Generac Power Systems 1043-1 User manual

2700PSI
The Reliable Ones
High Pressure Washer
Owners Manual
Problems?
Questions?
Before taking your unit
back to the store,
call the pressure washer
helpline at
1-800-2 0-1408
M-F 8-5 CST
This pressure
washer is
equipped with an
Automatic Cool
Down System.
See page 11 for
details
GENERAC
This symbol points out important safety instructions, which, if not followed, could
endanger the personal safety and/or property of yourself and others. Read and follow
all instructions in the manual before attempting to operate this unit.
Model No. 10431 (2 00 PSI High Pressure Washer) Manual No. B30 9 Revision 0 (3/16/98)

2
High Pressure Washer
Generac 2700PSI High Pressure Washer
GENERAC
CAUTION: Always disconnect spark plug wire and place wire where it cannot contact spark
plug to prevent accidental starting when setting up, transporting, adjusting or making repairs
to your high pressure washer.
 Engine exhaust gases contain DEADLY carbon monoxide gas.
This dangerous gas, if breathed in sufficient concentrations, can
cause unconsciousness or even death. Operate this equipment
on y in the open air where adequate venti ation is avai ab e.
 Gaso ine is high y FLAMMABLE and its vapors are EXPLOSIVE.
Do not permit smoking, open f ames, sparks or heat in the vicin-
ity whi e hand ing gaso ine. Avoid spi ing gaso ine on a hot engine.
A ow unit to coo for 2 minutes before refue ing. Comp y with a
aws regu ating storage and hand ing of gaso ine.
 Locate this pressure washer in areas away from combustib e
materia s, combustib e fumes or dust.
 The high pressure equipment is designed to be used with Gen-
erac authorized parts on y. If you use this equipment with parts
that do not comp y with minimum specifications, the user assumes
a risks and iabi ities.
 Some chemica s or detergents may be harmfu if inha ed or
ingested, causing severe nausea, fainting or poisoning. The harm-
fu e ements may cause property damage or severe injury.
 Do not a ow CHILDREN to operate the Pressure Washer at any
time.
 Operate engine on y at governed speed. Running the engine at
excessive speeds increases the hazard of persona injury. Do not
tamper with parts which may increase or decrease the governed
speed.
 Do not wear oose c othing, jewe ry or anything that may be
caught in the starter or other rotating parts.
 Before starting the Pressure Washer in co d weather, check a
parts of the equipment and be sure ice has not formed there.
 Units with broken or missing parts, or without protective housing
or covers shou d NEVER be operated.
 The muff er and air c eaner must be insta ed and in good condi-
tion before operating the Pressure Washer. These components
act as spark arrestors if the engine backfires.
 Check the fue system for eaks or signs of deterioration such as
chafed or spongy hose, oose or missing c amps or damaged tank
or cap. Correct a defects before operating the Pressure Washer.
 Do not spray f ammab e iquids.
 Never aim the gun at peop e, anima s or p ants.
 High pressure spray can cause paint chips or other partic es to
become airborne and f y at high speeds.
 The high pressure stream of water that this equipment produces
can pierce skin and its under ying tissues, eading to serious
injury and possib e amputation.
 A ways wear eye protection when you use this equipment or
when you are in the vicinity where the equipment is in use.
 Never move the machine by pu ing on the high pressure hose.
Use the hand e provided on the top of the unit.
 A ways be certain the spray gun, nozz es and accessories are cor-
rect y attached.
 Never use a spray gun which does not have a trigger ock or trig-
ger guard in p ace and in working order.
 Use a respirator or mask whenever there is a chance that vapors
may be inha ed. Read a instructions with mask so you are cer-
tain the mask wi provide the necessary protection against inha ing
harmfu vapors.
 High pressure spray may damage fragi e items inc uding g ass.
Do not point spray gun at g ass when in the high pressure spray
mode.
 Keep the hose connected to machine and the spray gun whi e
the system is pressurized. Disconnecting the hose whi e the unit
is pressurized is dangerous.
 Ho d the spray gun firm y in your hand before you start the unit.
Fai ure to do so cou d resu t in an injury from a whipping spray
gun. Do not eave the spray gun unattended whi e the machine
is running.
 The c eaning area shou d have adequate s opes and drainage to
reduce the possibi ity of a fa due to s ippery surfaces.
 Keep water spray away from e ectric wiring or fata e ectric shock
may resu t.
 Do not secure trigger gun in the pu -back (open) position.
 Do not by-pass any safety device on this machine.
 The muff er and engine heat up during operation and remain hot
immediate y after shutting it down. Avoid contact with a hot muf-
f er or engine or you cou d be severe y burned.
 Operate and store this unit on a stab e surface.
 Never a ow any part of the body to come in contact with the f uid
stream. DO NOT come in contact with a f uid stream created by
a eak in the high pressure hose.
 High pressure hose can deve op eaks from wear, kinking, abuse,
etc. Water spraying from a eak is capab e of injecting materia
into skin. Inspect hose each time before using it. Check a hoses
for cuts, eaks, abrasions or bu ging of cover, or damage or move-
ment of coup ings. If any of these conditions exist, rep ace hose
immediate y. Never repair high pressure hose. Rep ace it with
another hose that meets minimum pressure rating of your pres-
sure washer.
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects, or other reproductive harm.
WWAARRNNIINNGG::

Generac 2700PSI High Pressure Washer
GENERAC
3
High Pressure Washer
CONGRATULATIONS on your purchase of a
GENERAC high pressure washer It has been
designed, engineered and manufactured to give you
the best possible dependability and performance
Should you experience any problem you cannot
easily remedy, please contact your nearest GEN-
ERAC Authorized Service facility, or call the 1-800
number listed on the front of this manual We have
competent, well-trained technicians and the proper
tools to service or repair this unit
Please read and retain this manual The instructions
will enable you to assemble and maintain your high
pressure washer properly
CUSTOMER
RESPONSIBILITIES
 Read and observe the safety rules
 Follow regular schedule in maintaining, caring for
and using your high pressure washer
 Follow the instructions under Customer Responsi-
bilities and Storage sections of this Owner's
Manual
PRODUCT SPECIFICATIONS
Pressure Washer Specifications
Outlet Pressure 2700 psi
Flow Rate 2 5 gallons per minute (gpm)
Detergent Mix Use undiluted detergent
approved for pressure
washers
Water Supply Not to Exceed 140°F
Temperature
Automatic Cool Will cycle when water
Down System reaches 140°-145°F
Engine specifications
Engine Model Briggs & Stratton Vanguard
Rated Horsepower 6 0
Displacement 181cc
Spark Plug
Type RC-12YC
Set Gap To: 0 030 inch (0 76mm)
Gasoline Capacity 4 2 U S quarts
Oil . . . . . . . . . . . . . . . SAE 30
In the State of California a spark arrestor is required
by law (Section 4442 of the California Public
Resources Code) Other states may have similar
laws Federal laws apply on federal lands
NOTE: The spark arrestor must be maintained in
effective working order by the owner/operator
You can order a replacement spark arrestor through
your authorized Generac service facility See Engine
Owners Manual for part number
Model Number 1043-1
Serial Number
Date of Purchase
The model and serial numbers will be found on a
decal attached to the pressure washer You should
record both serial number and date of purchase and
keep in a safe place for future reference

4
High Pressure Washer
KNOW YOUR PRESSURE WASHER
Read this owners manual and safety rules before operating your high pressure washer. Com-
pare the illustrations with your high pressure washer to familiarize yourself with the locations of various controls
and adjustments Save this manual for future reference
Generac 2700PSI High Pressure Washer
GENERAC
Pump  Develops high pressure
Recoil Starter  Used for starting engine manually
Spray Gun  Controls the application of water and
chemical onto cleaning surface with trigger device
Includes safety latch
Chemical Valve Handle  The handle allows you to
select the high pressure spray or the chemical spray
(located on the wand)
Dual Element Air Cleaner  Uses a dry type filter
element and foam pre-cleaner to limit the amount of
dirt and dust that gets in the engine
Water Inlet  Connection for garden hose
Dual Lance  Must be connected to the spray gun
Spark Arrestor Muffler  Exhaust muffler lowers
engine noise and is equipped with a spark arrestor
screen, a USDA mandate for engine use in national
forests and parks
High Pressure Outlet  Connection for high pressure
hose
High Pressure Hose  Connect one end to water
pump and the other end to spray wand
Goggles  Always use the enclosed goggles or other
eye protection when running your pressure washer
Automatic Cool Down System  Cycles water
through pump when water reaches 140°-145°F Warm
water will discharge from pump onto base of unit.
This system prevents internal pump damage.
Choke - not shown on this view of unit
Spray Gun
Chemical Valve Handle
High Pressure Hose
Goggles
Dual element
Air Cleaner
Gas Tank
Water Inlet
Pump equipped with
Automatic Cool Down System
High Pressure Outlet
Engine Oil Fill Cap
Pressure Control
Knob
Spark Arrestor
Muffler
Dual Lance
Chemical
Concentration Knob

High Pressure Washer
5
Read entire owners manual before you attempt to
assemble or operate your new pressure washer
Your new pressure washer has been assembled at
the factory with the exception of those parts left
unassembled for shipping purposes
REMOVE PRESSURE
WASHER FROM CARTON
 Remove parts box included with pressure washer
 Slice two corners at guide handle end of carton
from top to bottom so the panel can be folded down
flat, then remove all packing material
 Roll pressure washer out of carton
CARTON CONTENTS
Items in the carton include:
 Main Unit
 Manual Bag
 Owners Manual
 Engine Owners Manual
 Parts Box (which includes the following):
 Wireform
 Goggles
 Spray Gun
 Dual Lance
 High Pressure Hose
 Nozzle Cleaning Kit
 Handle
 Handle Parts Bag (which includes the following):
 2 carriage bolts
 2 knobs
If any of the above parts are missing or damaged, call
the pressure washer helpline at 18002 01408.
PREPARING THE PRESSURE
WASHER FOR USE
If you have any problems with the assembly of your
pressure washer or if parts are missing or damaged,
call the Pressure Washer Helpline at 1-800-2 0-1408.
To prepare your pressure washer for operation you
will need to perform these tasks:
 Attach the handle and attach the wire form that
holds high pressure hose and spray gun
 Connect high pressure hose to the spray gun and
the pump and connect water supply to the pump
 Add oil to engine crankcase
 Add fuel to fuel tank
Attach the Handle
 Place the top of the handle onto the bottom of the
handle already connected to the main unit making
sure the holes in the top align with the holes on the
handle supports (Figure 1)
Note: It may be necessary to move the handle
supports from side to side in order to align the handle
so it will slide over the handle supports
Generac 2700PSI High Pressure Washer
AASSSSEEMMBBLLYY
GENERAC
Figure 1 — Attach the top of the handle to the
bottom of the handle.
Make sure the
holes on the top
of the handle
supports are
aligned with the
holes in the
bottom of the
handle.
Handle
Handle
Supports

 Insert the carriage bolts form the outside through
the holes on the handle and attach the plastic
knobs on the inside Tighten the knobs by hand
(Figure 2)
 Insert the wire support with the longer arm positioned
on the left From this view (from rear of unit) the hook
should resemble a J (Figure 3)
Add Engine Oil
IMPORTANT: Any attempt to crank or start the
engine before it has been properly serviced with the
recommended oil may result in an engine failure
Note: When adding oil to the engine crankcase, use
only high quality detergent oil rated with API service
classification SF,SG, SH or SH/CD rated SAE 30
weight Select the oils viscosity grade according to
your expected operating temperature Do Not Use
SAE 10W40 Oil
Although multi-viscosity oils (5W30, 10W30, etc )
improve starting in cold weather, these multi-viscosity
oils will result in increased oil consumption when used
above 32°F Check your engine oil level more
frequently to avoid possible damage from running
low on oil
 Place pressure washer on a level surface
 Clean area around oil fill and remove yellow oil fill
cap (Figure 4)
 Pour oil into the oil fill opening until it reaches the
top DO NOT OVERFILL
 Install yellow oil cap, hand tighten securely
Note: Check Oil Often During Engine Breakin.
Add Gasoline
DANGER! Never fill fuel tank indoors.
Never fill fuel tank when engine is
running or hot. Do not smoke when filling
fuel tank.
WARNING! Never fill fuel tank completely
full. Fill tank to about 1/2" below the
bottom of the filler neck to provide space
for fuel expansion. Wipe away any fuel
spillage from engine and equipment
before starting.
Generac 2700PSI High Pressure Washer
AASSSSEEMMBBLLYY
GENERAC
6
High Pressure Washer
Figure 3 — Fit wire form on handle.
Figure 4 — Add oil to engine crankcase. Do not
attempt to start engine without
adding oil.
Figure 2 — Insert the carriage bolt and attach
the knobs.
colder 32°F warmer
5W30 SAE 30
Yellow
Oil Fill Cap

Generac 2700PSI High Pressure Washer
GENERAC
AASSSSEEMMBBLLYY
7
High Pressure Washer
The manufacturer recommends fresh, clean unleaded
automotive gasoline
 Use clean fuel and store in approved, clean, cov-
ered containers Use clean fill funnels Never use
stale gasoline left over from last season or gaso-
line stored for long periods
 Clean area around fuel fill cap, remove cap
(Figure 5)
 Add UNLEADED gasoline, slowly, to fuel tank
Use a funnel to prevent spillage
 Install fuel cap and wipe up any spilled gasoline
Connect Hose and Water
Supply to Pump
IMPORTANT: You must assemble wand and attach
all hoses before you start engine Starting engine
without all hoses connected and water supplied will
damage pump
 Uncoil high pressure hose and attach the end of the
hose with the threaded end to the base of the spray
gun (Figure 6) Tighten by hand
 Attach other end of high pressure hose to the high
pressure outlet on the pump (Figure 7) Tighten by
hand
 Before you connect your garden hose to the water
inlet, inspect the water inlet screen (see Figure 8)
Clean the screen if it contains debris or have it
replaced if damaged Do not run the pressure
washer if the water inlet screen is damaged.
 Connect garden hose to water inlet Tighten firmly
by hand (Figure 8)
 Turn on the water (open valve completely)
 Squeeze trigger on gun to purge pump system of
air and impurities Squeeze until a steady stream
appears
Warning: Before starting the pressure
washer, be sure you are wearing
adequate eye protection.
Figure 7 — Connect high pressure hose to
pump.
Figure 6 — Connect high pressure hose
to spray gun.
Figure 8 — Connect the garden hose to water
inlet and turn ON the water.
Figure 5 — Add gasoline to fuel tank.
Gas Cap
Connect High Pressure
Hose Here
Connect Garden
hose here.
Check Screen
for Damage.
Connect high
pressure hose
here

Generac 2700PSI High Pressure Washer
GENERAC
AASSSSEEMMBBLLYY
8
High Pressure Washer
 Attach dual lance to spray gun Tighten by hand
(Figure 9) CHECKLIST BEFORE
STARTING ENGINE
If you have reached this point, look back over the
assembly to see if you have performed all of the fol-
lowing
 Check for properly tightened hose connections
(high pressure and water supply) and for tight con-
nections and that there are no kinks, cuts, or
damage to the high pressure hose, or garden hose
 Check that oil has been added to proper level in
engine crankcase before trying to start the pressure
washer
 Add proper gasoline to fuel tank
 Provide proper water supply (not to exceed 140°F)
 Be sure to read Safety Rules and Operation sec-
tions before using the pressure washer
Figure 9 — Connect nozzle extension to spray
gun.

HOW TO USE YOUR
PRESSURE WASHER
If you have any problems operating your pressure
washer, please call the pressure washer helpline at
1-800-2 0-1408
You have assembled your high pressure washer and
have prepared the engine for starting You are now
ready to clean your car, boat, the outside of a building
or whatever you plan to clean
How to Start Your Engine
The best way to start your engine-powered pressure
washer for the first time is to follow these instructions
step-by-step This starting information also applies
whenever you start the engine after you have let the
pressure washer sit idle for at least a day
 This pressure washer requires a water source that
flows at least 2 gallons per minute Do not attempt
to siphon water from a non-pressurized container.
Place the pressure washer close enough to an out-
side water source so that no more than 50' of
garden hose is needed
 Check that the high pressure hose is tightly
connected to the spray gun and to the pump
See ASSEMBLY section for illustrations
 Connect the garden hose to water inlet on the
pressure washer pump and turn the water on all
the way.
IMPORTANT: Do not run pump without the water
supply connected and turned on You must follow this
caution or the pump will be damaged
 Set choke control to Choke position Note: This
is a multi-position choke
 Move the throttle control to the Fast position
Note: For a warm engine, be sure the Throttle Con-
trol Lever is in the Fast position and the Choke
Lever is in the Run position
 Turn the fuel shutoff valve to the On position
 Move the stop control to the On position
 Squeeze the trigger on the spray gun to relieve air
pressure caused by turning ON the water Water
will spew out the gun in a thin stream Continue to
hold trigger until you have a steady stream of water
and no air remains This will make it easier to pull
start the engine Release the trigger
 Grasp rope handle and pull slowly until you feel
some resistance Then pull cord rapidly to over-
come compression, prevent kickback and start the
engine Let rope return to starter slowly
Note: Always keep the throttle control in the Fast
position when operating the pressure washer
 When the engine starts, gradually move the choke
control from one position to the next until it is in the
Run position
If after 3 pulls the engine fails to start, disengage the
spray gun safety latch, squeeze the trigger to relive
water pressure, re-engage the spray gun safety latch,
move the choke control to the Run position and pull
the recoil starter handle rapidly (Max 3 pulls)
How to Stop Your Pressure
Washer
Important: Do Not move the choke control to
Choke position to stop the engine Backfire or
engine damage may occur
 Move the throttle control to the Idle or Slow
position
 Wait for the engine to idle down
 Move the stop control to the Off position
 Close the fuel shutoff valve
Squeeze trigger on the spray gun to relieve
pressure in the hose. Simply shutting off the
engine will not release pressure in the system
Note: A small amount of water will squirt out when
you release the pressure
Generac 2700PSI High Pressure Washer
GENERAC
9
High Pressure Washer
Figure 11 — Safety Latch.
Safety Latch On

Generac 2700PSI High Pressure Washer
GENERAC
10
High Pressure Washer
How to Use the Dual Lance and
Adjust Pressure
You now should know how to START your pressure
washer and how to STOP it The information in this
section will tell you how to adjust the pressure and
apply detergent or any other cleaning chemicals
IMPORTANT: You must attach all hoses and turn
on the water source fully before you start the engine
Starting the engine without all the hoses connected
and without the water turned on will damage the
pump
DANGER! Never put hands in front of
nozzle.
 Located on the side of the pump is a pressure con-
trol knob You can increase and decrease the
pressure of the spray by turning the knob clockwise
or counterclockwise respectively (Figure 12)
 Point the nozzle toward the ground and squeeze
the trigger to test the pressure Be careful not to
spray your feet
 For most effective cleaning, keep spray nozzle
between 8 to 24 inches away from cleaning sur-
face
 If you get spray nozzle too close, especially using
high pressure, you may damage the cleaning sur-
face
 Do not get closer than 6 inches when cleaning
automobile tires
Applying Detergent
IMPORTANT: Use soaps designed specifically for
pressure washers. Household detergents could
damage the pump
IMPORTANT: You must attach all hoses and turn
on the water source fully before you start the engine
Starting the engine without all the hoses connected
and without the water turned on will damage the
pump
To apply detergent follow these steps:
 Prepare the detergent solution as required by the
job
 Hang the detergent solution on J hook of the wire-
form on the handle
 Place small filter end of the chemical injecting tube
into the detergent container (Figure 13)
 Adjust chemical concentration knob for desired
chemical concentration
 Open the chemical valve handle fully on the lance
by turning it counterclockwise
IMPORTANT: Detergent cannot be applied without
the water source turned on
 Make sure garden hose is connected to water inlet
Check that high pressure hose is connected to
spray gun and pump (see ASSEMBLY), and start
engine
 Apply detergent to a dry surface, starting from the
bottom and working up to avoid streaking
Figure 12 — Pressure control knob.
Figure 13 — Insert the small filter into container
of cleaning solution.
Pressure Control Knob
Chemical
Concentration
Knob

Generac 2700PSI High Pressure Washer
GENERAC
11
High Pressure Washer
 Allow the detergent to soak in for 3-5 minutes
before washing and rinsing Reapply to prevent
surface from drying
 For washing, start at lower portion of area to be
washed and work upward, using long, even,
overlapping strokes
CAUTION: Keep the plastic injector tube
from coming in contact with the hot
muffler. This will damage the plastic tube.
When inserting the filter into a cleaning
agent bottle, route the tube so as to keep
it from inadvertently contacting the hot
muffler.
Pressure Washer Rinsing
WARNING: Be extremely careful if you
must use the pressure washer from a
ladder, scaffolding or any other relatively
unstable location. Pressure in a running
washer builds as you climb. When you
press the trigger, the recoil from the initial
spray could force you to fall. The high
pressure spray could also force you to fall if
you are too close to the cleaning surface.
For Rinsing:
 Remove the chemical injector hose from the
chemical bottle to stop detergent from flowing
Spray until the detergent has cleared form the gun
 Turn the chemical valve handle clockwise fully until
it stops This puts the gun into high pressure mode
 Keep the spray gun a safe distance from the area
you plan to spray
 Apply a high pressure spray to a small area and
then check the surface for damage If no damage
is found, you can assume it is okay to continue
cleaning
 Start at top of area to be rinsed, working down with
same overlapping strokes as you used for cleaning
Automatic Cool Down System
(Thermal Relief)
If you run the engine on your pressure washer for 3-5
minutes without pressing the trigger on the spray gun,
circulating water in the pump can reach a tempera-
ture between 140145°F When the water reaches
this temperature, the automatic cool down system
engages and cools the pump by discharging the
warm water onto the ground. This system prevents
internal damage to the pump

Generac 2700PSI High Pressure Washer
GENERAC
12
High Pressure Washer
GENERAL MAINTENANCE
RECOMMENDATIONS
The warranty of the high pressure washer does not
cover items that have been subjected to operator
abuse or negligence To receive full value from the
warranty, operator must maintain high pressure
washer as instructed in this manual
 Some adjustments will need to be made periodi-
cally to properly maintain your high pressure
washer
 All adjustments in the Service and Adjustments
section of the engine owners manual should be
made at least once each season
 Once a year you should clean or replace the spark
plug, clean or replace the air filter and check the
gun and wand assembly for wear A new spark plug
and clean air filter assure proper fuel-air mixture
and help your engine run better and last longer
BEFORE EACH USE
 Check engine oil level
 Check water inlet screen for damage
 Check high pressure hose for leaks
 Check detergent inlet hose and filter for damage
 Check gun and wand assembly for leaks
PRESSURE WASHER
MAINTENANCE
Check and Clean Inlet Screen
Examine screen on the water inlet Clean if the
screen is clogged or replace if screen is damaged
Check High Pressure Hose
High pressure hose can develop leaks from wear,
kinking, or abuse Inspect hose each time before
using it Check for cuts, leaks, abrasions or bulging of
cover, damage or movement of couplings If any of
these conditions exist, replace hose immediately
DANGER: Water spraying from a leak is
capable of injecting material into skin.
Inspect hose each time before using it.
Never repair a high pressure hose.
Replace it with another hose that meets
the maximum pressure rating of your
pressure washer.
Check Detergent Hose
Examine the filter on the detergent hose and clean if
clogged Hose should fit tightly on barbed fitting
Examine hose for leaks or tears Replace the filter or
hose if either is damaged
Check Gun and Wand
Examine hose connection to gun and make sure it is
secure Test trigger by pressing it and making sure it
springs back into place when you release it Put safety
latch in on position and test trigger You should not be
able to press trigger
Purge Pump of Air and
Contaminants
To remove the air from the pump, follow these
steps:
 Set up the pressure washer as described in the
ASSEMBLY section and connect the water supply
 Remove the dual lance from the gun
 Squeeze the trigger on the gun and hold
To remove any contaminants from the pump,
follow these steps:
 Set up the pressure washer as described in the
ASSEMBLY section, and connect the water supply
 Remove the dual lance from the spray gun
 Start the engine according to instructions in OPER-
ATION section
 Squeeze the trigger on the spray gun and hold
 When the water supply is steady and constant,
engage the safety latch and refasten the dual lance
Cleaning Chemical Injector Hose
If you have used the chemical injector hose you must
flush it with clean water before stopping the engine
To clean the chemical injector hose:
 Place the small filter end of the chemical injector
hose in a bucket of clean water
 Open the chemical valve handle fully on the lance
by turning it counterclockwise This puts the gun in
low pressure
 Squeeze the spray gun trigger for 1 - 2 minutes to
flush the chemical injector hose
 Shut off the engine
Important: Simply shutting OFF engine will not release
pressure in the system When engine has shut
down, squeeze the trigger on the gun to relieve the
pressure in the hose.

Nozzle Maintenance
If the nozzle on the dual lance becomes restricted or
clogged with foreign materials, such as dirt, excessive
pump pressure may develop If this nozzle becomes
partially clogged, it can cause a pulsing sensation
during use This generally is not a pump related
problem, but rather a clogged or partially restricted
nozzle
If the nozzle becomes clogged or partially restricted,
immediately clean the nozzle with the kit included
with your pressure washer by following these instruc-
tions:
 Shut off the engine and turn off the water supply
 Press trigger to relieve pressure
 Separate the dual lance from the gun
 Use the wire included in the kit (Figure 14) or a
small paper clip to free the foreign materials clog-
ging or restricting the nozzle
Figure 14 — Removing and cleaning nozzle.
 Remove additional debris by back flushing water
supply through dual lance (Figure 15) Back flush
between 30 to 60 seconds Back flush both lances
by turning chemical valve handle
Figure 15 — Backflushing the nozzle.
 Reconnect the dual lance to the spray gun
 Reconnect the water supply, turn on the water, and
start the engine
 Test the pressure washer by operating with nozzle
in the high and in the low position
ENGINE MAINTENANCE
See the engine Owners Manual for instructions on
how to properly maintain the engine
SERVICE AND
ADJUSTMENTS
See the engine Owners Manual for instructions on
how to properly service and adjust the engine
13
High Pressure Washer
Generac 2700PSI High Pressure Washer
GENERAC

14
High Pressure Washer
PREPARING THE UNIT FOR
STORAGE
Water should not remain in the unit for long periods of
time Sediments of minerals can deposit on pump
parts and freeze pump action If you do not plan to
use the pressure washer for more than 30 days,
follow this procedure:
1 Flush chemical injector hose by placing the injector
filter into a pail of clean water while running pres-
sure washer and squeezing the spray gun trigger
with the dual lance in low pressure mode Flush for
two minutes
2 Shut off the engine and let it cool, then remove all
hoses
3 Place Run/Stop Switch in STOP position
4 Empty the pump of all liquids by pulling recoil
handle about 6 times This should remove most of
the liquid in the pump
NOTE: To protect unit from freezing temperatures,
draw R V Antifreeze fluid into pump by pouring
Antifreeze fluid into a 3-foot section of garden hose
connected to inlet adapter and pulling recoil handle
twice
5 Store in a clean, dry area
STORING THE ENGINE
See the engine Owners manual for instructions on
how to properly store the engine
GENERAC
Generac 2700PSI High Pressure Washer

NOTES
15
High Pressure Washer
GENERAC
Generac 2700PSI High Pressure Washer

TROUBLESHOOTING POINTS
Generac 2700PSI High Pressure Washer
GENERAC
16
High Pressure Washer
Problem Cause Correction
Pump has fo owing prob ems: 1. Lance in ow pressure mode. 1. Adjust chemica va ve hand e to
fai ure to produce pressure, erratic high pressure.
pressure, chattering, oss of pressure, 2. Water in et is b ocked. 2. C ear in et.
ow water vo ume. 3. Inadequate water supp y. 3. Provide adequate water f ow.
4. Garden hose is kinked or eaking. 4. Straighten garden hose, patch eak.
5. C ogged in et hose strainer. 5. Check and c ean water in et screen.
6. Water supp y is over 140°F. 6. Provide coo er water supp y.
7. Out et hose is b ocked or eaks. 7. C ear b ocks in out et hose.
8. Gun eaks. 8. Rep ace gun.
9. Nozz e is obstructed. 9. C ear nozz e.
10. Pump is fau ty. 10. Contact Generac service faci ity.
Detergent fai s to mix with spray. 1. Chemica injector hose is not submerged. 1. Insert chemica ine into deter
gent.
2. Chemica injector hose is c ogged. 2. C ean or rep ace fi ter/chemica
injector hose.
3. Nozz e is in high pressure mode. 3. Push nozz e forward for ow
pressure mode.
4. Chemica concentration knob is c osed. 4. Open chemica concentration knob.
Engine runs we when not spraying Engine speed is too s ow. Contact Generac service faci ity.
but bogs down when the trigger is
squeezed.

TROUBLESHOOTING POINTS
17
High Pressure Washer
GENERAC
Generac 2700PSI High Pressure Washer
PROBLEM CAUSE CORRECTION
Engine wi not start; or starts 1. Low oi eve . 1. Fi crankcase to proper eve .
and runs rough. 2. Dirty air c eaner. 2. C ean or rep ace air c eaner.
3. Out of gaso ine. 3. Fi fue tank.
4. Sta e gaso ine. 4. Drain gas tank; fi with fresh fue .
5. Spark p ug wire not connected 5. Connect wire to spark p ug.
to spark p ug.
6. Bad spark p ug. 6. Rep ace spark p ug.
7. Water in gaso ine. 7. Drain gas tank; fi with fresh fue .
8. Excessive y rich fue mixture. 8. Contact Generac service faci ity.
9. Intake va ve stuck open or c osed. 9. Contact Generac service faci ity.
10. Engine has ost compression. 10. Contact Generac service faci ity.
Engine shuts down during operation. 1. Out of gaso ine. 1. Fi fue tank.
2. Low oi eve . 2. Fi crankcase to proper eve .
Engine acks power. Dirty air fi ter. Rep ace air fi ter.
Engine hunts or fa ters. Engine not operating proper y. Contact Generac service faci ity.

GENERAC
EXPLODED VIEW  PRESSURE WASHER
Drawing No B3080
Generac 2700PSI High Pressure Washer
18
High Pressure Washer
18

REPAIR PARTS  PRESSURE WASHER
Drawing No B3080
GENERAC
19
High Pressure Washer
Generac 2700PSI High Pressure Washer
1 A1040D 1 HOSE, 4-1/2 Chemical Clear
2 A1041 1 FILTER, Chemical Hose
3 70453 1 TAG, Warning Oil
4 97178 2 KNOB, Handle 1/4 - 20 PW
5 31669 2 BOLT, 1/4 - 20 x 1-3/4 Carriage
7 99583 8 NUT, Flange Lock 5/16-18
8 B1982 1 BUMPER
9 97054 1 TAG, Pres Adjust
10 B1288 1 TAG, PW Breather Cap
11 B1232 1 CLAMP, Hose 7/16 Dia
14 45771 8 NUT, M8 - 1 25 Hex
15 22129 9 LOCKWASHER, M8
16 21217 2 MOUNT, Rubber Shock
18 97100 1 CAP, H P Adaptor
19 97098 1 CAP, Garden Hose Inlet
20 B2043 7 BOLT, 5/16-18 x 1-3/4 Carriage
21 N/A 1 ASSEMBLY, Pump
(see pump exploded view)
22 B2223C 1 ENGINE
23 B1983 1 HANDLE
24 B1631A 1 BILLBOARD, Plastic
25 B1932 1 DECAL, Instructions
26 B1981 2 SUPPORT, Handle
27 B2192 1 DECAL, Generac
28 B1760 2 ASSEMBLY, 10" Tire & Wheel
29 75402 2 PUSHNUT, 50 Dia
30 AB1770 1 BASE
31 52858 2 NUT, M8 1 25 Locking
32 42909 2 HHCS, M8 1 25 x 30
33 50190 2 WASHER, M8 Flat
34 27007 2 MOUNT, Donut Type Vibration
35 20566 1 DECAL, Generac #1-800
36 B2150 1 HOOK , Gun
37 B3081 1 DECAL, Logo
38 52857 2 NUT, M6 1 0 Locking
39 20707 1 BRACKET, Pump Support
40 21216 2 MOUNT, Rubber Shock
41 38750 2 HHCS, M6 1 0 x 30
42 91630 1 HOSE, High Pressure
43 87815 1 GOGGLES, Saftey
44 B2140C 1 LANCE, Dual
45 B1862 1 GUN, High Pressure
46 B2203 1 KIT, Handle Fastening
47 B2508 1 KIT, Cleaning
48 B1460 2 CAP, Vinyl (black)
49 B2168 1 HANGER, Hose, Gun, Jug
50 42907 1 SHCS, M8 1 25 x 16 Lg
51 95441 0 SPACER, Engine Pilot (not
shown)
52 B3088 1 DECAL, Engine
53 B3079 1 MANUAL
54 B3084 1 MANUAL,Engine
ITEM PART NO.QTY DESCRIPTION ITEM PART NO.QTY DESCRIPTION

EXPLODED VIEW  PUMP
GENERAC
Generac 2700PSI High Pressure Washer
Drawing No B3087
20
High Pressure Washer
