GeoVision GV-IP LPR Camera 5R User manual

Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
User's Manual
GV-IP LPR Camera 5R /
GV-Hybrid LPR Camera 10R
LPRCAM5RV10-10RV102-A

© 2013 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in part, without the
written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is accurate.
GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no
responsibility for errors or omissions. No liability is assumed for incidental or consequential
damages arising from the use of the information or products contained herein. Features and
specifications are subject to change without notice.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: [phone]
Fax: [phone]
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV series products are
trademarks of GeoVision, Inc. Windows and Windows XP are registered trademarks of
Microsoft Corporation.
September 2013

i
Preface
Welcome to the GV-Hybrid LPR Camera 10R / GV-IP LPR Camera 5R User’s Manual.
The GV-IP LPR Camera has a series of models designed to meet different needs. This
manual is designed for the following models and firmware versions:
Models Firmware Version
GV-Hybrid LPR Camera 10R 1.02
GV-IP LPR Camera 5R 1.0

ii
Contents
Naming Definition..................................................................................................... v
Options .................................................................................................................... v
Note for Connecting to GV-System......................................................................... v
Note for Installing Camera Outdoor....................................................................... vi
Chapter 1 Introduction........................................................................................... 1
1.1 GV-Hybrid LPR Camera 10R....................................................................................1
1.1.1 Features........................................................................................................2
1.1.2 System Requirements ..................................................................................3
1.1.3 Packing List ..................................................................................................4
1.1.4 Overview.......................................................................................................5
1.1.5 Device Installation.........................................................................................6
1.1.6 Connecting the Camera..............................................................................10
1.2 GV-IP LPR Camera 5R...........................................................................................12
1.2.1 Features......................................................................................................13
1.2.2 System Requirements ................................................................................14
1.2.3 Packing List ................................................................................................15
1.2.4 Overview.....................................................................................................16
1.2.5 Device Installation.......................................................................................17
1.2.6 Connecting the Camera..............................................................................18
1.2.7 Adjusting the Angles...................................................................................19
1.2.8 Replacing the Silica Gel Bag......................................................................22
1.2.9 Installing the Sun-Shield Cover ..................................................................23
Chapter 2 Getting Started.................................................................................... 24
2.1 Looking Up the IPAddress.....................................................................................24
2.2 Accessing Your Surveillance Images......................................................................27
2.3 Configuring the Basics............................................................................................28
Chapter 3 Guest Mode and Live View Panel...................................................... 29
3.1 The Live View Window...........................................................................................30
3.2 The Control Panel of the Live View Window ..........................................................32
3.3 Snapshot of a Live Video........................................................................................35
3.4 Video Recording.....................................................................................................35
3.5 Picture-in-Picture and Picture-and-Picture View.....................................................36
3.6 Alarm Notification ...................................................................................................38
3.7 Video and Audio Configuration...............................................................................39
3.8 Remote Configuration.............................................................................................40
3.9 Camera Name Display ...........................................................................................40

iii
3.10 Image Enhancement ............................................................................................40
Chapter 4 Administrator Mode............................................................................ 41
4.1 Video & Motion.......................................................................................................43
4.1.1 Video Settings.............................................................................................44
4.1.2 Motion Detection.........................................................................................49
4.1.3 Privacy Mask ..............................................................................................50
4.1.4 Text Overlay................................................................................................51
4.1.5 Tampering Alarm.........................................................................................52
4.2 Events & Alerts .......................................................................................................54
4.2.1 E-mail..........................................................................................................55
4.2.2 FTP.............................................................................................................57
4.2.3 Center V2....................................................................................................59
4.2.4 VSM............................................................................................................61
4.2.5 Backup Center............................................................................................63
4.2.6 GV-Video Gateway / GV-Recording Server................................................65
4.2.7 ViewLog......................................................................................................67
4.2.8 RTSP..........................................................................................................68
4.3 Monitoring...............................................................................................................69
4.3.1 GV-Hybrid LPR Camera 10R......................................................................69
4.3.2 GV-IP LPR Camera 5R...............................................................................70
4.4 Recording Schedule...............................................................................................71
4.4.1 Recording Schedule Settings .....................................................................71
4.5 Network ..................................................................................................................72
4.5.1 LAN Configuration ......................................................................................72
4.5.2 Advanced TCP/IP .......................................................................................74
4.5.3 IP Filtering...................................................................................................78
4.5.4 SNMP Settings ...........................................................................................79
4.6 Management...........................................................................................................81
4.6.1 Date and Time Settings ..............................................................................81
4.6.2 GPS Maps Settings ....................................................................................83
4.6.3 Storage Settings .........................................................................................85
4.6.4 User Account ..............................................................................................88
4.6.5 Log Information...........................................................................................89
4.6.6 System Log.................................................................................................90
4.6.7 Tools ...........................................................................................................92
4.6.8 Language....................................................................................................94
Chapter 5 Advanced Applications...................................................................... 95
5.1 Upgrading System Firmware..................................................................................95

iv
5.1.1 Using the Web Interface .............................................................................96
5.1.2 Using the GV-IP Device Utility....................................................................97
5.2 Backing Up and Restoring Settings......................................................................100
5.3 Restoring to Factory Default Settings...................................................................102
5.3.1 Using the Web Interface ...........................................................................102
5.3.2 Directly on the Camera.............................................................................102
5.4 Verifying Watermark .............................................................................................103
5.4.1 Accessing AVI Files ..................................................................................103
5.4.2 Running Watermark Proof ........................................................................103
5.4.3 The Watermark Proof Window..................................................................104
Chapter 6 DVR Configurations ......................................................................... 105
6.1 Setting Up IP Cameras.........................................................................................107
6.1.1 Customizing Camera Settings..................................................................110
6.2 Remote Monitoring with Multi View ...................................................................... 112
6.3 Remote Monitoring with E-Map............................................................................ 114
Chapter 7 CMS Configurations..........................................................................116
7.1 Center V2 ............................................................................................................. 116
7.2 VSM...................................................................................................................... 118
7.3 Dispatch Server.................................................................................................... 119
Chapter 8 Smart Device Connection ..................................................................... 120
8.1 Android.................................................................................................................121
8.1.1 Connecting to the Camera........................................................................121
8.1.2 Accessing Live View.................................................................................123
8.2 Apple ....................................................................................................................125
8.2.1 Connecting to the Camera........................................................................126
8.2.2 Accessing Live View.................................................................................127
Specifications ....................................................................................................... 129
GV-Hybrid LPR Camera 10R........................................................................................129
GV-IP LPR Camera 5R .................................................................................................133
Appendix............................................................................................................... 136
A. The CGI Command...................................................................................................136
B. RTSP Protocol Support.............................................................................................137
C. Settings for Internet Explorer 8 or later.....................................................................138

v
Naming Definition
GV-System
GeoVisionAnalog and Digital Video Recording Software. The
GV-System also refers to Multicam System, GV-NVR System,
GV-DVR System and GV-Hybrid DVR System at the same time.
Options
Optional devices can expand your camera’s capabilities and versatility. Contact your dealer
for more information.
Device Description
GV-PA191 PoE
Adapter
The GV-PA191 PoE adapter is designed to provide power and
network connection to the cameras over a single Ethernet cable. The
GV-PA191 PoE adapter is only available for GV-IP LPR Camera 5R.
GV-Mount
Accessories
The GV-Mount Accessories allows you to install GV-Hybrid LPR
Camera 10R / GV-IP LPR Camera 5R on the wall corner and pole.
For details, see Installing the Arctic Box Camera / Installing the Bullet
Camera, GV-Mount Accessories Installation Guide on the GV-IP LPR
Camera Software DVD.
Note for Connecting to GV-System
The GV-Hybrid LPR Camera 10R / GV-IP LPR Camera 5R is designed to work with and
record on GV-System, a hybrid or digital video management system.
Once the camera is connected to the GV-System, the resolution set on the GV-System will
override the resolution set on the camera’s Web interface. You can only change the resolution
settings through the Web interface when the connection to the GV-System is interrupted.

vi
Note for Installing Camera Outdoor
When installing the GV-Hybrid LPR Camera 10R / GV-IP LPR Camera 5R outdoor, mind the
following:
1. Set the camera above the junction box to prevent water from entering the camera along
the cables.
2. Waterproof the PoE, power and TV-out cables with waterproof silicon rubber or the like.
3. To prevent the lens from fogging up, replace the silica gel bag every time you open the
camera, and conceal the gel bag in camera within 2 minutes of exposing to open air. The
silica gel bag loses it effectiveness when the dry camera is opened.
4. For each newly replaced silica gel bag, allow it to absorb moisture for at least 5 hours
before operating the camera.
5. The camera casing can be hot due to its IR LED. Make sure you unplug the power cable
and allow the camera casing to cool down before handling the camera.

Chapter 1 Introduction
1.1 GV-Hybrid LPR Camera 10R
The GV-Hybrid LPR Camera 10R is a 1.3 MP B/W network camera designed solely for
recognition of reflective license plates on vehicles traveling at 120 km/hr (75 mph) or less.
With its high-power LEDs and intelligent IR, the camera is able to automatically adjust its
shutter speed to the scene and produce clear license plate capture under low-light conditions.
Under certain conditions, the GV-Hybrid Camera 10R can capture up to two lanes in a single
shot. It is also able to work in environments with extreme temperatures from as low as -40°C
(-40°F) up to 50°C (122°F).
The GV-Hybrid LPR Camera 10R can be easily configured through its Web interface and you
can record and play back recordings using the free GV-NVR software included in the standard
package.

2
1.1.1 Features
1.3 megapixel B/W progressive scan CMOS
Dual streams from MJPEG or H.264
Up to 30 fps at 1280 x 1024
Recognition for reflective License Plate only
Maximum Speed 120 km/h (75 mph)
Ingress protection (IP67)
Vandal Resistance (IK10)
Built-in heater and fan
Support for TV-out
Two-way audio
Defog
Motion detection
Tampering alarm
Privacy mask
Text overlay
IP address filtering
Power supplied through PoE (IEEE 802.3 at)
Support for iPhone, iPad, Android and 3GPP
ONVIF (Profile S) conformant
31 languages on Web interface

Introduction
3
1
1.1.2 System Requirements
To access the camera functions and settings through Web browser, ensure your PC is in good
network connection and use one of the following Web browsers:
Microsoft Internet Explorer 7.x or later
Google Chrome
Mozilla Firefox
Safari
Note:
1. For users of Internet Explorer 8 or later, additional settings are required. For details,
see Appendix C.
2. With non-IE browsers,
A. Motion Detection, Text Overlay, two-way audio and GPS map settings are not
supported.
B. The Play function is only available on the live view window (Figure 3-2).
C. RTSP streaming must be kept as enabled. For more details, see 4.3.8 RTSP /
3GPP.

4
1.1.3 Packing List
GV-Hybrid LPR Camera 10R
Screw Anchor x 4
Screw x 4
Washer x 4
Big Torx Wrench
Small Torx Wrench
Sun-Shield Cover x 1
Silica Gel Bag x 2 (1 already installed)
Sticker x 2
GV-PA481 PoE Adapter
GV-PA481 Power Cord
GV-LPR Capture Dongle
GV-IP LPR Camera Software CD
GV-NVR Software DVD
GV-ASManager Software DVD

Introduction
5
1
1.1.4 Overview
To access the functional panel of the GV-Hybrid LPR Camera 10R, follow the section below to
remove its camera cover first.
1 2
45
3
Figure 1-1
No. Name Description
1 IR power plug Supplies power to the built-in IR LEDs.
2 Status LED Turns on when the unit is ready for use.
3 Silica gel bag Keeps the camera housing dry.
4 Zoom Screw Adjusts the zoom of the camera.
5 Focus Screw Adjusts the focus of the camera.

6
1.1.5 Device Installation
1.1.5.1 Installation Guidelines
To produce quality image and to avoid software recognition errors, make sure you adhere to
the guidelines when installing your GV-Hybrid LPR Camera 10R. See GV-LPR Camera
Installation Guide.
1.1.5.2 Installing the Camera
After you have read through the installation guides and chosen an installation site, follow the
steps below to install the GV-Hybrid LPR Camera 10R.
1. Mark the installation site and drill four holes for screw anchors.
2. Insert the supplied screw anchors.
3. Secure the camera to the wall using the supplied washers and screws.
Figure 1-2
4. Connect the camera to the network and supply power via the PoE cable. See 1.6
Connecting the Camera.
5. Access the live view. See 2.1 Accessing the Live View.

Introduction
7
1
6. Based on the live view, adjust the angle of the camera. Loosen the indicated screw with
the supplied big torx wrench and adjust the joint.
Figure 1-3
Tilt Adjustment
Figure 1-4
Pan Adjustment
Figure 1-5

8
7. Based on the live view, adjust the focus and zoom of the camera.
A. Unscrew the cover with the supplied small torx wrench.
Figure 1-6
B. Hold the connectors and unplug them.
Figure 1-7
Important:
1. Unscrew and remove the cover carefully. Pulling the cover off may cause damages to
the inner wiring of the camera.
2. To prevent the live view from being darkened when the cover is removed, see LPR
Setting in 4.1.1 Video Setting.
C. Adjust the focus and zoom.
Figure 1-8

Introduction
9
1
8. Replace the silica gel bag. Paste the sticker to the front side of the silica gel bag. Press
the sticker several times to make sure it adheres properly. Paste the silica gel bag to the
indicated place.
Figure 1-9
Important:
1. Be sure that the silica gel bag is concealed in the camera housing within 2 minutes of
exposing to open air.
2. To prevent the lens from fogging up, you must replace the silica gel bag every time you
open the camera. The gel bag loses its effectiveness when the dry camera is opened.
3. For each newly replaced silica gel bag, allow it to absorb moisture for at least 5 hours
before operating the camera.
9. Refer to step 7 to plug the connectors and secure the camera cover.

10
1.1.6 Connecting the Camera
Follow the steps below to connect your GV-Hybrid LPR Camera 10R.
1. Optionally connect a speaker to the green RCA wire and an external microphone to the
pink RCA wire.
2. Optionally connect a monitor to the black BNC wire. Enable the TV-Out function by
selecting the correct signal format at the TV Out field on the Web interface. See 4.1.1
Video Settings.
3. Connect the camera’s cable to the GV-PA481 PoE adapter as illustrated below. The
power and network will be supplied simultaneously.
Figure1-10
4. When the status LED of the camera is on, .you are ready to access the live view, adjust
the image clarity and configure the basics. See Getting Started, Chapter 2.

Introduction
11
1
1.1.6.1 Wire Definition
Figure 1-11
No. Wire Color Definition
1 Black (thick) PoE
2 Black BNC TV out
3 Green RCA Audio Out
4 Pink RCA Audio In

12
1.2 GV-IP LPR Camera 5R
Ideal for parking lot installation, the GV-IP LPR Camera 5R is a 1.3 MP B/W network camera
designed for recognition of reflective license plates on vehicles traveling at 60 km/hr (37 mph)
or less. With its multiple LEDs and intelligent IR, the camera is able to automatically adjust its
shutter speed to the scene and produce clear license plate capture under low-light conditions.
The motorized varifocal lens take the advantage of its motorized focus / zoom in that the user
can remotely adjust the focus and zoom through the Web interface. It is weather proof (IP67)
and also able to work in environments with temperatures ranging from -10°C (14°F) to 50°C
(122°F).
The GV-IP LPR Camera 5R can be easily configured through its Web interface and you can
record and play back recordings using the free GV-NVR software included in the standard
package.
