Note for Connecting to GV-VMS / DVR / NVR
The camera is designed to work with and record on GV-DVR / NVR / VMS, a video
management system.
Once the camera is connected to the GV-DVR / NVR / VMS, the resolution set on the GV-DVR
/ NVR / VMS will override the resolution set on the camera’s Web interface. You can only
change the resolution settings through the Web interface when the connection to the GV-DVR
/ NVR / VMS is interrupted.
Face Recognition is only supported by GV-VMS. When applying Face Recognition, one
camera can only be connected to one GV-VMS at a time.

iii
Note for Recording
1. By default, the recording function is disabled. Configure the function in the camera’s Web
interface to record alarm events to the memory card inserted in the camera upon
disconnection from GV-DVR / NVR / VMS. See 4.4.3 Tools, GV-Face Recognition Camera
User’s Manual for details.
2. Mind the following when using a memory card for recording:
Recorded data on the memory card can be damaged or lost if the data are accessed
while the camera is under physical shock, power interruption, memory card
detachment or when the memory card reaches the end of its lifespan. No guarantee is
provided for such causes.
The stored data can be lost if the memory card is not accessed for a long period of
time. Back up your data periodically if you seldom access the memory card.
Memory cards are expendable and their durability varies according to the conditions of
the installed site and how they are used. Back up your data regularly and replace the
memory card annually.
Replace the memory card when its read/write speed is lower than 6 MB/s or when the
memory card is frequently undetected by the camera.
To avoid power outage, it is highly recommended to apply a battery backup (UPS).
3. For better performance, it is highly recommended to use memory cards of the following
specifications:
Micro SD card of MLC NAND flash, Class 10.

iv
Note for Installing Camera Outdoor
When installing the camera outdoor, be sure that:
1. The camera is set up above the junction box to prevent water from entering the camera
along the cables.
2. Any PoE, power, audio and I/O cables are waterproofed using waterproof silicon rubber
or the like.
3. The screws are tightened and the cover is in place after opening the camera cover.

1
1. Introduction
Welcome to the GV-Face Recognition Camera Quick Start Guide. In the following
sections, you will learn the basic installations and configurations. For a detailed user
manual, see GV-Face Recognition Camera User’s Manual.
1.1 Packing List
1.1.1 GV-VD8700
GV-VD8700 Camera
Screw x 4
Screw Anchor x 4
Audio Wire x 2
I/O Cable
RJ-45 Connector
Installation Sticker
Waterproof Rubber Sets (for RJ-45
Cat.5 and DC12V / for RJ-45 Cat. 6)
PG21 Conduit Connector
Torx Wrench
Big Concave Hexagon Wrench
Small Concave Hexagon Wrench
Silica Gel Bag
Sticker (for Silica Gel Bag)
Conduit Converter
Ruler
8 GB Micro SD Card (MLC, SDHC, Class 10)
(The Micro SD Card is preinstalled and
formatted in the camera)
Download Guide
Warranty Card
1.1.2 GV-FD8700-FR
GV-FD8700-FR Camera
Screw x 3
Screw Anchor x 3
I/O Cable
Audio Wire x 2
Torx Wrench
Installation Sticker
8 GB Micro SD Card (MLC, SDHC, Class 10)
(The Micro SD Card is preinstalled and
formatted in the camera)
Download Guide
Warranty Card

Introduction
2
1
1.2 Optional Accessories
Optional devices can expand your camera’s capabilities and versatility. Contact our
sales representatives for more information.
Name Details
GV-Mount Accessories The GV-Mount Accessories provides a comprehensive
lineup of accessories for installing the camera on
ceiling, wall corner and pole. For details, see GV-Mount
Accessories Installation Guide.
GV-PA191 PoE Adapter
The GV-PA191 is a Power over Ethernet (PoE) adapter
designed to provide power to the IP device through a
single Ethernet cable.
GV-PoE Switch The GV-PoE Switch is designed to provide power along
with network connection for IP devices. The GV-PoE
Switch is available in various models with different
numbers and types of ports.
GV-Relay V2 The GV-Relay V2 is designed to expand the voltage
load of GV IP devices. It provides 4 relay outputs, and
each can be set as normally open (NO) or normally
closed (NC) independently as per your requirement.
Metal PG21 Conduit
Connector (only for
GV-VD8700)
The metal PG21 conduit connector allows you to run the
wires through a 3/4” conduit pipe.
Power Adapter Contact our sales representatives for the countries and
areas supported.

3
1.3 Overview
12 3 45
7
912
8
14
10 11 13
6
15

Introduction
4
1
No. Name Description
1 LED Indicators
The power LED (top) turns on when the power is on
and turns off when there is no power supply. The
status LED (bottom) turns on when the system
operates normally and turns off when an error occurs.
2 Audio Out Currently not functional.
3 Line In
Connects to a microphone for audio input.
Note: This interface only works with an external
microphone with powered supply.
4 LAN / PoE Connects to a 10/100 Ethernet or PoE.
5 DC 12V Connects to power.
6 Rotational Screw Loosens to rotate the camera.
7 Conduit Connector
Waterproofs the Ethernet cable.
Note: Not available for GV-FD8700-FR.
8 Default Button
Resets the camera to factory default settings. For
details, see Chapter 7 Restoring to Factory Default
Setting.
9 Focus Screw Adjusts the focus of the camera.
10 Zoom Screw Zoom the camera in or out.
11 Tilt Screw Loosens the screw to tilt the camera.
12 I/O Connector Connects to I/O devices.
13 Built-in Microphone
Connectors
Connects to a built-in microphone. For details, see
Chapter 3 Connecting the Camera.
Note: Not available for GV-FD8700-FR.
14 Conduit Connector
Waterproofs the audio / I/O wires.
Note: Not available for GV-FD8700-FR.
15 Memory Card Slot Contains a micro-SD card (SD/SDHC/SDXC/UHSI,
Class 10) to store recording data.

5
1.4 Installation Flowchart
See the flowchart for a clear idea of the installation process before proceeding to
Chapter 2 Installation. Refer to the relevant sections in the User’s Manual if needed.

6
2. Installation
This section introduces the standard installations of the cameras.
Note:
1. An improper installation location can affect face recognition results. For optimal face
recognition results, follow the recommended guidelines to install the camera. For
details, see 5.1 Ideal Camera Position.
2. You can also install the camera on ceilings, wall corners (concave or convex), and
poles. For details on these installations, see GV-Mount Accessories Installation
Guide.
2.1 GV-VD8700
The camera is designed for outdoors. With the standard package, you can install the
camera on the ceiling.
1. Remove the housing cover with the supplied torx wrench.

7
2. Optionally remove the cables that attach the built-in microphone to the camera to
assist with installation.
Cables for built-in microphone
3. Remove the back plate with the supplied torx wrench and remove the safety lock
with a Philips screwdriver. Keep the removed screw for later use.
Safety loc
k
4. Thread wires into the camera.
A. Rotate to remove the cap of the conduit connector.

Installation
8
2
B. Unplug the conduit connector inside the housing and disintegrate the
connector. You should have 3 parts:
C. Thread the audio wires and I/O wires through the conduit entry and then
through parts 1, 2, and 3 of the conduit connector.
Tip:
1. To make the threading easier, it is recommended to thread the wires in the
order described in Step 4-C.
2. Use a pair of pliers to help you pull the wires through the camera.
If you use cat 5 Ethernet cable, there are 5 holes each labeled with its diameter. Remove
the plugs and push the wires to the corresponding hole listed below:
Plug
3.2 mm: Audio
1.9 mm: DIDO

9
IMPORTANT:
1. Use the supplied ruler and leave at least 14 cm of I/O wires and 10 cm of audio
wires between their connectors on the camera and the conduit connector.
2. The plugs are used to prevent water from entering the camera housing. Keep
the unused holes plugged and save the removed plugs for future use.
3. Only thread the wires through their designated holes on the conduit connector
to make sure the wires are properly sealed.
If you use cat 6 Ethernet cable, thread the DC 12V wires through the conduit connector.
Refer to the following for the corresponding holes and their diameters.
3.2 mm: Audio
1.9 mm: DIDO
1.9mm: DC 12V
IMPORTANT: Leave more than 10 cm of power wires between their connectors
on the camera and the conduit connector.

Installation
10
2
5. Install the Ethernet cable.
A. Rotate to remove the indicated cap and the plug inside.
B. Thread an Ethernet cable (the end with no RJ-45 connector) and the optional
power adapter wires from the back panel through the conduit connector.
IMPORTANT: Use the supplied ruler and leave about 14 cm of the Ethernet cable
between the connector on the camera and the conduit connector.
C. Re-install the cap. Make sure the cap is installed tightly to waterproof the
camera.

11
6. Connect the wires to the camera. For details, see Chapter 3 Connecting the
Camera.
Tip: Unscrew the indicated screws and lift the camera to help you connect the
wires and insert the memory card.
7. Sort out the wires at the back. You can have the wires come out from positions A
and B or from C.
AB
C

Installation
12
2
8. Secure the back plate to the ceiling.
A. Paste the sticker to the ceiling. The arrow on the sticker indicates the
direction that the camera faces.
B. Drill 4 holes for screws. The recommended ones are indicated as ‘1’.
C. Insert the screw anchors to the 4 holes.
D. Drill holes A & B or only hole C for sorting out the wires according to the
figure in Step 7.
E. Secure the back plate to the ceiling with the supplied screws.
9. Secure the camera to the desired location.
A. Secure the safety lock to the camera with the screw you removed from the
back plate in Step 2.
Safety lock
B. Thread all the wires into the ceiling and connect them.
C. Secure the camera to the back plate with the torx wrench.
10. Access the live view. For details, see Chapter 4 Accessing the Camera.

13
11. Adjust the angle, focus and zoom of the camera.
Pan Adjustment Tilt Adjustment
Rotational Adjustment
Zoom Adjustment
Loosen the screw
Focus Adjustment
Loosen the screw
12. Replace the silica gel bag, organize the wires and secure the camera cover with
the torx wrench.
Organize
the wires
to avoid
blocking
the lens

Installation
14
2
2.2 GV-FD8700-FR
The camera is designed for indoors. With the standard package, you can install the
camera on the ceiling or the wall. Before installation, make sure the installing site is
shielded from rain and moisture.
1. Use the supplied torx wrench to loosen three screws on the housing cover, and
take out the camera body.
2. Place the installation sticker where you want to install it, and make 3 marks on the
ceiling or the wall for screw anchors
3. Drill the marks and insert the screw anchors.
4. Connect the camera to network and power. For details, see 1.5 Connecting the
Camera.
5. Secure the camera to the ceiling or the wall with the supplied screws.
6. Access the live view. For details, see Chapter 4 Accessing the Camera.
7. Loosen the tile screw, pan screw or rotational screw. Adjust the angles based on
the live view as needed, and tighten the screws again. See Step 11, 2.1
GV-VD8700 for illustrations.
