GGM gastro EMH15 User manual

Compact Ice-cream Maker
It is important that you read these instructions before using your compact ice-cream maker and
we strongly recommend that you keep them in a safe place for future reference.
Model N EMH15 o.:

1
IMPORTANT SAFETY INSTRUCTIONS………………………………………………. ….2
PREPARING YOUR ICE MAKER FOR USE
IMPORTANT SAFETY TIPS………………………………………………………………………3
GETTING TO KNOW YOUR UNIT………………………………………………………… ………………………………………………………….4 .4
OPERATING PROCEDURES & MAINTENANCE
UNPACKING
UNPACKING YOUR YOUR ICE ICE MAKER MAKER…………………
…………………. .…………………………………………… ……………………………………………. .. .6 6
CONNECTING
CONNECTING YOUR YOUR ICE ICE MAKER MAKER……………… ………………. .……… ………. .…………………………………… ……………………………………..6 ..6
CLEANING
CLEANING AND AND MAINTAINING MAINTAINING YOUR YOUR ICE ICE MAKER MAKER… …. .………………………………………… …………………………………………. .6 6
USING YOUR ICE MAKER……………….……..…………………………………………..7
TROUBLESHOOTING
TROUBLESHOOTING…………………………… ……………………………. .…………………………………………… ……………………………………………..10 ..10

2
DANGER
WARNING
!
Your safety and the safety of others are very important.
We have provided many important safety messages manual and your appliance.
Always read and obey all safety massages.
This is the safety alert symbol:
!
All safety messages will follow the safety alert symbol and the word “DANGER” or “WARNING”.
These words mean:
You can be killed or seriously injured if you don’t immediate follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance
of injury, and tell you what can happen if the instructions are not followed.
TABLE OF CONTENTSIMPORTANT SAFETY INSTRUCTIONSPREPARING YOUR ICE MAKER FOR USE
!

3
When using electrical appliances, basic safety precautions should be followed to reduce the
risk of fire, electric shock, and injury to persons or property. Read all instructions before using
any appliance.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
Do not operate this，or any other appliance with a damaged cord.
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent
or a similarly qualified person in order to avoid a hazard.
This ice-cream maker must be positioned so that the plug is accessible.
Connect to properly polarized outlets only. No other appliance should be plugged into the
same outlet. Be sure that the plug is fully inserted into the receptacle.
Do not run the power cord over carpeting or other heat insulators. Do not cover the cord.
Keep cord away from traffic areas, and do not submerge in water.
We do not recommend the use of an extension cord, as it may overheat and become a risk
of fire. If you must use an extension cord, use No.14AWG minimum size and rated no less
than 1875 watts.
Unplug the ice-cream maker before cleaning or making any repairs or servicing.
Exercise caution and use reasonable supervision when appliance is used near children.
Do not use your ice-cream maker outdoors. Place the ice-cream maker away from direct
sunlight and make sure that there is at least 4inches(10 cm) of space between the back of
your unit and wall. Keep a minimum distance of 4inches(10 cm) on each side of your unit
free. Keep the enough air circulation around your unit.
Do not clean your ice-cream maker with flammable fluids. The fumes can create a fire
hazard or explosion.
Do not tip over.
If the ice-cream maker is brought in from outside in wintertime, give it a few hours to warm
up to room temperature before plugging it in.
Children should be supervised to ensure that they do not play with the appliance.
This appliance must be earthed.
Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
This appliance is intended to be used in household and similar applications such as
– staff kitchen areas in shops, offices and other working environments;
– farm houses and by clients in hotels, motels and other residential type environments;

4
– bed and breakfast type environments;
–catering and similar non-retail applications.
DANGER – Risk Of Fire or Explosion. Flammable Refrigerant Used. Do Not Use
Mechanical Devices To Defrost Ice Maker. Do Not Puncture Refrigerant Tubing.
DANGER – Risk Of Fire Or Explosion. Flammable Refrigerant Used. To Be
Repaired Only By Trained Service Personnel. Do Not Puncture Refrigerant Tubing.
CAUTION – Risk Of Fire Or Explosion. Flammable Refrigerant Used. Consult Repair
Manual/Owner’s Guide Before Attempting To Install or Service This Product. All Safety
Precautions Must be Followed.
CAUTION – Risk Of Fire Or Explosion. Dispose Of Property In Accordance With Federal Or
Local Regulations. Flammable Refrigerant Used .
CAUTION-Risk Of Fire Or Explosion Due To Puncture Of Refrigerant Tubing; Follow
Handling Instructions Carefully. Flammable Refrigerant Used.
The ice maker should be installed in accordance with the safety standard for Refrigeration
Systems, ASHRAE15. The ice maker shall not be installed in corridors or hallways of public
buildings.
If the unit is with problem need to be maintained, that replacing with like components and
that servicing shall be done by factory authorized service personnel, so as to minimize the
risk of possible ignition due to incorrect parts or improper service.
IMPORTANT:
The wires in this mains lead are colored in accordance with the following code:
Green or Green with a strip Yellow: Grounding
White: Neutral
Black: Live
WANING: To avoid a hazard due to instability of the appliance, it must be placed at an even
or flat surface.
WARNING: When positioning the appliance ensure the supply cord is not trapped or
damaged.
WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the
rear of the appliance.

5
General instruction
1. Measuring Cup
2. Touchpad Control Panel with LCD display
3. Ice Cream Shovel
4. Rotation shaft of stir motor
5. Transparent cover
6.
7.
Mixing Paddle
8.
Mixing Bowl with Lift-Out Handle.
9.
Hot Air outlet
Cabinet
Position of control panel & function
GETTING TO KNOW YOUR UNIT

6
Touch Control Panel:
A. Button to start/pause the stir motor
B. Button to select soft ice-cream setting or hard ice-cream setting or stir function
C. Button to turn on/off the unit.
D. Button to increase the ice cream making time
E. Button to increase the ice cream making time
F. LCD display window
1: ON/OFF symbol : if the unit is off, this symbol will flash; if the unit is on, this symbol
will always display.
2: Stir function setting symbol: With this symbol, means that it has been set with paddle
working only to blend the ice-cream material completely. And when the paddle works only,
this symbol will flash slowly.
3. Soft/Hard ice cream symbol:
---Soft Ice-cream symbol
-----Hard Ice-cream symbol
4. Cooling operation symbol: the compressor is running.
5. Keep cool symbol: When the symbol will flash, the unit keep cooling to frozen the ice
cream
6. Stir motor running symbol: take out the paddle when the stir function stop.
7. Time display: Showing time countdown when making ice cream, and showing keep
cooling time when ice cream making stop.
UNPACKING YOUR ICE-CREAM MAKER
1. Remove the exterior and interior packaging. Check if all the parts, such as the paddle,
ice-cream mixing bowl, and ice-cream scoop etc., are inside. If any parts are missing,
please contact our customer service.
2. Clean the ice-cream mixing bowl, paddle, and ice-cream scoop first.
3. Put the unit on a level & flat counter top, and without direct sunlight and other sources of
heat (i.e.: stove, furnace, radiator).
4. Maker sure that there is at least 10mm gap between the back & LH/RH sides with the wall.
5. Allow one hour for the refrigerant fluid to settle before plugging in the unit.
6. The appliance must be positioned so that the plug is accessible.
OPERATING PROCEDURES & MAINTENANCE

7
DANGER
CONNECTING YOUR ICE-CREAM MAKER
* Improper use of the grounded plug can result in the risk of electrical shock. If the
power cord is damaged please call our customer service.
1. This unit should be properly grounded for your safety. The power cord of this appliance is
equipped with a grounding plug which mates with standard grounding wall outlets to
minimize the possibility of electric shock.
2. Plug your appliance into an exclusive, properly installed, grounding wall outlet. Do not
under any circumstances, damage the grounding means of the plug under any
circumstances. Any questions concerning power and/or grounding should be directed
toward a certified electrician.
3. This appliance requires a standard 110-120Volt, 60Hz electrical outlet with good grounding
means.
4. DO NOT immerse the compressor/motor base in water.
CLEANING
CLEANING AND AND MAINTAINING MAINTAINING YOUR YOUR ICE ICE-CREAM -CREAM MAKER MAKER
Before using your ice-cream maker, it is strongly recommended to clean it thoroughly.
1. Turn the transparent cover by counterclockwise, be sure the arrow on lid is lined up with the
lock icon on the base, then you can take the cover out.
2. Take out the paddle and ice-cream mixing bowl.
3. Use a dry, clean, soft cloth to clean the internal wall of the ice-cream making house
smoothly, no need to use water or wet cloth to clean it.
4. The outside of the unit should be cleaned regularly with a mild detergent solution and warm
water. DO NOT immerse the compressor/motor base in water., it will wet the inside
electrical parts and cause the electrical safety problem.
5. Then you can put the transparent cover, paddle, ice-making mixing bowl, and the ice-cream
scoop into the water, and use the wet and soft cloth to clean them. Then dry them before
running the unit. Warning: Don’t use the abrasive tool to wipe them.
6. Dry all the parts and exterior with a clean soft cloth.
7. Put back all the parts to the original position.
8. When the machine is not to be used for a long time, clean & dry all the parts and the unit.
!

8
How to make the ice-cream
Please prepare the material of the ice-cream per your personal food recipe or the
attached recipe paper. No need to put the material and the ice-cream mixing bowl
into freezer for freezing ahead, this ice-cream maker can freeze the material and
make the ice-cream directly.
Please follow the step：
1/Put your ice-cream material inside the ice-cream mixing bowl and also with
some warm water, then stir smoothly and mix it uniformly.
2/Put the ice-cream mixing bowl filled with material into the ice-cream making
house.
3/Install the paddle on the rotating shaft.
4/Put back the transparent cover and turn it clockwise to install tightly. Then
plug in the unit.

9
5/Press the MODE button to select the Soft or Hard ice cream, or stir function,
also can press the TIME+ or TIME- button to change the duration time a little during
the making process.
6/ You can add some other favorite ingredient during making process.
7/In order to dig out the sphere ice-cream from the bowl by the sphere
ice-cream device after the hard ice-cream is made, please take out the paddle
when making the hard ice-cream. Use the ice-cream scoop to wipe down the soft
ice-cream from the surface of paddle and then make hard ice cream.
8/Once the ice-cream making process completed, you can enjoy it at once. If you
don’t finish, you can put the ice-cream mixing bowl back in the ice-cream making
housing to keep cool.

10
WARNING:
1/With the ice-cream making time passed, the ice-cream become more
harder, the stir motor will be locked and the paddle will stop rotating. It is
normal, but when the unit enter the hard ice-cream making process, the
internal control system will buzz to remind you, please take out the paddle.
2/ Be sure don't pour ice-cream material volume exceeding 60% of the ice
cream mixing bowl maximum capacity. Otherwise it will overflow the bowl.
3/ When making the soft ice-cream, it may frost between the ice-cream
mixing bowl and the ice-cream making house, please wait several mins to let
the frost melt, then take out the ice-cream mixing bowl.
4/ When making the hard ice-cream, it may frost between the ice-cream
mixing bowl and the ice-cream making house, please wait longer to let the
frost melt, then take out the ice-cream mixing bowl.
Instruction for operation the control panel
1、Plug your ice-cream maker into the main power outlet, the LCD display window will display
like the following picture, and the “ ” symbol will flash.
2、You can let the paddle work only first to blend the ice-cream material
completely.
Press the Stir button, the LCD display window will display like the following
picture. It means the default time for paddle work is 5 minutes, you can use the
“TIME+” or “TIME-” button to change the paddle working time, one time is
5mins.And also you can press the Start/Stop button again to cancel this setting.
If you don’t need the paddle work first to blend the ice-cream material, just move
to the next step.
3、Press the “MODE” button to select “Soft ice-cream” or “Hard ice-cream” set,the

11
default set is Hard ice-cream with symbol. Press “MODE” button again,
change to symbol. Press Mode agin, change to Stir function only.
If you select the “Hard ice-cream” set, the unit will process the soft ice-cream
program first, and then change to Hard ice-cream program.
4、Press “ON/OFF” button to turn on the unit, the unit will start to work according to
the above setting program.
During the compressor running, you can also press the Stir button to Start or
Stop the paddle rotating.
After starting to make the soft ice-cream, it will run according to the default time
varied with the ambient temperature. And you can also set the “TIME+” or “TIME-”
button to change the ice-cream making duration time according to your personal
taste.
Following pictures explain the symbol changing sequence (with paddle only
work set):
When Soft ice-cream set:
When Hard ice-cream set:
Flashing
Number is decrsing Rotaing
Flashing
Number is decrsing Rotaing Cyclic displaying
Cyclic displaying
Flashing
Number is decrsing Rotaing
Flashing
Number is decrsing Rotaing Rotaing
Flashing
Number is decrsingCyclic displayingCyclic displaying

12
During Hard ice-cream set, after the above process, the buzz will sound for only 10
seconds, and at same time the symbol “ ”will flash 10 seconds. Please take
out the paddle. Then the unit start the Hard ice-cream making process.
Note 1: During the Soft ice-cream or the Hard ice-cream making process, you
can set the “TIME+” or “TIME-” button to change the ice-cream making
duration time according to your taste.
Note 2: If you don’t need the paddle to blend the ice-cream material first, Stir
function setting symbol won’t display.
5、It’s better to enjoy ice cream at once the whole process is completed, or pull
out the ice-cream mixing bowl and store in your fridge to avoid melting.
Also this unit can keep cool the ice cream. The symbol will display.
6、Press the Start/Stop button at any point in the Mixing/Cooling cycle to pause
the time and mixing. You can add more material into the bowl. To restart, press
the Start/Stop button again to continue.

13
TROUBLESHOOTING
PROBLEM
POSSIBLE CAUSE
SOLUTION
The ice-cream mixing bowl
can’t be taken out.
The water between the
ice-cream mixing bowl and
the ice-cream making
house frozen.
Wait for several mins, and then
take the mixing bowl out.
Make sure mixing bowl and the
base are dry before making ice
cream.
The duration time is not
over, but the paddle stop
rotating.
The ice-cream becomes
harder, the stir motor stuck.
Turn off the unit, take out the
ice-cream mixing bowl and scoop
out the ice-cream. Restart the
unit, then the paddle will recover
to rotate.
The ice-cream mixing bowl
can’t be put into the
ice-cream making housing.
The ice-cream mixing bowl
maybe deformed
Verify with the service department
and buy a new mixing bowl.
When just starting to run,
the serious noise happens
from the paddle or the
paddle is locked.
The ice-cream mixing bowl
maybe deform because of
not proper using
Verify with the service department
and buy a new mixing bowl.

11
