GeoMax Zenius5 Series User manual

en
de
es
fr
it
pt
GeoMax Zenius5 Series
Quick Guide
Version 1.0
avrora-arm.ru
[phone]

en
GeoMax Zenius5 Series
Quick Guide
Version 1.0
English

Zenius5 | 2Introduction
en
Introduction
Purchase Congratulations on the purchase of a GeoMax Zenius5.
Read and follow the User Manual available on the GeoMax website before using
the product.
• This Quick Guide contains first use directions as well as initial, basic
instructions for setting up the product and operating it.
• Keep all documentation for future reference!
Available
documentation
Refer to the GeoMax website for all Zenius5 documentation/software.
Intended use • Remote control of product.
• Data communication with external appliances.
Name Description/Format
Zenius5
Quick Guide
Provides an overview of the product. Intended as a
quick reference guide.

Zenius5 User
Manual
All instructions required in order to operate the
product to a basic level are contained in the User
Manual. Provides an overview of the product
together with technical data and safety directions.
-

Introduction Zenius5 | 3
en
Symbols The symbols used in this manual have the following meanings:
CAUTION Keeping the device too close to the human body during operation may pose a
health risk.
This device has been tested for typical operations near the human body, for
example handheld mode, with the device kept at 10 mm from the user’s body.
Precautions:
Use the device at least 10 mm apart from the human body.
Type Description
DANGER Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING Indicates a potentially hazardous situation or an unintended
use which, if not avoided, could result in death or serious
injury.
CAUTION Indicates a potentially hazardous situation or an unintended
use which, if not avoided, may result in minor or moderate
injury.
NOTICE Indicates a potentially hazardous situation or an unintended
use which, if not avoided, may result in appreciable material,
financial and environmental damage.
Important paragraphs which must be adhered to in practice
as they enable the product to be used in a technically correct
and efficient manner.

Zenius5 | 4Introduction
en
Care and trans-
port
• Protect the product against shock and vibration.
• Periodically carry out functional tests particularly after the product has
been dropped, stored for long periods or transported.
DangerousGoods
Regulations
The products of GeoMax are powered by Lithium batteries.
Lithium batteries can be dangerous under certain conditions and can pose a
safety hazard. In certain conditions, Lithium batteries can overheat and ignite.
When carrying or shipping your GeoMax product with Lithium batteries
onboard a commercial aircraft, you must do so in accordance with the
IATA Dangerous Goods Regulations.
GeoMax has developed Guidelines on “How to carry GeoMax prod-
ucts” and “How to ship GeoMax products” with Lithium batteries.
Before any transportation of a GeoMax product, we ask you to consult
these guidelines on our web page (http://www.geomax-posi-
tioning.com/dgr) to ensure that you are in accordance with the
IATA Dangerous Goods Regulations and that the GeoMax products can
be transported correctly.
Damaged or defective batteries are prohibited from being carried or
transported onboard any aircraft. Therefore, ensure that the condition
of any battery is safe for transportation.

Introduction Zenius5 | 5
en
The product must not be disposed with household waste.
The battery must be charged before using it for the first time.
The following advice is only valid for batteries, power adapter or docking
station.
Memory device The instrument has a SD card slot fitted as standard. A SD card can be inserted
and removed. Refer to Insert and remove a SIM Card or a SD Card step-by-
step.

Zenius5 | 6Instrument Components
en
1 Instrument Components
Zenius5 package The Zenius5 package includes the following components:
0014001_001
a
b
c
d
f
g
e
h
i
j
e

Instrument Components Zenius5 | 7
en
Front side of the
Zenius5
a) Zenius5
b) ZBA700 rechargeable battery
c) Capacitive stylus
d) Hand strap
e) Switching power supply
f) Mini USB cable
g) USB OTG cable
h) ZCH700 battery charger (optional)
i) Quick guide
j) Glass protection
a) Communication LED
b) GPS LED
c) Power LED
d) Screen
e) Keypad
f) Power key
g) Microphone
013752_001
g
f
e
d
c
b
a

Zenius5 | 8Instrument Components
en
Back side of the
Zenius5
Bottom panel of
the Zenius5
LED indicators
a) Camera
b) Speaker
c) Holder for hand strap
d) Release lever for battery
compartment
e) Compartment with slots
for battery, SIM card and
SD card
f) Hand strap fixation
013762_001
c
d
a
b
e
f
a) USB port
b) Hand strap holder
c) Serial connector
d) Power connector
ab dc
013764_001
a) Communication LED
b) GPS LED
c) Power LED
013776_001
abc

Instrument Components Zenius5 | 9
en
Keypad
Functions of the
keys
a) Left softkey
b) Send key
c) Function key
d) Camera key
e) Power key
f) Numeric keys and alter-
native function keys
g) Right softkey
h) End key
i) Backspace key
j) Start key
k) Enter key
l) Collect key
013753_001
a
b
c
d
h
i
j
e
f
g
k
l
Key Function
Left softkey
Performs the command shown on the
bottom left corner of the screen.
Send key
Dials or answers a call.

Zenius5 | 10Instrument Components
en
Function key
Switches the alterative functions of
the numeric keys on or off. If the
alternative functions are switched on,
the icon Fn appears in the navigation
bar.
Camera key
Press to open camera app. If camera
app is opened: Press to take a picture.
Power key
Turns the Zenius5 on or off.
Numeric keys
To enter numbers.
Right softkey
Performs the command shown on the
bottom right corner of the screen.
End key
Ends or rejects a call. Returns to the
start screen.
Key Function

Instrument Components Zenius5 | 11
en
Backspace key
Press to backspace over one character
in a text editable field.
Windows key
Press to open the start menu.
Enter key
Press to confirm selections.
Collect key
Press to record data during measure-
ments.
Depending on 3rd party software
implementation.
Key Function

Zenius5 | 12Instrument Components
en
Turning on the
Zenius5
step-by-step
Step Description
1. Place the Zenius5 on a flat and stable surface or hold the device in
your hand.
2. Ensure that either the device is connected with the AC power adapter
or the batteries are charged up.
3. Press and hold Power key until the LED power indicator turns
from red colour to green colour.
The operating system needs usually about 30-40 seconds for booting
up. When the main screen is displayed, the Zenius5 is ready to use.
0013770_001

Instrument Components Zenius5 | 13
en
Turning off the
Zenius5
step-by-step
Step Description
1. Press the Power key for at least 3 seconds to open the Power Off
menu.
Within the menu, the following options are available:
•OK: The operating system shuts down and the device is turned
off.
•Cancel: Close the Power Off menu and return to the main
screen.
2. To turn off the device, select the option OK.
After turning off the Zenius5, wait for at least 5 seconds before
turning on the device again.

Zenius5 | 14Instrument Components
en
Sleep mode acti-
vation
step-by-step
To activate the sleep mode of Zenius5 do the following:
The LED communication indicator stays green during sleep mode. Any
incoming call ends the sleep mode.
Step Description
The Zenius5 must be switched on.
1. Press and hold the Power key for 1 second.
The Zenius5 enters the sleep mode. The LED power indicator turns
to green.
2. Press the Power key again to resume operation.

Operation Zenius5 | 15
en
2 Operation
2.1 Inserting and Charging the Battery
Inserting and
charging
step-by-step
100-240 V
5b
5a
4b
4b 4a
2a
2a
2a
2b
3b
5s
=OFF
1
3a
1
00
-2
0014003 001
0014003_001

Zenius5 | 16Operation
en
1. Turn off the Zenius5 and place it on a stable surface, with the back side
facing up.
2. Lift the latch handle of the cover and turn it counterclockwise to the
vertical unlock position and remove the cover of the battery compart-
ment.
3. To insert the battery to the compartment, attach the bottom side of the
battery to the compartment at an angle and then lower the upper side
to engage the connector.
4. Reattach the compartment cover by inserting it bottom first. Fit the
latch handle into place. Secure the latch by turning it clockwise to the
horizontal lock position.
The IP rating is only ensured if the battery compartment is
attached correctly.
5. Attach the AC Adapter to the Zenius5 and to a mains socket to start
charging.
Only use the charger delivered with the Zenius5.
When using the Zenius5 for the first time, wait until the battery
is fully charged. The initial charging takes approximately
6 hours.

Operation Zenius5 | 17
en
2.2 Inserting and Removing a SIM Card and SD Card
• Keep the card dry.
• Use it only within the specified temperature range.
• Do not bend the card.
• Protect the card from direct impacts.
Failure to follow these instructions could result in data loss and/or permanent
damage to the card.
CAUTION Always ground yourself to remove any static charge before touching the
SIM/SD card. The electronic devices are sensitive to static electricity.
Precautions:
1) Only experienced personnel should open the mechanical housing of the
device.
2) Use a grounding wrist strap all the time.
3) Place all the electronic components in a static-dissipative surface or static-
shielded bag when they are not in the chassis.

Zenius5 | 18Operation
en
Apply general practice for working with static-sensitive devices when you open
the device, insert the SIM or SD card and closing the device:
• Discharge any static charge before opening the device and working with
the SIM or SD card.
• The device must not be subject to high electrostatic potentials when it is
open.
• Minimise contact with internal components of the device.
• Avoid any discharges of static electricity near the device when inserting the
SIM or SD card.

Operation Zenius5 | 19
en
Insert and
remove a
SIM Card or a
SD Card
step-by-step
2a
2a
2a
2b
3
5s
=OFF
1
5
5
6
6
4b
4a
0014004_001
