GeoVision GV-IPCam H.264 Series User manual

Hardware Manual
GV-IPCam H.264
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Vandal Proof IP Dome
ICH264TIV301

© 2015 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in
part, without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any
kind and assumes no responsibility for errors or omissions. No liability is
assumed for incidental or consequential damages arising from the use of
the information or products contained herein. Features and specifications
are subject to change without notice. Note: no memory card slot or local
storage function for Argentina.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: [phone]
Fax: [phone]
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc. Windows and Windows
XP are registered trademarks of Microsoft Corporation.
April 2015

Content
Content ................................................................................i
Options ..............................................................................iii
Note for Adjusting Focus and Zoom............................... v
Note for Installing Camera Outdoor............................... vi
Chapter 1 Vandal Proof IP Dome (Part I) ........................1
1.1 Packing List ..............................................................................3
1.2 Features ...................................................................................4
1.3 Overview ..................................................................................6
1.4 Installation ................................................................................8
1.4.1 Hard-Ceiling Mount ......................................................9
1.4.2 In-Ceiling Mount.........................................................15
1.5 Connecting the Camera..........................................................18
1.5.1 Wire Definition ...........................................................18
1.5.2 Power Connection......................................................20
1.5.3 Voltage Load Expansion (Optional)............................21
1.6 Loading Factory Default..........................................................22
Chapter 2 Vandal Proof IP Dome (Part II) .....................23
2.1 Packing List ............................................................................25
2.2 Features .................................................................................28
2.3 Overview ................................................................................30
i

2.4 Installation ..............................................................................32
2.4.1 Installation of Weatherproof Shield.............................43
2.5 Connecting the Camera..........................................................45
2.5.1 Power Connection......................................................45
2.5.2 I/O Device Connections .............................................45
2.6 Loading Factory Default..........................................................47
ii

Options
Optional devices can expand your camera’s capabilities and versatility.
Contact your dealer for more information.
Device Description
Power Adapter
The power adapter is available for all Vandal Proof
IP Dome. The supported regions are listed below:
•GV-VD120D / 121D / 122D / 123D / 220D /
221D / 222D / 223D / 320D / 321D / 322D /
323D / 2400 / 3400 (except GV-VD1500 /
2500): Australia, Europe, U.K, U.S.A
•GV-VD1500 / 2500: Australia, Brazil, Europe,
U.K, U.S.
•GV-VD1530 / 1540 / 1540-E / 2430 / 2440 /
2440-E / 2530 / 2540 / 2540-E / 3430 / 3440 /
3440-E / 5340 / 5340-E: Argentina, Australia,
Brazil, Europe, U.K and U.S. Note that power
cord is not supplied with the power adapter for
these models.
GV-PA191 PoE
Adapter
The GV-PA191 PoE adapter is designed to provide
power and network connection to the cameras over
a single Ethernet cable.
GV-POE Switch
The GV-POE Switch is designed to provide power
along with network connection for IP devices. The
GV-POE Switch is available in various models with
different numbers and types of ports.
GV-Mount
Accessories
The GV-Mount Accessories provide a
comprehensive lineup of accessories for installation
on ceiling, wall corner and pole. For details, see GV-
Mount Accessories Installation Guide on the
Software DVD.
iii

Device Description
GV-Relay V2
The GV-Relay V2 is designed to expand the voltage
load of GV IP devices. It provides 4 relay outputs,
and each can be set as normally open (NO) or
normally closed (NC) independently as per your
requirement.
Metal PG21
Conduit
Connector
The metal PG21 conduit connector is used for
running the wires of GV-VD1530 / 2430 / 2530 /
3430, GV-VD1540 / 2440 / 2540 / 3440 / 5340 and
GV-VD2540-E / 5340-E through a 3/4” conduit pipe.
Weatherproof
Shield
The weatherproof shield is made for GV-VD1530 /
2430 / 2530 / 3430, GV-VD1540 / 2440 / 2540 /
3440 / 5340, and GV-VD2540-E / 5340-E to protect
the camera from rain and snow.
iv

Note for Adjusting Focus and Zoom
When adjusting the Focus and Zoom Screws, do not over tighten the
Focus and Zoom screws. The screws only need to be as tight as your
finger can do it. It is not necessary to use any tools to get them tighter.
Doing so can damage the structure of lens.
The maximum torque value for all the zoom and focus screws is 0.049 N.m
v

Note for Installing Camera Outdoor
When installing the camera outdoor, be sure that:
1. The camera is set up above the junction box to prevent water from
entering the camera along the cables.
2. Any PoE, power, audio and I/O cables are waterproofed using
waterproof silicon rubber or the like.
vi

3. After opening the camera cover, ensure the screws are tightened
and the cover is in place.
4. The silica gel bag loses its effectiveness when the dry camera is
opened. To prevent the lens from fogging up, replace the silica gel
bag every time you open the camera, and conceal the gel bag in
camera within 2 minutes of exposing to open air.
vii

Vandal Proof IP Dome (Part I)
1
Chapter 1 Vandal Proof IP Dome
(Part I)
The Vandal Proof IP Dome is a series of outdoor camera designed for
vandal protection. They are equipped with automatic infrared cut filters and
IR LED for day and night surveillance. The WDR Pro models can produce
clear image for scenes containing contrasting intensity of lights. The super
low lux models can display color live view in near darkness. For related
models, see 1.2 Features.
These Vandal Proof IP Domes can be installed on wall and ceiling using
the standard package. They can also be installed on wall corners and
poles using the GV-Mount accessories (optional). For more details, see
GV-Mount Accessories Installation Guide on the Software DVD.
Model No. Specification Description
GV-VD120D
(IK10+, Transparent Cover)
GV-VD121D
(IK10+, Smoked Cover)
GV-VD122D
(IK7, Transparent Cover)
GV-VD123D
(IK7, Smoked Cover)
Varifocal
Lens
Auto Iris, f:3 ~ 9
mm, F/1.3, 1/2.7”
ø 14 mm lens
mount
1.3 MP Low
Lux, H.264,
Vandal Proof IP
Dome
1

Model No. Specification Description
GV-VD220D
(IK10+, Transparent Cover)
GV-VD221D
(IK10+, Smoked Cover)
GV-VD222D
(IK7, Transparent Cover)
GV-VD223D
(IK7, Smoked Cover)
2 MP, H.264,
Vandal Proof IP
Dome
GV-VD320D
(IK10+, Transparent Cover)
GV-VD321D
(IK10+, Smoked Cover)
GV-VD322D
(IK7, Transparent Cover)
GV-VD323D
(IK7, Smoked Cover)
Varifocal
Lens
Auto Iris, f:3 ~ 9
mm, F/1.3, 1/2.7”
ø 14 mm lens
mount
3 MP, H.264,
Vandal Proof IP
Dome
GV-VD1500
(IK10+, Transparent Cover)
GV-VD2500
(IK10+, Transparent Cover)
1.3 MP / 2 MP
Super Low Lux,
Vandal Proof IP
Dome
GV-VD2400
(IK10+, Transparent Cover)
GV-VD3400
(IK10+, Transparent Cover)
Varifocal
Lens
Auto Iris, f:3 ~ 9
mm, F/1.2, 1/2.7”
ø 14 mm lens
mount
2 MP / 3 MP,
H.264, WDR
Pro, Vandal
Proof IP Dome
2

Vandal Proof IP Dome (Part I)
1
1.1 Packing List
•Vandal Proof IP Dome •Silica Gel Bag x 2
•Screw Anchor x 4
•Torx Wrench
•Ceiling Screw x 4
•Blue Screw x 3
•T-Cap Screw x 3
•Small Screw Cap x 3
•T-Cap x 3
•Plastic Clip x 3
•Focus Adjustment Cap
•2-Pin Terminal Block
•Power Adapter
•GV-NVR Quick Start Guide
•GV-IPCAM H.264 Quick
Start Guide
•GV-NVR Software DVD
•GV-IPCAM H.264 Software
DVD
Note:
1. Focus Adjustment Cap is only needed and supplied for IK10+
models.
2. The power adapter can be excluded upon request.
3

1.2 Features
•Image sensor
Camera Model Image Sensor
GV-VD120D / 121D / 122D /
123D
1/3" progressive scan low lux
CMOS
GV-VD1500 1/3’’ progressive scan super low
lux CMOS
GV-VD2500 1/2.8’’ progressive scan super
low lux CMOS
GV-VD2400 / 3400 1/3.2" progressive scan CMOS
GV-VD220D / 221D / 222D /
223D
GV-VD320D / 321D / 322D /
323D
1/2.5’’ progressive scan CMOS
•Dual streams from H.264 or MJPEG
•Frame rate
Camera Model Frame Rate
GV-VD120D / 121D / 122D /
123D / 1500
Up to 30 fps at 1280 x 1024
GV-VD220D / 221D / 222D /
223D / 2400 / 2500 Up to 30 fps at 1920 x 1080
GV-VD320D / 321D / 322D /
323D / 3400 Up to 20 fps at 2048 x 1536
•Day and night function (with removable IR-cut filter)
•Wide Dynamic Range Pro (for GV-VD2400 / 3400 only)
•Defog
•Intelligent IR
•Vandal resistance (IK10+ and IK7)
•Ingress protection (IP67 rating)
4

Vandal Proof IP Dome (Part I)
5
1
3-axis mechanism (pan / tilt / roll)
Micro SD card slot (SD/SDHC) for local storage
NAS recording
Recording assigned by GV-Edge Recording Manager (Windows &
Mac)
One sensor input and alarm output
TV-out support
Two-way audio
3D noise reduction (for GV-VD1500 / 2500)
2D noise reduction (except for GV-VD1500 / 2500)
Motion detection
Tampering alarm
Visual automation
Text overlay
Privacy mask
IP address filtering
DC 12V / AC 24V / PoE (IEEE 802.3af)
Megapixel lens
Support for iPhone, iPad, Android and 3GPP
31 languages on Web interface
ONVIF (Profile S) conformant

1.3 Overview
1234 5
6 7 8 9 7
10 11
Figure 1-1
No. Name Description
1 Power LED Turns on (green) when the power is on and
turns off when there is no power supply.
2 Status LED
Turns on (green) when the system operates
normally and turns off when system error
occurs.
3 Default Button Resets the camera to factory default. For
details, see 1.6 Loading Factory Default.
4 Memory Card
Slot
Inserts a micro SD card (SD/SDHC, version
2.0 only, Class 10) to store recording data.
5 Thread Lock Locks the housing cover to the camera body
to prevent the cover from falling.
6 Pan Disc Loosens to pan the camera.
7 Tilt Screw Loosen the screw to tilt the camera.
6

Vandal Proof IP Dome (Part I)
1
No. Name Description
8 Rotational Screw Loosens to adjust the camera angle.
9 Zoom Screw Adjusts the zoom of the camera.
10 Focus Screw Adjusts the focus of the camera.
11 Silica Gel Bag Absorbs moisture in the camera body.
7

1.4 Installation
The Vandal Proof IP Dome is designed for outdoors. With the standard
package, there are two ways to install the Vandal Proof IP Dome: hard-
ceiling mount and in-ceiling mount.
Note: You can also install the camera:
•on a power box (of the 4" square and double gang type) using the
standard package
•to ceilings, wall corners (concave or convex), and poles using
optional mounting kits
For details on these installations, see GV-Mount Accessories Installation
Guide on the Software DVD.
8

Vandal Proof IP Dome (Part I)
1
1.4.1 Hard-Ceiling Mount
Figure 1-2
1. Unpack the camera package and take out the camera body.
Unscrew the
housing cover
Unscrew thread
lock
9

Unscrew the inner
housing
Take out the
camera body
10

Vandal Proof IP Dome (Part I)
1
2. Mark the position of four screw holes on the desired installation
location, and drill holes in the marked locations. Drill the ellipse part if
you wish to put the wires through it.
Figure 1-3
3. Insert the screw anchors to the 4 holes on the ceiling.
4. Secure the back cover to the ceiling with 4 ceiling screws.
Figure 1-4
5. Refer to step 1 to secure the camera body with inner housing.
6. Thread the cable through the conduit entry at the side of the back
cover. Alternatively pass the wires through the ellipse hole at the
bottom of the back cover.
11
