Genesis Razer X User manual
Razer X Multi-Jaw Demolition Tool (GRX)
SAFETY & OPERATOR’S MANUAL
© 2021 Genesis Attachments, LLC
Genesis GRX
2
CONTACT INFORMATION
View and download all manuals: genesisattachments.com/manuals
Patents: genesisattachments.com/products/patents
Asia Pacic Representative Oce
24 Upper Serangoon View #12-28
Singapore 534205
Phone: +65 9673 9730
E-mail:
Europe/Africa/Middle East
Genesis GmbH
Teramostrasse 23
87700 Memmingen, Germany
Phone: +49 83 31 9 25 98 0
Fax: +49 83 31 9 25 98 80
genesis-europe.com
E-mail:
Central America & Colombia
Bogota, Colombia
Phone: +57 1 610 8160 / 795 8747
E-mail:
Genesis Attachments
1000 Genesis Drive
Superior, WI 54880 USA
Toll Free: 888-SHEAR-IT
(888-743-2748)
Phone: 715.395.5252
E-mail:
© 2021 Genesis Attachments, LLC Genesis GRX 3
PREFACE
To ensure years of safe, dependable service, only trained and authorized persons should operate
and service your Genesis attachment. It is the responsibility of the product’s owner to ensure the
operator is trained in the safe operation of the product and has available this manual for review.
It is the responsibility of the operator and maintenance personnel to read, fully understand and
follow all operational and safety-related instructions in this manual. The attachment should not
be operated until you have read and fully understand these instructions. Always use good safety
practices to protect yourself and those around you.
Important
This operator’s manual must accompany the attachment at all times and be readily available to
the operator.
Manual Replacement
Should this manual become damaged or lost or if additional copies are required, immediately
ontact any authorized Genesis dealer or the Genesis Service Department at 888-743-2748 or
715-395-5252 for a replacement.
Registration Form
Genesis indicating the date the attachment went into service.
Possible Variations
Genesis cannot anticipate every possible circumstance that might involve a potential hazard as
the owner’s requirements and equipment may vary. Therefore, the warnings in this publication and
on the product may not be all-inclusive, and you must satisfy yourself that the procedure,
application, work method or operating technique is safe for you and others before operating.
Public Notice
Genesis reserves the right to make changes and improvements to its products and technical
literature at any time without public notice or obligation. Genesis also reserves the right to
discontinue manufacturing any product at its discretion at any time.
Warranty
All work or repairs to be considered for warranty reimbursement must be pre-authorized by the
authorization by the Genesis Service Department will render all warranty reimbursement
consideration null and void without exception. See page 61 for Warranty Claim Procedures.
Improper operation or improperly performed maintenance may render any warranty null and void.
© 2021 Genesis Attachments, LLC
Genesis GRX
4
TABLE OF CONTENTS
CONTACT INFORMATION 2
PREFACE 3
Important 3
Manual Replacement 3
Registration Form 3
Possible Variations 3
Public Notice 3
Warranty 3
SAFETY STATEMENTS 7
OPERATIONAL SAFETY 8
Read Manual Before Operating or Maintaining the Attachment 8
Personal Protection 8
Know Your Equipment 8
Before Operating 8
Check the Equipment 9
Stability 9
Know the Work Area 10
Starting Procedure 10
Place the Load Safely 10
Safely Operate Equipment 11
Transporting the Attachment 12
Equipment Condition 12
Working Overhead 12
Power Lines 12
Use Care with Hydraulic Fluid Pressure 13
Prioritized Oil Flow 14
Emergency Situations 14
Unsafe Conditions 14
Crystalline Silica Dust 14
Process Material Safely 15
Lift the Load Safely 15
Place the Load Safely 15
MAINTENANCE/TRANSPORT LOCK BOLTS 16
ROTATION LOCK 17
ATTACHMENT INSTALLATION 18
Dual-Pump Flow 18
ROTATOR INSTALLATION 20
Case Drain Line 20
Foot Switch Installation 20
Rotation Circuit - Gear Pump Type 21
Rotation Circuit - Auxiliary Valve on Machine 22
ELECTRICAL INSTALLATION 23
HYDRAULIC START-UP 24
Start-up Procedure 24
JAW SET CHANGE-OVER 25
MAINTENANCE SAFETY 27
© 2021 Genesis Attachments, LLC Genesis GRX 5
TABLE OF CONTENTS
MAINTENANCE SCHEDULE 29
Four-Hour Checklist 29
Eight-Hour Checklist 30
Long-term Maintenance 30
LUBRICATION POINTS 31
BOLT TORQUE SPECS 32
SHEAR JAW SET MAINTENANCE 33
Blade Bolts 33
PIERCING BLADES 34
Replacement 36
GUIDE BLADES 37
Shimming 37
Rotation 38
Replacement 38
Adjustment Plates 38
PRIMARY AND SECONDARY BLADES 39
Removal 39
Adjustment Plates 40
Rotation 40
Blade Gap 41
Blade Gap Measuring Procedure 41
Shimming 41
RAZOR BLADE 42
CRACKER & PULVERIZER JAW SET MAINTENANCE 43
Pulverizing Teeth 43
Concrete Cracking Tips 44
Cutting Blades 45
Blade Removal 45
GENERAL WELDING GUIDELINES 46
Welding Ground Clamp 46
Welding Rules 46
HARD-SURFACING 47
SHEAR JAW BUILD-UP 48
SHEAR JAW HARD-SURFACING PATTERNS 49
CRACKER JAW WELDING MAINTENANCE 50
Hard-Surfacing Patterns 50
HYDRAULIC/ROTATION MAINTENANCE 51
Hydraulic Requirements 51
Rotation Valve Input 51
Rotation Valve Settings 51
GenFlow Regeneration Valve 52
Regeneration Valve Adjustment 52
GENFLOW REGENERATION VALVE - HOW IT WORKS 53
GENFLOW REGENERATION VALVE 54
GRX 295 54
GRX 395 54
© 2021 Genesis Attachments, LLC
Genesis GRX
6
TABLE OF CONTENTS
SLEWING RING MAINTENANCE 55
ROTATION CIRCUIT 56
Auxiliary Valve Rotation 56
Gear Pump Rotation 56
TROUBLE-SHOOTING GUIDE 58
Attachment 58
Rotator 59
Lock-Pin 60
WARRANTY 61
Claim Procedure 61
Blade Warranty 61
PARTS ORDER POLICY AND PROCEDURE 62
Parts Orders Should Include 62
Placing Orders 62
Part Numbers 62
Shipping 62
Invoices 62
Returns 62
Return Goods Authorization 62
PARTS ORDER FORM 63
CONTACT INFORMATION 64
For bolt torque specs, see the Genesis Fastener Manual.
genesisattachments.com/manuals
NOTICE
© 2021 Genesis Attachments, LLC Genesis GRX 7
SAFETY STATEMENTS
This symbol by itself or used with a safety signal word
throughout this manual is used to call attention to
instructions involving your personal safety or the safety
of others. Failure to follow these instructions can result in
injury or death.
This statement is used where serious injury or death
could result if the instructions are not followed properly.
!WARNING
This statement is used where minor or moderate injury
could result if the instructions are not followed properly.
!
CAUTION
This statement is used where property damage could
result if the instructions are not followed properly.
NOTICE
!DANGER
This statement is used where serious injury or death will
result if the instructions are not followed properly.
© 2021 Genesis Attachments, LLC
Genesis GRX
8
!WARNING
Serious injury or death could result if appropriate
protective clothing and safety devices are not used.
Personal Protection
Use protective clothing and safety devices appropriate for the working conditions. These may
include but are not limited to:
3Hard hat
3Safety glasses, goggles or face shield
3Hearing protection
3Safety shoes
3Heavy gloves
3
3
Know Your Equipment
Know your attachment’s capabilities, dimensions and functions before
operating. Inspect your attachment before operating and never operate an
attachment that is not in proper working order. Remove and replace any
damaged or worn parts.
Before Operating
3Warn all others in the area that you are about to start operation.
3Perform the Check the Equipment steps outlined in this manual.
3Check underneath and around the machine. Make sure all personnel and equipment are
clear from the area of operation and equipment movement. Check clearances in all
directions, including overhead.
3Be properly seated in the operator’s seat.
3Do not attempt to operate until you have read and fully understand this manual and the
OEM manual for the carrier.
OPERATIONAL SAFETY
Read Manual Before Operating or Maintaining the Attachment
Read this manual before attempting to operate the attachment. This operator’s
manual should be regarded as part of the attachment. For proper installation,
operation and maintenance of the attachment, operators and maintenance
personnel must read this manual.
© 2021 Genesis Attachments, LLC Genesis GRX 9
Check the Equipment
Before use, check the equipment to ensure it is in good operating condition.
Check the following:
3
3
3Hydraulic hoses and hose connections for wear or leaks. Repair or replace any damaged
hoses or connections.
3All control levers for proper operation.
3Rotation bearing. Visually check for loose or damaged bolts. If
3Grease rotation bearing and pinion gear.
3Check for loose or missing pin retaining bolts.
3Check cylinders for dents (barrel) or dings (rod).
GOOD
CONDITION
3
!WARNING
Serious injury or death could result if warnings or
instructions regarding carrier stability and the work area
are not followed properly.
Stability
Your Genesis attachment is sized for carrier stability. However, improper operation, faulty
3Know the working ranges and capacities of the carrier to avoid tipping.
3Use the recommended carrier counter weight.
• Ground conditions
• Grade
• Weight of attachment
• Contents of attachment
• Operator judgement
For greater stability, knuckle the attachment to bring the load closer to the center of rotation
(center of gravity) while lifting. Use extra caution during reaching to avoid tipping.
OPERATIONAL SAFETY
© 2021 Genesis Attachments, LLC
Genesis GRX
10
Know the Work Area
Check clearances in the work area. Keep all bystanders at a safe distance. Do not work under
obstacles. Always check your location for overhead and buried power lines or other utilities before
operation.
ground. If level ground is not possible, position the carrier to use the attachment to the front or
back of the carrier. Avoid working over the side of the carrier.
To reduce the risk of tipping and slipping, never park on a grade exceeding 10% (one-foot rise
over the span of a ten-foot run).
Starting Procedure
Before operating, walk completely around the equipment to make certain no one is under it, on it
or close to it. Keep all bystanders at least 75 feet away from the area of operation and equipment
movement. Let all other workers and bystanders know you are preparing to start. DO NOT operate
until everyone is clear.
Always be properly seated in the operator’s seat before operating any carrier controls.
To start:
3Make sure all controls are in the center (neutral) position.
3Be properly seated.
3Slowly operate all functions to check for proper operation and to bleed air from the
hydraulic system.
To shut down:
3Return your Genesis attachment to a rest position on the ground.
3
3Work controls in all directions to relieve hydraulic pressure, per excavator manufacturer’s
instructions.
!WARNING
Serious injury or death could result if warnings or
instructions regarding safe operation are not followed
properly.
Place the Load Safely
Do not move the attachment, or anything held in the jaws, over people, equipment or buildings. Do
not throw or drop the contents. Operate the controls smoothly and gradually.
OPERATIONAL SAFETY
© 2021 Genesis Attachments, LLC Genesis GRX 11
Safely Operate Equipment
See your carrier’s manual for these instructions.
3Operate only from the operator’s seat. Check the seat belt daily and replace if frayed or
damaged.
3
are taking prescription medication or over-the-counter drugs ask your medical provider
whether you can safely operate equipment.
3Never leave equipment unattended with the engine running or with the attachment in a
raised position. Apply the brakes before exiting the equipment.
3Do not exceed the lifting capacity of your carrier.
3Avoid conditions that can lead to tipping. The carrier can tip when operated on hills, ridges,
banks and slopes. Avoid operating across a slope which could cause the carrier to overturn.
3Reduce speed when driving over rough terrain, on a slope, or when
turning to avoid overturning the carrier.
3Never use the attachment as a work platform or personnel carrier.
3Keep all step plates, grab bars, pedals and controls free of dirt, grease,
debris and oil.
3Never allow anyone to be around the equipment when it is operating.
3Do not operate poorly maintained or otherwise faulty equipment. Inform the proper authority
3Do not alter or remove any safety features.
3
in doubt on any safety issue, contact your supervisor or safety
coordinator for an explanation.
3A heavy load can cause equipment instability. Use extreme care during travel. Slow down
on turns and watch out for bumps. The equipment may need additional counter-weights to
counterbalance the weight of the attachment.
OPERATIONAL SAFETY
© 2021 Genesis Attachments, LLC
Genesis GRX
12
Power Lines
Do not operate the machine near energized power lines. All local, state/provincial and federal
regulations must be met before approaching power lines, overhead or under-
ground cables, or power sources of any kind with any part of the carrier or
attachment. Always contact the appropriate utility when operating near power
lines. The lines should be moved, insulated, disconnected or de-energized
and grounded before operating in the area.
Current in high voltage lines may arc some distance from the wire to a nearby ground. Keep all parts
of the machine at least 50 feet (16m) away from power lines.
Working Overhead
Avoid handling material overhead whenever possible. Safety glass and wire mesh
created during handling. Falling Object Protection Structures, or FOPS, are
necessary for any application where material is to be handled overhead.
Transporting the Attachment
3Travel only with the attachment in a safe transport position to prevent uncontrolled
movement. Drive slowly over rough ground and on slopes.
3
3Do not drive close to ditches, excavations, etc., as cave-in could result.
3Do not smoke when refueling the prime mover. Allow room in the fuel tank for expansion.
Wipe up any spilled fuel. Secure cap tightly when done.
Equipment Condition
Never operate poorly maintained equipment. When maintenance is required, repair or replace
parts immediately.
!WARNING
Serious injury or death could result if warnings or
instructions regarding working overhead are not followed
properly.
!DANGER
Serious injury or death will result if warnings or instructions
regarding power lines are not followed properly.
OPERATIONAL SAFETY
© 2021 Genesis Attachments, LLC Genesis GRX 13
Use Care with Hydraulic Fluid Pressure
Hydraulic leaks under pressure may not be visible.
3Keep unprotected body parts, such as face, eyes and arms as far away
develop gangrene or other permanent injuries.
3
3Wear safety glasses and protective clothing and use a piece of cardboard
or wood when searching for hydraulic leaks.
Do Not Use Your Hands!
See illustration below.
3Hydraulic oil becomes hot during operation. Do not let hydraulic oil or
components contact skin, as it could cause severe burns. Allow hydraulic
components to cool before working on them. Use appropriate protective
clothing and safety equipment. If burned, seek immediate medical attention.
!WARNING
Serious injury or death could result if warnings or
followed properly.
OPERATIONAL SAFETY
© 2021 Genesis Attachments, LLC
Genesis GRX
14
OPERATIONAL SAFETY
IMPORTANT: Concrete and masonry products contain silica sand.
Quartz, which is a form of silica and the most common mineral in the
Earth’s crust, is associated with many types of rock.
Some activities that may have silica dust present in the air include
demolition, sweeping, loading, sawing, hammering, drilling or planing of
rock, concrete or masonry.
It is recommended to use dust suppression (such as water) or dust
collection (such as a vacuum) along with personal protective equipment
if necessary during the operation of any attachment that may cause high
levels of silica dust.
Prioritized Oil Flow
operations or high reach conditions.
Emergency Situations
Unsafe Conditions
Do not operate if an unsafe condition exists. Stop operation immediately, shut down the machine
and report the unsafe condition to the proper authority. Equipment operation and maintenance
sense while operating and be alert to unsafe conditions.
Crystalline Silica Dust
It is recommended to use dust suppression, dust collection and if necessary, personal protective
equipment during the operation of any attachment that may cause high levels of dust.
!DANGER
Exposure to respirable crystalline silica dust along with
other hazardous dusts may cause serious or fatal
respiratory disease.
© 2021 Genesis Attachments, LLC Genesis GRX 15
!WARNING
Using your Genesis attachment in unauthorized
applications may create an unsafe situation and will void
the warranty.
Process Material Safely
• Do not process hardened steel material such as tool steel, railroad rail, axles, springs,
machined parts or high-strength material. Hardened/high-strength material breaks, rather than
your Genesis attachment and base carrier hydraulic systems.
• Do not operate any functions of the carrier while cutting or crushing with your attachment,
including boom and drive functions.
• Do not pull down structures with your Genesis attachment. Doing so may cause falling debris
or material to break free and exceed the capacities of the carrier, causing a tipping hazard and
rotation component failures.
• Do not use rotation to pry or break material. Doing so exerts high back-driving forces and
spikes to the rotation circuit components that cannot be cushioned hydraulically. It may also
cause motor and gearbox failures. The rotator should only be used for positioning an
attachment.
• Do not process pressurized containers unless the main valve has been removed and you are
absolutely certain the container is empty.
• Do not process spring loaded brake chambers and automotive struts as the release of
compressed springs is extremely dangerous. Nothing made of spring material or containing
springs should be processed.
Lift the Load Safely
• The hydraulic system has been preset and tested by your dealer. Do not alter hydraulic set-
tings without consulting an authorized Genesis dealer or the Genesis Service Department.
Doing so will void the warranty and may cause structural damage, accidents or tipping.
• Make sure the load is held securely in the jaws. Do not move a loaded attachment if load is
loose or dangling. Make sure the load is pinched between the jaws – never cradle a load.
• For greater stability, knuckle the attachment to bring the load closer to the center of rotation
(center of gravity) while lifting. Use extra caution during reaching to avoid tipping.
Place the Load Safely
• Do not move the attachment, or anything held in the jaws, over people, equipment or
buildings. Place the load gently. Do not throw or drop the contents.
• Operate the controls smoothly and gradually. Jerky controls are hazardous and may cause
damage to the carrier.
•
• Never substitute pins or bolts. Use factory supplied pins. Replace all bolts with the same size
and grade. Failure to do so may cause serious injury or death.
• Use your Genesis attachment only as directed in this manual. Do not use the attachment to lift
and move other objects. Doing so may cause instability and tipping.
OPERATIONAL SAFETY
© 2021 Genesis Attachments, LLC
Genesis GRX
16
MAINTENANCE/TRANSPORT LOCK BOLTS
GRX demolition tools ship from the factory with lock bolts installed in the body and cylinder lock
pins as show below.
The lock bolts are to be installed any time the tool is transported or maintenance is performed to
prevent inadvertent lock pin movement during these operations.
Remove the lock bolts prior to normal operation.
© 2021 Genesis Attachments, LLC Genesis GRX 17
ROTATION LOCK
Rotation (transport) locks are installed at the factory to allow the bracket to be shipped with the
from the truck and mounting it to the excavator.
Rotation locks MUST be removed before operating the attachment to prevent rotation
system damage.
The rotation locks are located inside the small bolt covers for the slewing ring and marked with
threaded into the rotation lock for removal.
There are TWO locks in every attachment, one on either side of the bracket. In some cases, one
of the port blocks may need to be removed to access the rotation lock. The rotation locks and red
© 2021 Genesis Attachments, LLC
Genesis GRX
18
ATTACHMENT INSTALLATION
Preparation of the excavator prior to attachment delivery will make installation safer and
easier. Contact Genesis or your Genesis dealer for assistance.
Dual-Pump Flow
An excavator typically has two hydraulic pumps that supply oil to its main control valve, which
Summating is the preferred method of achieving maximum speed to an attachment. However,
interchanging the stick and bucket circuits may also substantially increase speed.
an auxiliary circuit spool to the stick circuit helps reduce back pressure in the system and speed
up jaw open and close.
depending on whether the bucket and auxiliary are on separate sides of the main valve and
whether the auxiliary circuit can be proportionally controlled by teeing into the bucket pilot control
circuit.
The auxiliary circuit must also be capable of proportionally controlling pump initiation on the
gradually increasing or decreasing, which can cause sharp, damaging spikes in the hydraulic
circuit.
If excavator circuits are electronically controlled, it may be necessary to reduce the spool shift and
pump initiation in the excavator software to take spiking out of the circuit when changing
attachment cylinder direction from full extend or full retract.
which in turn slows how the spool shifts and the pumps stroke up.
© 2021 Genesis Attachments, LLC Genesis GRX 19
The attachment is usually shipped in an upright position. Extreme care must be used when
inverting the attachment for installation.
Follow the excavator OEM’s removal and safety instructions to remove the bucket or other stick
attachments.
Blocking may be required to raise the mounting bracket into
proper position.
Track the excavator to the attachment with the jaws facing the
operator. Lift the excavator stick over the attachment,
carefully positioning the stick tip connection with the
attachment mounting main pivot bore. Pin the excavator stick
to the attachment.
Slowly raise the boom to lift the attachment, allowing the
cylinder pivot connection to come within range of the
excavator cylinder stroke.
Extend the excavator cylinder until the power link bore lines
up with the cylinder pivot connection. Pin the excavator
cylinder to the attachment.
Crowd and extend the attachment, checking closely to make sure there is no interference between
the bracket and hard lines. Also check for interference between the cylinder and boom/stick.
Install excavator hydraulic hoses, supply and return, from the stick tip to the attachment manifold
blocks. See page 23 for electrical installation.
The stick and bucket circuits are oriented as to rod and bore sides of their respective cylinders. Be
sure to connect rod-to-rod and bore-to-bore when connecting a circuit to the attachment. When
these are reversed, extra pressure is needed to open the jaw, which pulls down the engine,
de-strokes the pumps, increases jaw cycle time, creates high oil temperature and burns more fuel.
The attachment must be vertical before putting oil into it or an air lock in the regen valve may
prevent the jaw from opening.
!WARNING
Be sure hydraulic pressure is relieved before disconnect-
ATTACHMENT INSTALLATION
!WARNING
Removing any connecting pin may be hazardous. To remove
a connecting pin, position the attachment on the ground and
properly support.
when striking pins. Keep all personnel at a safe distance.
© 2021 Genesis Attachments, LLC
Genesis GRX
20
Case Drain Line
pressure in this line must be below 50 PSI at all times.
Foot Switch Installation
Install the foot switch in the excavator and connect with electrical harness. Consult excavator
dealer when using an alternate to the Genesis supplied foot switch.
White Normal Open
Black Normal Open Red
2 Amp Fuse
24 Volt
To Rotator
(A) Black (B) Green (C) White
Green To Ground
ROTATOR INSTALLATION
