GENI shiva SV-150R User manual

Unprecedented performance
comes in this promising package --
the first die-cast aluminum scanner case
made in Asia. SHIVA scan has the form
to entice and the functions to captivate.
TM
CAUTION!
SV-150R/200R/250R TM
Copyright 2002 Geni Electronics Co., Ltd.

CONGRATULATIONS!
You are smart. You have one of the best
scanners around.
And with the Geni mark, you are ensured of high quality and reliability
for years to come.
You can rely on Geni Electronics Co., Ltd., for more excellent lighting
products. We design and manufacture strobes, effects, and scanners.
And we work hard to keep you, our customer, satisfied.
You can get some of the best quality, best priced products on the
market from Geni. You know that, because you're smart. Always get
the best -- with Geni.
Main Office/Factory:
Geni Electronics Co., Ltd.
Tel: [phone]
Fax: [phone]
Showroom:
Geni Electronics Co., Ltd.
Taipei World Trade Center, Room 3A-04
No. 5, Section 5, Hsin Yi Road,
Taipei, Taiwan
Tel: [phone]
Fax: [phone]
th
No. 22, Chung Cheng 5 Street
Yung Kang Tainan Hsien, Taiwan
Get the best -- get Geni!
Geni Quality Sets the Standard

CONTENTS
TM
ABOUT SHIVA-150R/200R/250R
APPENDIX 2
APPENDIX 1
SECTION 2 - OPERATION
SECTION 1 - SETTING UP
DMX Channel Control Diagram
DMX Address Chart
Product Specifications
Trouble-shooting
Lamp Removal
Maintenance
Service Dip Switches
Function Settings
Channel Control Positions
DMX512 Control
Focusing the Lens
Scanner Installation
Lamp Installation
Inspection
Warning
Scanner Diagrams
Features
Description Page 1
Page 1
Page 2
Page 3
Page 3
Page 4
Page 5
Page 5
Page 14
Page 13
Page 12
Page 11
Page 10
Page 9
Page 8
Page 8
Page 7
Page 6
Page 6
Page 6
APPENDIX 3
APPENDIX 4
Gobos
Gobo Dimensions

14
Exterior
Diameter:
25.2 mm
Gobo
Pattern
Diameter:
20 mm
Dimensions
APPENDIX 4
Gobo Dimensions
Note:
TM
Shiva-150R/200R/250R
scanner gobos are
suitable for these
two scanners. They
can also be used
TM
in Sharma-200
color changers. Do
not install gobos
from
into non-rotating
gobo scanners
Shiva-150/200/250 .
Shiva-150R/200R/
TM
250R
TM
ABOUT SHIVA-150R/200R/250R
Description
Focus, self-test, X/Y direction options, and more
Convenient to use:
Axial fans with long-life ball bearings
6 precision, quality stepper motors
Built to last:
Smooth micro-stepping
170 pan, 90 tilt
True mechanical linear dimming 0-100%
Innovative single-motor shutter, 1-7 frequency-per-second strobe
Engineered to perform:
Strobe and dimming
Nine dichroic colors + white
Six rotating replaceable gobos
Effect variety to make great shows:
AR & IR coated lenses
Large optical path
Excellent optics for high lumen output:
Die-cast aluminum case for beauty and strength
Features
TM
1
Shiva-150R/200R/250R is the scanner to win with.
Excellent optics provide high lumen output. Six rotating replaceable gobos,
nine pure dichroic colors + white, strobe and dimming provide variety for
great light shows. Precision engineering and quality components make for
smooth movement and exact X/Y placement. Shiva-150R/200R/250R
scanner is value-engineered to beat all competition.
TM
TM
Unprecedented performance comes in this promising package --
the first die-cast aluminum scanner case made in Asia. Shiva-
TM
150R/200R/250R scanner has the form to entice and the functions to
captivate.
And with every model, Geni's user-oriented design lets you work at your
convenience. User aids, including focus assistance, self-test function, X/Y
direction control, and color/gobo change transition options, enhance
programming convenience and pleasure.

SHIVA Scanner Diagrams
TM
C
B1 - Service Dip Switches
B2 - Slide-out Lamp Holder
B3 - Middle Screw
B4 - Fuse Holder
B5 - IEC Power Socket
B6 - Lamp Holder Screws
B7 - Function Dip Switches
B8 - Canon DMX Signal Socket
(Signal Out)
B9 - DMX Dip Switches
B10 - Canon DMX Signal Socket
(Signal In)
B11 - Earth Ground
B10
B9
B8
B7
B6
B5
B4
B3
B2
B1
B11
TM
SHIVA Scanner Back Panel
B1 - Service Dip Switches
B2 - Slide-out Lamp Holder
B3 - Middle Screw
B4 - Fuse Holder
B5 - IEC Power Socket
B6 - Lamp Holder Screws
B7 - Function Dip Switches
B8 - Canon DMX Signal Socket
(Signal Out)
B9 - DMX Dip Switches
B10 - Canon DMX Signal Socket
(Signal In)
B11 - Earth Ground
2
SHIVA Scanner
AI - Bracket
A2 - Stepper Motor
A3 - Mirror
A4 - Lens
A5 -
A6 -
TM
Bracket Knob
Air Vents A6
A2
A1
A3
A4
A5
Gobo 10
Gobo 9
Gobo 8
Gobo 7
Gobo 6
Gobo 5
Gobo 4
Gobo 3
Gobo 2
Gobo 1
Note: Gobos 1-6 are standard in
TM
SHIVA-150R/200R/250R
scanners. Gobos 7-10 are also
available.
13
APPENDIX 3
SHIVA-150R/200R/250R Scanner Gobos
TM

TM
Every Shiva-150R/200R/250R scanner was thoroughly tested and
shipped in perfect condition. Carefully unpack your Shiva-
TM
150R/200R/250R scanner and remove the bag with components
from the carton. Inspect equipment for shipping damage. Contact
your Geni dealer immediately if damage has occurred or if
something is missing.
Packing list:
TM
Shiva-150R/200R/250R scanner
IEC power cord
Operating manual
Follow standard precautions for all electronic products.
!Warning!
This appliance must be earthed (grounded). Disconnect from
power before removing covers or servicing. Keep case closed while
operating.
Shiva-150R/200R/250R scanner contains no user serviceable parts.
Refer servicing to qualified technicians only.
Lamp and components become hot during operation. Allow time to
cool before handling.
Keep flammable material at least one meter away from unit. Do
not operate in wet conditions or near liquids.
Keep air vents clear to avoid overheating. Never insert objects into
air vents.
Lamp produces hazardous UV light. Do not look directly at lamp
when lit. Do not expose skin to uncovered lamp.
If objects fall on unit, disconnect mains power supply immediately.
Have a qualified technician inspect for safety before operating.
Never remove warning or informative labels from the unit.
TM
SECTION 1 - SETTING UP
Inspection
3
APPENDIX 2
DMX Channel Control Diagram
12
66ChannelChannel
TiltTilt
55ChannelChannel
PanPan
44ChannelChannel
RotationRotation
33ChannelChannel
GoboGobo
22ChannelChannel
ColorColor
11ChannelChannel
ShutterShutter
255
Fast
Slow
175
Indigo
144-174
Dark Blue
128-143
Red
112-127
Purple
96-111
Orange
80-95
Green
64-79
Light Blue
48-63
Yellow
32-47
Pink
16-31
White
0-15
255
Fast
Slow
175
Indigo
144-174
Dark Blue
128-143
Red
112-127
Purple
96-111
Orange
80-95
Green
64-79
Light Blue
48-63
Yellow
32-47
Pink
16-31
White
0-15
00
CloseClose
DimmerDimmer
159159
160160
1 fps1 fps
StrobeStrobe
7 fps7 fps
253253
254254
OpenOpen
255255
00
Gobo 1Gobo 1
4242
4343
GoboGobo
8585
8686
Gobo 3Gobo 3
127127
128128
Gobo 4Gobo 4
170170
171171
Gobo 5Gobo 5
213213
214214
Gobo 6Gobo 6
255255
00
RotationRotation
NoNo
77
88
RotationRotation
GoboGobo
wisewise
Clock-Clock-
131131
132132
Counter-Counter-
RotationRotation
GoboGobo
wisewise
clock-clock-
255255
00
Degrees:Degrees:
170170
Degrees:Degrees:
255255
9090
Degrees:Degrees:
255255
00
Degrees:Degrees:
22

APPENDIX 1
DMX Addressing Chart
ValueDMX 256128
4
6
32
61
8
4
2
1
98
7
654
3
2
1
SwitchDip
DMX512 Dip switches and values have the following relationship:
SHIVA
Unit 14
Unit 13
Unit 12
Unit 11
Unit 10
Unit 9
Unit 8
Unit 7
Unit 6
Unit 5
Unit 4
Unit 3
Unit 2
Unit 1
Address
79
73
67
61
55
49
43
37
31
25
19
13
7
19
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
9
8
76543
21
N
O
Dip Switches SHIVA Address Dip Switches
Unit 15
Unit 16
Unit 17
Unit 18
Unit 19
Unit 20
Unit 21
Unit 22
Unit 23
Unit 24
Unit 25
Unit 26
Unit 27
Unit 28
85
91
157
151
145
139
133
127
121
115
109
103
97
163
11
This means, for instance, that the first DMX dip switch has a DMX value of 1,
and the fifth DMX dip switch has a value of 16.
TM
TM
Since each Shiva-150R/200R/250R has 6 channels, starting
addresses would be set as follows: First scanner starting address
= 1; Second scanner starting address = 7, etc.
Use a ball-point pen or toothpick to set dip switch addresses
appropriately. See the guide DMX512 Basics for more
information. For convenience, Shiva-150R/200R/250R starting
addresses for 28 units and corresponding DMX dip switch settings
are listed below.
4
2. Remove lamp from packaging. Read
lampinstructions. Do not touch lamp bulb
with bare hands, as this could damage
the lamp. Grasp the lamp stem and
wear lint-free gloves.
1. Loosen two screws (B6) on the slide-out
lamp holder (B2). Don't loosen the middle
screw (B3). Pull the lamp holder (B2) out
as far as possible, about 10 cm.
Caution! Lamp and metal components get hot during operation. Always
disconnect power and allow unit to cool before opening the unit cover.
Lamp Installation
B11
B10
B9
B8
B7
B6
B5
B4
B3
B2
B1
For the sake of brevity, this manual refers to "Shiva-
TM TM
150R/200R/250R " scanner. Actually, "Shiva-150R/200R/250R "
TM
refers to the three scanners with similar functions: Shiva-200R
scanner uses HSD-200 lamp which has a 2000-hour lamp life.
TM
Shiva-250R scanner uses EHJ 64655 G6.35 24V/250W (50-hour)
TM
or EHJ 64657 G6.35 24V/250W (300-hour) lamp. Shiva-150R
uses PHILIPS CDM-SA/T 150W/942 . Always use the correct lamp
for your unit.
TM
3a. For Shiva-150R scanner: Note that the CDM-SA/T
150W/942 lamp stem has two pegs, one thicker than the other.
Match the pegs with the holes in the lamp socket. Insert the
pegs into the lamp socket.
TM
3b. For Shiva-200R scanner: Use HSD-200 lamp ,Same as
above procedure.
TM
3c. For Shiva-250R scanner: Use either EHJ 64655 G6.35
24V/250W (50-hour) or EHJ 64657 G6.35 24V/250W (300-
hour) lamp. Both of these lamps have two pegs of the same
size. Insert pegs into the lamp Socket.
4. Make sure the lamp is in straight. Push the lamp mechanism (B2)
straight back into place and fasten screws (B6) on the lamp
holder (B2). If you feel strong resistence when pushing the lamp

TM
Model: SHIVA-200R scanner
Dimensions: 670x300x180mm
Lamp: HSD-200 or MSD-200
Voltage: 230V~50Hz
Weight: 15 kgs
Power consumption: 300VA
Fuse: T5A/250V 20mm
Signal: USITT DMX512
Signal connection: 3-pin XLR
Signal termination: built-in (manual)
Addressing: Standard DMX512 9-pin binary
Channels: 6
Product Specifications
10
TM
Model: SHIVA-150R scanner
Dimensions: 670x300x180mm
Lamp: PHILIPS CDM-SA/T 150W/942
Voltage: 120V~60Hz
Weight: 15.4 kgs
Power consumption: 300VA
Fuse: T5A/250V 20mm
Signal: USITT DMX512
Signal connection: 3-pin XLR
Signal termination: built-in (manual)
Addressing: Standard DMX512 9-pin binary
Channels: 6
TM
Model: SHIVA-250R scanner
Dimensions: 670x300x180mm
Lamp: 24V/250W EHJ 64655 G6.35
or 24V/250W EHJ 64657 G6.35
Voltage: 230V~50Hz; 120V~50/60Hz
Weight: 15 kgs
Power consumption: 300VA
Fuse: T5A/250V 20mm
Signal: USITT DMX512
Signal connection: 3-pin XLR
Signal termination: built-in (manual)
Addressing: Standard DMX512 9-pin binary
Channels: 6
TM
Model: SHIVA-200R scanner
Dimensions: 670x300x180mm
Lamp: HSD-200 or MSD-200
Voltage: 120V~60Hz
Weight: 13 kgs
Power consumption: 500VA
Fuse: 7A/250V 20mm
Signal: USITT DMX512
Signal connection: 3-pin XLR
Signal termination: built-in (manual)
Addressing: Standard DMX512 9-pin binary
Channels: 6
5
3. Rotate lens to obtain a sharp focus.
2. The scanner shutter will open, pan and tilt will align to center, and a
small white spot will appear for easy focusing.
1. Set Function dip switch #7 to the "on" position.
6. The lamp will light (but may be covered by the shutter). You might hear the
color and gobo wheels reset and pause. New scanners sometimes smoke
and emit an odor briefly as paint and dust are burnt away.
7. external flexible cable or cord of this luminaire is damaged, it shall be
replaced by a special cord or cord exclusively available from the
manufacturer or his service agent.
5. Check that your power supply and the specified scanner voltage are the
same. Plug mains power cord into the IEC socket (B5) on the back of unit.
Plug the mains power cord into properly grounded power supply.
4. Avoid signal interference by flipping Function dip switch #8 to the "on"
position on the last scanner in a series of DMX units.
3. Set scanner DMX addresses by flipping the appropriate DMX dip switche s.
For more information, see Appendix 1,theDMX512 Address Chart a nd
the guide DMX512 Basics.
1. Use a 35-kg rated or stronger clamp to
secure the scanner bracket (A1) onto a firm
truss. Tilt unit as desired and tighten scanner
bracket knobs (A5). Allow at least onem eter
on all sides for proper cooling. Keep unit
away from liquids and flammable items.
Lastly, pass safety rope (A7) through bracket of
the unit, hitch the safety rope round the truss and
buckle it up.
Scanner Installation
Focusing the Lens
2. Link DMX512 signal cables to the DMX
sockets B8 and B10 on the back plate of the
scanner. "Daisy chain" the scanners as
illustrated in the guide DMX Basics. Always use
120 ohm shiel ded, 22 or 24 AWG, braided shield microphone cables and
three-pin canon XLR connectors.
high quality, twisted pair

SECTION 2 - OPERATION
Function settings are designed to make installation and programming
convenient and fast. Simply activate a Function dip switch to get the option
you want.
Please refer to Appendix 2,theDMX Channel Control Diagram, for a more
detailed explanation of effect positions.
When using a DMX controller, channels
correlate with scanner functions. So
when you move a slider on the color channel, for example, the colors will
TM
change. Shiva-150R/200R/250R scanner effect channels follow:
Channel Control Positions
DMX512 Control
Dimming
Strobe and
Shutter:
Channel 1 Channel 2
Colors
Channel 3
Gobos
Channel 4
Gobo
Rotation
Channel 5
Pan
Channel 6
Tilt
Function Settings
Function Dip Switch Diagram
#1 Off
Transitions between colors
and gobos are visible.
#1 On
Transitions between colors or gobos
are covered by the shutter.
#2 Off
Color wheel stops at any
position; Single colors or
adjacent two-color
combinations are possible.
#3 Off
Exterior control mode. For use
with any DMX controller.
6
5
43
21
N
O
7
6
5
43
21
N
O
88 6
5
43
21
N
O
7
6
5
43
21
N
O
88
6
5
43
21
N
O
7
6
5
43
21
N
O
88
6
5
43
21
N
O
7
6
5
43
21
N
O
88
6
5
43
21
N
O
7
6
5
43
21
N
O
88
6
5
43
21
N
O
7
6
5
43
21
N
O
88
Color wheel stops only at full color
positions. Only single colors are
possible.
Built-in slow motion program is activated.
#3 On
6
9
3. Disconnect DMX512 cable. Turn on Function dip switch #4,
activating the self-test function. If scanner operates properly, the DMX
signal cable or connector is likely at fault. Replace the DMX cable.
2. Check DMX512 dip switch settings. Make sure the unit is addressed
properly. Make sure that Function dip switches 1-5 and 7 are off.
5. If lamp is not discolored or cracked, reinsert it. Close the lamp holder,
tightening two screws (B6) securely. Connect power.
6. If lamp doesn't light, refer servicing to a qualified technician.
Problem: Lamp light is not visible but fan is turning.
Solution:
4. Disconnect power. Let unit cool. Check lamp. If lamp is cracked or
discolored, rather than clear, replace it. See Lamp Installation a n d L amp
Removal sections for details.
Trouble-shooting
The following trouble-shooting guide is provided to help product users solve
minor problems. Always refer servicing to a qualified technician.
Problem: Lamp is not lit and fan is not turning. (Fan can be seen through the
back panel.)
Solution:
1. Check electric mains for proper power connection. Check that the
power supply matches product power supply specifications.
2. Check the fuse. First, disconnect mains power supply. Use a flat-head
screwdriver to pry open the fuse holder casing (B4) near the IEC socket
(B5). If the fuse is discolored, rather than clear, replace it. A replacement
fuse is provided in the fuse holder (B4). Always use appropriate type of
fuse. (See Product Specifications.)
1. Adjust your DMX controller sliders to open the scanner shutter channel,
channel 1. Refer to Appendix 2 and controller instruction manual if
necessary.
Proper DMX512 addresses must be set on each scanner. Appendix 1
is a Chart of standard addressing for the six-channel Shiva-
TM
150R/200R/250R scanner. Refer to the guide DMX512 Basics for
more information.

3. Dispose lamps properly. Keep used lamps away from children and
animals.
2. With one hand on the lamp socket and the other on the stem of the lamp
bulb, pull the lamp stem away from the socket.
Lamp Removal
To remove lamps, follow the directions below. Always allow unit to cool
before changing lamps or opening the unit cover.
1. Loosen two screws (B6) on the slide-out lamp holder (B2). Do not loosen
the middle screw (B3). Pull the lamp holder (B2) out as far as possible,
about 10 cm.
Maintenance
8
Warning: Disconnect power and let unit cool before handling. Never open
unit cover when in use. Keep away from water and other liquids.
Lamps have special characteristics that should be observed to prolong
their use. Wait about ten minutes after disconnecting electric power to
TM
Shiva-150R/200R scanner before supplying power again. The CDM-
SA/T 150W/942 and HSD-200 lamp will not relight immediately after
being turned off. Wait about one minute after disconnecting power to
TM
Shiva-250R scanner before supplying power again. Even though
halogen lamps, like EHJ 64657 G6.35 24V/250W, restart quickly after
being extinguished, wait one minute to protect scanner electronics.
To maintain maximum brightness, clean the unit regularly with a damp
cloth or glass cleaner.
1. Wipe lens clean regularly.
2. Keep internal optical path free from dust or cobwebs.
3. Clean internal parts once a year with a brush and strong vacuum
#4 On
#5 Off
X-axis (pan) movements
progress from left to right.
X-axis (pan) movements progress from
right to left.
#5 On
#6 Off
Y-axis (tilt) movements progress
from low to high.
Y-axis (tilt) movements progress from
high to low.
#6 On
#7 Off
Exterior control mode. For use
with any DMX controller.
#7 On
Focus assistance is activated; a gobo
appears for easy focusing.
Function Dip Switch Diagram (Cont.)
6
5
43
21
N
O
7
6
5
43
21
N
O
86
5
43
21
N
O
7
6
5
43
21
N
O
8
6
5
43
21
N
O
7
6
5
43
21
N
O
8
6
5
43
21
N
O
7
6
5
43
21
N
O
8
6
5
43
21
N
O
7
6
5
43
21
N
O
8
6
5
43
21
N
O
7
6
5
43
21
N
O
8
6
5
43
21
N
O
7
6
5
43
21
N
O
8
6
5
43
21
N
O
7
6
5
43
21
N
O
8
6
5
43
21
N
O
7
6
5
43
21
N
O
8
6
5
43
21
N
O
7
6
5
43
21
N
O
8
#8 Off
Exterior control mode. For use
with any DMX controller.
#8 On
DMX512 signal termination; activate this
function dip switch on the last in a series
of DMX units to maintain a clear signal.
7
Service Dip Switches
For general use, do not activate Service dip switches.
TM
Note that Shiva-250R scanner does not have service dip switches.
Service dip switches are aids to technicians working on Shiva-150R/200R
scanner. They have two functions, both of which are explained below.
Service Dip Switch Diagram
Motor power supply is "off" while lamp is lit.
#1 On
Motor power supply is "on" while lamp is not lit.
#2 On 21
N
O
21
N
O
21
N
O
21
N
O
TM
#4 Off
Exterior control mode. For use
with any DMX controller.
Self-test function; scanner runs through
a pre-set pattern of actions.
