GeoMax Zenith 16 Series User manual

GeoMax Zenith16/40 Series
Quick Guide
Version 1.1

Quick Guide 5
Quick Guide 19
Guía Rápida 35
Guide abrégé 49
Guida rapida 65
Guia Rápido 79
Краткое руководство 93
Korte handleiding 107
en
de
es
fr
it
pt-br
ru
nl

GeoMax Zenith16/40 Series
Quick Guide
Version 1.1
English

1 Important Information about your
Instrument
Read and follow the User Manual on the accompanying data storage device
before using the product.
Keep for future reference!
•Computing with software
•Recording measurements
•Carrying out measurement tasks using various GNSS measuring tech-
niques
•Recording GNSS and point related data
•Remote control of product
•Data communication with external appliances
•Measuring raw data and computing coordinates using carrier phase
and code signal from GNSS satellites (GNSS systems)
☞
Intended use
Important Information about your Instrument 6
en

The product must not be disposed with household waste.
•FCC Part 15 (applicable in US)
•Hereby, GeoMax declares that the radio equipment type Zenith16 is
in compliance with Directive 2014/53/EU and other applicable Euro-
pean Directives.
The full text of the EU declaration of conformity is available at the
following Internet address: http://www.geomax-positioning.com/
Downloads.htm.
Class 2 equipment according to European Direc-
tive 2014/53/EU (RED) for which following EEA Member
States apply restrictions on the placing on the market or on
the putting into service or require authorisation for use:
•France
•Italy
•Norway (if used in the geographical area within a radius
of 20 km from the centre of Ny-Ålesund)
Conformity to
national
regulations
Important Information about your Instrument 7
en

•FCC Part 15, 22 and 24 (applicable in US)
•Hereby, GeoMax declares that the radio equipment type Zenith40 is
in compliance with Directive 2014/53/EU and other applicable Euro-
pean Directives.
The full text of the EU declaration of conformity is available at the
following Internet address: http://www.geomax-positioning.com/
Downloads.htm.
Class 2 equipment according to European Direc-
tive 2014/53/EU (RED) for which following EEA Member
States apply restrictions on the placing on the market or on
the putting into service or require authorisation for use:
•France
•Italy
•Norway (if used in the geographical area within a radius
of 20 km from the centre of Ny-Ålesund)
Conformity to
national regula-
tions
Important Information about your Instrument 8
en

2 Instrument Components
4573_002
a
b
c
d
e
a TNC-connector for external
UHF antenna, only for
models with UHF radio
b Battery compartment with
microSD and SIM card slot
c Keyboard with LEDs,
ON/OFF button and Func-
tion button
d Serial, USB and power port
e Antenna Reference Plane
(ARP) is where the instru-
ment heights are meas-
ured to.
GNSS receiver
components
Instrument Components 9
en

Button Function
ON/OFF
If the GNSS receiver is off:
Turns on the GNSS receiver when held for 2 s.
☞While the Zenith16/40 is booting the two
Power LEDs flash.
If the GNSS receiver is already on:
Turns off the GNSS receiver when held for 2 s.
☞All functions described assume the Zenith16/40 is already on.
Button Function
Function Press and hold button for <1 s.
Switches the receiver between rover or base mode.
Press and hold button for 3 s.
Updates the base position coordinates when the GNSS
receiver is in base mode. The RTK base LED flashes
ON/OFF button
Function button
Instrument Components 10
en

Button Function
for 2 s. When no position is available, the LED flashes
red.
Press and hold button for 5 s.
Connects to the configured RTK base station or NTRIP
server when the GNSS receiver is in rover mode. The
RTK rover LED flashes for 2 s. No action if a rover
mode is not configured.
Instrument Components 11
en

3 Environmental specifications
Descrip-
tion
Value
Tempera-
tures (°C) GNSS receiver -40 to +65 (operation) -40 to +80 (storage)
Battery -20 to +55
(operation) -40 to +70 (storage)
Protection IP68 (IEC 60529)
Withstands powerful jets and temporarily immersion
under water.
MIL-STD-810G 1 506.6 & 1 512.6
Fully dust tight MIL-STD-810G 1 510.6
Vibration Vibration test according to ISO 9022-36-05
Shock Withstands a 2 m (6.6 ft) pole topple over onto hard sur-
face.
Environmental
specifications
Environmental specifications 12
en

Descrip-
tion
Value
Humidity 100% condensing
The effects of condensation are to be effectively counter-
acted by periodically drying out the GNSS receiver.
Environmental specifications 13
en

4 Transport
When transporting the equipment in the field, always make sure that you
•either carry the product in its original container,
•or carry the tripod with its legs splayed across your shoulder, keeping
the attached product upright.
Never carry the product loose in a road vehicle, as it can be affected by
shock and vibration. Always carry the product in its container and secure it.
For products for which no container is available use the original packaging
or its equivalent.
When transporting the product by rail, air or sea, always use the complete
original GeoMax packaging, transport container and cardboard box, or its
equivalent, to protect against shock and vibration.
Transport in the
field
Transport in a
road vehicle
Shipping
Transport 14
en

When transporting or shipping batteries, the person responsible for the
product must ensure that the applicable national and international rules
and regulations are observed. Before transportation or shipping, contact
your local passenger or freight transport company.
Shipping, trans-
port of batteries
Transport 15
en

5 Operation
The battery must be charged before using it for the first time.
19101_001
1
23
4
☞The battery is inserted in the bottom part of the GNSS receiver.
☞
Change battery
step-by-step
Operation 16
en

1. Push the slide fastener of the battery compartment in the direc-
tion of the arrow with the open-lock symbol.
2. Remove the cover from the battery compartment.
3. With the battery contacts facing upwards, slide the battery into
the cover of the battery compartment.
4. Push the battery downwards so that it locks into position.
5. Insert the cover of the battery compartment into the compart-
ment and push the slide fastener in the direction of the arrow
with the close-lock symbol.
6. To remove a battery, push the slide fastener of the battery com-
partment in the direction of the arrow with the open-lock symbol
and remove the cover.
7. Push the battery slightly upwards and at the same time pull out
the bottom part of the battery. This releases the battery from its
fixed position.
8. Remove the battery.
Operation 17
en

GeoMax AG
www.geomax-positioning.com
874755-1.1.0en
Original text (874755-1.1.0en)
© 2019 GeoMax AG, Widnau, Switzerland

GeoMax Zenith16/40 Serie
Quick Guide
Version 1.1
Deutsch

1 Wichtige Informationen über Ihr
Instrument
Vor der Verwendung des Produkts die Gebrauchsanweisung auf dem beige-
fügten Datenträger lesen und befolgen.
Sorgfältig aufbewahren!
•Berechnung mit Software.
•Aufzeichnen der Messungen.
•Durchführung von Messaufgaben mit verschiedenen GNSS-Messtech-
niken.
•Aufzeichnung von GNSS und punktbezogenen Daten.
•Fernbedienung des Produkts.
•Datenkommunikation zu externen Geräten.
•Messung und Aufzeichnung von Rohdaten und Koordinaten mit Hilfe
von GNSS (GNSS-Empfängern).
☞
Verwendungs-
zweck
Wichtige Informationen über Ihr Instrument 20
de
