Genie Z-34/22IC User manual

Service Manual
(from serial number 3242 to 4799)
Refer to inside cover for additional serial number information
Part No. 128267
Rev A
July 2007

Z-34/22 IC Part No.128267
July 2007
ii
Introduction
Important
Read, understand and obey the safety rules and
operating instructions in the appropriate
Genie Z-34/22 IC Operator’s Manual before
attempting any maintenance or repair procedure.
This manual provides detailed scheduled
maintenance information for the machine owner
and user. It also provides repair procedures for
qualified service professionals.
Basic mechanical, hydraulic and electrical
skills are required to perform most procedures.
However, several procedures require specialized
skills, tools, lifting equipment and a suitable
workshop. In these instances, we strongly
recommend that maintenance and repair be
performed at an authorized Genie dealer
service center.
Technical Publications
Genie Industries has endeavored to deliver the
highest degree of accuracy possible. However,
continuous improvement of our products is a Genie
policy. Therefore product specifications are subject
to change without notice.
Readers are encouraged to notify Genie of errors
and send in suggestions for improvement. All
communications will be carefully considered for
future printings of this and other manuals.
Contact Us:
http://www.genieindustries.com
e-mail:[email protected]
Copyright © 1997 by Genie Industries
128267 Rev A July 2007
Third Edition, First Printing
"Genie" and "Z" are registered trademarks of
Genie Industries in the USA and many other
countries.
Printed on recycled paper
Printed in U.S.A.
Serial Number Information
Genie Industries offers the following Service
Manual for this models:
Title Part No.
Z-34/22 IC Service Manual, First Edition
(from serial number 101 to 1186) ......................... 43037
Z-34/22 IC Service Manual, Second Edition
(from serial number 1187 to 3241).....................119987
Z-34/22 IC Service Manual, Fourth Edition
(from serial number 4800)..................................128300
Introduction

Part No.128267 Z-34/22 IC
July 2007
INTRODUCTION
Serial Number Legend
Z3422 07 - 12345
Model
Model year
Sequence
number
PN - 77055
Country of manufacture: USA
This machine complies with:
Genie Industries
18340 NE 76th Street
Redmond, WA 98052
USA
ANSI A92.5
CAN B.354.4
Model: Z-34/22
Serial number: Z342207-12345
Electrical schematic number: ESXXXX
Machine unladen weight:
Rated work load (including occupants): XX kg
Maximum allowable inclination of the chassis:
0 deg
Gradeability: N/A
Maximum allowable side force : XX N
Maximum number of platfrm occupants: XX
Model year: Manufacture date: 02/01/07
2007
Maximum wind speed : XX m/s
Maximum platform height : XX m
Maximum platform reach : XX m
Serial number
stamped on chassis
Serial label
(located under cover)
iii

Z-34/22 IC Part No.128267
July 2007
This page intentionally left blank.
iv

Part No.128267 Z-34/22 IC
July 2007
v
Danger
Failure to obey the instructions and safety rules
in this manual and the appropriate
Genie Z-34/22 IC Operator’s Manual will result in
death or serious injury.
Many of the hazards identified in the
operator’s manual are also safety hazards
when maintenance and repair procedures
are performed.
Do Not Perform Maintenance
Unless:
You are trained and qualified to perform
maintenance on this machine.
You read, understand and obey:
- manufacturer’s instructions and safety rules
- employer’s safety rules and worksite
regulations
- applicable governmental regulations
You have the appropriate tools, lifting
equipment and a suitable workshop.
Safety Rules
Section 1 • Safety Rules

Z-34/22 IC Part No.128267
July 2007
SAFETY RULES
vi
Section 1 • Safety Rules
Personal Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Read each procedure thoroughly. This
manual and the decals on the machine,
use signal words to identify the following:
Safety alert symbol—used to alert
personnel to potential personal
injury hazards. Obey all safety
messages that follow this symbol
to avoid possible injury or death.
Indicates an imminently hazardous
situation which, if not avoided, will
result in death or serious injury.
Indicates a potentially hazardous
situation which, if not avoided,
could result in death or serious
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may cause minor or moderate
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may result in property damage.
Be sure to wear protective eye wear and
other protective clothing if the situation
warrants it.
Be aware of potential crushing hazards
such as moving parts, free swinging or
unsecured components when lifting or
placing loads. Always wear approved steel-toed
shoes.
Workplace Safety
Be sure to keep sparks, flames and
lighted tobacco away from flammable and
combustible materials like battery gases
and engine fuels. Always have an approved fire
extinguisher within easy reach.
Be sure that all tools and working areas
are properly maintained and ready for
use. Keep work surfaces clean and free of
debris that could get into machine components and
cause damage.
Be sure any forklift, overhead crane or
other lifting or supporting device is fully
capable of supporting and stabilizing the
weight to be lifted. Use only chains or straps that
are in good condition and of ample capacity.
Be sure that fasteners intended for one
time use (i.e., cotter pins and self-locking
nuts) are not reused. These components
may fail if they are used a second time.
Be sure to properly dispose of old oil or
other fluids. Use an approved container.
Please be environmentally safe.
Be sure that your workshop or work area
is properly ventilated and well lit.

Part No.128267 Z-34/22 IC
July 2007
Table of Contents
vii
Introduction
ImportantInformation................................................................................................... ii
SerialNumberInformation............................................................................................ ii
SerialNumberLegend................................................................................................. iii
Section1 SafetyRules
GeneralSafetyRules.................................................................................................. v
Section2 Rev Specifications
A MachineSpecifications.......................................................................................... 2 - 1
PerformanceSpecifications ................................................................................... 2 - 2
Hydraulic Oil Specifications ................................................................................... 2 - 3
HydraulicComponentSpecifications...................................................................... 2 - 4
ManifoldComponentSpecifications ....................................................................... 2 - 5
MachineTorqueSpecifications .............................................................................. 2 - 5
KubotaD-905EngineSpecifications ...................................................................... 2 - 6
KubotaDF-752EngineSpecifications .................................................................... 2 - 7
Perkins403C-11EngineSpecifications ................................................................. 2 - 8
HydraulicHose and FittingTorque Specifications .................................................. 2 - 9
SAEand Metric FastenerTorqueCharts.............................................................. 2 - 10

Z-34/22 IC Part No.128267
July 2007
TABLE OF CONTENTS
viii
Section3 Rev ScheduledMaintenanceProcedures
Introduction............................................................................................................ 3 - 1
Pre-DeliveryPreparation ........................................................................................ 3 - 3
MaintenanceInspectionReport.............................................................................. 3 - 5
AChecklistAProcedures
A-1 Inspect the Manuals and Decals .................................................................. 3 - 7
A-2 PerformPre-operationInspection ................................................................. 3 - 8
A-3 Perform Function Tests................................................................................ 3 - 8
A-4 PerformEngineMaintenance ....................................................................... 3 - 9
A-5 Perform 30 Day Service ............................................................................... 3 - 9
A-6 Inspect the Engine Air Filter ....................................................................... 3 - 10
A-7 PerformEngineMaintenance-KubotaModels........................................... 3 - 11
A-8 PerformEngineMaintenance-KubotaModels........................................... 3 - 11
A-9 PerformEngineMaintenance-KubotaModels........................................... 3 - 12
A-10 GreasetheTurntableRotationBearingandWormDriveGear .................... 3 - 12
A-11 PerformEngineMaintenance-KubotaModels........................................... 3 - 13
A-12 DraintheFuelFilter/WaterSeparator-DieselModels ................................ 3 - 14
AChecklistBProcedures
B-1 ChecktheEngine Choke -Gasoline/LPGModels....................................... 3 - 16
B-2 Check the Exhaust System ....................................................................... 3 - 17
B-3 Inspect the Battery..................................................................................... 3 - 17
B-4 Inspect the Electrical Wiring....................................................................... 3 - 19
B-5 Inspect the Tires, Wheels and Lug Nut Torque........................................... 3 - 19
B-6 ConfirmtheProperBrakeConfiguration...................................................... 3 - 20
B-7 Check the Oil Level in the Drive Hubs ........................................................ 3 - 20
B-8 PerformEngineMaintenance-Perkins403C-11Models ............................ 3 - 21
B-9 Check and Adjust the Engine RPM ............................................................ 3 - 21
B-10 TesttheGroundControlOverride ............................................................... 3 - 23
B-11 Test the Platform Self-leveling ................................................................... 3 - 24

Part No.128267 Z-34/22 IC
July 2007
TABLE OF CONTENTS
ix
Section3 Rev ScheduledMaintenanceProcedures,continued
B-12 Test the Engine Idle Select ........................................................................ 3 - 24
B-13 Test the Fuel Select Operation - Gasoline/LPG Models ............................. 3 - 25
B-14 Test the Drive Brakes ................................................................................ 3 - 26
B-15 Test the Drive Speed - Stowed Position ..................................................... 3 - 27
B-16 Test the Drive Speed - Raised or Extended Position .................................. 3 - 28
B-17 Inspect the Fuel and Hydraulic Tank Cap Venting Systems ....................... 3 - 29
B-18 Perform Hydraulic Oil Analysis................................................................... 3 - 30
B-19 Test the Alarm Package (if equipped) ........................................................ 3 - 30
B-20 ReplacetheDieselFuelFilter/WaterSeparatorElement -
DieselModels ............................................................................................ 3 - 31
B-21 PerformEngineMaintenance-KubotaD905Models.................................. 3 - 33
AChecklistCProcedures
C-1 GreasethePlatformOverloadMechanism(ifequipped) ............................. 3 - 34
C-2 Test the Platform Overload System (if equipped) ....................................... 3 - 34
C-3 Clean the Fuel Tank - Diesel Models.......................................................... 3 - 37
C-4 PerformEngineMaintenance-DieselModels ............................................ 3 - 38
C-5 PerformEngineMaintenance-KubotaD905Models.................................. 3 - 38
AChecklistDProcedures
D-1 Check the Primary Boom Wear Pads ......................................................... 3 - 39
D-2 ChecktheFree-wheelConfiguration ........................................................... 3 - 39
D-3 ReplacetheDrive HubOil .......................................................................... 3 - 40
D-4 Replacethe HydraulicFilters...................................................................... 3 - 41
D-5 Checkthe TurntableRotationBearingBolts ............................................... 3 - 42
D-6 InspectforTurntableBearingWear ............................................................ 3 - 43
D-7 PerformEngineMaintenance ..................................................................... 3 - 44
AChecklistEProcedures
E-1 Test or Replace the Hydraulic Oil ............................................................... 3 - 45
E-2 GreasetheSteerAxle Wheel Bearings,2WDModels ................................ 3 - 46
E-3 PerformEngineMaintenance ..................................................................... 3 - 48
E-4 PerformEngineMaintenance-Perkins403C-11Models ............................ 3 - 48

Z-34/22 IC Part No.128267
July 2007
TABLE OF CONTENTS
x
Section4 Rev RepairProcedures
Introduction............................................................................................................ 4 - 1
APlatformControls
1-1 Drive Joystick .............................................................................................. 4 - 2
1-2 BoomFunctionSpeedController .................................................................. 4 - 5
APlatformComponents
2-1 PlatformLevelingSlaveCylinder.................................................................. 4 - 6
2-2 PlatformRotator ........................................................................................... 4 - 7
2-3 PlatformOverloadSystem(if equipped) ....................................................... 4 - 9
AJibBoomComponents
3-1 Jib Boom.................................................................................................... 4 - 11
3-2 Jib Boom Bell Crank .................................................................................. 4 - 12
3-3 Jib Boom Lift Cylinder ................................................................................ 4 - 12
APrimaryBoomComponents
4-1 Plastic Cable Track.................................................................................... 4 - 14
4-2 PrimaryBoom ............................................................................................ 4 - 14
4-3 Primary Boom Lift Cylinder......................................................................... 4 - 18
4-4 ExtensionCylinder ..................................................................................... 4 - 19
4-5 PlatformLevelingMasterCylinder.............................................................. 4 - 21
ASecondaryBoomComponents
5-1 SecondaryBoom........................................................................................ 4 - 25
5-2 SecondaryBoomLift Cylinder .................................................................... 4 - 29
AKubotaD-905Engine
6-1 TimingAdjustment ..................................................................................... 4 - 30
6-2 GlowPlugs................................................................................................. 4 - 30
6-3 RPM Adjustment........................................................................................ 4 - 30
6-4 Flex Plate................................................................................................... 4 - 30
6-5 CoolantTemperatureandOilPressureSwitches........................................ 4 - 31

Part No.128267 Z-34/22 IC
July 2007
TABLE OF CONTENTS
Section4 Rev RepairProcedures,continued
AKubotaDF-752Engine
7-1 ChokeAdjustments.................................................................................... 4 - 32
7-2 TimingAdjustment ..................................................................................... 4 - 32
7-3 CarburetorAdjustment................................................................................ 4 - 32
7-4 RPM Adjustment........................................................................................ 4 - 32
7-5 Flex Plate................................................................................................... 4 - 32
7-6 CoolantTemperatureandOilPressureSwitches........................................ 4 - 33
APerkins403C-11Engine
8-1 TimingAdjustment ..................................................................................... 4 - 34
8-2 RPM Adjustment........................................................................................ 4 - 34
8-3 Flex Plate................................................................................................... 4 - 34
8-4 CoolantTemperatureandOilPressureSwitches........................................ 4 - 35
AHydraulicPumps
9-1 Auxiliary Pump........................................................................................... 4 - 36
9-2 FunctionPump........................................................................................... 4 - 37
9-3 DrivePump ................................................................................................ 4 - 38
AManifolds
10-1 FunctionManifoldComponents .................................................................. 4 - 40
10-2 Valve Adjustments - Function Manifold ...................................................... 4 - 44
10-3 Jib Boom / Platform Rotate Manifold Components ..................................... 4 - 45
10-4 Brake/2-speedManifoldComponents,2WDModels ................................. 4 - 46
10-5 2WDTractionManifoldComponents .......................................................... 4 - 47
10-6 4WDTractionManifoldComponents .......................................................... 4 - 48
10-7 Valve Adjustments - Traction Manifold ....................................................... 4 - 50
10-8 Valve Coils................................................................................................. 4 - 51
xi

Z-34/22 IC Part No.128267
July 2007
TABLE OF CONTENTS
xii
Section4 Rev RepairProcedures,continued
AFueland Hydraulic Tanks
11-1 FuelTank................................................................................................... 4 - 53
11-2 HydraulicTank ........................................................................................... 4 - 54
ATurntableRotationComponents
12-1 RotationHydraulicMotor ............................................................................ 4 - 55
AAxleComponents
13-1 HubandBearings,2WDModels................................................................. 4 - 56
Section5 Rev Schematics
Introduction............................................................................................................ 5 - 1
A ElectricalSymbols Legend .................................................................................... 5 - 2
A HydraulicSymbolsLegend .................................................................................... 5 - 3
A Electrical Schematic - Diesel Models
(fromserialnumber3242to3577).......................................................................... 5 - 5
A Electrical Schematic - Diesel Models
(fromserialnumber3578to4799).......................................................................... 5 - 7
A Electrical Schematic - Gasoline/LPG Models
(fromserialnumber3242to3577).......................................................................... 5 - 9
A Electrical Schematic - Gasoline/LPG Models
(fromserialnumber3578to4799)........................................................................ 5 - 11

Part No.128267 Z-34/22 IC
July 2007
TABLE OF CONTENTS
xiii
Section5 Rev Schematics,continued
A GroundControlBoxWiringDiagram-DieselModels
(fromserialnumber3242to3308)........................................................................ 5 - 17
A GroundControlBoxWiringDiagram-DieselModels
(fromserialnumber3309to3577)........................................................................ 5 - 18
A GroundControlBoxWiringDiagram-DieselModels
(fromserialnumber3578to4799)........................................................................ 5 - 19
A GroundControlBoxWiringDiagram-Gasoline/LPGModels
(fromserialnumber3242to3308)........................................................................ 5 - 20
A GroundControlBoxWiringDiagram-Gasoline/LPGModels
(fromserialnumber3309to3577)........................................................................ 5 - 21
A GroundControlBoxWiringDiagram-Gasoline/LPGModels
(fromserialnumber3578to4799)........................................................................ 5 - 22
A PlatformControl BoxWiringDiagram -DieselModels
(fromserialnumber3242to3577)........................................................................ 5 - 23
A PlatformControl BoxWiringDiagram -DieselModels
(fromserialnumber3578to4799)........................................................................ 5 - 24
A PlatformControlBoxWiringDiagram-Gasoline/LPG Models
(fromserialnumber3242to3577)........................................................................ 5 - 25
A PlatformControlBoxWiringDiagram-Gasoline/LPG Models
(fromserialnumber3578to4799)........................................................................ 5 - 26
A GeneratorOptionWiringDiagram(fromserialnumber3242to4081).................... 5 - 27
A GeneratorOptionWiringDiagram(fromserialnumber4082to4799).................... 5 - 28
A LoadSenseOptionWiringDiagram(fromserialnumber3242to3577) ................ 5 - 29
A Manifold and Limit Switch Wiring ......................................................................... 5 - 30
A Hydraulic Schematic, 2WDModels ...................................................................... 5 - 31
A Hydraulic Schematic, 4WDModels ...................................................................... 5 - 33

Z-34/22 IC Part No.128267
July 2007
This page intentionally left blank.
xvi

Part No.128267 Z-34/22 IC 2 - 1
Section 2 • SpecificationsJuly 2007
REV A Specifications
Machine Specifications
Tires and wheels Rough terrain Industrial
Tire size 10-16.5 NHS 9-14.5 LT
Tire ply rating Tread 6
Sidewall 6
Overall tire diameter 30.5 in 28 in
77.5 cm 71.1 cm
Wheel diameter 16.5 in 14.5 in
42 cm 36.8 cm
Wheel width 10 in 7 in
25.4 cm 18 cm
Wheel lugs, 4WD 9 @ 5/8-18
Wheel lugs, 2WD
Front 8 @ 5/8-18 8 @ 5/8-18
Rear 9 @ 5/8-18 9 @ 5/8-18
Tire pressure 45 psi 100 psi
3.1 bar 6.89 bar
Lug nut torque 125 ft-lbs 125 ft-lbs
(lubricated) 170 Nm 170 Nm
For operational specifications, refer to the
Operator's Manual.
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice.
Fluidcapacities
Fuel tank capacity 9.3 gallons
35.2 liters
Hydraulic tank capacity 18 gallons
68.1 liters
Hydraulic system capacity 22 gallons
(including tank) 83.3 liters
Drive hubs 17 fl oz
0.5 liter
Drive hub oil type: EP 80-90W gear oil
API service classification GL5

2 - 2 Z-34/22 IC Part No.128267
Section 2 • Specifications July 2007
REV A
Performance Specifications
Drive speeds, maximum (before serial number 3578)
2WD 4WD
Boom stowed, high range 4.5 mph 4.0 mph
7.2 km/h 6.4 km/h
40 ft/6.1 sec 40 ft/6.8 sec
12.2 m/6.1 sec 12.2 m/6.8 sec
Boom raised or extended 0.6 mph 0.6 mph
1km/h 1km/h
40 ft/40 sec 40 ft/40 sec
12.2 m/40 sec 12.2 m/40 sec
Drive speeds, maximum (after serial number 3577)
2WD 4WD
Boom stowed, high range 4.0 mph 3.5 mph
6.4 km/h 5.6 km/h
40 ft/6.8 sec 40 ft/7.8 sec
12.2 m/6.8 sec 12.2 m/7.8 sec
Boom raised or extended 0.6 mph 0.6 mph
1km/h 1km/h
40 ft/40 sec 40 ft/40 sec
12.2 m/40 sec 12.2 m/40 sec
Braking distance, maximum 3 to 4 ft
on paved surface 0.9 to 1.2 m
Gradeability See Operator's Manual
SPECIFICATIONS
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice.
Boom function speeds, maximum
from platform controls (with rated load in platform)
Jib boom up 24 to 30 seconds
Jib boom down 15 to 21 seconds
Primary boom up 15 to 21 seconds
Primary boom down 13 to 19 seconds
Primary boom extend 24 to 30 seconds
Primary boom retract 14 to 20 seconds
Secondary boom up 15 to 21 seconds
Secondary boom down 11 to 17 seconds
Turntable rotate, 355° 62 to 68 seconds
Platform rotate, 160° 4 to 7 seconds

Part No.128267 Z-34/22 IC 2 - 3
Section 2 • SpecificationsJuly 2007
REV A
Hydraulic Oil Specifications
Hydraulic Oil Specifications
Before serial number 3335
Hydraulic oil type Shell Donax TG (Dexron III)
After serial number 3334
Hydraulic oil type Chevron Rykon MV equivalent
Viscosity grade Multi-viscosity
Viscosity index 200
Cleanliness level, minimum 15/13
Water content, maximum 200 ppm
Chevron Rykon MV oil is fully compatible and
mixable with Shell Donax TG (Dexron III) oils.
Genie specifications require hydraulic oils which are
designed to give maximum protection to hydraulic
systems, have the ability to perform over a wide
temperature range, and the viscosity index should
exceed 140. They should provide excellent antiwear,
oxidation, corrosion inhibition, seal conditioning, and
foam and aeration suppression properties.
Optional fluids
Biodegradable Petro Canada Environ MV46
Statoil Hydra Way Bio Pa 32
BP Biohyd SE-S
Fire resistant UCON Hydrolube HP-5046
Quintolubric 822
Mineral based Shell Tellus T32
Shell Tellus T46
Chevron Aviation A
Continued use of Chevron
Aviation A hydraulic fluid when
ambient temperatures are
consistently above 32°F / 0°C may
result in component damage.
Note: Use Chevron Aviation A hydraulic fluid when
ambient temperatures are consistently below
0°F / -18°C.
Note: Use Shell Tellus T46 hydraulic oil when oil
temperatures consistently exceed 205°F / 96°C.
Note: Genie specifications require additional
equipment and special installation instructions for
the approved optional fluids. Consult the Genie
Industries Service Department before use.
SPECIFICATIONS

2 - 4 Z-34/22 IC Part No.128267
Section 2 • Specifications July 2007
REV A
Hydraulic Component
Specifications
Drive pump
Type: bi-directional variable
displacement piston pump
Displacement 1.71 cu in
per revolution 28 cc
Flow rate @ 3000rpm 22 gpm
84 L/min
Function pump
Type: Fixed displacement gear pump
Displacement 0.24 cu in
per revolution 4 cc
Flow rate @ 3000rpm 3 gpm
11.4 L/min
Auxiliary pump
Type: Fixed displacement gear pump
Displacement 0.5 gpm
1.9 L/min
Auxiliary pump 3400 psi
relief pressure 234.5 bar
Front drive motors, 4WD models
Displacement per revolution 1.83 cu in
(before serial number 3734) 30 cc
Displacement per revolution 1.53 cu in
(after serial number 3733) 25 cc
Rear drive motors, all models
Displacement per revolution 1.83 cu in
(before serial number 3734) 30 cc
Displacement per revolution 1.53 cu in
(after serial number 3733) 25 cc
SPECIFICATIONS
Function manifold
System relief 3200 psi
valve pressure 220.7 bar
Primary boom down relief 1600 psi
valve pressure 110 bar
Secondary boom down relief 1600 psi
valve pressure 110 bar
Tractionmanifold
Hot oil shuttle relief pressure
2WD models 170 psi
11.7 bar
4WD models 150 psi
10.3 bar
Hydraulic filters
Hydraulic tank Beta 10 ≥200
return line filter with 25 psi / 1.7 bar bypass
Medium pressure filter Beta 3 ≥200
Medium pressure filter 50 psi
bypass pressure 3.45 bar
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice.

Part No.128267 Z-34/22 IC 2 - 5
Section 2 • SpecificationsJuly 2007
REV A
Manifold Component
Specifications
Plug torque
SAE No. 2 36 in-lbs / 4 Nm
SAE No. 4 10 ft-lbs / 13 Nm
SAE No. 6 14 ft-lbs / 19 Nm
SAE No. 8 38 ft-lbs / 51 Nm
SAE No. 10 41 ft-lbs / 55 Nm
SAE No. 12 56 ft-lbs / 76 Nm
Valve Coil Resistance
Note: The following coil resistance specifications are at
an ambient temperature of 68°F / 20°C. As valve coil
resistance is sensitive to changes in air temperature,
the coil resistance will typically increase or decrease by
4% for each 18°F / 20°C that your air temperature
increases or decreases from 68°F / 20°C.
Valve coil specifications
2 position 3 way solenoid valve, 10V DC 6Ω
(schematic items L, M, N, O, P, Q, R, S, T, U,
AA, AB, BA and BB)
3 position 4 way solenoid valve, 10V DC 6Ω
(schematic item E, CH, CI)
Proportional solenoid valve, 12V DC 5Ω
(schematic item D)
SPECIFICATIONS
Machine Torque Specifications
Platform rotator
3/4-10 center bolt, GR 8 (dry) 380 ft-lbs
515 Nm
3/4-10 center bolt, GR 8 (lubricated) 280 ft-lbs
379 Nm
3/8-16 bolts, GR 8 (dry) 44 ft-lbs
60 Nm
3/8-16 bolts, GR 8 (lubricated) 33 ft-lbs
45 Nm
Turntable rotate assembly
Rotate bearing mounting bolts, lubricated 180 ft-lbs
244 Nm
Rotate bearing motor 93 ft-lbs
mounting bolts, lubricated 126 Nm
Drive motor and hubs
Drive hub mounting bolts, lubricated 180 ft-lbs
244 Nm
Drive motor mounting bolts, lubricated
3/8-16, GR 5 23 ft-lbs
31 Nm
7/16 -14, GR 5 37 ft-lbs
50 Nm
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice.

2 - 6 Z-34/22 IC Part No.128267
Section 2 • Specifications July 2007
REV ASPECIFICATIONS
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice.
Kubota D-905 Engine
Displacement 54.86 cu in
0.90 liters
Number of cylinders 3
Bore and stroke 2.83 x 2.90 inches
72 x 73.6 mm
Horsepower, gross intermittent 26 @ 3600 rpm
19.3kW
Firingorder 1 - 2 - 3
Compression ratio 23:1
Compression pressure 412 to 469 psi
28.4 to 32.3 bar
Lowidle 1300 rpm
Frequency 260 hz
Highidle 3000 rpm
Frequency 600 hz
Governor centrifugal mechanical
Valve clearance, cold 0.0057 to 0.0072 in
0.145 to 0.183 mm
Enginecoolant
Capacity 3.3 quarts
3.1 liters
Lubrication system
Oil pressure 36 to 64 psi
2.48 to 4.41 bar
Oil capacity 5.4 quarts
(including filter) 5.1 liters
Oil viscosity requirements
Units ship with 15W-40.
Extreme operating temperatures may require the use of
alternative engine oils. For oil requirements, refer to the
Engine Operator Handbook on your machine.
Injection system
Injection pump make Bocsh MD
Injection timing 13° to 25° BTDC
Injection pump pressure 1991 psi
137 bar
Fuel requirement
For fuel requirements, refer to the engine Operator's
Manual on your machine.
Battery
Type 12V DC
Group 34/78
Quantity 1
Ampere hour 75AH
Cold cranking ampere 900A
Reserve capacity @ 25A rate 125 minutes
Alternator
Output 30A, 14V DC
Fan belt deflection 1/4to 3/8 inch
7 to 9 mm
