Genmitsu PROVerXL 4030 V2 User manual

PROVerXL4030V2CNCルーターキット
V1.1 Jun 2023
USER MANUAL
Genmitsu
PROVerXL 4030 V2 CNC Router Kit
PROVerXL 4030 V2 CNC Fräs-/Graviermaschine
English
日本語
01 - 31
Deutsch
65 - 95
33 - 63
BENUTZERHANDBUCH
取
扱
説
明
書

Contents
Welcome
Disclaimer
Specifications
Unboxing
Dimesion
Mechanical Installation
Adjusting Lead Screw
Maintenance
Wiring
Software Setup
Test Project
Z Probe Setup
01
02
03
04
07
08
17
19
20
24
27
29

01
Welcome
Thank you for purchasing the Genmitsu PROVerXL 4030 V2 CNC Router Kit from SainSmart.
All your setup materials will be located on the included USB Drive, located in your accessories box. Inside you will find:
● PDF version of this manual
● Windows USB Driver
● GrbIControl/Candle software for Windows
● Sample files
Please visit SainSmart Online Resource Center installing drivers and software for your CNC.
https://docs.sainsmart.com/article/bhhdcyg7hk-prover-xl-4030-v2
Scan QR code to find information.
The drivers and software can also be found on the included USB drive.
For technical support, please email us at [email protected].
Help and support is also available from our Facebook group. (SainSmart Genmitsu CNC Users Group)
Scan QR code to join the group.
Scan To Join
User Community
Scan To Find
CNC Resource

02
Disclaimer
Please be careful when using your CNC machine. This machine is an electrical device with moving parts and dangerous working
areas.
Genmitsu CNC Machines are for Indoor Use Only.
You must be 18 years or older to operate this machine, unless supervised by a knowledgeable adult familiar with the machine.
Wear proper Personal Protection Equipment (Safety Glasses etc.).
Always place the CNC Machine on a stable surface.
The 4030 V2 utilizes a high amp power supply. It is recommended that you do not plug the CNC Router into an extension cord,
or power strip as it may damage the machine.
Ensure the Emergency Stop Button is easily accessible at all times.
Never disassemble the Power Supply or Electrical Components. This will VOID the warranty.
DO NOT TOUCH the machine spindle, or place any body part near the working area when the machine is operating. Serious
injury may occur.
DO NOT leave children unsupervised with the CNC Machine even when it's not operating. Injury may occur.
DO NOT leave the machine unattended while it's operating.
Ensure your CNC Machine is in a well-ventilated area. Some Materials may discharge smoke or fumes during operation.

Specifications
03
Model Name
Work Area
Overall Dimensions
Control Board Compatibility
MCU
Max Speed
CAM Software
Body Material
Running Accuracy
Repositioning Accuracy
Stepper Driver
X, Y ,Z Axis Motor
Spindle Power
Spindle Voltage
Power Supply
Torque
X&Y Axis Transmission
Z Axis Transmission
PROVerXL 4030 V2
400 x 300 x 110mm (15.75" x 11.81" x 4.33")
740 x 605 x 488mm (29.13" x 23.82" x 19.21")
GRBL 1.1h
8-Bit
5000mm/min
Software Based on GRBL Firmware, e.g. Candle, UGS
Metal Frame & Hybrid Spoilboard
Circular: ≤ ±0.05mm; Rectangle: ≤ ±0.02mm
≤ ±0.05mm
WSD6056DN56
NEMA 23, 76mm, Closed-loop Stepper Motor
MAX 400W 10000RPM
DC, 0-48V Adjustable
48V 7A & 24V 8A
2.2N・m
1204 Ball Screw
12mm Linear Shaft & 1204 Ball Screw

Unboxing
04
01 XY Axis Base Module 02 X-axis Module 03 XZ Axis Module
(with spindle installed)
04 Coupler 05 X-axis Motor 06 Y-axis Drag Chain
Bracket A
07 Y-axis Drag Chain
Bracket B 08 Y-axis Drag Chain 09 X-axis Drag Chain Bracket A

Unboxing
05
10 X-axis Drag Chain
Bracket B 11 X-axis Drag Chain 12 Slot Drill
13 Flat Engraving 14 Grass Fuse Tube 15 USB A-to-B Cable
16 USB Drive 17 (4) Clamp Kit 18 Z-Probe Kit

Unboxing
06
19 Power Cord 20
Wrench
(1) 14-17
(1) 13-15
21
Allen Wrench
2mm, 2.5mm,
3mm, 4mm,
22 Wrench
26 (4) 5mm
Flat Washer
23 Hexagonal Driver
for Lead Screw 24 Flat Head Cap Screw (9) M5×14, (9) M4×6 25
Socket Head Cap Screw
(5) M4×6, (5) M4×12
(5) M5×12, (5) M5×16
27 (4) 5mm Spring Washer 28 65mm Spindle Mount 29 User Manual

740mm
605mm
488mm
Dimension
07

08
Mechanical Installation
STEP 1 Confirm Y-axis roller module position
What you need:
Measure the distance between the Y-axis roller module and the fixed plate at the motor end on both sides, as shown in the figure
Y1 and Y2. Adjust the ball screw with the hexagonal driver to ensure that the length of Y1 is equal to Y2.
23 Hexagonal Driver for Lead Screw 01 XY Axis Base Module
Y1 Y2

09
Mechanical Installation
STEP 2 Installing X-axis Module
What you need:
Remove the XY axis base module and the X-axis module, mount the X-axis module on the XY axis base module with (4) screws
both left and right.
01 XY Axis Base Module 02 X-axis Module 24 (8) M5×14
Flat Head Cap Screw
XY Axis Base Module
X-axis Module
(4) M5×14
Flat Head Cap Screw
1
2
21

10
Mechanical Installation
STEP 3 Installing XZ Axis Module
What you need:
Mount the XZ axis module onto the X-axis Module as shown below with (4) screws, flat washers followed by spring washers.
03 XZ Axis Module
(with spindle installed) 25 (4) M5×16
Socket Head Cap Screw 26 (4) 5mm
Flat Washer 27 (4) 5mm Spring Washer
1
2
(4) Spring Washer
(4) Flat Washer
XZ Axis Module
(4) M5×16 Socket Head Cap Screw
(with flat washer and spring washer)

11
Mechanical Installation
STEP 4 Installing Lead Screw Coupler and X-axis Motor
What you need:
1. Insert the X-axis coupler onto the lead screw, and then insert the X-axis motor into the coupling.
2. Tighten the (4) socket head cap screws, then tighten (2) coupler grub screws to secure the leadscrew and motor shaft.
04 Coupler 05 X-axis Motor
25 (4) M4×12 Socket Head Cap Screw
Coupler X-axis Motor
Screw of Coupler
(4) M4×12
Socket Head Cap Screw

12
Mechanical Installation
STEP 5 Installing Y-axis Drag Chain Brackets
What you need:
1. Install Y-axis drag chain bracket A with (2) M5×12 socket head cap screws.
2. Install Y-axis drag chain bracket B with (2) M4×6 socket head cap screws.
06 Y-axis Drag Chain
Bracket A 07 Y-axis Drag Chain
Bracket B 25 Socket Head Cap Screw (2) M4×6, (2) M5×12
Y-axis Drag Chain Bracket A Y-axis Drag Chain Bracket B
M4×6 Socket Head Cap Screw
(2) M5×12 Socket Head Cap Screw

13
Mechanical Installation
STEP 6 Installing Y-axis Drag Chain
What you need:
Attach the Y-axis drag chain to the Y-axis drag chain brackets and secure with (2) flat head cap screws.
08 Y-axis Drag Chain 24 (4) M4×6 Flat Head Cap Screw
(4) M4×6 Flat Head Cap Screw
Y-axis Drag Chain

Mechanical Installation
14
STEP 7 Installing X-axis Drag Chain Bracket
What you need:
1. Install X-axis drag chain bracket A with (2) M5×12 socket head cap screws.
2. Install X-axis drag chain bracket B with (2) M4×6 socket head cap screws.
09 X-axis Drag Chain
Bracket A 10 X-axis Drag Chain
Bracket B
(2) M4×6
Socket Head Cap Screw
(2) M5×12
Socket Head Cap Screw
X-axis Drag Chain bracket B
25 Socket Head Cap Screw
(2) M4×6, (2) M5×12
X-axis Drag Chain
Bracket A

15
Mechanical Installation
STEP 8 Installing X-axis Drag Chain
What you need:
Attach the X-axis drag chain to the X-axis drag chain brackets and secure (2) flat head cap screws.
11 X-axis Drag Chain 24 (2) M4×6 Flat Head Cap Screw
X-axis Drag Chain(2) M4×6
Flat Head Cap Screw

16
Mechanical Installation
STEP 9 Replace 65mm Spindle Mount
What you need:
1. Unscrew the 52mm set screw and remove the 52mm spindle mount as the figure.
2. Install the 65mm spindle mount using the screws just removed and lock the screws.
3. Then install the corresponding spindle you need.
28 65mm Spindle Mount
(2) 52mm Set Screw
52mm Spindle Mount
65mm Spindle Mount
(2) 52mm Set Screw

17
Adjusting Lead Screw
There are hexagonal clips on the end face of the Y-axis and X-axis lead screw, which can be used to adjust the lead screw by
inserting the hexagonal driver into the clips and twisting the lead screw, as shown in the figure below.
The tools you need:
23 Hexagonal Driver for Lead Screw
S
i
d
e
v
i
e
w

Adjusting Lead Screw
18
Turn the eccentric nut catch with the Allen wrench to adjust the loosening or tightening of the roller module, as shown in figure 1.
How to adjust the Roller Module loosening or tightening
It has been adjusted by the factory, if you accidentally touch it, you can adjust it as shown in figure 2.
Closed-loop Stepper Motor Encoder Adjustment
Eccentric Nut Adjustment Clamp
figure 1figure 2
Encoder
