GeoVision GV-FD5300 User manual

GV-FD3400 August 8, 2013
- 1 -
GV-FD5300 5MP H.264 WDR IR Fixed IP Dome
•1/2.5"progressivescanCMOS
•DualstreamsfromH.264andMJPEG
•Upto20fpsat2560x1920
•3‐axismechanism(pan/tilt/roll)
•Varifocalmegapixellens
•IntelligentIR
•2‐wayaudio
•Onesensorinputandalarmoutput
•TV‐outsupport
•Built‐inMicroSD(SDHC/SDXC)cardslot
forlocalstorage
•DC12V/AC24V/PoE
•WideDynamicRange(WDR)
•Defog
•Motiondetection
•Tamperingalarm
•Privacymask
•RemovableIR‐cutfilterforDay/Night
function
•IPaddressfiltering
•SupportsiPhone,iPad,Android&3GPP
•31languagesonWebinterface
•ONVIF(ProfileS)conformant
*NoMemorycardslot&localstoragefunctionfor
Argentina.

ActiveTamperingAlarm
TamperedFocusChangeCameraShift

Introduction
TheGV‐FD5300isanindoorcameradesignedwith3‐axisforeasyandflexibleinstallation.TheFixedIPDomeisequippedwithan
automaticIR‐cutfilterandIRLEDsfordayandnightsurveillance.Withoptionalaccessories,thecameracanbeinstalledonvarious
typesoflocationsincludingwallsurface,wallcorner,poleandceiling.

Overview











GV-FD3400 August 8, 2013
- 2 -
Dimensions
Hard‐CeilingMount
In‐CeilingMount
Specifications
Camera
ImageSensor1/2.5”progressivescanlowluxCMOS
PictureElements2560(H)x1920(V)
Color 0.15LuxatF/1.6
Minimum
IlluminationB/W
IRON 0Lux
ShutterSpeedAutomatic,Manual(1/5~1/8000sec.)
WhiteBalanceAutomatic,Manual(2800K~8500K)
GainControlAutomatic
S/NRatio45dB
BLCYes
Lens
MegapixelYes
Day/NightYes(withremovableIR‐cutfilter)
LensType Varifocal
FocalLength 4.5~10mm
MaximumApertureF/1.6
Mount CSMount
ImageFormat1/2.5”
FocusManual(w/lock)
ZoomManual(w/lock)
Operation
IrisManual(w/lock)
Max.Torque(Focus/ZoomScrews)0.049N.m
IRLEDQuantity 10IRLEDs
Max.IRDistance15m(50ft.)
Operation
VideoCompressionH.264,MJPEG
VideoStreamingDualstreamsfromH.264andMJPEG
FrameRate
10fpsat2560x1920
*Theframerateandtheperformancemayvarydependingonthenumberofconnectionsanddata
bitrates(differentscenes).
ImageSettingBrightness,Contrast,Sharpness,Gamma,WhiteBalance,Flicker‐less,ImageOrientation,ShutterSpeed,
BacklightCompensation,D/NSensitivity,WDR,Defog

GV-FD3400 August 8, 2013
- 3 -
Operation
AudioCompressionG.711
Two‐wayAudioYes
SensorInput1Input(DryContact)
AlarmOutput1Output(200mA5VDC)
VideoResolution
4:32560x1920,2048x1536,1600x1200,1280x960
16:91920x1080,1280x720
MainStream
5:41280x1024
4:3640x480,320x240
16:9640x360,448x252
SubStream
5:4640x512,320x256
Network
Interface10/100Ethernet
EthernetProtocolHTTP,HTTPS,TCP,UDP,SMTP,FTP,DHCP,NTP,UPnP,DynDNS,3GPP/ISMA,RTSP,PSIA,SNMP,QoS
(DSCP),ONVIF(ProfileS)
Mechanical
Pan0°~350°
Tilt10°~90°
CameraAngle
Adjustment
Rotation0°~340°
TemperatureDetector Yes
Mechanical
Power2‐pinterminalblock,PoE
Ethernet Ethernet(10/100Base‐T),RJ‐45cable
Audio 1Inmicrophonephonejack,3.5mm(0.14”)
1OutStereophonejack,3.5mm(0.14”)
DigitalI/O 3‐pinterminalblock,pitch2.5mm(0.1”)
LocalStorageMicroSDmemorycardslot(SDHC/SDXCforClass6cardorabove)
Connectors
TV‐Out BNCconnector(640x480resolution)
LEDIndicator2LEDs:Power,Status
General
EnvironmentTemperature 0°C~50°C(32°F~122°F)
Humidity 10%to90%(nocondensation)
PowerSource 12VDC/24VAC/PoE
Max.PowerConsumption 12W
Dimensionsø155x110mm(6.1’’x4.33”)
Weight 580g(1.28lb)
VandalResistanceIK7
Regulatory CE,FCC,C‐Tick,RoHScompliant
PoweroverEthernet
PoEStandard IEEE802.3afPoweroverEthernet/PD
PoEPowerSupplyType End‐Span
PoEPowerOutput PerPort48VDC,350mA.Max.15.4watts
WebInterface
InstallationManagement Web‐basedconfiguration
MaintenanceFirmwareupgradethroughWebBrowserorUtility
AccessfromWebBrowser
CameraLiveView,VideoRecording,ChangeVideoQuality,BandwidthControl,ImageSnapshot,Digital
I/OControl,Audio,PictureinPicture,PictureandPicture,PrivacyMask,VisualAutomation,Tampering
Alarm,TextOverlay,DigitalPTZ
Language
Arabic/Bulgarian/Czech/Danish/Dutch/English/Finnish/French/German/Greek/Hebrew/
Hungarian/Indonesian/Italian/Japanese/Lithuanian/Norwegian/Persian/Polish/Portuguese/
Romanian/Russian/Serbian/SimplifiedChinese/Slovakian/Slovenian/Spanish/Swedish/Thai/
TraditionalChinese/Turkish
Applications
NetworkStorageGV‐NVR,GV‐System,GV‐BackupCenter,GV‐RecordingServer
SmartDeviceAccessGV‐EyeforAndroidsmartphone,tablet,iPhone,andiPodTouch
GV‐EyeHDforiPad
LiveViewingIE,mobilephone
CMSServersupport GV‐ControlCenter,GV‐CenterV2,GV‐VSM

GV-FD3400 August 8, 2013
- 4 -
Note:
1.Donotuseclothesoranyordinarymaterialtocleanthecameracoversincetheymayresultinscratches.
2.Specificationsaresubjecttochangewithoutnotice.

Accessories
ModelNo.NameDetails
GV‐Mount100StraightTubeandJunctionBoxKit

Dimensions:200x170x257.5mm
(7.9’’x6.7’’x10.1”)
Weight:3.17Kg(6.99lb)
GV‐Mount101StraightTubeKit

Dimensions:219x125x332mm
(8.6’’x4.9’’x13.1”)
Weight:1.8Kg(3.97lb)
GV‐Mount200WallPendantTube

Dimensions:225x140x250mm
(8.9’’x5.5’’x9.8”)
Weight:900g(1.98lb)
GV‐Mount203
WallPendantTubeandJunctionBox
Kit

Dimensions:315x195.5x225mm
(12.4’’x7.7’’x8.9”)
Weight:2.95Kg(6.5lb)
GV‐Mount300ConvexCornerAdapterKit

Dimensions:238.6x409.5mm
(9.4’’x16.1”)
Weight:4.27Kg(9.41lb)
GV‐Mount310ConcaveCornerAdapterKit

Dimensions:238.6x409.5mm
(9.4’’x16.1”)
Weight:4.27Kg(9.41lb)
GV‐Mount400
PoleMountBracketKit
(Ø4"~6")

Bracket:241x161mm(9.5’’x6.3’’)
Weight:1.70Kg(3.75lb)
SteelStrapDiameter:Ø4"~6"

GV-FD3400 August 8, 2013
- 5 -
ModelNo.NameDetails
GV‐Mount410
PoleMountBracketKit
(Ø6"~7.5")

Bracket:241x161mm(9.5’’x6.3’’)
Weight:1.70Kg(3.75lb)
SteelStrapDiameter:Ø6"~7.5"
GV‐Mount702ExtensionTube

Fouroptionsareavailable.
Dimensions:
Ø5.4x10or20or30or50cm
(Ø2.1’’x3.9’’or7.9’’or11.8’’or
19.7”)
Weight:
180gor390gor550gor800g
(0.4lbor0.86lbor1.21lbor1.76lb)
GV‐Mount900WallMountBracket

Dimensions:154x108x50mm
(6.1’’x4.3’’x2”)
GV‐Mount902GV‐FDSeriesDomeHousing
 
Dimensions:Ø186x97.5mm
(Ø7.3’’x3.8”)
Weight:600g(1.32lb)
41‐81053‐HK2SmokedCover

Dimensions:
ø103.7x55mm(4.08’’x2.16”)
Weight:30g(0.07lb)
VandalResistance:IK7
GV‐PA191PoweroverEthernet(PoE)Adapter

TheGV‐PA191isaPowerover
Ethernet(PoE)adapterdesignedto
providepowertotheIPdevice
throughasingleEthernetcable.
GV‐RelayV2GV‐RelayV2

TheGV‐RelayV2isdesignedto
expandthevoltageloadofGVIP
devices.Itprovides4relayoutputs,
andeachcanbesetasnormally
open(NO)ornormallyclosed(NC)
independentlyasperyour
requirement.
PowerAdapterPoweradaptersareavailablein4regions:U.S.A.,Australia,U.KandEurope.
