geratech EGE-WHD5-EXT User manual

EGE-WHD5-EXT
Wireless HD Video Transmission Solition

EGE-WHD5-EXT
Wireless HD Video Transmission Solition

Important Information
Please read this user manual before you use this product, it contains all the notes and impor¬tant
things regarding operating this product. In accordance with the safety precautions and operating
instructions listed on this user manual, ourapplies provided the product is handled properly for its
intended use, but may not apply to below cases:
Repairs or product modification and alterations have been executed by unauthorized personnel.
The damages are caused by accidents including but not limited to lightning, fire, exposed to rain or
water,and moisture.
Do not use provided power adapter with specific power voltage which are not compliant with the
rated voltage range in the attached label of the power adapter in package.
The model label on the product has been modified or the warranty tag has been removed by
unauthorized personnel.
Safety Precaution
To reduce the risks of electricity, do not remove or open the cover. No user-serviceable parts
are inside. Please return to original factory for maintenance
The high temperature in the process of operating the device may cause the high risk of
scalding.
Please use our standard power adapter.Detailed information Please refer to the rated vol
age range showed on the label at the back of package's power adapter.
Danger: Be careful with electricity.
As connecting any equipment (such as any player or TV , etc.),please turn off the power to the
product before any operation is undertaken.
Power outlet:To prevent electric shock or fire, short circuit, please make sure the type of electrical
plug used on the receiver's and transmitter's powercord are compliant with the rated voltage range
in the attached label of the power adapter in package.
Power cord: Do not place any heavy articles above on the power cord. To avoid being stepped on
or pinched by heavy items, the power cord should not be located on the place where people pass
by frequently.
Power overloading: Avoid overloading wall's electrical outlets and extension cord or other
multi-socket; otherwise could result in electric shock or fire.
Lightning: For protection from lightning or when the product is left unattended for a long period,
please disconnect it from the power source.
Please disconnect the power cord from the power outlet when you are not using the receiver and
transmitter, this will reduce the risk of electric shock or fire.
EGE-WHD5-EXT
Wireless HD Video Transmission Solition

Warning
This product should not be exposed to dripping or splashing. Do not place any object filled
with liquid on the product(eg. vases).
To avoid electric shock, please do not block or stick anything on the air vent of product; do
not remove the cover or put the object just like pins, steel wire into the gap of the air vent.
Please place the receiver/transmitter on a flat with hard and stable surface.
Ventilation: please do not block the air vents on the receiver/transmitter or place any heavy object
on top of them . Blocking the air flow can damage the product itself. Please make sure that there is
adequate ventilation distance between the receiver and TV, and also put the product away from
direct sunlight or any source of heat.
Water Exposure: To reduce the risk of electric shock or fire , please do not expose the
receiver/transmitter to rain or moisture.
Weassume no responsibilityforany damage or result caused by using otheradapters instead of our
standard adapters
Special Notice
Although the product has provided the function of data encryption when transmitting, you still need
to pay attention to deliberate signal interception. There will be the Possibility of a third party inte
tionally intercept the transmission signal since the product adopt wireless communication. Please
do not use the product on confidential and important communications, or life-related
communictions The main concern is that the content of wireless communication might be received
by the third party's wireless devices deliberately or accidentally.
The impact of radio waves (such as the following environment may cause the abnormal audio and
video(blocked image, noise ...etc.).
1) Transmit near the wall which is hard for the radio waves to get through.
2) Quite close to the refrigerator, metal fitment and appliances, or next to the crowded situation.
This product has been tested and manufactured to comply with national electrical safety rules,
however, there will be noise caused by the interference with other machines in rare cases. If the
interference is happened, please keep a certain distance away from other machines.
The product is susceptible to interference from 5GHz wireless local area network or other wireless
devices.
Optimal range between transmitter and receiver is between 1 meter and 50 meters within line of
sight indoor.
Please do not set up the transmitter and receiver in metal shelf, or it will hinder the wireless
communications.
1080P/60 Hz Wireless transmitting.
It will take 30-40 seconds to boot the system before wireless communication start, the media
receiver can not be operated during this time.
EGE-WHD5-EXT
Wireless HD Video Transmission Solition

CONTENTS
Foreword 1
Brief Introduction 1
Features 1
Structure & Interface 2
The Transmitter EGE-WHD5-EXT 2
The Receiver EGE-WHD5-EXT 3
Packing List 4
Product Installation Instruction 4
Specification 7
Indication 8
Troubleshooting 9
FCC Statement 10
FCC Radiation Exposure Statement10
Cautions 10
................................................................................
...........................................................................
...........................................
.................................................................................
.....................................
..........................................................................
....................................................................
..........................................
....................................
..................................................................
.............................................................
...............................................................................
.......................................................................
..............................................................................
EGE-WHD5-EXT
Wireless HD Video Transmission Solition

Foreword
Please read this manual carefully before you use this p roduct and reta in it properly for future
reference.
If there is any doubt or difficulty in the process of product usage, please feel free to contact us or
the dealer.
The company reserves the authority to amend the specification.
Brief Introduction
This wireless HD Video solution enables wireless transmission of video/audio from any HDMI video
source such as PC/HDTV to display devices in eludes HDTV/HD Monitor over the 5 GHz band, with
very low latency.
It does not require any special configuration or software driver instal lation - simply connect the trans-
mitter to the HDMI output of the video source and the receiver to the HD MI input of the Panel/TV/Moni-
tor. Its Plug & Play operation makes it the ultimate solution for the most demanding indoor/outdoor
professional environments.
This solution is widely applicable to family enterta inments, office presentation, lecture, education,
medical treatment, party, conference, etc.
Features
Support HD devices with HDMI input/output, include Blu-ray player, DVD player, PC, laptop, HDTV,
etc.
5GHz Wireless HD video transmission Support multi resolution up to 1080P
HDMI Input/Output, support multi devices with HDMI
Low latency <60ms
Effective range: 50m (Line of sight)
WPS transmitter - receiver pairing
Plug & Play - full hardware design, no software is required
AES128/256 Encryption
1
EGE-WHD5-EXT
Wireless HD Video Transmission Solition

CONNECTING AND OPERATING
1) Connect the HDMI input source (such as HD-DVD/ PS3 /STB etc.) into transmitter over HDMI cable.
2) Connect the output of transmitter and input of receiver over CAT5E or CAT6 cable.
3) Connect the HDMI oustput (such as: HD-LCD/D-DLP) into receiver over HDMI cable.
4) Connect yhe IR TX cable into ‘‘IRTX’’ port of the transmitter; Connect the IR RX cable into IR RX
Structure & Interface
The Transmitter EGE-WHD5-EXT
DC Power: Power socket for DC adapter,
HDMI IN: Connect to HD Video source device such as DSLR/DV, Blu-ray Player, Laptop, HDTV, etc.
USB: USB socket for upgrading.
Pairing: For devices paring, use a pin point to press for about 5 seconds then release, the devices will
be paring.
Channel Switch: Press to change the channel
LED indicators: RED for Networking; Green for Video
1R OUT Socket: Connect with IR extension connector to transmit IR signal
2
1
2
3
4
5
6
EGE-WHD5-EXT
Wireless HD Video Transmission Solition

The Receiver EGE-WHD5-EXT
DC Power: Power socket for DC adapter.
HD MI Output: connect to HD display device such as HDTV, Projector, LED Screen, etc.
USB: USB socket for upgrading.
Pairing: For devices paring, use pin to push for about 5 seconds then release, the devices will be
paring.
Channel Switch: Press to change the channel
LED i ndicators: RED for Networking; Green for Video
IR IN Socket: Connect with IR extension connector to receive the IR signal
3
1
2
3
4
5
6
EGE-WHD5-EXT
Wireless HD Video Transmission Solition

4
Packing List
Pleace check the packing list carrefuly, if any part missed, pleace contact your dealer. Components of
all models are subject to the following packing list.
TX:EGE-WHD5-EXT RX:EGE-WHD5-EXT
Wireless HD Transmitter x1 Wireless HD Receiver x1
Adaptor with USB cable x1 Adaptor with USB cable x1
HDMI cable x1 IR Extension connector x1
IR Extension connector x1
The adaptor may very according to certain conditions in different country/region.
Product Installation
1) Locate the transmitter and receiver respectively to the base. To avoid interference from other
devices, please do not place any barriers near to the devices.
2) Connect to power adaptor to the transmitter and receiver. Connect the IR extension connector to
the IR Output socket of transmitter, and put it properly in front of IR sensor area of video source; and
connect to the IR Input socket of receiver.
EGE-WHD5-EXT
Wireless HD Video Transmission Solition

5
3) After communicating the power transmitter and receiver system startup, the system start after the
completion of the following OSD displayed on the device screen: ¨Connecting to transmitter¨
EGE-WHD5-EXT
Wireless HD Video Transmission Solition

6
4) Wait for the system start, and the screen will display text "Connecting to transmitter" then the
images shows up, which means the product is working.
5) Whenthe system working properly, user can uset he remote controller of HD player at the HDTV
side. The remote controller should be aligned to IR connector of the receiver.
6) While connected, user can press the Channel Switch of transmitter or receiver to change to other
channel for better transmission.
Remarks
1) Remote extension connector only supports 38~56 KHz remote's signal protocol.
2) Please make sure the transmitter and receiver are located in the effective reception distance and
range, if they are located out of the range, the signal wouldn't be received.
EGE-WHD5-EXT
Wireless HD Video Transmission Solition

7
Transmitter Receiver
EGE-WHD5-EXT EGE-WHD5-EXT
Free Band (USA):5151 ~ 5250MHz, 5725 ~ 5825 MHz
Free Band (JAN & EU) :5151 ~ 5250 MHz
RF Communication 2x2 MI MO
Modulation Mode OFDM
Power Consumption 5W 3W
Transmission Range 50m
Fraquency Stability ± 20 PPM
Reveiving Sensitivity - 65 dBm
System Latency ≤ 60 ms
Antenna 2 2 4dBi Built-in Antenna
Encryption AES128/256
Network Mode AP Station
Standart Protocol HDMI 1.3; HDMI 1.4 3D; HDCP
Power Supply DC 5V/2A
Dimension 101 59 21 mm
Video Formats Supported 1080P 1080I 720P 576P 576I 480P 480I HD 3D
Video Compress Formats H.264
Audio Formats Supported PCM
Operating Temperature 0-40 C
Storage Temperature -20 C - 80 C
Operating Humidity 15 ~ 85%RH
Since the product’s improving procces, all the performance, design and specifications of our
products are subject to minor change without prior notice.
ITEM
Rrequency
Specifacation
EGE-WHD5-EXT
Wireless HD Video Transmission Solition

8
Indicators
LED Indicator Display Status
Network Indicator Indicator ON Device Power ON
(RED) Twinkle Slowly Connecting...
Video Indicator Indicator ON Video Transmission ON
(BLUE) Twinkle Slowly NO Video Signal Input
Both Network & Video Twinkle Quickly Pairing...
Indicator Twinkle Alternatively Quickly Channel Switch is ON...
EGE-WHD5-EXT
Wireless HD Video Transmission Solition

9
Trouble Shooting
Posible Reasons Solutions
No signals are input toTV
Receiver is notturned on. Power on receiver.
Transmitteris on sleeping. Remove the hDMI cable then connect
it to awake the device.
Receiver and TV are not connected. Connectthe receiverandTV by the
HDMI cable.
Haven't switched TV to HDMI input. SwitchTVto HDMI input.
Poor contact of receiver orTV's HDMI cable Unplug and then plug the HDMI cable
of the receiver orTV.
TV turn into standby mode Switch theTVto normal operation mode.
Abnormal working of receiver. Reboot the receiver.
No image appear on TV
Poor contact of receiver orTV's HDMI cable. Re-plug the HDMI cable of the receiver
or TV
Abnormal working of receiver Reboot the receiver
Receiver failure Please contact your distributor
Abnormal coloronTV screen
Poor contact of receiver orTV's HDMI cable. Unplug and then plug the HDMI cable
of the receiver orTV.
Poor contact of transmitter or player's HDMI cable. Unplug and then plug the HDMI cable of
theTX and player.
Abnormal working of transmitter or receiver Reboot the transmitter and receiver.
Video blocking or mosaics on the image displayed on TV
Transmitter or receiver is not placed erectly. Place theTX or RX onto the base and
maintain them erectly
The transmitter and receiver are out of effect range. Move the receiver closer to the
transmitter.
Several solid wall partitionTXand RX. Reduce the number of solid walls
betweenTX and RX
There are obstacles or interference Press the channel switch button to
between TX a nd RX. change to another channel.
Images appear on TV normally but no voice is output.
Player orTV is muted. Open the volume of player orTV.
Player orTV's volume is too low. Turn up the volume of player orTV.
Current player don't support the output audio format Switch the output audio format of player.
Abnormal working of transmitter or receiver Reboot the transmitter and receiver
EGE-WHD5-EXT
Wireless HD Video Transmission Solition

10
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules.These limits are designed to provide reasonable protection
against harmful interference in a residential installation.This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:-Reorient or
relocate the receiving antenna. Increase the separation between the equipment and receiver. Con-
nect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.To assure continued compliance,
any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this equipment. (Example use only shielded interface cables when
connecting to computer or peripheral devices).
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environ-
ment. This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter. This equipment complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may cause
undesired operation.
Cautions!
The manufacturer is not responsible for any radio orTV interference caused by unauthorized modifica-
tions to this equipment. Such modifications could void the user authority to operate the equipment.
EGE-WHD5-EXT
Wireless HD Video Transmission Solition

www.geratech.com.tr
www.egerate.com
www.egerate-store.com
