failure to follow proper
installation requirements could result in death, serious
injury, and damage to equipment or property.
(000115)
WARNING
Moving Parts. Do not wear jewelry when
starting or operating this product. Wearing
jewelry while starting or operating this product
could result in death or serious injury.
(000111)
WARNING
Moving Parts. Keep clothing, hair, and
appendages away from moving parts. Failure
to do so could result in death or serious injury.
(000108)
WARNING
Hot Surfaces. When operating machine, do not
touch hot surfaces. Keep machine away from
combustibles during use. Hot surfaces
could result in severe burns or fire.
(000146)
WARNING
Equipment and property damage. Do not alter
construction of, installation, or block ventilation for
generator. Failure to do so could result in unsafe
operation or damage to the generator.
WARNING
Risk of injury. Do not operate or service this
machine if not fully alert. Fatigue can impair the
ability to service this equipment and could result
in death or serious injury. (000215)
WARNING
Environmental Hazard. Always recycle batteries at an
official recycling center in accordance with all local
laws and regulations. Failure to do so could result in
environmental damage, death or serious injury.
(000228)

Safety Rules & General Information
Owner’s Manual for 50 Hz Air-Cooled Generators 3
Exhaust Hazards
Adequate, unobstructed flow of cooling and ventilating air
is critical to correct generator operation. Do not alter the
installation or permit even partial blockage of ventilation
provisions, as this can seriously affect safe operation of
the generator. The generator must be installed and
operated outdoors only.
Electrical Hazards
WARNING
Injury and equipment damage. Do not use
generator as a step. Doing so could result in falling,
damaged parts, unsafe equipment operation,
and could result in death or serious injury. (000216)
(000209a)
WARNING
This product is not intended to be used in
a critical life support application. Failure to
adhere to this warning could result in
death or serious injury.
Asphyxiation. Running engines produce
carbon monoxide, a colorless, odorless,
poisonous gas. Carbon monoxide, if not
avoided, will result in death or serious injury.
(000103)
DANGER
(000178a)
Asphyxiation. Always use a battery operated carbon
monoxide alarm indoors and installed according to
the manufacturer’s instructions. Failure to do so
could result in death or serious injury.
WARNING
(000144)
DANGER
Electrocution. Contact with bare wires,
terminals, and connections while generator
is running will result in death or serious injury.
(000150)
DANGER
Electrocution. Never connect this unit to the electrical
system of any building unless a licensed electrician
has installed an approved transfer switch. Failure to
do so will result in death or serious injury.
(000131a)
DANGER
Electrical backfeed. Use only approved switchgear to
isolate generator when electrical utility is the primary
power source. Failure to do so will result in death,
serious injury, and equipment damage.
(000152)
DANGER
Electrocution. Verify electrical system is
properly grounded before applying power.
Failure to do so will result in death or serious
injury.
(000188)
DANGER
Electrocution. Do not wear jewelry while
working on this equipment. Doing so will
result in death or serious injury.
(000104)
DANGER
Electrocution. Water contact with a power
source, if not avoided, will result in death
or serious injury.
(000144)
DANGER
Electrocution. Contact with bare wires,
terminals, and connections while generator
is running will result in death or serious injury.
(000145)
DANGER
Electrocution. In the event of electrical accident,
immediately shut power OFF. Use non-conductive
implements to free victim from live conductor. Apply
first aid and get medical help. Failure to do so will
result in death or serious injury.

Safety Rules & General Information
4Owner’s Manual for 50 Hz Air-Cooled Generators
Fire Hazards
Comply with regulations the Occupational Safety and
Health Administration (OSHA) has established. Also,
verify that the generator is installed in accordance with
the manufacturer’s instructions and recommendations.
Following proper installation, do nothing that might alter a
safe installation and render the unit in noncompliance
with the aforementioned codes, standards, laws and
regulations.
Explosion Hazards
WARNING
Fire hazard. Do not obstruct cooling and
ventilating airflow around the generator. Inadequate
ventilation could result in fire hazard, possible
equipment damage, death or serious injury. (000217)
WARNING
Fire and explosion. Installation must comply
with all local, state, and national electrical
(000218)
building codes. Noncompliance could result in unsafe
operation, equipment damage, death or serious injury.
WARNING
Fire hazard. Use only fully-charged fire
(000219)
extinguishers rated “ABC” by the NFPA. Discharged or
improperly rated fire extinguishers will not extinguish
electrical fires in automatic standby generators.
(000100a)
WARNING
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
WARNING
required safety equipment could result in
death or serious injury. (000221)
Risk of electrocution. Refer to NFPA 70E for
safety equipment required when working with
with a live electrical system. Failure to use
(000147)
WARNING
Risk of Fire. Unit must be positioned in a
manner that prevents combustible material
accumulation underneath. Failure to do so
could result in death or serious injury.
(000192)
DANGER
(000151)
DANGER
Connection of fuel source must be done by a qualified
professional technician or contractor. Incorrect installation
of this unit will result in death, serious injury, and damage
to equipment and property damage.
(000174)
DANGER
Risk of fire. Allow fuel spills to completely dry
before starting engine. Failure to do so will
result in death or serious injury.
(000110)
WARNING
Risk of Fire. Hot surfaces could ignite
combustibles, resulting in fire. Fire could
result in death or serious injury.

General Information
Owner’s Manual for 50 Hz Air-Cooled Generators 5
Section 2: General Information
The Generator
Figure 2-1. GTH-530 Engine 8 kVA Unit
Figure 2-2. GT-990 Engine, 10 & 13 kVA Units
A. Exhaust Enclosure D. Battery Compartment G. Circuit Breakers J. Oil Fill Cap
B. Composite Base E. Fuel Regulator H. Control Panel K. Air Filter
C. Oil Filter F. Fuel Inlet (Back) I. Data Label (See Sample) L. Oil Dipstick
000701
A
L
BCDE
F
G
H
KJI
000901
A
B
L
CDE
K
F
G
H
JI

General Information
6Owner’s Manual for 50 Hz Air-Cooled Generators
Specifications
Generator
Engine
The specification sheet for your generator was included in the documentation provided with the unit at the time of purchase. For additional copies,
consult your local Independent Authorized Service Dealer for your specific generator model.
Model 8 kVA 10 kVA 13 kVA
Rated Voltage 220/230/240
Rated Maximum Load
Current (Amps) at
Rated Voltage*
36.4 / 34.8 / 33.3 45.5 / 43.5 / 41.7 59.1 / 56.5 / 54.2
Main Circuit Breaker 40 Amp 50 Amp 63 Amp
Phase 1
Rated AC Frequency 50 Hz
Battery Requirement Group 26R, 12 Volts and 540 CCA Minimum
(See Replacement Parts)
Enclosure Steel Steel Steel
Weight (lbs./ kilos) 387 / 175.4 435 / 197.3 471 / 213.6
Normal Operating
Range
This unit is tested in accordance to UL 2200 standards with an operating temperature of -20 ºF (-29 ºC) to 122 ºF
(50 ºC). For areas where temperatures fall below 32 ºF (0 ºC) a cold weather kit is recommended. When operated
above 77 ºF (25 ºC) there may be a decrease in engine power. (Please reference the engine specifications section.
These generators are rated in accordance with UL 2200, Safety Standard for Stationary Engine Generator Assemblies, and CSA-C22.2 No. 100-04
Standard for Motors and Generators.
* Natural Gas ratings will depend on specific fuel BTU / joules content. Typical derates are between 10-20% off the LP gas rating.
** Circuits to be moved must be protected by same size breaker. For example, a 15 amp circuit in the main panel must be a 15 amp circuit in the
transfer switch.
Model 8 kVA 10 & 13 kVA
Type of Engine GTH-530 GT-990
Number of Cylinders 2 2
Displacement 32.3 in3(530 cc) 60.5 in3(992 cc)
Cylinder Block Aluminum w/ cast iron sleeve
Recommended Spark Plug (See Replacement Parts)
Spark Plug Gap 0.030 in (0.76 mm) 0.040 in (1.02 mm)
Valve Clearance 0.002–0.004 in (0.05–0.1 mm) 0.002–0.004 in (0.05–0.1 mm)
Starter 12 VDC
Oil Capacity Including Filter Approx. 1.7 qt (1.6 L) Approx. 1.9 qt (1.8 L)
Recommended Oil Filter (See Replacement Parts)
Recommended Air Filter (See Replacement Parts)
Engine power is subject to and limited by such factors as fuel BTU/joules, ambient temperature and altitude. Engine power decreases about 3.5 percent
for each 1000 feet (304.8 meters) above sea level, and also will decrease about 1 percent for each 10 °F (1 ºC) above 60 °F (15 ºC) ambient temperature.

General Information
Owner’s Manual for 50 Hz Air-Cooled Generators 7
Protection Systems
The generator may have to run for long periods of time
with no operator present to monitor the engine/generator
conditions. Therefore, the generator is equipped with a
number of systems to automatically shut down the unit to
protect it against potentially damaging conditions. Some
of these systems are as follows
Alarms:
Warnings:
The control panel contains a display which alerts the
operator when a fault condition occurs. The above list is
not all inclusive. For more information about alarms and
control panel operation, see Section 3 Operation.
NOTE: A warning will indicate a condition on the
generator that should be addressed but will not shut the
generator down. An alarm will shut the generator down to
protect the system from any damage. In the event of an
alarm, an owner can clear the alarm and restart the
generator prior to contacting an Independent Authorized
Servicing Dealer. If the intermittent issue occurs again,
contact an independent Authorized Servicing Dealer.
Emission Information
The engine used in this generator is not certified to
United States EPA emission standards, or any other
emission standards. Sale or use of this generator is not
legal in the U.S. or any country which has emission
standards that are applicable to this product.
Fuel Requirements
The engine has been fitted with a dual fuel carburetion
system. The unit will run on natural gas or LP gas
(vapor), but it has been factory set to run on natural gas.
The fuel system will be configured for the available fuel
source during installation.
Recommended fuels should have a BTU (joules) content
of at least 1000 BTUs per cubic foot (37.26 megajoules
per cubic meter) for natural gas, or at least 2500 BTUs
per cubic foot (93.15 megajoules per cubic meter) for LP
gas (vapor).
NOTE: If converting to LP gas from natural gas, a
minimum LP tank size of 250 gallons (946 liters) is
recommended. See the Installation Manual for complete
procedures and details.
Battery Requirements
Group 26R, 12V, minimum 540 CCA.
For proper battery maintenance procedures, see Section
4 Maintenance.
Battery Charger
The battery charger is integrated into the control panel
module in all models. It operates as a “Smart Charger”
which ensures output charging levels are safe and
continuously optimized to promote maximum battery life.
Engine Oil Requirements
For proper oil viscosity, see chart in Figure 4-1.
•High Temperature
•Low Oil Pressure
•Overcrank
•Overspeed
•Overvoltage
•Undervoltage
•Overload
•Underspeed
•RPM Sensor Loss
•Controller Fault
•Wiring Error
•Fuse Problem
•Stepper Overcurrent
•Charger Warning
•Charger Missing AC
•Low Battery
•Battery Problem
•Exercise Set Error
•USB Warning
•Download Failure
(000105)
DANGER
Explosion and Fire. Fuel and vapors are
extremely flammable and explosive. Add fuel
in a well ventilated area. Keep fire and spark
away. Failure to do so will result in death
or serious injury.

General Information
8Owner’s Manual for 50 Hz Air-Cooled Generators
Replacement Parts
Accessories
Performance enhancing accessories are available for air-cooled generators.
NOTE: Contact an Independent Authorized Servicing Dealer for additional information on accessories.
Description 8 kVA 10 & 13 kVA
26R Exide Battery 0H3421S
Spark Plug 0E9368 (BPR6HS) 0E7585A (RC14YC4)
Oil Filter 070185E
Air Filter 0E9371A 0J8478
Control Panel Fuse 0D7178T
Transfer Switch Fuses 073590A
Accessory Description
Cold Weather Kit Recommended in areas where temperatures fall below 32 ºF (0 ºC).
Scheduled Maintenance Kit Includes all pieces necessary to perform maintenance on the generator along
with oil recommendations.
Auxiliary Transfer Switch Lockout Enables any of the transfer switches to completely lock out one large electrical
load by tying into its control system.
Fascia Base Wrap The fascia base wrap snaps together around the bottom of the new air-cooled
generators. This offers a sleek, contoured appearance as well as offering
protection from rodents and insects by covering the lifting holes located in the
base. Requires use of the mounting pad shipped with the generator.
Touch-Up Paint Kit Very important to maintain the look and integrity of the generator enclosure.
This kit includes touch-up paint and instructions.
Wireless Local Monitor Completely wireless and battery powered, the Wireless Local Monitor
provides you with instant status without ever leaving the house. Status lights
(red, yellow and green) alert owners when the generator needs attention.
Magnetic backing permits refrigerator mounting and gives a 600 foot (182.9
meter) line of sight communication.

Operation
Owner’s Manual for 50 Hz Air-Cooled Generators 9
Section 3: Operation
Site Prep Verification
It is important that the generator is installed in such a way
that the airflow into and out of the generator is not
impeded. Verify that all shrubs or tall grasses have been
removed within 3 ft. (0.91 m) of the intake and discharge
louvers on the sides of the enclosure. It is also important
that the generator is not subject to water intrusion. Verify
that all potential sources such as water sprinklers, roof
run-off, rain gutter down spouts and sump pump
discharges are directed away from the generator
enclosure.
Turn the generator OFF before performing maintenance.
Remove 7.5 Amp fuse, T1 and T2 battery charge fuses,
and disconnect battery cables to prevent accidental start
up. Disconnect the NEGATIVE (-) cable first, then
disconnect the POSITIVE (+) cable. When connecting
the cables, connect the POSITIVE cable first, the
NEGATIVE cable last.
Side Compartment
Local codes may require that the side compartment be
locked. A hasp is provided so the owner/operator can
secure the side compartment with a padlock. Check local
codes for side compartment locking requirements.
Figure 3-1. Open Side Compartment
Main Circuit Breaker (Generator Disconnect)
This is a 2-pole breaker rated according to relevant
specifications. See “A” in Figure 3-1.
LED Indicator Lights
See “B” in Figure 3-1.
•Green LED “Ready” light is on when utility is
present and the control panel button is in the AUTO
position. This also indicates when the generator is
running.
•Red LED “Alarm” light is on when the generator is
OFF or a fault is detected. Contact an Independent
Authorized Servicing Dealer.
•Yellow LED “Maintenance” light.
NOTE: Yellow LED may be on at the same time as either
the Red or Green LED.
Generator Enclosure
The lid is locked for shipping and remains locked while
the generator is in normal operation. A set of keys is
attached to the bottom left corner of the circuit breaker
box door.
1. Cut the cable tie to remove the keys.
2. Use the keys to open the lid of the generator.
NOTE: The enclosed keys provided with this unit are
intended for service personnel use only.
Figure 3-2. Circuit Breaker Box and Keys
(As Shipped)
3. There are two locks securing the lid, one on each
side (A in Figure 3-3). To properly open the lid,
press down, on the lid, above the side lock and
unlock the latch.
4. Repeat for the other side. If pressure is not applied
from the top, the lid may appear stuck.
Automatic start-up. Disconnect utility power and
render unit inoperable before working on unit.
Failure to do so will result in death or serious injury.
(000191)
DANGER
(000182)
WARNING
001241
AB C
000867

Operation
10 Owner’s Manual for 50 Hz Air-Cooled Generators
NOTE: Always verify that the side locks are unlocked
before attempting to lift the lid.
5. Once the lid is open, remove the front access
panel by lifting it up and out.
NOTE: Always the lift the front access panel up before
pulling away from enclosure (B and C in Figure 3-3). Do
not pull the panel away from the enclosure before lifting
up (D in Figure 3-3).
Figure 3-3. Side Lock Location and Front Panel Removal
Before performing any maintenance on the generator, set
to OFF, remove 7.5 Amp fuse, T1 and T2 battery charge
fuses, and disconnect battery cables to prevent
accidental start up. Disconnect the cable from the battery
post indicated by a NEGATIVE, NEG or (–) first, then
remove the POSITIVE, POS or (+) cable. When
reconnecting the cables, connect the POSITIVE cable
first, the NEGATIVE cable last.
NOTE: The enclosed keys provided with this unit are
intended for service personnel use only.
000597
A
A
001028
B DC
Automatic start-up. Disconnect utility power and
render unit inoperable before working on unit.
Failure to do so will result in death or serious injury.
(000191)
DANGER
(000182)
WARNING

Operation
Owner’s Manual for 50 Hz Air-Cooled Generators 11
Control Panel Interface
The control panel interface is located under the lid of the
enclosure. Before attempting to lift the lid of the
enclosure, verify that both left and right side locks are
unlocked. To remove the front cover, lift the cover straight
up to disengage the side hooks, then tilt and lift it away
from the unit.
When closing the unit, ensure that both left and right side
locks are securely locked.
NOTE: All appropriate panels must be in place during
any operation of the generator. This includes operation
by a servicing technician while conducting
troubleshooting procedures. Figure 3-4. Generator Control Panel
Using the Auto/Off/Manual Buttons
NOTE: Damage caused by mis-wiring of the interconnect wires is not warrantable.
Interface Menu Displays
The LCD Display
Menu System Navigation
To get to the MENU, use the “Escape” button from any page. It may require pressing it many times before getting to the
MENU page. Navigate to the desired menu by using the ↑/↓buttons. When the desired menu is displayed and flashing,
press the “Enter” button. See Figure 3-5 and Figure 3-6 Navigation Menu.
000425
Button Description of Operation
Auto
Selecting this button activates fully automatic system operation. It also allows the unit to
automatically start and exercise the generator according to the exercise timer (see Battery
Charger).
Off This button shuts down the engine and also prevents automatic operation of the unit.
Manual This button will crank and start the generator. Transfer to standby power will not occur unless
there is a utility failure.
Feature Description
HOME page
The default page which will be displayed if no buttons are pressed for 60 seconds. This page
normally shows the current Status message and the current date and time. The highest priority
active Alarm/Warning will be automatically posted on this page as well as flashing the backlight
when such a condition is detected. In the case of multiple Alarms/Warnings, only the first
message will be displayed. To clear an Alarm or Warning, press the OFF button and then press
the ENTER key.
Display Backlight Normally off. If the operator presses any button, the backlight will automatically light and remain
on for 30 seconds.
MAIN MENU page
Allows the operator to navigate to all other pages or sub-menus by using the Arrows and Enter
buttons. This page can be accessed at any time with several presses of the dedicated Escape
button. Each press of the Escape button takes the operator to the previous menu until the MAIN
MENU displays. This page contains information for—History; Status; Edit; Debug.

Operation
12 Owner’s Manual for 50 Hz Air-Cooled Generators
Figure 3-5. Navigation Menu (1 of 2)
EVOLUTION/SYNC2.0 HSB MENU M
A
P
“Run Log”
ESC
ENTER
ENTER
SYSTEM
B
A
TTER
Y
HISTOR
Y
EDIT
Exercise Time
Å 14:00 Wednesday Æ
Firmware Update
Å Press Enter Æ
ESC
Current Date/Time
Å 2/12/13 12:22 Æ
ESC
ENTER
ENTER
ESC
ESC
ESC
ESC
ENTER
ENTER
ESC
ESC
ENTER
ENTER
ESC
ENTER
ENTERENTER
ENTER
ENTER
ENTER
ENTER
ESC
ESC
Switched to “OFF”
Hours of Protection
0 (H)
Language
Å English Æ
Fuel Selection
Å NG or
L
P Æ
Firmware Update
Å Insert USB Æ
“Alarm Log”
-
A
larm Log +
- Run Log +
- 1 thru 50 +
- 1 thru 50 +
Warning Message(s)
Charger Warning
Charger Missing
A
C
Low Battery
Battery Problem
Exercise Set Error
USB Warning
Download Failure
Running Manual
Running-Utility Lost
Running-Remote Start
Running-2 Wire Start
Running - Exercise
Switched Off
Stopped -
A
uto
Stopped -
A
larm
Alarm Message(s)
High Temperature
Low Oil Pressure
Overcrank
Overspeed
Overvoltage
Undervoltage
Overload
Underspeed
RPM Sensor Loss
Controller Fault
Wiring Error
Stepper Overcurrent
Fuse Problem*
ESC
Select Min (0-59)
- 0 +
ESC
ESC
Select Hour (0-23)
- 14 +
ESC ESC
Quiet Test Mode ?
- YES or NO +
Select Frequency
- WEEK
L
Y
+
- BIWEEK
L
Y
+
- MONTHL
Y
+ Quiet Test Mode only on
certain models
Language
+ English -
Fuel Selection
+ NG or
L
P -
ENTER
Cold Smart Start?
Å YES or NO Æ
ESC
Cold Smart Start?
- YES or NO +
Language
+ Espanol -
+
-
+
-
Battery Condition
“Good” “Inspect Battery” or “Check Battery”
*“Fuse Problem” on
Firmware 1.11 and older
ON
L
Y
Note: Menu functions and features may vary depending
on unit model and firmware revision.
001479a

Operation
Owner’s Manual for 50 Hz Air-Cooled Generators 13
\
Figure 3-6. Navigation Menu (2 of 2)
UP ARROW = +
DOWN ARROW = -
ESC
DATE/TIME
SUB MENUS
MAINT
DEALER
EXAMPLE:
Inspect Battery 200 RnHr or 12/27/13
and
Next Maintenance 200 RnHr or 12/27/13
Current Date/Time
02/14/13 07:40
ESC
ESC
ENTER
ENTER ESC ENTER
ESC ESC ESC
ENTER
ENTER
ESC
MAINT:
Maint. Log
Run Hrs
Scheduled
ENTER
ENTER
Select Month (1-12)
- 2 +
Run Hours (H)
0.0
Select Date (1-31)
- 13 +
ENTER
Select Year (0-99)
- 13 +
ENTER
ENTER
Access Requires Password
Possible Message(s)
Corrupted File
Invalid File
File Not Found
Unsupported Device
"Current:V XXXX "
"USB: V XXXX"
"Are You Sure?"
"- Yes or No +"
ESC
ENTER
ESCENTER
ESCENTER
Select “Yes” then Press “Enter” to continue or Press “ESCAPE” to escape out of updating.
During update process the Blue “Manual” light flashes, then the Green “Auto” light flashes. Sequence
does this twice. When update is complete the unit returns to Install Wizard menu.
When the controller powers up the very first screen displays the version number for a few seconds.
When update is complete remove Thumb Drive, then follow the Install Wizard Menu.
- 1 thru 50 +
"Battery Maintained"
"Schedule A Serviced"
"Schedule B Serviced"
"Maintenance Reset"
"Inspect Battery"
"Service Schedule A"
"Service Schedule B"
ESC
Select Min (0-59)
- 0 +
ESC
Select Hour (0-23)
- 14 +
Language
+ Francais -
Language
+ Portuguese -
+
-
+
Select Day
- Wednesday +
001479b
+
-

Operation
14 Owner’s Manual for 50 Hz Air-Cooled Generators
Battery Charger
NOTE: The battery charger is integrated into the control
module in all models.
The battery charger operates as a “Smart Charger” that
ensures:
•Output is continually optimized to promote maximum
battery life.
•Charging levels are safe.
NOTE: A warning is displayed on the LCD when the
battery needs service.
Manual Transfer Operation
Prior to automatic operation, manually exercise the
transfer switch to verify that there is no interference with
proper operation of the mechanism. Manual operation of
the transfer switch is required if electronic operation
should fail.
Transfer to Generator Power Source
1. Verify that the generator is in the OFF mode.
2. Set the main circuit breaker (Generator
Disconnect) to OFF or OPEN.
3. Turn off the utility power supply to the transfer
switch using the means provided (such as a utility
main line circuit breaker).
4. Use the manual transfer handle (A in Figure 3-7)
inside the transfer switch to move the main
contacts to the STANDBY position (loads
connected to the standby power source).
5. To crank and start the engine, press the control
panel MANUAL button.
6. Allow the engine to stabilize and warm up for a few
minutes.
7. Set the main circuit breaker (Generator
Disconnect) to ON or CLOSED. The standby
power source now powers the loads.
Figure 3-7. Manual Transfer Switch Operation
(000132)
DANGER
Electrocution. Do not manually transfer under load.
Disconnect transfer switch from all power sources
prior to manual transfer. Failure to do so will result
in death or serious injury, and equipment damage.
000228
A
B
MANUAL
•Will not transfer to generator if utility is present.
•Will transfer to generator if utility fails (below 65% of nominal for five consecutive seconds).
•Will transfer back when utility returns for 15 consecutive seconds. The engine will continue to
run until removed from the MANUAL mode.
AUTO
•Will start and run if utility fails for five consecutive seconds. (factory default)
•Will start a 5 second engine warm-up timer (or 30 seconds; refer to Cold Smart Start).
–Will not transfer if utility subsequently returns.
–Will transfer to generator if utility is not present.
•Will transfer back to utility once utility returns (above 80% of nominal) for 15 seconds.
•Will not transfer back to utility unless utility returns. The generator will shut down if the OFF
button is pressed or a shutdown alarm is present.
•Once utility power is returned, the generator will shut down after one minute cool-down time.
EXERCISE
•Will not exercise if generator is already running in either AUTO or MANUAL mode.
•During exercise, the controller will only transfer if utility fails during exercise for five seconds
(or 30 seconds; refer to Cold Smart Start), and will switch to AUTO.

Operation
Owner’s Manual for 50 Hz Air-Cooled Generators 15
Transfer Back to Utility Power Source
When utility power has been restored, transfer back to
utility source and shut down the generator. To manually
transfer back to utility power and shut down the
generator:
1. Set the Main Circuit Breaker (Generator
Disconnect) to OFF or OPEN.
2. Allow the engine to run for two minutes at no-load
to stabilize the internal temperatures.
3. Press the control panel OFF button. The engine
should shut down.
4. Ensure that utility power supply to the transfer
switch is turned off.
5. Use the manual transfer handle (A in Figure 3-7)
inside the transfer switch to move the main
contacts back to the UTILITY position (loads
connected to the utility power source).
6. Turn on the utility power supply to the transfer
switch using the means provided.
7. Press the control panel AUTO button.
Automatic Transfer Operation
To select automatic operation:
1. Make sure the transfer switch main contacts are
set to the UTILITY position (loads connected to the
utility power source).
2. Be sure that normal UTILITY power source voltage
is available to transfer switch terminal lugs N1 and
N2.
3. Press the AUTO button on the control panel
interface.
4. Set the main circuit breaker (Generator
Disconnect) to the ON (Closed) position.
With these steps complete, the generator will start
automatically when utility source voltage drops below a
preset level. After the unit starts, loads are transferred to
the standby power source.
Automatic Sequence of
Operation
Utility Failure
With the generator set to AUTO, when utility fails (below
65% of nominal) a five second (dealer programmable)
line interrupt delay time is started. If utility is still gone
when the timer expires, the engine will crank and start.
Once started, a five second engine warm-up timer will be
initiated (or a 30 second warm-up timer; refer to Cold Smart
Start). When the warm-up time expires, the controller will
transfer the load to the generator. If the utility power is
restored (above 80% nominal) at any time from the
initiation of the engine start until the generator is ready to
accept load (five second warm-up time has not elapsed),
the controller will complete the start cycle and run the
generator through its normal cool down cycle, however,
the load will remain on the utility source.
Cranking
The system will control the cyclic cranking as follows:
•Five cranking cycles as follows: 16 second crank,
seven (7) second rest, 16 second crank, seven (7)
second rest, followed by three (3) additional cycles of
seven (7) second cranks followed by seven (7) second
rests.
Cold Smart Start
The Cold Smart Start feature can be enabled in the EDIT
menu. With Cold Smart Start enabled, the generator will
monitor ambient temperature and the warm-up delay will
be adjusted based on prevailing conditions.
On a startup in AUTO mode, if the ambient temperature
is below a fixed temperature (based on model) the
generator will warm up for 30 seconds. This allows the
engine to warm before a load is applied. If the ambient
temperature is at or above the fixed temperature, the
generator will startup with the normal warm-up delay of 5
seconds.
When the generator engine is started, a check for proper
output voltage build up will be performed.
If some condition impedes normal voltage creation, such
as frost crystals or dust/dirt prevent a good electrical
connection, the start sequence will be interrupted so that
a cleaning cycle of the internal electrical connections can
be attempted.
The cleaning cycle is an extended “Warming Up” period
which lasts for several minutes while the normal
generator voltage output is determined to be low. During
this cycle, the generator controller will display the
“Warming Up” on its display screen.
If the cleaning cycle fails to clear the obstruction, the
generator controller display will show the “Under Voltage”
message.
After several minutes, the alarm message can be
cleared, and a restart of the generator attempted.
If the problem persists, make no further attempts to start.
Contact an Independent Authorized Service Dealer.
Load Transfer
The transfer of load when the generator is running is
dependent upon the operating mode.

Operation
16 Owner’s Manual for 50 Hz Air-Cooled Generators
Shutting Generator Down While
Under Load
Important! To turn the generator off during utility
outages to perform maintenance, or conserve fuel,
follow these steps:
To turn the generator OFF (while running in AUTO
and online):
1. Turn the main utility disconnect OFF.
2. Turn the main line circuit breaker (MLCB) on the
generator to OFF (OPEN).
3. Turn the generator OFF.
To turn the generator back ON:
1. Put the generator back into AUTO and allow to
start and warm-up for a few minutes.
2. Set the MLCB on the generator to ON.
The system will now be operating in automatic mode.
The main utility disconnect can be turned ON (CLOSED).
To shut the unit off, this complete process must be
repeated.
