GeoVision GV-BX120D series User manual

GV-IP Camera
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Box Camera
Ultra Box Camera
Arctic Box Camera
Target Box Camera
ICH265HISIV114-A
Quick Start Guide

© 2018 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in
part, without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any
kind and assumes no responsibility for errors or omissions. No liability is
assumed for incidental or consequential damages arising from the use of
the information or products contained herein. Features and specifications
are subject to change without notice. Note: no memory card slot or local
storage function for Argentina.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: [phone]
Fax: [phone]
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc.
July 2018

Contents
Caution................................................................................v
Safety Notice......................................................................v
Options ..............................................................................vi
Creating GV-IP Camera’s Login Credentials............... viii
Note for Installing Camera Outdoor............................... ix
Note for USB Storage and WiFi Adapter ........................ x
Note for Silica Gel Bags................................................... x
Chapter 1 Box Camera .................................................... 1
1.1 Packing List................................................................................6
1.1.1 For H.265 Cameras ......................................................6
1.1.2 For H.264 Cameras ......................................................7
1.2 Overview....................................................................................8
1.2.1 GV-BX120D / 130D Series / 140DW / 220D Series /
320D Series / 520D.................................................................8
1.2.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400
Series / 2500 Series / 2600 / 2700 Series /3400 Series / 4700
Series / 5300 Series / 5700 Series / 12201 ..........................10
1.3 Connecting the Camera...........................................................13
1.3.1 GV-BX120D / 130D Series / 140DW / 220D Series /
320D Series / 520D...............................................................13
i

1.3.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400
Series / 2500 Series / 2600 / 2700 Series / 3400 Series / 4700
Series / 5300 Series / 5700 Series / 12201 ..........................15
1.4 Accessory Installation..............................................................17
1.4.1 C-Mount Lenses..........................................................17
1.4.2 Infrared Illuminators (Optional) ...................................18
1.5 I/O Terminal Block ...................................................................19
1.5.1 Pin Assignment...........................................................19
1.5.2 Connecting to GV-Relay V2 (Optional).......................20
1.6 Loading Factory Default...........................................................21
1.6.1 Using the Web Interface .............................................21
1.6.2 Directly on the Camera ...............................................22
Chapter 2 IR Arctic Box Camera .................................. 23
2.1 Packing List..............................................................................24
2.2 Overview..................................................................................27
2.2.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E /
2400-E / 3400-E / 4700-E / 5300-E.......................................27
2.2.2 GV-BX2510-E / 5310-E................................................28
2.3 Installation................................................................................29
2.4 Connecting the Camera...........................................................35
2.4.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E /
2400-E / 3400-E / 4700-E / 5300-E.......................................35
ii

2.4.2 GV-BX2510-E / 5310-E...............................................37
2.5 Notice for Using the IR Arctic Box Camera..............................40
2.5.1 Enabling IR LED after Loading Default.......................41
2.5.2 Disabling Status LED under Low Light Conditions .....42
2.6 Loading Factory Default...........................................................43
2.6.1 Using the Web Interface ..............................................43
2.6.2 Directly on the Camera ................................................43
Chapter 3 Ultra Box Camera......................................... 44
3.1 Packing List..............................................................................45
3.2 Overview...................................................................................46
3.3 Installation................................................................................47
3.4 Connecting the Camera...........................................................49
3.5Loading Factory Default ...........................................................50
3.5.1 Using the Web Interface ..............................................50
3.5.2 Directly on the Camera ................................................50
Chapter 4 Target Box Camera...................................... 51
4.1 Packing List..............................................................................51
4.2 Overview..................................................................................52
4.3 Installation................................................................................53
4.4 Connecting the Camera...........................................................55
4.5 Loading Factory Default...........................................................56
4.5.1 Using the Web Interface ..............................................56
iii

4.5.2 Directly on the Camera ................................................56
Chapter 5 Accessing the Camera................................. 57
5.1 System Requirement ...............................................................57
5.2 Accessing the Live View..........................................................58
5.2.1 Checking the Dynamic IP Address .............................59
5.2.2 Configuring the IP Address.........................................61
5.2.3 Configuring the Wireless Connection..........................63
5.3 Adjusting Image Clarity............................................................66
Chapter 6 The Web Interface........................................ 68
Chapter 7 Upgrading System Firmware ...................... 71
iv

Caution
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
Safety Notice
The GV-IPCAM uses a Lithium battery as the power supply for its internal
real-time clock (RTC). The battery should not be replaced unless required!
If the battery does need replacing, please observe the following:
•Danger of Explosion if battery is incorrectly replaced
•Replace only with the same or equivalent battery, as recommended by
the manufacturer
•Dispose of used batteries according to the manufacturer's instructions
v

Options
Optional devices can expand your camera’s capabilities and versatility.
Contact your dealer for more information.
Device Description
Power Adapter
The power adapter is available for all Box Camera,
Ultra Box Camera, and Target Box Camera. Contact
your sales representative for the countries and areas
supported.
GV-PA191 PoE
Adapter
The GV-PA191 PoE adapter is designed to provide
power and network connection to the cameras over
a single Ethernet cable.
GV-PA482 PoE
Adapter
The GV-PA482 PoE adapter is designed to provide
power and network connection to GV-BX1500-E /
2400-E / 2510-E / 3400-E / 5300-E / 4700-E / 5310-
E over a single Ethernet cable.
GV-POE Switch
The GV-POE Switch is designed to provide power
along with network connection for IP devices. The
GV-POE Switch is available in various models with
different numbers and types of ports.
GV-Mount
Accessories
The GV-Mount Accessories provide a
comprehensive lineup of accessories for installation
on ceiling, wall corner and pole. For details, see GV-
Mount Accessories Installation Guide.
vi

Device Description
GV-WiFi Adapter
The GV-WiFi Adapter is a plug-and-play device
designed to connect your camera to to wireless
network. The product complies with IEEE 802.11
b/g/n (Draft 3.0) standards for wireless networking.
Note: Only compatible models and firmware
versions can support GV-WiFi Adapter.
GV-Relay V2
The GV-Relay V2 is designed to expand the voltage
load of GV IP devices. It provides 4 relay outputs,
and each can be set as normally open (NO) or
normally closed (NC) independently as per your
requirement.
vii

Creating GV-IP Camera’s Login
Credentials
The default Administrator and Guest accounts are no longer supported by
GV-IPCAM H.265 series firmware V1.14 or later. When purchasing a
new camera or performing factory resetting, you need to set up a login
username and password for the camera.
1. Download and install GV-IP Device Utility from the company
website.
2. On the GV-IP Device Utility window, click to search for your GV-
IP camera.
3. Double-click your GV-IP camera in the GV-IP Device Utility list. This
dialog box appears.
4. Click the Change Username and Password tab to type a new
username and password. Note that the new password must meet
the password strength requirements.
5. Optionally click Upgrade all devices to use the same username
and password on all other devices.
viii

Note for Installing Camera Outdoor
When installing the IR Arctic Box Camera outdoor, be sure that:
1. The camera is set up above the junction box to prevent water from
entering the camera along the cables.
2. Any PoE, power, audio and I/O cables are waterproofed using
waterproof silicon rubber or the like.
3. The silica gel bag loses its effectiveness when the dry camera is
opened. To prevent the lens from fogging up, replace the silica gel
bag every time you open the camera, and conceal the gel bag in
camera within 2 minutes of exposing to open air.
ix

x
Note for USB Storage and WiFi
Adapter
Mind the following limitations and requirements for using USB storage and
GV-WiFi Adapter:
1. The USB hard drive must be of 2.5’’ or 3.5’’, version 2.0 or above.
2. The USB hard drive’s storage capacity must not exceed 2TB.
3. USB flash drives and USB hubs are not supported.
4. External power supply is required for the USB hard drive.
5. To connect a GV-WiFi Adapter, make sure it is connected before the
camera is powered on.
Note for Silica Gel Bags
1. The silica gel bag loses its effectiveness when the dry camera is
opened. To prevent the lens from fogging up, replace the silica gel
bag every time you open the camera, and conceal the gel bag in
camera within 2 minutes of exposing to open air.
2. When the camera is shipped, a silica gel bag will be included inside
the camera. For the first-time user, replace the silica gel bag prior to
the installation to avoid foggy live view.

Box Camera
1
Chapter 1 Box Camera
The Box Camera is a series of indoor IP cameras consisting of fixed focal
and varifocal models in different resolutions. The Box Camera supports
lens replacement and features an automatic infrared-cut filter for day and
night surveillance. The super low lux models are capable of displaying
color live view in near darkness. Models equipped with a mini USB port
can be connected wirelessly through a GV-WiFi Adapter (optional). The
WDR Pro models can produce clear image for scenes with contrasting
intensity of lights. Models using P-Iris allow for precise control of exposure,
producing images with better clarity and contrast. The Box Camera models
are detailed below:
Box Camera
Model No. Specifications Description
GV-BX120D Auto Iris, f:2.8 ~ 12
mm, F/1.4, 1/3” CS
Lens
1.3 MP, H.264,
Low Lux, D/N
GV-BX130D-0
Varifocal
Lens Auto Iris, f: 2.8 ~ 12
mm, F/1.4, 1/3’’ CS
Lens
1.3 MP, H.264,
D/N
GV-BX130D-1 Fixed Lens Fixed Iris, f: 4 mm,
F/1.4, 1/3’’ CS Lens 1.3 MP, H.264, D/N
GV-BX140DW Fixed Iris, f: 2.8 ~ 12
mm, F/1.4, 1/3’’ CS
Lens
1 MP, H.264,
D/N, WDR Pro
GV-BX220D-2
Varifocal
Lens Auto Iris, f: 2.8 ~ 6
mm, F/1.3, 1/3’’ CS
Lens
2 MP, H.264,
D/N
1

Model No. Specifications Description
GV-BX220D-3 Varifocal
Lens
Auto Iris, f: 2.8 ~ 12
mm, F/1.4, 1/3’’ CS
Lens
2 MP, H.264,
D/N
GV-BX320D-0 Auto Iris, f:3.1 ~ 8
mm, F/1.2, 1/3” CS
Lens
GV-BX320D-1 Auto Iris, f: 2.8 ~ 6
mm, F/1.3, 1/3’’ CS
Lens
3 MP, H.264,
D/N
GV-BX520D
Varifocal
Lens
Manual Iris, f: 4.5 ~
10 mm, F/1.6, 1/2’’
CS Lens
5 MP, H.264,
D/N
GV-BX1200-0F 1.3 MP, H.264,
Low Lux, D/N
GV-BX1300-0F Fixed Lens Fixed Iris, f: 4 mm,
F/1.5, 1/3’’ CS Lens 1.3 MP, H.264,
D/N
GV-BX1200-1F 1.3 MP, H.264,
Low Lux, D/N
GV-BX1300-1F 1.3 MP, H.264,
D/N
GV-BX1500-1F 1.3 MP, H.264,
Super Low
Lux, D/N
GV-BX2400-1F 2 MP, H.264,
D/N, WDR Pro
GV-BX2500-1F 2 MP, H.264, Super Low
Lux, D/N
GV-BX3400-1F
Fixed Lens Fixed Iris, f: 8 mm,
F/1.6, 1/2.5’’ CS
Lens
3 MP, H.264,
D/N, WDR Pro
2

Box Camera
1
Model No. Specifications Description
GV-BX1200-2F 1.3 MP, H.264,
Low Lux, D/N
GV-BX1300-2F 1.3 MP, H.264,
D/N
GV-BX1500-2F 1.3 MP, H.264, Super Low
Lux, D/N
GV-BX2400-2F 2 MP, H.264,
D/N, WDR Pro
GV-BX2500-2F 2 MP, H.264,
Super Low
Lux, D/N
GV-BX3400-2F
Fixed Lens Fixed Iris, f: 12 mm, F/1.6, 1/2.5’’ CS
Lens
3 MP, H.264,
D/N, WDR Pro
GV-BX1200-3V 1.3 MP, H.264,
Low Lux, D/N
GV-BX1300-3V 1.3 MP, H.264,
D/N
GV-BX1500-3V 1.3 MP, H.264,
Super Low
Lux, D/N
GV-BX2500-3V
Auto Iris, f:2.8 ~ 12
mm, F/1.4, 1/2.7” CS
Lens
2 MP, H.264,
Super Low
Lux, D/N
GV-BX2600 Auto Iris, f:3 ~ 10.5 mm, F/1.4, 1/2.7” CS
Lens
2 MP, H.264,
Super Low
Lux, D/N,
WDR Pro
GV-BX3400-5V
Varifocal
Lens
Auto Iris, f: 2.8 ~ 6
mm, F/1.3, 1/3’’ CS
Lens
3 MP, H.264,
D/N, WDR Pro
3

Model No. Specifications Description
GV-BX5300-6V Varifocal
Lens
Auto Iris, f: 4.5 ~ 10
mm, F/1.6, 1/2’’ CS
Lens
5 MP, H.264,
D/N
GV-BX1500-8F 1.3 MP, H.264, Super Low
Lux, D/N
GV-BX2500-8F 2 MP, H.264,
Super Low
Lux, D/N
GV-BX3400-8F 3 MP, H.264,
D/N, WDR Pro
GV-BX5300-8F
Fixed Iris, f: 2.8 mm,
F/1.8, 1/2.5’’ CS
Lens
5 MP, H.264,
D/N
GV-BX4700-8F Fixed Iris, f: 2.8 mm, F/1.8, 1/2.5’’ CS
Lens
4 MP, H.265,
Super Low
Lux, D/N,
WDR Pro
GV-BX2700-8F Fixed Iris, f: 2.8 mm, F/1.8, 1/2.5’’ CS
Lens
2 MP, H.265,
Super Low
Lux, D/N,
WDR Pro
GV-BX5700-8F
Fixed Lens
Fixed Iris, f: 2.95
mm, F/2.0, 1/1.8’’ CS
Lens
5 MP, H.265,
Low Lux, D/N,
WDR
GV-BX12201 Varifocal
Lens
DC drive Iris, f: 4.1 ~
9 mm, F/1.6, 1/1.8”
CS Lens
12 MP, H.264,
D/N
4

Box Camera
1
P-Iris Models
Model No. Specifications Description
GV-BX1500-3V 1.3 MP, H.264,
Super Low Lux, D/N
GV-BX2500-3V 2 MP, H.264, Super
Low Lux, D/N
GV-BX3400-3V
P-Iris, f: 3 ~ 10.5
mm, F/1.4, 1/2.5”
CS Lens
3 MP, H.264, D/N,
WDR Pro
GV-BX2700-3V P-Iris, f: 3 ~ 10.5 mm, F/1.4, 1/2.7”
CS Lens
2 MP, H.265, Super
Low Lux, D/N, WDR
Pro
GV-BX4700-3V P-Iris, f: 3 ~ 10.5 mm, F/1.4, 1/2.7”
CS Lens
4 MP, H.265, Super
Low Lux, D/N, WDR
Pro
GV-BX5300-6V
Varifocal
Lens
P-Iris, f: 3.3 ~ 10.5
mm, F/1.4, 1/2.5’’
CS Lens 5 MP, H.264, D/N
GV-BX5700-3V P-Iris, f: 3.6 ~ 10 mm, F/1.5, 1/1.8”
CS Lens
5 MP, H.265, Low
Lux, D/N, WDR
5

1.1 Packing List
1.1.1 For H.265 Cameras
•Box Camera
•Terminal Block (2-Pin and 3-Pin)
•Fixed Focal or Varifocal Megapixel Lens
•Six Lens Rings (only for Varifocal Lens)
•Video Out Wire
•Camera Holder
•Holder Screw x 2
•Download Guide
•Warranty Card
6

Box Camera
1
1.1.2 For H.264 Cameras
•Box Camera
•Terminal Block (2-Pin and 3-Pin)
•Fixed Focal or Varifocal Megapixel Lens
•Six Lens Rings (only for Varifocal Lens)
•Video Out Wire
•Camera Holder
•Holder Screw x 2
•Power Adapter
•Download Guide
•Warranty Card
Note: The power adapter can be excluded upon request.
7

1.2 Overview
1.2.1 GV-BX120D / 130D Series / 140DW / 220D Series /
Series / 520D320D
12 3 4 5 6
7 8 9 10
12 13
14
16
15
11
Figure 1-1
Note:
1. The Auto Iris connector (No. 7) is only functional in GV-BX120D,
GV-BX130D-0, GV-BX220D and GV-BX320D.
2. The Light Sensor (No.11) is only available in GV-BX140DW. Keep
the Light Sensor unobscured for accurate light detection.
3. The Iris Screw (No.13) is only available for GV-BX520D.
4. The Zoom Screw (No. 15) is not available for GV-BX130D-1.
No. Name Description
1 Video Out Connects to a portable monitor for setting the
focus and angle of Box Camera during initial
installation.
2 Memory Card
Slot Inserts a micro SD card (SD/SDHC, version 2.0 only, Class 10) to store recording data.
8
