GEOSOFT DENT ENDOEST-MOTOR User manual

USER’S GUIDE
ENDODONTIC MOTOR WITH APEXLOCATOR
ENDOEST-MOTOR
CJSC Geosoft Dent

USER’S GUIDE
2 www.geosoft.ru / en
Congratulations!
! On buying the device, be sure to check the delivery set, presence and correctness
of the Quality Warranty Card filling, the acceptance certificate and product selling
marks.
! Please, thoroughly read the user’s guide before using the device. Keep the User’s
guide for future use.
! Please, address to the manufacturer, if you have some questions when using the
device. Hotline: [phone] (extension 170), E-mail: hotline @ geosoft.ru
CONTENTS
1. General information ........................................…………………………
1.1. The device brief summary………………………………..…………………..
1.2. Field of application…………………………………….…………………….
1.3. Contraindications………………………………………...………………….
1.4. Safety measures and warnings…………………...…………………………..
2. Delivery set...............................................……………………………...
3. Accessories………………….………………………………………….
4. Specifications…………………………………………………………..
5. The device description. Operating controls and indication ....................
5.1. Control unit………...………………………………………………………...
5.1.1. Display...……………………………………………………………………
5.1.2. Keyboard……………………………………………………………...……
5.1.3.Program library for the Ni-Ti file systems………………………………………
5.1.4.Sound indication…………………………………………………………………...
5.2. Micromotor………………………………….………………………….………..
5.2.1. Light indication on the micromotor…………………………………………….
5.3. Additional operating controls………………..………………………..……..
6. Makeready………………………………..…………………………….
6.1. Components connecting………...…………………………………...……….
6.1.1. Wired components connecting……………………………………………….
6.1.2. The micromotor head connecting ………………………………………....
6.1.3. Fixing Ni-Ti instrument (file)…………………………………………………….
6.1.4. Apexlocator electrodes connecting……………………………….………..
6.1.5 Micromotor stand assembly...…………………………………………………….
6.2. Accumulators………………………………………………………………...
4
4
5
5
5
8
9
11
13
13
14
15
17
18
20
20
21
22
22
22
23
23
24
25
26

ENDOEST-MOTOR
3
hotline @ geosoft.ru
6.2.1. Accumulators charging………………………………….………………..
6.2.2. Function of accumulators charge control…………..……………………..
6.2.3. Power saving function……...……………………………………………..
7. Using…………………………………………………………………...
7.1. Power switching on………………………………………………………….
7.2. Calibration of the micromotor system …….…………………………..……..
7.3. Selection of the Ni-Ti system, working program and file …….……………...
7.4. The device settings………………….………………………………………..
7.4.1. Individual settings of the file (speed, limit torque)……………………………
7.4.2. Program general settings……………………………………………………….
7.4.3. Program factory settings reset……………………………………………..
7.5. Micromotor start/stop …………..………...…………………………………..
7.6. Apexlocator…………………………………………………………………………..
7.6.1. Apexlocator check out……………………………………………………………
7.6.2. Apexlocator switch on/off…………………………………………………...
7.7. Bookmarks making and activating………….………..………………………..
7.8. Power switching off………………………………………………………………...
8. Step-by-step instruction on the device using in all the operating
modes……………………………. ……………………………………...
8.1. The device using in the endomotor mode………..…………………………..
8.2. The device using in the apexlocator mode……………………………..…..
8.3. The device using in the mixed mode …………………………...………………
9. Fundamental operating instructions of the apexlocator ………..……..
10. Caring for the device. Information on sterilization and disinfection...
10.1. Micromotor head lubricating ……………………………………………...
10.2. Pre-sterilization cleaning and sterilization ……….………………………..
10.3. Disinfection………………………………………………………………...
10.4. Replacing the foam rubber sponge in the clean-stand………………………..
11. Maintenance…………………….……………………………………
11.1. Replacing the accumulator unit ………………………………………………...
11.2. Replacing the seal ring on the micromotor head ……………………………..
12. Firmware updating ………………………………….……………….
13. Troubleshooting …………………………..……………………...…..
14. Storage conditions, transportation and use…………………………...
15. Information on utilization…………………………………………….
16. Information on certification…………………………………………..
17. Warranty…………………...........................…………………………
18. Symbol descriptions………………………………………………….
Appendix. Electromagnetic Emissions and Immunity…………………...
26
26
27
28
28
28
30
31
31
34
39
39
40
40
40
41
41
42
42
43
44
46
49
49
49
50
51
51
51
52
53
54
58
58
58
60
61
62

USER’S GUIDE
4 www.geosoft.ru / en
1. GENERAL INFORMATION
1.1. The device brief summary
«EndoEst-Motor” is a compact device combining endodontic motor with
microprocessor control for working with rotating Ni-Ti instruments and
apexlocator for localization of root canal apical constriction (apex).
The device operates in three modes: only in endomotor, only in apexlocator
or mixed mode when the apexlocation function controls operation of
endomotor .
There is a large program library for systems of rotating Ni-Ti files from the
leading manufacturers (see table 1) with preset speed and limit torque value
for each file in the endomotor mode.
Additionally, the device has “Basic” user program with capability of
independent programming up to 10 value combinations of speed and limit
torque for each file.
Table 1. List of programmed Ni-Ti systems
Manufacturer Name of the Ni-Ti system
Dentsply
Maillefer
ProTaper Universal, PathFile, GT Series X, System GT, ProFile
Komet AlphaKite System, EasyShape System
VDW FlexMaster, Mtwo
FKG Dentaire RaCe , S-Apex, BioRaCe, , iRaCe
SybronEndo Twisted Files, K3 Endo, К3XF
Sendoline NiTi-TEE, S5
Micro Mega EndoFlare, НЕRO 642, НЕRO Shaper, НЕRO Apical, Revo-S,
R-Endo
R&S CMA System

ENDOEST-MOTOR
5
hotline @ geosoft.ru
1.2. Field of application:
The device is designed for use in dentistry (endodontics) and can be used
only in hospitals by medical specialists licensed to practice dentistry. The
manufacturer is not responsible for the device misuse.
1.3. Contraindications
Do not use the device on patients with pacemakers.
1.4. Safety measures and warnings
! Use the device only with the “Geosoft Dent” authentic accessories (see part
3. “Accessories”).
! Do not dismount and do not anyhow change the device construction. The
device has no elements to be serviced by user except the accumulator power
unit. In the case of the device integrity damage, the warranty is
considered to be invalid.
! Avoid any liquid ingress into the device case.
! Do not use the device close to inflammables. The device does not operate in
the presence of inflammable anesthetic mixtures with air, oxygen or nitrogen
oxides.
! Use only sterile and disinfected device components. The device sterilization
and disinfection shall be carried out before the first device use and after each
patient in order to avoid cross infection (for more details see part 10 “Caring
for the device. Information on sterilization and disinfection”).
! Be sure to lubricate and sterilize the micromotor head before its use after
each patient. Avoid lubricant ingress into the micromotor expanded parts.
! Use cofferdam when working in patient’s oral cavity.
! In the case of any abnormality in the endomotor functioning (noise,
shakiness, vibrations, heating etc.), stop using the device immediately and try

USER’S GUIDE
6 www.geosoft.ru / en
to find the cause of malfunction basing on the information represented in part
13 of this user’s guide.
! This endomotor has function of the file limit torque restriction what lessens
probability of break during its use. In spite of it, files may break down
because of wrongly set limit torque value in the program or because of worn
out files. Carefully incorrectly set value of the limit torque in the program
and using worn-out files. Be sure to follow the manufacturer’s instructions
concerning the use of endodontic instruments and avoid use of worn-out and
damaged files.
! Do not use curved, deformed or not corresponding to the ISO file. Use of
such a file may result in injury.
! Always clean the shank of the file to be set. Mud penetration into the clutch
head may cause loss of concentricity and the file clutching power worsening,
loss of the apexlocator contact.
! Do not start the micromotor until the file is securely fixed in the clutch
head.
! Avoid inadvertent contact with rotating micromotor parts and/or rotating
file.
! In some cases apex determination with electronic apexlocator may be not
enough accurate and reliable (see part 9. “Fundamental operating
instructions of the apexlocator”). Make an X-ray image and base on the
information received from both methods before using the electronic
apexlocator.
! The device requires special safety precautions with regard to
electromagnetic compatibility (EMC), and the EMC information contained in
this manual must be strictly adhered to during installation and operation. It is
especially important not to use the device near fluorescent lamps, radio
transmitters or remote controls, portable or mobile radio frequency
communications equipment.

ENDOEST-MOTOR
7
hotline @ geosoft.ru
! The apexlocator malfunction is possible when using it in the area of strong
electromagnetic interference (EMC). Don’t use the device close to
electromagnetic waves emitting equipment. Malfunctions may take place
close to the equipment marked with symbol.
! Do not use this device in conjunction with other equipment, or as part of
other equipment.
! Do not use the accessories, transducers and cables other than those listed
below. This may result in increased emissions or decreased immunity
performance of the device. The manufacturer guarantees the electromagnetic
compatibility of the following elements: Micromotors “DC-НР” and “DC-
MM” with a maximum cable length 1.6 m; Cable “Signal Line” with
maximum length 1.65 m; Foot control pedal with a maximum cable length
1.8m; Mains charger with a maximum cable length 1.8 m
! The device normally operates at temperatures 10-35°С, relative air
humidity not more than 80%, atmosphere pressure (101±3) kPa. Any
violation of the pointed restrictions may lead to the device misoperation.
1.5. Side effects: Not revealed

USER’S GUIDE
8 www.geosoft.ru / en
2. DELIVERY SET
The device delivery set is represented in the table 2 and fig. 1
Table 2. The device delivery set
Number of pieces in the set
Variant
“НР”
Variant
“ММ”
Control unit 1 1
Micromotor “DC-НР” with the head 1 -
Micromotor “DC-MM” with the head - 1
Cable “Signal Line” (USВB-plug) 1 1
File clip (“Probe Princh”) 1 1
Lip clip (“Oral Hook”) 1 1
Mains charger 1 1
Foot control pedal - 1
“Stand Master”, “Stand Satellite”, clean-stand 1 1
Cable USB-miniUSB 1 1
User’s guide 1 1
Position name № on
the
fig.1
1
2
3
4
5
6
7
8
9
10
-
Fig.1
3
2 1
8
10
9
6
7
5
4

ENDOEST-MOTOR
9
hotline @ geosoft.ru
3. ACCESSORIES
Additional accessories for the «EndoEst-Motor” are represented in the table
3.
Table 3
Outward
appearance
Number of
order
Position name Pcs. in
the pack
GE99.069.000 Micromotor “DC-HP”
Micromotor for working with rotating
Ni-Ti instruments in the set with the
head GЕ99.124.000
1
GE99.131.000 Micromotor “DC-ММ”
Micromotor for working with rotating
Ni-Ti instruments in the set with the
head GЕ99.120.000
1
GE99.124.000 Miniature head “EH-20ML” with
friction fixing
is an additional head for the
micromotor “DC-HP”
1
GЕ99.133.000 Seal ring for the head
is additional silicon seal ring for the
head GЕ99.124.000
3
GE99.120.000 Head “EndoAce” in the electric
insulated housing
is an additional head for the
micromotor “DC-MM”
1
GE99.096.000 Cable “Signal Line”
is a cable for apexlocation procedure.
Plug -USBB
1
GE99.047.000
GE99.121.000
File clip (“Probe Princh”)
is used as a clutch of the active
electrode during apexlocation
procedure.
3
1

USER’S GUIDE
10 www.geosoft.ru / en
Extension of table 3
Outward
appearance
Number of
order
Position name Pcs. in
the pack
GE99.062.000
GE99.123.000
Lip clip (“Oral Hook”)
is used as passive electrode during
apexlocation procedure.
3
1
GE99.097.000 Foot control pedal
Foot control pedal of the micromotor.
One-positional.
1
GE99.104.000 Mains charger
Input voltage: (220±10%) V, ~50Hz;
Output voltage: 9V; 500 mA.
Plug– USBB
1
GE99.110.000 Accumulator unit
is an additional Li-Po accumulator
unit for the «EndoEst-Motor” (2*3,7V)
1
GE99.112.000 Stand “Stand-Master”
is a stand for the micromotor “DC-
HP” and “DC-MM”
1
GE99.113.000 Stand «Stand-Satellite»
is a stand for the clean-stand
GЕ99.118.000
1
GE99.117.000 Fixing element
for the stands «Stand-Master” and
“Stand-Satellite”
5
GЕ99.118.000 Clean-stand for the stand “Stand-
Satellite”
is for mechanical cleaning and
temporary storage of the working files
1

ENDOEST-MOTOR
11
hotline @ geosoft.ru
4. SPECIFICATIONS
4.1. Control unit
 Power source - Li-Ро accumulator unit (2*3,7V; 700 mA/h);
 Electrical safety - class II, type В;
 LСD-display - type: alphanumeric, size: 60*16 mm, dimension: 16
symbols*2 lines, color: blue;
 Adjustment range of the file rotation speed - from 150 to 600 rpm (by
increment 10 rpm);
 Accuracy of the preset rotation speed stabilization when applying forces -
±10% ;
 Adjustment range of the file rotation limit torque - from 0,2 to 5,5 Ncm
(by increment 0,1 Ncm);
 Accuracy of the preset rotation limit torque - ±15% ;
 Max. rotation speed at the limit torque 5,5 Ncm - 300 rpm;
 Max. limit torque at rotation speed 600 rpm - 2,7 Ncm;
! Accessories are shipped apart at extra cost.
Extension of table 3
Outward
appearance
Number of
order
Position name Pcs. in
the pack
GЕ255.000.000 Endodontic stand «EstTray»
is a stand for the micromotor “DC-
HP” and “DC-MM” with clean-stand
1
GE99.061.000 Foam rubber sponges for the
clean-stand
are one-time sponges (
∅ 50*10mm)
25
GЕ99.161.000 Adapter for lubrication
Adapter for lubrication micromotor
heads GЕ99.124.000 and
GE99.120.000
1

USER’S GUIDE
12 www.geosoft.ru / en
 Measurement range in the apexlocator mode - from 3,1 to – 0,4;
 Adjustment range of the apical shelf point position in the apexlocator
mode - from 0,1 to 0,5 (by increment 0,1);
 Measurements accuracy in the apical area (from 0,5 to the apex) with
probability 87% - ± 0,1;
 Time of the device operation in the standby mode until the device
automatic switch off - 30±1 min;
 Duration of the power source full charge - 4 h;
 The accumulators life cycle - not < 300 recharge cycles;
 Degree of protection against dust and moisture - IP51;
 Overall dimensions (L*W*H) - (100*76,5*138) ±3 mm;
 Weight- 360±10 g.
4.2. Micromotor “DC-HP” with head
 Maximal rotation speed - 600 rpm;
 Head: model EH-20ML (miniature, with friction fixing, gear ratio 1:1,
latch type);
 Overall dimensions - (Ø 22,5*160) ±5 mm; Weight - 95±10 g;
 Cable length - 1,5±0,1 m; plug - IEEE-1394 (6pin)
4.3. Micromotor “DC-ММ” with head
 Maximal rotation speed - 500 rpm;
 Head: model “EndoAce” (1:1,42 reduction, electric insulated housing,
push button chuck);
 Overall dimensions - (Ø 22,5*167) ±5 mm; Weight - 90±10 g;
 Cable length - 1,5±0,1 m; plug - IEEE-1394 (6pin)
4.4. Mains charger
 Input/output voltage - (220±10%) V, ~50Hz / 9V; 500 mA.
4.5. Foot control pedal
 Nominal load - 10А 250VAC;
 Overall dimensions - 80*82*34 mm; Weight - 170±10 g;
 Cable length - 1,7 ±0,1 m; plug - аudio mono 3,5 mm.
The device service time - 5 years.

ENDOEST-MOTOR
13
hotline @ geosoft.ru
5. THE DEVICE DESCRIPTION.
OPERATING CONTROLS AND INDICATIONS
5.1. Control unit
Outward appearance of the «EndoEst-Motor” control unit is represented in
the figure 2.
Where:
1 - case: а - front panel, b - back panel;, c - cover of the battery compartment
(accumulator unit);
2 - LСD-display (see p.5.1.1);
3 - keyboard (see p.5.1.2);
4 - button “Reset”;
5 - accumulators charge indicator;
6 - socket “APEX/CHARGE” for the mains charger connecting (7, fig.1) or
the apexlocator cable “Signal Line” (4, fig.1);
Figure 2. Control unit
2
3
1а
1c
4
5
6 9
8
10
11
7
1b

USER’S GUIDE
14 www.geosoft.ru / en
7 - socket miniUSB for the “USB-miniUSB” cable connecting (10, fig.1)
(for connecting the device control unit with computer in order to update the
device firmware version);
8 - socket “MICROMOTOR” for connecting the micromotor “DC-HP” (2,
fig.1) or “DC-MM” (3, fig.1);
9 - socket “PEDAL” for the foot control pedal connecting (8, fig.1);
10 - fixing screws (5 pcs);
11 - rating plate.
5.1.1. Display
The main display indication elements are represented in the figures 3 and 4
Figure 3. Indication on the display in working programs of the endomotor mode (as
an example of system “Mtwo” (VDW)).
where: 1 - sequence number of the file in the working program;
2 - abbreviated name of the Ni-Ti system;
3 - the file name (size according to ISO/taper or other symbol);
4 - preset rotation speed of the file in rpm ;
5 - preset rotation limit torque of the file in Ncm;
6,7 - tips on the control buttons used (see table 5);
8,9 - symbol “points” (displays only when speed/limit torque value on the screen
does not correspond to the factory setting);
10 - graphic scale of the current limit torque;
11 - preset function for the micromotor when attaining the file rotation limit
torque: АТ - “Autotwist”, АR - “Autoreverse” or АS - “Autostop” (see p. 7.4.2B
- setting “Limit torque”).
b) in the motor rotating mode
а) in the standby mode
4
3 2
6
8 9
7
5
1
10 11

ENDOEST-MOTOR
15
hotline @ geosoft.ru
7
9
3
1
6
4 5
2 8
10
Figure 4. Indication on the display in the apexlocator mode.
where: 1 - preset localized point in the canal: АL - “Apex” or (0.1- 0.5) Sh -
‘Shelf” (see p. 7.4.2 D - setting “Locatable point”);
2 - current distance from the working file top to the preset localized point in the
canal (from 3.1 to -0.4);
3 - graphic scale of the current distance to the localized point;
4 - symbol “arrow” (displays when the working file top overruns the limits of the
preset localized point in the canal);
5 - preset function for the micromotor when attaining the localized point in the
canal with the working file top: AR “Autoreverse” or АS - “Autostop” (see p.
7.4.2C - setting “Limit apex”).
5.1.2. Keyboard
Figure 5. Keyboard
а) example 1 b) example 2
1 2
3
5
4
1

USER’S GUIDE
16 www.geosoft.ru / en
Table 4. The control buttons description
Pos
fig.
5
Name Functional designation
1 «POWER» - The device switching on/off
- Control of the power batteries current charge level
2 «SET» - Entering the mode of program general settings (menu
“Settings”)/Reset of the endomotor current position mode
3 «START/
STOP»
- Micromotor start/stop
4/5 «<» / «>» - Program navigating through the menu to the left/right
- Scroll to the previous/next file in the endomotor working
program
- Rotation speed lessen/increase in the mode of the file
individual settings
6/7 «-» / «+» - Limit torque lessen/increase in the mode of the file
individual settings
- Apical shelf value lessen/increase in the apexlocator mode
8 «ENTER» - Selection confirming
- Entering the mode of the file individual settings in the
endomotor mode (speed and limit torque changing) / Exit
out of the mode of individual settings
- Saving the selected parameter in the mode of the program
general settings
9 «LEVEL
UP»
- Reset of the previous program menu level
10 «1» - «6» - Making and activating one of the six individual
bookmarks in the program
1+2 «POWER»
+ «SET»
- Reset of the device factory settings when switching the
device on
4+5 «<» + «>» - Reset of the rotation speed factory settings in the mode of
the file individual settings
6+7 «-» + «+» - Reset of the rotation limit torque factory settings in the
mode of the file individual settings
1+10 «POWER»
+«1»
- Micromotor “DC-HP” activation when switching the
device power on
1+10 «POWER»
+«2»
- Micromotor “DC-MM” activation when switching the
device power on

ENDOEST-MOTOR
17
hotline @ geosoft.ru
5.1.3. Program library for the Ni-Ti file systems
The device has a large “standard” programs library for working with the Ni-
Ti file systems of the leading manufacturers with preset rotation speed and
limit torque value for each file.
All the “standard” working programs are figuratively separated into two
groups: main and additional (see table 5).
Table 5. Programs library for the Ni-Ti file systems
Name of the
Ni-Ti system
Name of the working programs
Main Additional
ProTaper Univ. Treatment / Retreatment -
PathFile -
GT Series X Small canal / Large canal / Tortuous canal
System GT Small canal / Medium canal / Large canal Add. files
ProFile Small canal / Medium canal / Large canal Individual
AlphaKite Sys. Narrow canal / Medium canal / Wide canal Individual
EasyShape Sys. -
FlexMaster Narrow canal / Medium canal / Large canal Individual
Mtwo Treatment 1 / Treatment 2 / Treatment 3 / Retreatment -
RaCe Wide canal / Standard canal/ Narrow canal Individual
S-Apex -
BioRaCe Standard canal / Difficult canal -
iRaCe Standard canal / Difficult canal -
Twisted Files Large canal / Small canal / Apical files Individual
K3 Endo Procedure 06 / Procedure 04 / VTVT-pack /G-pack Individual
К3XF Procedure 06 / Procedure 04 Individual
NiTi-TEE Standard Add. file

USER’S GUIDE
18 www.geosoft.ru / en
Extension of table 5
Main programs are those drawn up taking into account recommendations of
the Ni-Ti system manufacturers concerning the files using order when
treating different canal types (taking into account size and degree of canal
complication), primary or repeated canal treatment and etc.
Additional working programs are those having all the files range of the
selected Ni-Ti system (program “Individual”) or separate files not included
into the main working programs (programs “Add. Files”)
Besides the “standard” working programs, the device has one more accessible
program (“Basic”), designed for user-programming of 10 different
combinations of rotation speed and limit torque value for any files used by
dentist.
5.1.4. Sound indication
The device operation is accompanied with sound indication.
On default all the device factory settings have sound signals activated (see
table 6).
Name of the
Ni-Ti system
Name of the working programs
Main Additional
S5 Standard / Apical files/ Retreatment -
EndoFlare -
НЕRO 642 Easy canal / Average canal / Difficult canal Individual
НЕRO Shaper Easy canal / Average canal / Difficult canal Individual
НЕRO Apical -
Revo-S -
R-Endo -
CMA System -

ENDOEST-MOTOR
19
hotline @ geosoft.ru
Table 6. Sound indication
Volume adjustment of sound signals or their switching off is realized in the
mode of program general settings (see p. 7.4.2E “Setting “Volume””)
Type of sound signal
Power switch on/off Two-time signal
Endomotor
operation
Micromotor start/stop One-time signal
Current rotation limit torque
of the file is 70% higher than
the preset value
Discontinuous signal
Micromotor operation in the
mode of “reverse
rotation” (counterclockwise)
Signal of type “rattle”
Apexlocator
operation
The file is in the area from
3,1 to 0.0 mm
(safe area)
Discontinuous signal gets more
frequent as the working file top
gets closer to the apex/apical
shelf
The file overruns the limits
of the apex/shelf point
(dangerous area)
Continuous signal
Program
messages
Informational and warning
messages
One-time signal. Type 2
Error messages Two-time signal. Type 2
Operating
controls
pressing
Pressing the active operating
controls
One-time signal. Type 3
Pressing the inactive
operating controls
Two-time signal. Type 3
Action

USER’S GUIDE
20 www.geosoft.ru / en
5.2. Micromotor
The micromotor “DC-HP” and “DC-MM” outward appearance is represented
in the figures 6 and 7.
Figure 6. Micromotor “DC-HP”
2
3 1 4 5
Figure 7. Micromotor “DC-ММ”
2
1 4 5
where:
1 - micromotor case;
2 - sterilizable head;
3 - button “START/STOP” (micromotor start/stop);
4 - transparent insertion with 2 color LED indicator (see p.5.2.1.);
5 - cable.
5.2.1. Light indication on the micromotor
The micromotor operation is followed with additional warning light
