Generac Power Systems 2000PSI User manual

2000PSI
This symbol points out important safety instructions, which, if not followed, could
endanger the personal safety and/or property of yourself and others. Read and follow all
instructions in the manual before attempting to operate this unit.
Model No. 1040 3 (2000 PSI High Pressure Washer) Manual No. B4561 Revision 0 (4/12/1999)
Owner’s Manual
Problems?
Questions?
Before taking your unit
back to the store,
call the pressure washer
helpline at
1-800-270-1408
M-F 8-5 CT
GENERAC
The Reliable Ones

2
Generac Portable Products 2000 PSI High Pressure Washer
SAFETY RULES
DANGER! Always disconnect spark plug
wire and place wire where it cannot
contact spark plug to prevent accidental
starting when setting up, transporting,
ad usting or making repairs to your high
pressure washer.
 Engine exhaust gases contain DEADLY carbon
monoxide gas. This dangerous gas, if breathed
in sufficient concentrations, can cause
unconsciousness or even death. Operate this
equipment only in the open air where adequate
ventilation is available.
 Gasoline is highly FLAMMABLE and its vapors
are EXPLOSIVE. Do not permit smoking, open
flames, sparks or heat in the vicinity while
handling gasoline. Avoid spilling gasoline on a
hot engine. Allow unit to cool for 2 minutes
before refueling. Comply with all laws
regulating storage and handling of gasoline.
 Locate this pressure washer in areas away
from combustible materials, combustible fumes
or dust.
 The high pressure equipment is designed to be
used with Generac authorized parts only. If you
use this equipment with parts that do not
comply with minimum specifications, the user
assumes all risks and liabilities.
 Some chemicals or detergents may be harmful
if inhaled or ingested, causing severe nausea,
fainting or poisoning. The harmful elements
may cause property damage or severe in ury.
 Do not allow CHILDREN to operate the
Pressure Washer at any time.
 Operate engine only at governed speed.
Running the engine at excessive speeds
increases the hazard of personal in ury. Do not
tamper with parts which may increase or
decrease the governed speed.
 Do not wear loose clothing, ewelry or anything
that may be caught in the starter or other
rotating parts.
 Before starting the Pressure Washer in cold
weather, check all parts of the equipment and
be sure ice has not formed there.
 Units with broken or missing parts, or without
protective housing or covers should NEVER be
operated.
 The muffler and air cleaner must be installed
and in good condition before operating the
Pressure Washer. These components act as
spark arrestors if the engine backfires.
 Check the fuel system for leaks or signs of
deterioration such as chafed or spongy hose,
loose or missing clamps or damaged tank or
cap. Correct all defects before operating the
Pressure Washer.
 Do not spray flammable liquids.
 Never aim the gun at people, animals or
plants.
 High pressure spray can cause paint chips or
other particles to become airborne and fly at
high speeds.
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects, or other reproductive harm.
WARNING:
IMPORTANT!  SAFETY RULES  IMPORTANT!

3
Generac Portable Products 2000 PSI High Pressure Washer
 Never allow any part of the body to come in
contact with the fluid stream. DO NOT come in
contact with a fluid stream created by a leak in
the high pressure hose.
 The high pressure stream of water that this
equipment produces can pierce skin and its
underlying tissues, leading to serious in ury
and possible amputation.
 Always wear eye protection when you use this
equipment or when you are in the vicinity
where the equipment is in use.
 Never move the machine by pulling on the high
pressure hose. Use the handle provided on the
top of the unit.
 Always be certain the spray gun, nozzles and
accessories are correctly attached.
 Never use a spray gun that does not have a
trigger lock or trigger guard in place and in
working order.
 Use a respirator or mask whenever there is a
chance that vapors may be inhaled. Read all
instructions with mask so you are certain the
mask will provide the necessary protection
against inhaling harmful vapors.
 High pressure spray may damage fragile items
including glass. Do not point spray gun at glass
when in the et spray mode.
 Keep all hoses connected to pressure washer
and the spray gun while the system is
pressurized. Disconnecting the hoses while the
unit is pressurized is dangerous.
 Hold the spray gun firmly in your hand before
you start the unit. Failure to do so could result
in an in ury from a whipping spray gun. Do not
leave the spray gun unattended while the
machine is running.
 The cleaning area should have adequate
slopes and drainage to reduce the possibility of
a fall due to slippery surfaces.
 Keep water spray away from electric wiring or
fatal electric shock may result.
 Do not secure gun trigger in the pullback
(open) position.
 Do not bypass any safety device on this
machine.
 The muffler and engine heat up during
operation and remain hot immediately after
shutting it down. Avoid contact with a hot
muffler or engine or you could be severely
burned.
 Operate and store this unit on a stable surface.
 High pressure hose can develop leaks from
wear, kinking, abuse, etc. Water spraying from
a leak is capable of in ecting material into
skin. Inspect hose each time before using it.
Check all hoses for cuts, leaks, abrasions or
bulging of cover, or damage or movement of
couplings. If any of these conditions exist,
replace hose immediately. Never repair high
pressure hose. Replace it with another hose
that meets maximum pressure rating of your
pressure washer.
IMPORTANT!  SAFETY RULES  IMPORTANT!

4
Generac Portable Products 2000 PSI High Pressure Washer
CONGRATULATIONS on your purchase of a
GENERAC high pressure washer. It has been
designed, engineered and manufactured to give you
the best possible dependability and performance.
Should you experience any problem you cannot
easily remedy, please contact your nearest
GENERAC Authorized Service facility, or call the
1800 number listed on the front of this manual. We
have competent, welltrained technicians and the
proper tools to service or repair this unit.
Please read and retain this manual. The instructions
will enable you to assemble and maintain your high
pressure washer properly.
CUSTOMER
RESPONSIBILITIES
 Read and observe the safety rules.
 Follow regular schedule in maintaining, caring for
and using your high pressure washer.
 Follow the instructions under Customer
Responsibilities and Storage sections of this
Owner's Manual.
PRODUCT
SPECIFICATIONS
Pressure Washer Specifications
Outlet Pressure . . . . 2000 psi
Flow Rate . . . . . . . . . 2.0 gallons per minute (gpm)
Detergent Mix . . . . . . Use undiluted detergent
approved for pressure
washers
Water Supply . . . . . . Not to Exceed 140°F
Temperature
Automatic Cool . . . . Will cycle when water
Down System reaches 140°-145°F
Engine Specifications
Engine Model . . . . . . Briggs & Stratton Quantum
Rated Horsepower . . 6.0
Displacement . . . . . . 190cc
Spark Plug
Type . . . . . . . . RJ19LM
Set Gap To: . . 0.030 inch (0.76mm)
Gasoline Capacity . . 1.6 U.S. quarts
Oil . . . . . . . . . . . . . . . SAE 30
In the State of California a spark arrestor is required
by law (Section 4442 of the California Public
Resources Code). Other states may have similar
laws. Federal laws apply on federal lands.
NOTE: If you equip the engine of your pressure
washer with a spark arrestor muffler, the spark
arrestor must be maintained in effective working order
by the owner/operator.
You can order a spark arrestor through your
authorized Briggs & Stratton service facility. See
Engine Owners Manual for part number.

5
Generac Portable Products 2000 PSI High Pressure Washer
Spray Gun
Adjustable Nozzle
Extension
High Pressure Hose
Goggles
Air Cleaner
Gas Tank
Water Inlet
Pump equipped with
Automatic Cool Down System
Recoil Starter
High Pressure Outlet
Oil Fill Tube
Adjustable Nozzle Extension  You must attach this
to the spray gun to provide high pressure stream. The
ad ustable nozzle allows you to ad ust the spray pattern
which, in turn, ad usts the force of spray.
Air Cleaner  Dry type filter element limits the amount
of dirt and dust that gets in the engine.
Automatic Cool Down System  Cycles water
through pump when water reaches 140°-145°F. Warm
water will discharge from pump onto ground. This
system prevents internal pump damage.
Gas Tank  Fill with regular unleaded gasoline only.
Goggles  Always use the enclosed goggles or other
eye protection when running your pressure washer.
High Pressure Hose  Connect one end to water
pump and the other end to spray wand.
High Pressure Outlet  Connection for high pressure
hose.
Oil Fill Tube  Fill engine with oil here. See page 7 for
oil recommendations.
Pump  Develops high pressure.
Recoil Starter  Used for starting the engine
manually.
Spray Gun  Controls the application of water onto
cleaning surface with trigger device. Includes safety
latch.
Water Inlet  Connection for garden hose.
KNOW YOUR PRESSURE WASHER
Read this owners manual and safety rules before operating your high pressure washer.
Compare the illustrations with your high pressure washer to familiarize yourself with the locations of various
controls and ad ustments. Save this manual for future reference.

6
Generac Portable Products 2000 PSI High Pressure Washer
Read entire owners manual before you attempt to
assemble or operate your new pressure washer. Your
new pressure washer has been assembled at the
factory with the exception of those parts left
unassembled for shipping purposes.
REMOVE PRESSURE
WASHER FROM CARTON
 Remove parts box included with pressure washer.
 Slice two corners at guide handle end of carton
from top to bottom so the panel can be folded down
flat, then remove all packing material.
 Roll pressure washer out of carton.
CARTON CONTENTS
Items in the carton include:
 Main Unit
 Parts Box (which includes the following):
 Wireform
 ORing Maintenance Kit.
 Goggles
 Nozzle Cleaning Kit
 Owners Manual
 Engine Manual
 Spray Gun
 Nozzle Extension
 High Pressure Hose
 Handle
 Bottle of Oil
 Owners Registration Card
 Parts Bag (which includes the following):
 1 carriage bolt
 1 carriage hook
 2 knobs
If any of the above parts are missing or damaged, call
the pressure washer helpline at 1 800 270 1408.
PREPARING PRESSURE
WASHER FOR USE
If you have any problems with the assembly of your
pressure washer or if parts are missing or damaged,
call the Pressure Washer Helpline at 1-800-270-1408.
To prepare your pressure washer for operation you
will need to perform these tasks:
 Attach the handle and the wire form that holds high
pressure hose and spray gun.
 Connect high pressure hose to the spray gun and
the pump, and connect water supply to the pump.
 Add oil to engine crankcase.
 Add fuel to fuel tank.
Attach the Handle
 Place the top of the handle onto the bottom of the
handle already connected to the main unit making
sure the holes in the top align with the holes on the
bottom (Figure 1).
Figure 1  Attach the top of the handle to the bottom of
the handle.
Make sure the
holes on the
top of the
handle are
aligned with the
holes in the
bottom of the
handle

7
Generac Portable Products 2000 PSI High Pressure WasherGenerac Portable Products 2000 PSI High Pressure Washer
 Insert the carriage bolt through the right hole
(looking at the front of the pressure washer) and
attach a plastic knob. Tighten the knob by hand
(Figure 2).
 Insert the carriage hook through the left hole
(looking at the front of the pressure washer). Pull
the recoil handle out slowly. Place the recoil string
through the hook and attach the plastic knob.
Tighten the knob by hand (Figure 2).

Insert the wire form with the longer arm positioned on
the left. From this view (from rear of unit) the hook
should resemble a J
(Figure 3) .
Add Engine Oil
IMPORTANT: Any attempt to crank or start the engine
before it has been properly serviced with the
recommended oil may result in an engine failure.
Note: When adding oil to the engine crankcase, use
only high quality detergent oil rated with API service
classification SF,SG, SH or SH/CD rated SAE 30
weight.
Select the oils viscosity grade according to your
expected operating temperature:
Do Not Use SAE 10W40 Oil.
Although multiviscosity oils (5W30, 10W30, etc.)
improve starting in cold weather, these multiviscosity
oils will result in increased oil consumption when used
above 32°F. Check your engine oil level more
frequently to avoid possible damage from running low
on oil.
 Place pressure washer on a level surface.
 Clean area around oil fill and remove oil dipstick
(Figure 4).
 Wipe dipstick clean. Pour oil into oil fill opening until
oil reaches FULL mark on the dipstick. Stop
occasionally to check oil level. DO NOT OVERFILL.
 Install oil dipstick, hand tighten securely.
Note: Check Oil Often During Engine Break in.
Figure 3  Fit wire form on handle.
Figure 4  Add oil to engine crankcase. Do not attempt
to start engine without adding oil.
Oil Fill Cap
Figure 2  Insert the carriage bolt and hook and attach
the knobs.
colder 32°F warmer
5W30 SAE 30

8
Generac Portable Products 2000 PSI High Pressure Washer
Add Gasoline
DANGER! Never fill fuel tank indoors. Never
fill fuel tank when engine is running or hot. Do
not smoke when filling fuel tank.
WARNING! Never fill fuel tank completely
full. Fill tank to about 1/2" below the bottom of
the filler neck to provide space for fuel
expansion. Wipe away any fuel spillage from
engine and equipment before starting.
The manufacturer recommends fresh, clean unleaded
automotive gasoline.
 Use clean fuel and store in approved, clean,
covered containers. Use clean fill funnels. Never
use stale gasoline left over from last season or
gasoline stored for long periods.
 Clean area around fuel fill cap, remove cap.
(Figure 5).
 Add UNLEADED regular gasoline, slowly, to fuel
tank. Use a funnel to prevent spillage.
 Install fuel cap and wipe up any spilled gasoline.
Connect Hose and Water Supply
to Pump
IMPORTANT: You must assemble wand and attach
all hoses before you start engine. Starting engine
without all hoses connected and water supplied will
damage pump.
 Uncoil high pressure hose and attach one end of
hose to the base of the spray gun (Figure 6).
Tighten by hand.
 Attach other end of high pressure hose to the high
pressure outlet on the pump (Figure 7). Tighten by
hand.
 Before you connect your garden hose to the water
inlet, inspect the Inlet Screen (Figure 8). Clean the
screen if it contains debris or have it replaced if
damaged. Do not run the pressure washer if the
inlet screen is damaged.
 Connect garden hose to water inlet. Tighten by
hand (Figure 8).
Figure 7  Connect high pressure hose to pump.
Figure 6  Connect high pressure hose to spray gun.
Figure 5  Add gasoline to fuel tank.
Fuel Cap

9
Generac Portable Products 2000 PSI High Pressure Washer
 Turn ON the water (open valve completely).
 Squeeze trigger on gun to purge pump system of
air and impurities.
CAUTION! Before starting the pressure
washer, be sure you are wearing adequate
eye protection.
 Attach nozzle extension to spray gun. Tighten by
hand (Figure 9).
CHECKLIST BEFORE
STARTING ENGINE
Look back over the assembly to see if you have
performed all of the following:
 Check for properly tightened hose connections
(high pressure and water supply) and for tight
connections and that there are no kinks, cuts, or
damage to the high pressure hose.
 Check that oil has been added to proper level in
engine crankcase before trying to start the pressure
washer.
 Add proper gasoline to fuel tank.
 Provide proper water supply (not to exceed 140°F).
 Be sure to read Safety Rules and Operation
sections before using the pressure washer.
Figure 9  Connect nozzle extension to spray gun.
Figure 8  Connect the garden hose to water inlet and
turn ON the water.
Check Screen for Damage

10
Generac Portable Products 2000 PSI High Pressure Washer
HOW TO USE YOUR
PRESSURE WASHER
If you have any problems operating your pressure
washer, please call the pressure washer helpline at
1-800-270-1408.
You have assembled your high pressure washer and
have prepared the engine for starting. You are now
ready to clean your car, boat or the outside of a
building or whatever you plan to clean.
How to Start Your Engine
The best way to start your enginepowered pressure
washer for the first time is to follow these instructions
stepbystep. This starting information also applies
whenever you start the engine after you have let the
pressure washer sit idle for at least a day.
 This pressure washer requires a water source that
flows at least 2.5 gallons per minute. Do not
attempt to siphon water from a non pressurized
container. Place the pressure washer close
enough to an outside water source so that no more
than 50' of garden hose is needed.
 Check that the high pressure hose is tightly
connected to the spray gun and to the pump. See
ASSEMBLY section for illustrations.
 Connect the garden hose to water inlet on the
pressure washer pump and turn the water on all
the way.
IMPORTANT: Do not run pump without the water
supply connected and turned on. You must follow this
caution or the pump will be damaged.
 Squeeze the trigger on the spray gun to relieve air
pressure caused by turning ON the water. Water
will spew out the gun in a thin stream. Continue to
hold trigger until you have a steady stream of water
and no air remains.This will make it easier to pull
start the engine. Release the trigger.
 Apply the safety latch to the spray gun trigger
(Figure 10).
 Move the Throttle Control Lever to the Fast
position.
 Set Choke Lever to Choke position.
Note: This is a multiposition choke.
Note: For a warm engine, be sure the Throttle Control
Lever is in the Fast position and the Choke Lever is
in the Run position.
 Grasp rope handle and pull slowly until you feel
some resistance. Then pull cord rapidly to
overcome compression, prevent kickback and start
the engine. Let rope return to starter slowly.
Note: Always keep the Throttle Control Lever in the
Fast position when operating the pressure washer.
 When the engine starts, gradually move the Choke
Lever from one position to the next until it is in the
Run position.
If after 3 pulls the engine fails to start, disengage the
spray gun safety latch, squeeze the trigger to relive
water pressure, reengage the spray gun safety latch,
move the Choke Lever to the Run position and pull
the recoil starter handle rapidly (Max. 3 pulls).
How to Stop Your Pressure
Washer
 Move the Throttle Control Lever to the Slow position.
 Wait for the engine to idle down.
 Move the Throttle Lever Lever to the Stop position.
 Simply shutting off the engine will not release
pressure in the system. Squeeze trigger on the
spray gun to relieve pressure in the hose.
Note: A small amount of water will squirt out when
you release the pressure.
Figure 10  Squeeze trigger to relieve water pressure,
release trigger and turn the safety latch
ON.
Safety Latch ON

11
Generac Portable Products 2000 PSI High Pressure Washer
How to Use the Adjustable
Nozzle and Adjust Pressure
You now should know how to START your pressure
washer and how to STOP it. The information in this
section will tell you how to ad ust the spray pattern
and apply detergent or any other cleaning chemicals.
DANGER! Never ad ust spray pattern when
spraying. Never put hands in front of nozzle to
ad ust spray pattern.
On the end of your spray gun is a nozzle that you can
slide forward and backward and that you can also
twist from side to side. With the ad ustable nozzle you
can ad ust the spray pattern to be either high
pressure or low pressure. You can also ad ust the
spray so it is concentrated in a stream pattern or
expanded into a fan pattern.
 Slide the nozzle forward when you wish to ad ust
the spray to low pressure mode (Figure 11). Slide
the nozzle backward to achieve high pressure.
 Located on the side of the pump is a pressure
control knob. You can increase and decrease the
pressure of the spray by turning the knob clockwise
or counterclockwise respectively (Figure 12).
 Point the nozzle toward the ground and press the
trigger to test the pattern.
 Twisting the nozzle ad usts the spray pattern from a
narrow pattern to a fan pattern.
 For most effective cleaning, keep spray nozzle
between 8 to 24 inches away from cleaning
surface.
 If you get the spray nozzle too close, especially
using high pressure mode, you may damage the
cleaning surface.
 Do not get closer than 6 inches when cleaning
automobile tires.
Figure 12  Pressure control knob.
Pressure Control Knob
Figure 11  Using the ad ustable nozzle.
Slide Nozzle Backward
for High Pressure
Mode
Slide Nozzle Forward
for low pressure
mode and detergent
application
Twist nozzle
counterclockwise for
fan spray pattern
Twist nozzle
clockwise for narrow
spray pattern

12
Generac Portable Products 2000 PSI High Pressure Washer
Applying Detergent with the
Adjustable Nozzle
IMPORTANT: Use soaps designed specifically for
pressure washers. Household detergents could
damage the pump.
IMPORTANT: You must attach all hoses before you
start the engine. Starting the engine without all the
hoses connected and without the water turned ON will
damage the pump.
To apply detergent follow these steps:
 Review the use of ad ustable nozzles on Page 11.
 Prepare the detergent solution as instructed.
 Hang the detergent solution on hook of the wireform
on the handle as shown (Figure 13).
 Place small filter end of the chemical in ecting tube
into the detergent container (Figure 13).
 Slide the ad ustable nozzle forward to low pressure
mode. Detergent cannot be applied with nozzle in
high pressure position.
IMPORTANT: Detergent cannot be applied without
the water source turned on.
 Make sure garden hose is connected to water inlet.
Check that high pressure hose is connected to
spray gun and pump, and start engine.
 Apply detergent to a dry surface, starting from the
bottom and working up to avoid streaking.
 Allow the detergent to soak in for 35 minutes
before washing and rinsing. Reapply if necessary to
prevent drying.
 For washing, start at lower portion of area to be
washed and work upward, using long, even,
overlapping strokes.
CAUTION! Keep the plastic in ector tube from
coming in contact with the hot muffler. When
inserting the filter into a cleaning agent bottle,
route the tube so as to keep it from
inadvertently contacting the hot muffler.
Note: After using chemical in ection, you must flush
the hose and the pump with clear water to prevent
chemicals from drying and clogging the chemical
in ection system. See Cleaning Chemical In ector
System on page 14.
Pressure Washer Rinsing
WARNING! Be extremely careful if you must
use the pressure washer from a ladder,
scaffolding or any other unstable location.
Pressure in a running washer builds as you
climb. When you press the trigger, the recoil
from the initial spray could force you to fall.
The high pressure spray is also dangerous if
you are too close to the cleaning surface.
For Rinsing:
 Slide nozzle backward to high pressure, squeeze
trigger and wait for detergent to clear.
 Keep the spray gun a safe distance from the area
you plan to spray.
 Apply a high pressure spray to a small area and
then check the surface for damage. If no damage is
found, you can assume it is okay to continue
cleaning.
 Start at top of area to be rinsed, working down with
the same overlapping strokes used for cleaning.
Note: You can also stop detergent from flowing by
simply removing siphon from bottle.
Automatic Cool Down System
(also called Thermal Relief)
If you run the engine on your pressure washer for 35
minutes without pressing the trigger on the spray gun,
circulating water in the pump can reach a temperature
between 140145°F. When the water reaches this
temperature, the automatic cool down system
engages and cools the pump by discharging the
warm water onto the ground. This system prevents
internal damage to the pump.
Figure 13  Insert the small filter into container of
cleaning solution.

13
Generac Portable Products 2000 PSI High Pressure Washer
GENERAL MAINTENANCE
RECOMMENDATIONS
The warranty of the high pressure washer does not
cover items that have been sub ected to operator
abuse or negligence. To receive full value from the
warranty, operator must maintain high pressure
washer as instructed in this manual.
 Some ad ustments will need to be made periodically
to properly maintain your high pressure washer.
 All ad ustments in the Service and Ad ustments
section of the engine owners manual should be
made at least once each season.
 Once a year you should clean or replace the spark
plug and clean or replace the air filter and check the
gun and wand assembly for wear. A new spark plug
and clean air filter assure proper fuelair mixture
and help your engine run better and last longer.
Before Each Use
 Check engine oil level.
 Check water inlet screen for damage.
 Check high pressure hose for leaks.
 Check detergent inlet hose and filter for damage.
 Check gun and wand assembly for leaks.
PRESSURE WASHER
MAINTENANCE
Check and Clean Inlet Screen
Examine screen on the water inlet. Clean if the
screen is clogged or replace if screen is damaged.
Check High Pressure Hose
High pressure hose can develop leaks from wear,
kinking, or abuse. Inspect hose each time before
using it. Check for cuts, leaks, abrasions or bulging of
cover, damage or movement of couplings. If any of
these conditions exist, replace hose immediately.
DANGER! Water spraying from a leak is
capable of in ecting material into skin. Inspect
hose each time before using it. Never repair a
high pressure hose. Replace it with another
hose that meets the maximum pressure rating
of your pressure washer.
Check Detergent Hose
Examine the filter on the detergent hose and clean if
clogged. Hose should fit tightly on barbed fitting.
Examine hose for leaks or tears. Replace the filter or
hose if either is damaged.
Check Gun and Wand
Examine hose connection to gun and make sure it is
secure. Test trigger by pressing it and making sure it
springs back into place when you release it. Put
safety latch in ON position and test trigger. You
should not be able to press trigger.
Check In-Line Filter
Refer to Figure 14 and service the in-line filter if it
becomes clogged, as follows:
1. Detach gun from high pressure hose. Detach lance
from gun and remove o-ring and screen from lance.
Flush the screen, gun, and lance with clean water
to clear debris.
2. If the screen is damaged, the o-ring kit contains a
replacement in-line filter screen and an o-ring. If
undamaged, reuse screen.
3. Place the in-line filter screen into the threaded end
of the lance. Direction does not matter. Push the
screen in with the eraser end of a pencil until it rests
flat at the bottom of the opening. Take care to not
bend the screen.
Figure 14  Service in-line filter
Lance
Filter Screen
O-ring

14
Generac Portable Products 2000 PSI High Pressure Washer
4. Place the o-ring into the recess. Push the o-ring
snugly against the in-line filter screen.
5. Assemble the lance to the spray gun, as described
earlier in this manual.
Purge Pump of Air and
Contaminants
To remove the air from the pump, follow these steps:
 Set up the pressure washer as described in the
ASSEMBLY section (starting on page 6) and
connect the water supply.
 Remove the wand extension from the gun.
 Squeeze the trigger on the gun and hold.
To remove any contaminants from the pump, follow
these steps:
 Set up the pressure washer as described in the
ASSEMBLY section, and connect the water supply.
 Remove the nozzle extension from the spray gun.
 Start the engine according to instructions in
OPERATION section.
 Squeeze the trigger on the spray gun and hold.
 When the water supply is steady and constant,
engage the safety latch and refasten the nozzle
extension.
Cleaning Chemical Injector
System
If you have used the chemical in ector system you
must flush it with clean water before stopping the
engine.
 Place the small filter end of the chemical in ection
tube in a bucket of clean water.
 Slide the ad ustable nozzle forward.
 Squeeze the spray gun trigger for 12 minutes to
flush the chemical in ection tube.
 Shut off the engine.
Important: Simply shutting OFF engine will not release
pressure in the system. When engine has shut down,
squeeze the trigger on the gun to relieve the
pressure in the hose.
Nozzle Maintenance
If the ad ustable nozzle becomes restricted or clogged
with foreign materials, such as dirt, excessive pump
pressure may develop. If this nozzle becomes
partially clogged, it can cause a pulsing sensation
during use. This generally is not a pump related
problem, but rather a clogged or partially restricted
ad ustable nozzle.
If the ad ustable nozzle becomes clogged or partially
restricted, immediately clean the nozzle with the kit
included with your pressure washer by following these
instructions:
 Shut off the engine and turn off the water supply.
 Separate the nozzle extension from the gun.
 Ad ust the nozzle extension to the stream position.
 Remove nozzle from the end of the wand extension
(Figure 15) using a 2mm or 5/64 allen wrench (like
the one included in the kit).
 Use the wire included in the kit (Figure 15) or a
small paper clip to free the foreign materials
clogging or restricting the nozzle.
 Remove additional debris by back flushing water
supply through wand extension (Figure 16). Back
flush between 30 to 60 seconds. Turn nozzle
extension to stream spray and move nozzle forward
and backward while flushing.
Figure 15  Removing and cleaning the nozzle.

15
Generac Portable Products 2000 PSI High Pressure Washer
 Reinstall nozzle into the wand extension. Do not
overtighten.
 Reconnect the nozzle extension to the spray gun.
 Reconnect the water supply, turn on the water, and
start the engine.
 Test the pressure washer by operating with nozzle
in the high and in the low position.
O Ring Maintenance
Through the normal operation of your pressure
washer, ORings, which keep the connections of the
hoses and gun tight and leakfree may become worn
or damaged.
Provided with your pressure washer is an ORing
Maintenance Kit (p/n B3057) which provides
replacement O-Rings, Rubber Washer and Water
Inlet filter.
To remove a worn or damaged O Ring:
 Use a small flathead screwdriver to get underneath
the O-Ring and pry it off.
ENGINE MAINTENANCE
See the engine Owners Manual for instructions on
how to properly maintain the engine.
SERVICE AND
ADJUSTMENTS
See the engine Owners Manual for instructions on
how to properly service and ad ust the engine.
PREPARING THE UNIT FOR
STORAGE
Water should not remain in the unit for long periods of
time. Sediments of minerals can deposit on pump
parts and freeze pump action. If you do not plan to
use the pressure washer for more than 30 days,
follow this procedure:
1.Flush chemical in ection tube by placing the in ector
filter into a pail of clean water while running
pressure washer and squeezing the spray gun
trigger with the ad ustable nozzle in low pressure
mode. Flush for 12 minutes.
2.Shut off the engine and let it cool, then remove all
hoses.
3.Place throttle lever in STOP position.
CAUTION! Be sure lever is in STOP
position before you continue. If you start
engine without proper water supply connected,
you can damage pump.
4.Empty the pump of all pumped liquids by pulling
recoil handle about 6 times. This should remove
most of the liquid in the pump.
NOTE: To protect unit from freezing temperatures,
draw windshield washer fluid into pump by pouring
RV antifreeze (antifreeze without alcohol) into a
3foot section of garden hose connected to inlet
adapter and pulling recoil handle twice.
5.Store in a clean, dry area.
STORING THE ENGINE
See the Engine Owners Manual for instructions on
how to properly store the engine.
Figure 16  Removing and cleaning the nozzle.

16
Generac Portable Products 2000 PSI High Pressure Washer
Problem Cause Solution
Pump has the following
problems:
Failure to produce adequate
pressure, erratic pressure,
chattering, loss of pressure
or low water volume.
1. Ad ustable nozzle in low
pressure.
2. Water inlet is blocked.
3. Inadequate water supply.
4. Garden hose is kinked or
leaking.
5. Clogged water inlet screen.
6. Water supply is over 140°F.
7. Outlet hose is blocked or leaks.
8. Gun leaks.
9. Nozzle is obstructed.
10. Pump is faulty.
1. Pull nozzle back to high pressure
position.
2. Clear inlet.
3. Make sure you have at least a 2.5
GPM flow for your garden hose.
4. Straighten garden hose or patch
leak.
5. Check and clean water inlet
screen.
6. Provide cooler water supply.
7. Clear blocks in outlet hose.
Replace immediately if leaking.
8. Use o-ring maintenance kit to
replace worn o-rings.
9. Clear nozzle.
10. Contact Generac service facility.
Detergent fails to mix with
spray.
1. Chemical in ector hose is not
submerged.
2. Chemical in ector hose is
clogged.
3. Ad ustable nozzle is in high
pressure mode.
1. Insert chemical line into
detergent.
2. Clean or replace filter/chemical
in ector hose.
3. Put ad ustable nozzle into low
pressure mode.
Engine runs well when not
spraying but bogs down
when trigger is squeezed.
1. Engine speed is too slow. 1. Contact Briggs & Stratton service
facility.
Engine will not start; or
starts and runs rough.
1. Low oil level.
2. Dirty air filter.
3. Out of gasoline.
4. Stale gasoline.
5. Spark plug wire not connected to
spark plug.
6. Bad spark plug.
7. Water in gasoline.
8. Excessively rich fuel mixture.
9. Intake valve stuck open or
closed.
10. Engine has lost compression
1. Fill crankcase to proper level.
2. Clean or replace air filter.
3. Fill fuel tank.
4. Drain gas tank; fill with fresh fuel.
5. Connect wire to spark plug.
6. Replace spark plug.
7. Drain as tank fill with fresh fuel.
8. Contact Briggs & Stratton service
facility.
9. Contact Briggs & Stratton service
facility.
10. Contact Briggs & Stratton service
facility.
Engine shuts down during
operation.
1. Out of gasoline.
2. Low oil level
1. Fill fuel tank.
2. Fill crankcase to proper level.
Engine lacks power. 1. Dirty air filter. 1. Replace air filter.
TROUBLESHOOTING

Generac Portable Products 2000 PSI High Pressure Washer
17
NOTES

18
Generac Portable Products 2000 PSI High Pressure Washer
EXPLODED VIEW PUMP

19
Generac Portable Products 2000 PSI High Pressure Washer
PARTS LIST PUMP
Item Part # Qty Description
1 B3287 1 O-RING, 1.62 I.D. x .12
2 B2260 1 ADAPTER, Engine
3 B2217 4 O-RING, 0.239 ID x 0.070
4 B2261B 4 SCREW, Button Hd 5/16 - 24 x
3/4" Lg
5 96400 3 SPRING, Piston Return
6 99735 1 ASSEMBLY, Oil Breather
7 93790 1 O-RING, 114 x 119 x 2.6
8 40945 6 SHCS, M6 x 1.0 x 20mm Lg
9 93652 1 SPRING, Thermal By-Pass
10 95416 1 PISTON, Thermal By-Pass
11 93876 1 O-RING, 2.9 x 6.5 x 1.78
12 A2069 1 GASKET, Head
13 93644 1 ACTUATOR, Thermal By-Pass
14 96053 3 SEAL, High Pressure
15 96015 3 RING, Bearing
16 B2665 6 WASHER, Steel Special
17 A2013 6 BOLT, Head M8 x 1.25 x
70mm Lg
18 97840 3 O-RING, Cap 15.6 x 19.16 x
1.78
19 97841 3 CAP, Outlet Port
20 B4229 0 KIT, Axial Cam 7/8" - 6.0 Lift
21 . . . . . . 2 BEARING SET, Thrust 15.5
22 . . . . . . 1 CAM, Axial 6.0 Lift
23 . . . . . . 1 ADAPTER, Engine
24 . . . . . . 1 WASHER, Thrust
25 . . . . . . 1 RETAINER, Push - On
26 . . . . . . 1 C-RING, Cam Retainer
27 B3478 0 KIT, Piston/Shoe
28 . . . . . . 3 ASSY., Ceramic Piston & Cap
29 . . . . . . 3 SHOE, Piston Pivot
30 B3508 0 KIT, Crankcase
31 . . . . . . 3 SPACER, Pilot
32 . . . . . . 3 SEAL, Oil Piston
33 . . . . . . 1 CRANKCASE, Pump
Item Part # Qty Description
34 B3509 0 KIT, Spacer Plate
35 . . . . . . 1 SPACER, Inlet Plate
36 . . . . . . 3 SEAL, High Pressure Dbl. Lip
37 B3513 0 KIT, Check Valve
38 . . . . . . 6 ASSY., Check Valve
39 . . . . . . 6 O-RING, Check Valve 12.4 x
15.56 x 1.78
40 B3479 0 KIT, Unloader Spindle
41 . . . . . . 1 CAP, Plastic
42 . . . . . . 1 SET SCREW, M6 x 8 Lg
43 . . . . . . 1 HANDLE, Unloader
44 . . . . . . 1 SPRING,Unloader
45 . . . . . . 1 ASSY., Spindle
46 B3507 0 KIT, Head
47 . . . . . . 1 ASSY., Pump Head (Med.
Frame)
48 B3510 0 KIT, High Pressure Outlet
49 . . . . . . 1 O-RING, Spindle 6 x 10 x 1.78
50 . . . . . . 1 SEAT, Ball Unloader
51 . . . . . . 1 BALL, Stainless Steel 9/32
Dia.
52 . . . . . . 1 SEAT, Trapped Line Pressure
53 . . . . . . 1 O-RING, 3.68 x 7.24 x 1.78
54 . . . . . . 1 VALVE, Shuttle Piston
55 . . . . . . 1 SPRING, Piston Trapped
Pressure
56 . . . . . . 1 VENTURI, Chemical
57 . . . . . . 1 O-RING, Venturi 10.82 x 14.38
x 1.78
58 B3829 0 ASSY., Chemical In ector
59 . . . . . . 1 BARB HOSE, Brass with
Nylon Insert
60 . . . . . . 1 BALL, 5.5 dia. Chemical
In ector
61 . . . . . . 1 SPRING, Chemical In ector
62 B3480 0 KIT, Complete Head
63 B3514 0 KIT, O-Ring/Seals

20
Generac Portable Products 2000 PSI High Pressure Washer
EXPLODED VIEW PRESSURE WASHER
