Generac Power Systems Magnum MLT3060M User manual

Owner’s Manual
Light Tower
MLT3060M • MLT3060K
SAVE THIS MANUAL FOR FUTURE REFERENCE
For technical assistance contact:
www.generacmobileproducts.com
Technical Support
1-800-926-9768
000000

ii Owner’s Manual for MLT3060M-K Light Tower
Use this page to record important information about your Light Tower
Record the information found on your unit data label on
this page. See unit serial number location (Unit Serial
Number Locations). The label plate is affixed to the
inside partition, to the left of the control panel console.
Engine and generator serial numbers are located on
separate data plates affixed to the engine and generator
respectively.
When contacting a Generac Mobile Products Authorized
Dealer about parts and service, always supply the
complete model number and serial number of the unit.
Operation and Maintenance: Proper maintenance and
care of the Light Tower ensures a minimum number of
problems and keeps operating expenses at a minimum. It
is the operator’s responsibility to perform all safety
checks, to verify that all maintenance for safe operation is
performed promptly, and to have the equipment checked
periodically by a Generac Mobile Products Authorized
Dealer. Normal maintenance, service and replacement of
parts are the responsibility of the owner/operator and, as
such, are not considered defects in materials or
workmanship within the terms of the warranty. Individual
operating habits and usage may contribute to the need
for additional maintenance or service.
Unit Model Number
Unit Serial Number
Engine Model
Number
Engine Serial
Number
Generator Model
Number
Generator Serial
Number
(000005)
WARNING
California Proposition 65. This product contains or
emits chemicals known to the state of California to
cause cancer, birth defects, and other reproductive
harm.
(000004)
WARNING
California Proposition 65. Engine exhaust and some
of its constituents are known to the state of California
to cause cancer, birth defects, and other reproductive
harm.

Owner’s Manual for MLT3060M-K Light Tower iii
Section 1: Safety Rules & General
Information
Introduction ..........................................................1
Read This Manual Thoroughly ....................................1
How to Obtain Service .................................................1
Safety Rules .........................................................1
General Hazards ..................................................2
Explosion and Fire Hazards ................................2
Trailer Hazards .....................................................2
Electrical Hazards ................................................3
Battery Hazards ...................................................3
Fuel Hazards ........................................................4
Engine Safety .......................................................4
Operating Safety ..................................................4
Positioning the Unit .....................................................4
Starting the Unit ...........................................................4
Raising and Lowering the Mast ...................................5
Service Safety ......................................................5
Towing Safety ......................................................6
Hitch and Coupling ......................................................6
Running Lights ............................................................6
Wheels and Tires ........................................................6
Safe Towing Techniques .............................................6
Reporting Trailer Safety Defects ........................6
Safety and Operating Decals ..............................7
Section 2: General Information
Specifications ....................................................13
Unit Dimensions ................................................14
Unit Serial Number Locations ..........................15
Component Locations .......................................16
Control Panel .....................................................17
Control Panel Features and Functions ......................18
PowerZone–DLA (If Equipped) .........................19
Controller Features and Functions ............................19
Operator Screens ......................................................20
Section 3: Operation
Light Tower Setup .............................................25
Prestart Checklist .............................................. 26
Raising the Mast ................................................ 26
Starting the Unit ................................................ 27
Preparing for Start-Up (with PowerZone
Controller, If Equipped) .................................... 28
Select AUTO or MANUAL Mode ...............................28
Manually Starting the Unit ................................ 28
Light Operation .................................................. 29
Light Operation (With PowerZone Controller, If
Equipped) ........................................................... 29
Engine Derating ................................................. 29
Wet Stacking ...................................................... 30
Customer Convenience Outlets ....................... 30
Shutting Down the Unit ..................................... 30
Shutting Down the Unit (with PowerZone
Controller, If Equipped) .................................... 30
Automatic Shutdown .................................................30
Lower Radiator Hose Heater (If Equipped) ..... 30
Spark Arrester (If Equipped) ............................ 31
Lowering the Mast ............................................. 31
Removing the Lights for Transportation ......... 31
Towing the Unit ................................................. 31
Tying the Unit Down .......................................... 32
Lifting the Unit ................................................... 32
Section 4: Maintenance
Emissions Information ...................................... 33
Daily Walk-Around Inspection ......................... 33
General Maintenance ........................................ 33
Preparing for Service .................................................33
Cleaning the Unit .......................................................33
Inspecting the Unit .....................................................33
Basic Maintenance Schedule ........................... 34
Resetting the Maintenance Alarms
(If Equipped) ...................................................... 37
Winch Use, Operation and Maintenance ......... 37
Prior to Use ...............................................................37
Operation ...................................................................37
Maintenance ..............................................................37
Table of Contents

Table of Contents
iv Owner’s Manual for MLT3060M-K Light Tower
Jack Maintenance ..............................................38
Trailer Wheel Bearings ......................................38
Section 5: Troubleshooting
General Troubleshooting ..................................39
Troubleshooting the Lights ..............................40
Section 6: Wiring Diagrams
Mast Junction Box Wiring and Light
Connections .......................................................41
AC Wiring ...........................................................42
DC Wiring—MLT3060M .....................................43
DC Wiring—MLT3060K ......................................44
DC Wiring for Optional Equipment ..................45
Trailer Wiring ......................................................46

Safety Rules & General Information
Owner’s Manual for MLT3060M-K Light Tower 1
Section 1: Safety Rules & General Information
Introduction
Thank you for purchasing a Generac Mobile Products LLC
product. This unit has been designed to provide high
performance, efficient operation, and years of use when
maintained properly.
The information in this manual is accurate based on
products produced at the time of publication. The
manufacturer reserves the right to make technical updates,
corrections, and product revisions at any time without
notice.
Read This Manual Thoroughly
If any section of the manual is not understood, contact your
nearest Generac Mobile Products Authorized Dealer, or
contact Generac Mobile Products Technical Service at
1-800-926-9768 or
www.generacmobileproducts.com
with any questions or concerns.
The owner is responsible for proper maintenance and safe
use of the equipment. Comply with regulations the
Occupational Safety and Health Administration (OSHA)
has established, or with equivalent standards. Also, verify
that the unit is applied, used, and maintained in accordance
with the manufacturer's instructions and recommendations.
Do nothing that might alter safe application/usage and
render the unit in noncompliance with the aforementioned
codes, standards, laws, and regulations
.
Save these instructions for future reference. This manual
contains important instructions for the unit that should be
followed during setup, operation and maintenance of the
unit and battery. ALWAYS supply this manual to any
individual that will use this machine.
How to Obtain Service
When the unit requires servicing or repairs, contact an
Generac Mobile Products Authorized Dealer for assistance.
Service technicians are factory-trained and are capable of
handling all service needs. For assistance locating a dealer,
go to
www.generacmobleproducts.com/parts-service/
find-service
. When contacting an Generac Mobile
Products Authorized Dealer about parts and service,
always supply the complete model number and serial
number of the unit as given on its data decal located on
the unit. Record the model number and serial numbers in
the spaces provided on the inside front cover of this
manual.
Safety Rules
The manufacturer cannot anticipate every possible
circumstance that might involve a hazard. The warnings in
this manual, and on tags and decals affixed to the unit are,
therefore, not all inclusive. If using a procedure, work
method or operating technique that the manufacturer does
not specifically recommend, verify that it is safe for others.
Also make sure the procedure, work method or operating
technique utilized does not render the equipment unsafe.
Throughout this publication, and on tags and decals affixed
to the unit, DANGER, WARNING, CAUTION and NOTE
blocks are used to alert personnel to special instructions
about a particular operation that may be hazardous if
performed incorrectly or carelessly. Observe them
carefully. Their definitions are as follows:
NOTE: Notes contain additional information important to
a procedure and will be found within the regular text of
this manual.
These safety alerts cannot eliminate the hazards that they
indicate. Common sense and strict compliance with the
special instructions while performing the action or service
are essential to preventing accidents.
(000100a)
WARNING
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
(000001)
DANGER
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
(000002)
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
(000003)
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.

Safety Rules & General Information
2Owner’s Manual for MLT3060M-K Light Tower
General Hazards Explosion and Fire Hazards
Trailer Hazards
Asphyxiation. Running engines produce
carbon monoxide, a colorless, odorless,
poisonous gas. Carbon monoxide, if not
avoided, will result in death or serious injury.
(000103)
DANGER
(000107)
WARNING
Hearing Loss. Hearing protection is
recommended when using this machine.
Failure to wear hearing protection could
result in permanant hearing loss.
(000111)
WARNING
Moving Parts. Keep clothing, hair, and
appendages away from moving parts. Failure
to do so could result in death or serious injury.
(000108)
WARNING
Hot Surfaces. When operating machine, do not
touch hot surfaces. Keep machine away from
combustibles during use. Hot surfaces could
result in severe burns or fire.
(000182)
WARNING
Only qualified service personnel may install, operate,
and maintain this equipment. Failure to follow proper
installation requirements could result in death, serious
injury, and damage to equipment or property.
WARNING
Risk of injury. Do not operate or service this machine
if not fully alert. Fatigue can impair the ability to service
this equipment and could result in death or serious
injury. (000215)
(000139)
WARNING
Risk of burns. Allow engine to cool before
draining oil or coolant. Failure to do so could
result in death or serious injury.
(000105)
DANGER
Explosion and Fire. Fuel and vapors are
extremely flammable and explosive. Add fuel
in a well ventilated area. Keep fire and spark
away. Failure to do so will result in death
or serious injury.
(000147)
WARNING
Risk of Fire. Unit must be positioned in a
manner that prevents combustible material
accumulation underneath. Failure to do so
could result in death or serious injury.
(000110)
WARNING
Risk of Fire. Hot surfaces could ignite
combustibles, resulting in fire. Fire could
result in death or serious injury.
WARNING
Trailer must be securely coupled to the hitch and the
chains correctly attached. Uncoupled or unchained
towing could result in death or serious injury. (000233)
WARNING
Do not operate this unit while transporting. Doing so
could result in death or serious injury.
(000231)
(000234a)
WARNING
Crushing hazard. Verify unit is properly secured and
on level ground. An unsecured unit can suddenly roll
or move, causing death or serious injury.
WARNING
Property or Equipment Damage. Tighten wheel lug
nuts after first 50 miles to factory specifications.
Failure to do so could result in death, serious injury,
property or equipment damage. (000235)

Safety Rules & General Information
Owner’s Manual for MLT3060M-K Light Tower 3
Electrical Hazards Battery Hazards
Always recycle batteries in accordance with local laws and
regulations. Contact your local solid waste collection site
or recycling facility to obtain information on local recycling
processes. For more information on battery recycling, visit
the Battery Council International website at: http://
batterycouncil.org
(000145)
DANGER
Electrocution. In the event of electrical accident,
immediately shut power OFF. Use non-conductive
implements to free victim from live conductor. Apply
first aid and get medical help. Failure to do so will
result in death or serious injury.
(000104)
DANGER
Electrocution. Water contact with a power
source, if not avoided, will result in death
or serious injury.
(000144)
DANGER
Electrocution. Contact with bare wires,
terminals, and connections while generator
is running will result in death or serious injury.
(000152)
DANGER
Electrocution. Verify electrical system is
properly grounded before applying power.
Failure to do so will result in death or serious
injury.
(000188)
DANGER
Electrocution. Do not wear jewelry while
working on this equipment. Doing so will
result in death or serious injury.
DANGER
Electrocution. DO NOT use the unit if
electrical cord is cut or worn through. Doing
so will result in death or serious injury.
(000263a)
(000188)
DANGER
Electrocution. Do not wear jewelry while
working on this equipment. Doing so will
result in death or serious injury.
(000137a)
WARNING
Explosion. Batteries emit explosive gases while charging.
Keep fire and spark away. Wear protective gear when
working with batteries. Failure to do so could result in
death or serious injury.
(000162)
WARNING
Explosion. Do not dispose of batteries in a fire. Batteries
are explosive. Electrolyte solution can cause burns and
blindness. If electrolyte contacts skin or eyes, flush with water
and seek immediate medical attention.
(000163a)
WARNING
Risk of burn. Do not open or mutilate batteries.
Batteries contain electrolyte solution which can
cause burns and blindness. If electrolyte contacts
skin or eyes, flush with water and seek immediate
medical attention.
WARNING
Environmental Hazard. Always recycle batteries at an
official recycling center in accordance with all local
laws and regulations. Failure to do so could result in
environmental damage, death or serious injury.
(000228)

Safety Rules & General Information
4Owner’s Manual for MLT3060M-K Light Tower
Fuel Hazards
•DO NOT fill fuel tank near an open flame, while
smoking, or while engine is running. DO NOT fill
tank in an enclosed area with poor ventilation.
•DO NOT operate with the fuel tank cap loose or
missing.
Engine Safety
Internal combustion engines present special hazards
during operation and fueling. Failure to follow the safety
guidelines described below could result in severe injury or
death. Read and follow all safety alerts described in the
engine operator's manual. A copy of this manual was
supplied with the unit when it was shipped from the factory.
•DO NOT run engine indoors or in an area with poor
ventilation. Make sure engine exhaust cannot seep
into closed rooms or ventilation equipment.
•DO NOT clean air filter with gasoline or other types
of low flash point solvents.
•DO NOT operate the unit without a functional
exhaust system.
•Shut the engine down if any of the following
conditions exist during operation:
• Abnormal change in engine speed.
• Loss of electrical output.
• Equipment connected to the unit overheats.
• Sparking occurs.
• Engine misfires or there is excessive engine/
generator vibration.
• Protective covers are loose or missing.
• Ambient air temperature is above 120°F (49°C).
Operating Safety
Positioning the Unit
•The area immediately surrounding the unit should
be dry, clean, and free of debris.
•Position and operate the unit on a firm, level
surface.
•If the unit is equipped with a frame grounding stud,
follow the National Electrical Code (NEC), state,
and local regulations when connecting.
Starting the Unit
(000192)
DANGER
Explosion and fire.Fuel and vapors are extremely
flammable and explosive. No leakage of fuel is
permitted. Keep fire and spark away. Failure to do
so will result in death or serious injury.
(000174)
DANGER
Risk of fire. Allow fuel spills to completely dry
before starting engine. Failure to do so will
result in death or serious injury.
(000260a)
High Voltage. Verify area above unit is clear
of overhead wires and obstructions. Contact
with high-voltage power lines will result in
death or serious injury.
DANGER
(000277)
WARNING
Burn hazard. Never operate lights with a
damaged or missing lens cover. Lamps are
hot and pressurized while in use. Unprotected
lamps can shatter, causing severe injury.
DANGER
Electrocution. DO NOT use the unit if
electrical cord is cut or worn through. Doing
so will result in death or serious injury.
(000263a)
CAUTION
(000291)
Equipment damage. Do not attempt to start or operate
a unit in need of repair or scheduled maintenance.
Doing so could result in serious injury, death, or
equipment failure or damage.
WARNING

Safety Rules & General Information
Owner’s Manual for MLT3060M-K Light Tower 5
Raising and Lowering the Mast
•Keep area around the unit clear of people while
raising and lowering the mast.
•ALWAYS lower the mast when not in use.
•The tower extends up to 30 ft (9.14 m). Make sure
area above trailer is open and clear of overhead
wires and obstructions.
•If for any reason any part of mast hangs up or
winch cable develops slack while raising or
lowering tower, STOP immediately! Contact a
Generac Mobile Products Authorized Service
Dealer.
•NEVER remove safety pin or pull mast locking pin
while tower is up.
Service Safety
This unit uses high voltage circuits capable of causing
serious injury or death. Only a qualified and licensed
electrician should troubleshoot or repair problems
occurring in this equipment.
• Before servicing the unit, verify the Control Power
switch and circuit breakers are in the OFF (O)
position, and the negative (-) terminal on the battery
is disconnected.
DO NOT perform even routine
service (oil/filter changes, cleaning, etc.) unless all
electrical components are shut down.
• ALWAYS use extreme caution when servicing this
unit in damp conditions. Do not service the unit if your
skin or clothing is wet. Do not allow water to collect
around the base of the unit.
• DO NOT wash the unit with high pressure hoses,
power washers, or steam cleaners. Water may
collect in the unit, causing damage to electrical parts.
• Replace all missing and hard to read decals. Decals
provide important operating instructions and warn of
dangers and hazards.
• Wear heavy leather gloves when handling winch
cables. Never let cables slip through bare hands.
• Only use mild soap and water to clean the lens covers.
Other chemicals may damage the lens covers.
•Make sure slings, chains, hooks, ramps, jacks and
other types of lifting devices are attached securely
and have enough weight-bearing capacity to lift or
hold the equipment safely. Always remain aware of
the position of other people around you when lifting
the equipment.
WARNING
Electrocution. Do not set up or operate
this unit if severe weather is expected.
Lightning strikes can kill or cause severe injury
even if you are not touching the unit. (000296)
WARNING
(000297)
> 60 mph> 60 mph Do not set up the unit if high winds
are expected. High winds can cause the
unit to tip or fall, causing severe injury
or machine damage.
(000279)
Personal injury or equipment damage. Do not raise
or lower the mast while the unit is operating.
Doing so can break the lenses and cause the
lamps to shatter.
WARNING
WARNING
Personal Injury. Stop immediately if the mast hangs
up or the winch cable develops slack. Excess slack
could cause the mast to collapse, resulting in personal
injury or equipment damage. (000265)
WARNING
Tipping hazard. Extend the outriggers and level the unit
before raising the mast. Keep the outriggers extended
while the mast is up. Failure to do so could cause the unit
to tip and fall and could result in death or serious injury.
(000266)
(000278)
WARNING
Burn hazard. Lamps become extremely hot
while in use. Allow 10–15 minutes for cooling
before handling or lowering mast. Touching a
hot lens or fixture can cause severe burns.

Safety Rules & General Information
6Owner’s Manual for MLT3060M-K Light Tower
Towing Safety
Towing a trailer requires care. Both the trailer and vehicle
must be in good condition and securely fastened to each
other to reduce the possibility of an accident. Some states
require that large trailers be registered and licensed.
Contact your local Department of Transportation office to
check on license requirements for your particular unit.
Hitch and Coupling
•Verify the hitch and coupling on the towing vehicle
are rated equal to, or greater than, the trailer's
Gross Vehicle Weight Rating (GVWR).
•Verify the trailer hitch and the coupling are
compatible. Make sure the coupling is securely
fastened to the vehicle.
•DO NOT tow trailer using defective parts. Inspect
the hitch and coupling for wear or damage.
•Connect safety chains in a crossing pattern under
the tongue.
•Before towing the trailer, verify the weight of the
trailer is equal across all tires. On trailers with
adjustable height hitches, adjust the angle of the
trailer tongue to keep the trailer as level as
possible.
Running Lights
Verify directional and brake lights on the trailer are
connected and working properly
Wheels and Tires
•Check trailer tires for wear and proper inflation.
•Verify wheel lug nuts are present and tightened to
the specified torque.
Safe Towing Techniques
•Practice turning, stopping and backing up in an
area away from heavy traffic prior to transporting
the unit.
•Maximum recommended speed for highway towing
is 45 mph (72 km/h). Recommended off-road
towing speed is 10 mph (16 km/h) or less,
depending on terrain.
•When towing, maintain extra space between
vehicles and avoid soft shoulders, curbs and
sudden lane changes.
Reporting Trailer Safety Defects
If you believe your trailer has a defect which could cause
a crash or could cause injury or death, you should
immediately inform the National Highway Traffic Safety
Administration (NHTSA) in addition to notifying Generac
Mobile Products LLC.
If NHTSA receives similar complaints, it may open an
investigation; and if it finds that a safety defect exists in a
group of vehicles, it may order a recall and remedy
campaign. However, NHTSA cannot become involved in
an individual problem between you, your dealer, or
Generac Mobile Products LLC.
To contact NHTSA, you may either call the Auto Safety
Hotline toll-free at 1-888-327-4236 (TTY:1-800-424-9153),
go to http://www.safercar.gov; or write to:
Administrator
NHTSA
1200 New Jersey Avenue S.E.
Washington, DC 20590
You can also obtain other information about motor vehicle
safety from http://www.safercar.gov.

Safety Rules & General Information
Owner’s Manual for MLT3060M-K Light Tower 7
Safety and Operating Decals
See Figure 1-1 through Figure 1-4. This unit features
numerous safety and operating decals. These decals
provide important operating instructions and warn of
dangers and hazards. The following diagrams illustrate
decal locations and descriptions.
Replace any missing or hard-to-read decals and use care
when washing or cleaning the unit. Decal part numbers
can be found in the parts manual at
www.generacmobileproducts.com.
ID Description
1 Warning–Stand Clear When Mast is Being Tilted
2 Warning–Hot Surface
3 Warning–Ultraviolet Radiation
4 Instruction–Raise Mast Manual Winch
5 Instruction–Raise Mast Electric Winch
6 Instruction–Mast Control Electric Winch
7 Danger–Do Not Remove
8 Danger–Electrocution
9 Instruction–Keep Tension on Cables
10 Mast Junction Box Wiring
11 Warning–Hot Surface, Fire and Explosion
12 Instruction–Towing Instructions
13 Instruction–Align Before Tilting Mast Down
14 Danger–Lower Mast Before Tilting, Do Not Position
Light Tower Under Power Lines
15 Forklift Pockets
16 Single Point Lift Location
17 Warning–Secure Mast Before Lifting or Towing
18 Instruction–Engine Operation
19 Danger–High Winds and Storms, Overhead
Obstructions
20 Danger–Do Not Move Unit With Tower Up
21 Warning–Read Manual Before Operating Unit
22 Warning–Verify Circuit Breaker is OFF Before
Starting Unit
23 Tie-Down Point
24 Secure Mast
25 Consult Manual
26 Warning–Pinch Point
27 Danger–Diesel Fuel, Asphyxiation, No Open Flame
28 Ultra Low Sulfur Fuel Only
29 Grounding Stud
30 Warning–Fire and Explosion
31 Warning–Moving Parts
32 Warning–Hot Surface, Moving Parts

Safety Rules & General Information
8Owner’s Manual for MLT3060M-K Light Tower
Figure 1-1. Decals - Front, Rear and Top
WARNING
WARNUNG
ADVERTENCIA
ADVERTISSEMENT
STAND CLEAR OF FRONTAND REAR OF MACHINE
WHEN MAST IS BEING TILTEDUP OR DOWN.
AUFENTHALTINVORDERER ODER HINTERER UMGEBUNG
DES GERÄTES VERMEIDEN WÄHREND MAST HOCH ODER
NIEDER GESCHWENKT WIRD.
MANTENGASE ALEJADO DE LAPARTE DELANTERA O
TRASERA DE LAMAQUINA MIENTRAS QUE SE ESTA
PROCEDIENDO A LEVANTAREL MASTIL A LA POSICION
VERTICAL O VOLCARLO A LA POSICION HORIZONTAL.
TENEZ-VOUS ADISTANCE DE L’AVANT ET DE
L’ARRIERE DE LAMACHINE PENDANT LE BASCULEMENT
DU MATDANS UN SENS OU DANS L’AUTRE.
ADVERTENCIA
WARNUNG
ADVERTISSEMENT
WARNING
ALWAYSKEEP TENSION ON CABLES! SLACK MAYCAUSE CABLE
DAMAGEAND EXCESSIVE WEAR!
¡CSIEMPRETENSIÓN DE LA SUBSISTENCIA EN LOS CABLES! ¡CCAUSA
FLOJACABLEDAMAGE DE MAYO Y DESGASTE EXCESIVO!
TOUJOURSTENSION DE SUBSISTANCE SUR DES CÂBLES !
CAUSELÂCHE CABLEDAMAGE DE MAI ET USAGE EXCESSIF !
IMMERUNTERHALT-SPANNUNGAUF KABELN! LOCKERE MAI URSACHE
CABLEDAMAGEUND ÜBERMÄSSIGE ABNUTZUNG!
Located on
bottom side
of mast
1. READ OPERATOR'SMANUAL.
2. USE HITCH RATER FORTRAILER'S
"GROSS VEHICLE WEIGHTRATING".
3. SECURELYATTACH TRAILER TO TOW VEHICLE.
4. ATTACH SAFETY CHAINS USING ACROSS
PATTERN.
5. ATTACH BREAKDOWN CHAIN TO VEHICLE.
6. CHECK TRAILER LIGHTS.
TOWING INSTRUCTIONS INSTRUCCIONES DE REMOLQUE
1. LEA EL MANUAL DEL OPERARIO.
2. UTILICE UN ACOPLE CORRECTAMENTE
CLASIFICADO PARALA "CLASE DE PESO
BRUTO" DEL VEHICULO DE REMOLQUE
3. ASEGURESE DEACOPLAR CORRECTAMENTE EL
REMOLQUEAL VEHICULO DE REMOLQUE.
4. FIJE EN CRUZ LAS CADENAS DE SEGURIDAD.
5. FIJE EN EL VEHICULO DE REMOLQUE
LACADENA DE DESPRENDIMIENTO.
6. CONTROLE LAS LUCES DEL REMOLQUE.
ABSCHLEPPINSTRUKTIONEN
1. LIRE LA NOTICE D’EMPLOI.
2. UTILISER UN CROCHET D’ATTELAGECONFORME
AUDEBIT NOMINAL DU POIDS BRUT DE
VEHICULE DU VEHICULETRACTEUR.
3. ATTACHER LA REMORQUE FERMEMENTAU
VEHICULETRACTEUR.
4. ATTACHER LES CHAINES DE SURETE EN
UTILISANTUNE METHODE CROISEE.
5. ATTACHERLA CHAINE DE REMORQUAGE AU VEHICULE.
6. VERIFIER LES LAMPES DE LA REMORQUE.
INSTRUCTIONS DE REMORQUAGE
1. BETRIEBSVORSCHRIFT LESEN.
2. ANHÄNGEVORRICHTUNG VERWENDEN,
DIE DER GESAMTBETRIEBSGEWICHTSKLASSE
ENTSPRICHT.
3. ANHÄNGER SICHER AM ZUGFAHRZEUG
BEFESTIGEN.
4. SICHERHEITSKETTEN KREUZWEISE ANBRINGEN.
5. ABREISSKETTE AM FAHRZEUG ANBRINGEN.
6. ANHÄNGERLEUCHTEN PRÜFEN.
N'ENLEVEZ PAS !
GEFAHR
PELIGRO
DANGER
DANGER
DO NOT REMOVE!
ENTFERNEN SIE NICHT!
NO QUITE! DANGER
GEFAHR
PELIGRO
DANGER
WARNUNG
ADVERTISSEMENT
ADVERTENCIA
WARNING
WARNING
WARNUNG
ADVERTENCIA
ADVERTISSEMENT
STANDCLEAR OF FRONT AND REAR OF MACHINE
WHEN MAST IS BEING TILTEDUP OR DOWN.
AUFENTHALTINVORDERER ODER HINTERER UMGEBUNG
DES GERÄTES VERMEIDEN WÄHREND MAST HOCH ODER
NIEDER GESCHWENKT WIRD.
MANTENGASE ALEJADO DE LAPARTE DELANTERA O
TRASERA DE LAMAQUINA MIENTRAS QUE SE ESTA
PROCEDIENDO A LEVANTAREL MASTIL A LA POSICION
VERTICAL O VOLCARLOA LA POSICION HORIZONTAL.
TENEZ-VOUS ADISTANCE DE L’AVANTET DE
L’ARRIERE DE LAMACHINE PENDANT LE BASCULEMENT
DU MATDANS UN SENS OU DANS L’AUTRE.
1
2
3
4
5
6
1
78
9
10
11
12

Safety Rules & General Information
Owner’s Manual for MLT3060M-K Light Tower 9
Figure 1-2. Decals - Left Side
A NON-SECURED, FALLINGMAST WILL
CAUSE SERIOUS INJURY OR DEATHIF A
PERSON IS HIT. TO SECURE MAST, INSERT
THE LOCK BAR INTO MAST MOUNTED
BRACKET THEN INSERT PIN.
EIN UNGESICHERTER HERABFALLENDER
MAST KANN SCHWERE, ODER
VERLETZUNGEN VERURSACHEN, WENN
ER AUF EINE PERSON FÄLLT. ZUM
SICHERN DES MASTES DIE
VERRIEGELUNGSSTANGE IN DIE
MASTMONTIERTE HALTERUNG STECKEN
UND DANN DEN SICHERUNGSSTIFT
EINSTECKEN.
UN MASTIL INCORRECTAMENTEFIJADO
PODRIA CAUSAR LESIONES SEVERAS O
MUERTE ALCAER SOBRE UNA PERSONA.
PARAFIJAR EL MASTIL, INTRODUZCA
PRIMERO EL PERNO DE BLOQUEO
DENTRO DE LA PIEZADE FIJACION
DEL MASTIL YLUEGO COLOQUE EL
PASADOR DE SEGURIDAD.
LA CHUTE D’UN MATMAL FIXE SUR
UNE PERSONNE PEUT ENTRAINER DES
BLESSURES GRAVES OU LAMORT.
POUR FIXER SOLIDEMENT LE MAT,
INSEREZ LA BARRE DE VERROUILLAGE
DANS LE SUPPORT DU MAT, PUIS
INSEREZ LA BROCHE.
GEFAHR
PELIGRO
DANGER
DANGER
DANGER
GEFAHR
PELIGRO
DANGER
Located on
control box
CERCIÓRESE DE QUE EL INTERRUPTOR PRINCIPALESTÉ
APAGADOANTES DE ENCENDER EL MOTOR.
MAKE SURE MAIN CIRCUITBREAKER IS OFF BEFORE
STARTING ENGINE.
TURN
MAIN
BREAKER
OFF
TURN
MAIN
BREAKER
OFF READ AND UNDERSTANDTHE SUPPLIED OPERATOR’S MANUAL
BEFORE OPERATINGTHIS MACHINE. FAILURE TO DO SO
INCREASES THE RISK OF INJURY TOYOURSELF OR OTHERS.
LIRE ET COMPRENDRE LA NOTICE D’EMPLOI FOURNIEAVEC LA
MACHINE AVANT DE LA METTRE EN SERVICE. A DEFAUT.VOUS
AUGMENTERIEZ LE RISQUE DE VOUS EXPOSER ET LES AUTRES
A DES BLESSURES.
LEA YENTIENDA EL MANUAL DE OPERACION PROVISTO CON EL
EQUIPO ANTES DE QUE OPERE ESTE EQUIPO. DE NO HACERSE
ASI. PODRIAAUMENTAR EL RIESGO DE DAÑOS PERSONALES Y
A OTRAS PERSONAS.
VOR INBETRIEBNAHME DIESES GERÄTES BEIGEFÜGTE BETRIEBSVOR-
SCHRIFT LESEN UND VERSTEHEN. NICHTBEFOLGUNG ERHÖHT DAS
RISIKO ZU EIGENER VERLETZUNG ODER ANDERER.
ÜBERZEUGEN SIE SICH HAUPTSTROMKREISBRECHER
IST VON VORHER STARTMOTOR.
ASSUREZ-VOUS LE CIRCUIT PRINCIPALLE BRISANT
EST D'AUPARAVANT MOTEUR DE DÉPART.
WARNUNG
ADVERTENCIA
ADVERTISSEMENT
ADVERTENCIA
ADVERTISSEMENT
WARNUNG
WARNING WARNING
OFF OFF
I
O
DO NOT MOVE UNIT WITH TOWER UP!
UNIT MUST BE MOVED WITH MAST DOWNAND
SECURE IN CRADLE!
NE BOUGEZ PAS D'UNITÉAVEC LA TOUR EN HAUT!
L'UNITÉ PEUT SEULEMENT ÊTRE BOUGÉE AVEC
LE MÂT EN BAS ET PROTÉGÉ DANS LE BERCEAU!
BEWEGEN SIE EINHEIT MIT DEM TURM NICHT!
EINHEIT KANN NUR MIT DEM MAST BEWEGT
WERDEN UNTEN UND GESICHERT IN DER WIEGE!
¡NO MUEVAUNIDAD CON TORRE!
UNIDAD PUEDE SER SÓLO MOVIDA CON MÁSTIL
¡ABAJO YASEGURADO EN CUNA!
DANGER
GEFHAR
PELIGRO
DANGER
N'INSTALLEZ PASL'UNITÉ EN FORT VENT OU
PENDANT LES ORAGES ÉLECTRIQUES !
VÉRIFIEZ LES OBSTRUCTIONS AÉRIENNES
AVANTUTILISATION !
¡CNO INSTALE LAUNIDAD EN FUERTE VIENTO
O DURANTE TORMENTASELÉCTRICAS!
¡CCOMPRUEBE PARASABER SI HAY
OBSTRUCCIONES DE ARRIBAANTES DE USAR!
DO NOT SET UP UNIT IN HIGH WIND OR
DURING ELECTRICAL STORMS!
CHECK FOR OVERHEAD OBSTRUCTIONS
BEFORE USING!
DANGER
STELLEN SIE NICHT MASSEINHEIT IM STARKEN
WIND ODER WÄHREND DER ELEKTRISCHEN
STÜRME AUF!
ÜBERPRÜFEN SIE AUF OBENLIEGENDE
HINDERNISSE, BEVOR SIE VERWENDEN!
GEFHAR
PELIGRO
DANGER
SHUT DOWN/GESCHLOSSEN/ARRÊTÉ/APAGADO
I
OI
O
I
O
I
O
I
O
I
OI
O
I
O
I
O
I
O
ALL CIRCUIT BREAKERS OFF!
ALLE CIRCUITBREAKERS WEG!
TOUS LES DISJONCTEURS AU LOIN !
TODOSLOS INTERRUPTORES APAGADO!
START ENGINE/LASSEN SIE MASCHINE AN/
METTEZ EN MARCHE LE MOTEUR/ENCIENDA EL MOTOR.
GLOW
PLUG
OFF
RUN
START
RELEASE KEY
LASSEN SIETASTE LOS
LIBÉREZ LA CLEF
LANCE LA LLAVE
GLOW
PLUG
OFF
RUN
START
ACTIVATEGLOW PLUGS
AKTIVIEREN SIE GLÜHKERZEN
ACTIVEZ LES PRISES DE LUEUR
ACTIVE LOS ENCHUFESDE RESPLANDOR.
GLOW
PLUG
OFF
RUN
START
CRANK ENGINETO START
REIZBARE MASCHINE ZUM ZU BEGINNEN
MOTEUR DÉTRAQUÉÀ COMMENCER
PONGA EL MOTORPARA COMENZAR.
TURN CIRCUIT BREAKERS ON.
SCHALTEN SIE CIRCUIT BREAKERS EIN!
ALLUMEZ LES DISJONCTEURS
GIRE LOS INTERRUPTORES.
1
2
3
4
6
5
STOP ENGINE.
STOPPEN SIE MASCHINE.
ARRÊTEZ LE MOTEUR
APAGUEEL MOTOR.
GLOW
PLUG
OFF
RUN
START
BEFORE STARTINGTHE ENGINE/BEVOR DIE MASCHINE ANGELASSEN WIRD
AVANTDE METTRE EN MARCHE LE MOTEUR/ANTES DE ENCENDER EL MOTOR:
ENGINE OPERATION/MASCHINE BETRIEB/
OPÉRATION DE MOTEUR/OPERACIÓN DEL MOTOR:
1. CHECK FUEL LEVEL.
Überprüfen Sie Kraftstoffniveau.
Vérifiez le niveau de carburant.
Compruebeel nivel del combustible.
2. CHECK ENGINE OIL LEVEL.
ÜberprüfenSie Triebwerkölstand.
Vérifiez le niveau d'huile à moteur.
Compruebeel nivel del aceite de motor.
3. CHECK COOLANT LEVEL.
Überprüfen Sie Kühlmittelniveau.
Vérifiez le niveau de liquide réfrigérant.
Compruebeel nivel del liquido refrigerador.
4. MAKE SURE MAIN CIRCUIT BREAKER IS OFF.
Stellen Sie sicher, daß Hauptschutzschalter aus ist.
Assurez-vousque le disjoncteur principal est éteint.
Cercioresede que el interruptor principal esté apagado.
!
I
OI
O
I
O
I
O
I
O
ALL CIRCUIT BREAKERS OFF!
ALLE CIRCUITBREAKERS WEG!
TOUS LES DISJONCTEURS AU LOIN !
TODOSLOS INTERRUPTORES APAGADO!
Located on inside of door
SECURE MAST IN TRANSPORT
LOCK BEFORE LIFTING OR TOWING!
DEN MAST VOR DEM ANHEBEN ODER
ABSCHLEPPEN IN DER
TRANSPORTHALTERUNGSICHERN!
VERROUILLEZ SOLIDEMENT LE MAT
POUR LE TRANSPORT AVANT DE
LE HISSER OU DE LE REMORQUER.
ADVERTENCIA
WARNUNG
ADVERTISSEMENT
FIJE EL MASTIL EN LATRABA DE
TRANSPORTE ANTES DE REMOLCAR
O LEVANTAREL MISMO.
WARNING
CONTACTWITH OVERHEAD ELECTRICAL POWER
LINES WILLCAUSE SERIOUS INJURY OR DEATH.
DO NOT POSITION LIGHTTOWER UNDER ELECTRICAL
POWER LINES.
KONTAKTMIT OBERIRDISCHEN STROM
FREILEITUNGEN KANN ZU SCHWEREN VERLETZUNGEN
ODER TODFÜHREN. NIEMALS BELEUTUNGSTURM
UNTER ELEKTRISCHEN LEITUNGENAUFSTELLEN.
ELCONTACTO CON CABLES ELECTRICOS DE
TENDIDOAEREO CONDUCIRA A GRAVES HERIDAS O
MUERTE. NUNCA UBIQUE LA TORREDE LUZ DEBAJO
DE CABLES ELECTRICOS DE TENDIDOAEREO.
TOUTCONTACT AVEC DES CABLES ELECTRIQUES
AERIENS PEUT PROVOQUER DE SERIEUSES
BLESSURES ET MEME LAMORT. NE POSITIONNEZ
PASLE MAT DECLAIRAGE SOUS DES CABLES
ELECTRIQUESAERIENS.
DANGER
GEFAHR
PELIGRO
COMPLETELYLOWER TOWER BEFORE TILTING MAST.
TILTINGAN EXTENDED MAST COULD CAUSE SERIOUS
INJURYOR DEATH.
VOR DEM EINSCHWENKEN DES MASTES,
BELEUCHTUNGSTURM GANZ NIEDERLASSEN.
EINSCHWENKUNG DES VERLÄNGERTEN MASTES KANN
SCHWERE VERLETZUNG ODER TODHERVORRUFEN.
BAJE ELMASTIL COMPLETAMENTE ANTES DE
VOLCARLOA LA POSICION HORIZONTAL. EL VOLCAR UN
MASTILEXTENDIDO PUEDE LLEGAR A CAUSAR GRAVES
HERIDAS O MUERTE.
RABAISSEZ COMPLETEMENT LE MATAVANTDE LE
BASCULER. LE GASCULEMENT D’UN MAT DEPLOYE
PEUT PROVOQUER DE SERIEUSES BLESSURES ETMEME
LAMORT.
DANGER
DANGER
GEFAHR
PELIGRO
DANGER
13
14
15
16
17
18
23
23
24
8
25
26
19
20
21
22

Safety Rules & General Information
10 Owner’s Manual for MLT3060M-K Light Tower
Figure 1-3. Decals - Right Side
SECURE MAST IN TRANSPORT
LOCK BEFORE LIFTING OR TOWING!
DEN MAST VOR DEM ANHEBEN ODER
ABSCHLEPPEN IN DER
TRANSPORTHALTERUNGSICHERN!
VERROUILLEZ SOLIDEMENT LE MAT
POUR LE TRANSPORT AVANT DE
LE HISSER OU DE LE REMORQUER.
ADVERTENCIA
WARNUNG
ADVERTISSEMENT
FIJE EL MASTIL EN LA TRABA DE
TRANSPORTE ANTES DE REMOLCAR
O LEVANTAREL MISMO.
WARNING WARNING
WARNUNG
ADVERTISSEMENT
ADVERTENCIA
DIESEL
DANGER
GEFAHR
PELIGRO
DANGER
Located inside
of door
6PJNJ
8/75$/2:
68/)85
)8(/21/<
17
15 15
16
22
27 28
29
23 23

Safety Rules & General Information
Owner’s Manual for MLT3060M-K Light Tower 11
Figure 1-4. Decals - Inside Unit
WARNUNG
ADVERTISSEMENT
WARNING
ADVERTENCIA
WARNING
WARNUNG
ADVERTISSEMENT
ADVERTENCIA
DANGER
GEFAHR
PELIGRO
DANGER
ADVERTENCIA
WARNUNG
ADVERTISSEMENT
WARNING
WARNUNG
ADVERTISSEMENT
ADVERTENCIA
WARNING
WARNING
WARNUNG
ADVERTISSEMENT
ADVERTENCIA
WARNUNG
ADVERTISSEMENT
ADVERTENCIA
WARNING
29
30
31
30
31
2
8
32

Safety Rules & General Information
12 Owner’s Manual for MLT3060M-K Light Tower
This page intentionally left blank.

General Information
Owner’s Manual for MLT3060M-K Light Tower 13
Section 2: General Information
Specifications
DESCRIPTION UNITS MLT3060M MLT3060K
Engine
EPA Tier — 4f 4f
Fuel Consumption—100% Prime gph (Lph) 0.47 (1.78) 0.50 (1.89)
Fuel Consumption—75% Prime gph (Lph) 0.35 (1.32) 0.38 (1.44)
Fuel Consumption—50% Prime gph (Lph) 0.24 (0.91) 0.25 (0.95)
Battery Type—Group Number — 24 24
Battery Voltage quantity per unit 12V (1) 12V (1)
Battery Rating amp-hours 440 CCA 440 CCA
Generator
Output - Standby kW (kVA) 6.0 (6.0) 6.0 (6.0)
Output Voltage volts 120/240, single phase 120/240, single phase
Output Amperes 120V (240V) amperes 50 (25) 50 (25)
Frequency Hz Hertz 60 60
Weights
Dry Weight lbs (kg) 1640 (744) 1657 (752)
Operating Weight lbs (kg) 1856 (842) 1873 (850)
Capacities
Fuel Tank Volume gal (L) 30 (114) 30 (114)
Usable Fuel Volume gal (L) 30 (114) 30 (114)
Coolant (including engine) qt (L) 4.5 (4.3) 4.8 (4.5)
Oil (including filter) qt (L) 3.8 (3.6) 5.4 (5.1)
Maximum Run Time hours 64 60
AC Distribution
Circuit Breaker Size amperes 30 30
Trailer
Hitch—Standard — 2 in. Ball 2 in. Ball
Maximum Tire Pressure psi (kPA) 50 (345) 50 (345)
Specifications are subject to change without notice.

General Information
14 Owner’s Manual for MLT3060M-K Light Tower
Unit Dimensions
Figure 2-1. Unit Dimensions
Specifications are subject to change without notice.
ABCDE
MLT3060M/K 170 in. (4.32 m) 68 in. (1.73 m) 30 ft (9.14 m) 49 in. (1.25 m) 98 in. (2.49 m)
D
B
A
E
C
A
B
C
D
E

General Information
Owner’s Manual for MLT3060M-K Light Tower 15
Unit Serial Number Locations
See Figure 2-2 to locate the unit ID tag and Vehicle Identification Number (VIN) tag on the unit. Important information,
such as the unit serial number, model number, VIN and tire loading information are found on these tags. Record the
information from these tags so it is available if the tags are lost or damaged. When ordering parts or requesting
assistance, you may be asked to provide this information.
Figure 2-2. Serial Number Locations
Unit ID Tag
Located on inside
of rear panel
VIN
Tag
TIRE AND LOADING INFORMATION
RENSEIGNEMENTS SUR LES
PNEUS ET LE CHARGEMENT
SEE OWNER’S
MANUAL FOR
ADDITIONAL
INFORMATION
VOIR LE
MANUEL DE
L’USAGER
POUR
PLUS DE
RENSEIGNEMENTS
MANUFACTURED BY/FABRIQUE PAR: Generac Mobile Products LLC DATE: 00/0000
GVWR/PNBV: 000KG (0000LBS) COLD INF. PRESS./
PRESS. DE
V.I.N./N.I.V.:
00000000000000000
TYPE: TRAILER
MODEL:
XXX000
GAWR / PNBE TIRE / PNEU RIM / JANTE GONF A FROID - KPA(PSI/LPC) SGL / DUAL
EACH
AXLE
THIS VEHICLE CONFORMS TOALL APPLICABLE STANDARDS PRESCRIBED UNDER THE U.S. FEDERAL MOTOR VEHICLE SAFETY STANDARDS(FMVSS)AND CANADIAN
MOTOR VEHICLE SAFETY REGULATIONSIN EFFECT ON THE DATE OF MANUFACTURE.
CE VEHICULE EST CONFORMEA TOUTES LES NORMES QUI LUI SONT APPLICABLES EN VERTU DU REGLEMENT SUR LASECURITE DES VEHICULES AUTOMOBILES DU CANADA EN VIGUEUR A LADATE SA
FABRICATION.
The weight of cargo should never exceed 0000KG (0000LBS)
Le poids du chargement ne doit jamais depasser 0000KG (0000LBS)
Serial Number
V
A
Model
KVA
Manufacturing Code
1 ph. 1.0PF 3 ph. .8PF 3 ph. 1.0PF
KW
Country of Origin
Weight (lbs/kg) RPM/Frequency
Rating
Ins. Class
FOR ELECTRICAL EQUIPMENT
ONLY. POUR MATERIAL
ELECTRIQUE SEULEMENT.
209649
Form: SFC626B
Manufactured by Generac Mobile Products LLC
[phone] [phone]

General Information
16 Owner’s Manual for MLT3060M-K Light Tower
Component Locations
Figure 2-3. Component Locations
AMast Rotation Knob FFuel Fill
BCentral Lift Point GOutriggers
CEngine Exhaust HEngine Access
DForklift Pockets IBattery
ERadiator Access JControl Box
A
B
C
D
E
F
G
H
I
J
