Giacomini KPM30 Series User manual

1
Main features
Mechanical characteristics
Dimensions: all versions are available on DIN rail mounting 6 modules of
105x115x60 mm
Plastic housing
• DIN rail mounting in accordance with DIN 43880 and CEI EN 50022
• Material: technopolymer
• Self-extinguishing: V2 (according to UL94) and 960 °C (according to IEC 695)
• Ball pressure test 125 °C
• Resistance to creeping current ≥ 250 V
• Grey RAL7035
Electrical characteristics
• Insulated power supply:
- DC power supply: 48 Vdc (36 Vmin…72 Vmax)
- AC power supply: 24 Vac +10/-15 %, 50/60 Hz
- Maximum absorption: P=11W, P=14VA, Imax=700 mA
• CPU: H8SX/1651 32-bit, 50 MHz
• FLASH program memory: 2+2 MByte
• SRAM data memory: 512 Kbytes organized in 16-bit
• EEPROM parameter data memory: 13 kByte + 32 kB
• NAND FLASH memory: 32 MByte
• Working cycle duration: 0,2 s typically (applications of average complexity)
• Clock: available as standard and integrated on the base
Battery characteristics
The battery used in the KPM30/KPM31 is "button" type lithium, code CR2430,
voltage 3Vdc and dimensions 24x3 mm.
Technical data
• Operating conditions: -10÷60 °C, 90 % R.H. non-condensing
• Storage and transportation conditions: -20÷70 °C, 90 % R.H. non-condensing
• Protection degree: IP40 front panel only
• Environmental pollution: 2
• Class according to the protection against electric shock: to be integrated on
Class I and/or II equipment
• Period of electrical stresses of the insulating parts: long
• Type of action: 1 C
• Type of disconnection or microinterruption: microinterruption
• Heat and re resistance class: Class D (UL94–V0)
• Immunity against voltage surges: Class II
• Ageing characteristics (hours of operation): 80.000
• No. of automatic operating cycles: 100.000 (EN 60730-1); 30.000 (UL 873)
• Software class and structure: Class A
• Surge immunity class: Class III (CEI EN 61000-4-5)
The device is not intended to be hand-held.
Dimensions
A B
C
A [mm] B [mm] C [mm]
105 60 110
Description
The KPM30 and KPM31 regulation unit derives from Giacomini's extensive
experience in the eld of thermoregulation of heating and cooling
systems. The KPM30 regulation unit is a device designed to be used in
Giacomini radiant heating and/or cooling systems in combination with bus
thermoregulation components and other communicating devices with
compatible protocols. The KPM30 module is equipped with a display and six
multifunctional keys; this allows programming of the system parameters via
a guided menu and the subsequent monitoring of the system by the user.
The KPM30 module allows for quick connection to the ambient thermostats
K492B, K495B and K495L and to the KPM35 expansion boards.
In addition, the operation of the circulator and the activation of the mixing
valve servo-control is managed automatically.
The KPM31 version has the same characteristics as the KPM30 but without
the display, therefore it must be installed in combination with the remote
display KD201 (which is an optional accessory for the KPM30 model). Thanks
to the plug-in terminals and the design compliant with the DIN standard, it
can be installed in accessible electrical panels.
Versions and product codes
The KPM30/KPM31 series is available in dierent versions:
• KPM30Y001, KPM31Y001: stand alone for the control of one mixing valve
• KPM30Y002, KPM31Y002: stand alone for the control of two mixing valves
• KPM30Y003, KPM31Y003: for the management of one to three ambient
thermostats and control of a mixing valve, a dehumidier or a fan-coil
• KPM30Y004, KPM31Y004: for the management of one to sixteen thermostats
and control of a mixing valve and seven air treatment machines (to be used
in combination with the KPM35 expansion boards)
• KPM30Y005, KPM31Y005: for the management of one to sixteen thermostats
and control of two mixing valves and seven air treatment machines (to be
used in combination with the KPM35 expansion boards)
Product code No. of mixing
valves
No. of ambient
thermostats
No. of air
treatment machines
KPM30Y001
KPM31Y001 1 - -
KPM30Y002
KPM31Y002 2 - -
KPM30Y003
KPM31Y003 1 1÷3 1
KPM30Y004
KPM31Y004 1 1÷16 (with KPM35) 7 (with KPM35)
KPM30Y005
KPM31Y005 2 1÷16 (with KPM35) 7 (with KPM35)
KPM30 KPM31
0676EN June 2016
ThermoregulaTion
Regulation unit KPM30 and KPM31

2
Commands
Legend
1Alarm button, allows to analyse the type of alarm and disable it after having
xed the problem
2PRG button, allows to access the menus
3ESC button, return to the previous menu
4DOWN button, allows to navigate the menus
5UP button, allows to navigate the menus
6ENTER button, allows to select and conrm
First start-up
Warning.
The installation and initial start-up of the system must only be carried
out by qualied personnel, in strict accordance with the regulations
in force.
The control unit is not congured at the rst start-up, warned by the rst
screen that appears on the display.
This screen allows to set the system installed in the control unit by following
the wizard.
1. language: select the desired language with the arrows and conrm with
enter.
2. external probe: indicate if the external probe is connected.
3. summer/winter selection: probe=from external probe, digital input=from
external contact, terminal=from display.
4. system type: indicate the type of system if oor, ceiling or radiators.
5. mixing valve type: 0..10V or 3-point oating (K281=85sec, K274=145sec,
K274J=160sec).
6. winter set point
7. summer set point
8. winter climatic curve
9. summer climatic curve
10. conrm conguration
PROGRAMMING of the regulation unit: KPM30Y001, KPM30Y002, KPM31Y001, KPM31Y002

3
Service menu
The service menu is accessible to the installer only. It allows to modify
additional parameters and reset the guided conguration.
1. Mixer parameters PI.
2. Summer mixer parameters.
3. Winter mixer parameters.
4. Displaying of winter compensation.
5. Winter compensation parameters.
6. Displaying of summer compensation.
7. Summer compensation parameters.
8. Enabling set up of screed.
9. Set-up parameters.
10. Alarms parameters.
11. Season change parameters from external probe.
12. Buzzer management.
13. Serial bus communication.
14. Language.
15. Guided conguration reset.
Main screen
The main screen allows a quick check of the
system's main water mixing functions.
Displays time, outside temperature if
congured, date, the mixing valve displayed,
the water temperature, the set water
temperature must reach and the mixing valve position as a percentage.
Visible symbols:
Summer / winter
Circulator running
Mixing valve closing
SCREED SET-UP screed set-up operation
Main navigation
It is possible to navigate using the up and down arrow keys.
To enter the main menu, press the PRG key.
Main menu
The sub-menu can be entered via the main menu for the detailed control of
the system.
1. STATE UNIT: Allows to enable and disable the entire system. If it is set by
the conguration, it allows the summer/winter change from the terminal and
change the date and time.
2. SERVICE: allows to enter the technical parameters menu with password.
3. VERSION: allows to analyse the version of the installed program.
To navigate, use the Up Arrow and Down Arrow selecting with ENTER. ESC
to exit.

4
Terminals
J1 - G - G0 24Vac +10/-15% 50/60Hz from safety transformer Class II
J2 - SYNC 24Vac +10/-15% 50/60Hz from safety transformer Class II
J2 - B1 Delivery probe radiant1
J2 - B2 Delivery probe radiant2
J2 - B3 External probe
J2 - B4 Not used
J2 - B5 Not used
J2 - B6 Summer open/winter closed
J2 - GND Common J2
J2 - +5Vref Not used
J2 - +VDC Not used
J2 - ID1 Consensus activation radiant 1
J2 - GND Common J2
J3 - C1 - NC1 - NO1 Circulator command radiant 1
J4 Connection RJ12 for KD201
J5 - Rx/Tx - GND Primary Bus
J6 Not used
J7 - TLAN - GND Not used
J8 - Rx/Tx - GND Not used
J9 - Y1 PWM PWM output for K489M mixer radiant 2
J9 - Y2 0...10V 0..10V output for mixer radiant 1
J9 - GND Common for Y1 – Y2
J10 - NO2 - C2 Circulator command radiant 2
J11- C3 Common J11
J11 - NO3 Mixer radiant 1 Down
J11 - NO4 Mixer radiant 1 UP
J11 - NO5 Mixer radiant 2 Down
J11 - NO6 Mixer radiant 2 UP
J11 - C3 Common J11
J12 - GND Common J12
J12 - ID2 Consensus activation radiant 2
J12 - B7 External alarm radiant 1
J12 - B8 External alarm radiant 2
Version KPM30Y002 allows the reset of 2 mixing valves.
Use the Up Arrow and Down Arrow selecting with ENTER to navigate the
various parameters in the window until the cursor is in the upper left to move
to the next window.
Press ESC repeatedly to exit and return to the main screen.

5
Electric connections KPM30Y001 / KPM31Y001
With one mixer 0...10 V at 24 Vac

6
Electric connections KPM30Y001 / KPM31Y001
With one mixer 3-point oating at 24 Vac

7
Electric connections KPM30Y002 / KPM31Y002
With two mixers 0...10 V at 24 Vac

8
Electric connections KPM30Y002 / KPM31Y002
With two mixers 3-point oating at 24 Vac

9
Commands
Legend
1Alarm button, allows to analyse the type of alarm and disable it after having
xed the problem
2PRG button, allows to access the menus
3ESC button, return to the previous menu
4DOWN button, allows to navigate the menus
5UP button, allows to navigate the menus
6ENTER button, allows to select and conrm
First start-up
Warning.
The installation and initial start-up of the system must only be carried
out by qualied personnel, in strict accordance with the regulations
in force.
The control unit is not congured at the rst start-up, warned by the rst
screen that appears on the display.
This screen allows to set the system installed in the control unit by following
the wizard.
1. language: select the desired language with the arrows and conrm with
enter.
2. external probe: indicate if the external probe is connected.
3. summer/winter selection: probe=from external probe, digital input=from
external contact, terminal=from display.
4. system type: indicate the type of system if oor, ceiling or radiators.
5. winter set point
6. summer set point
7. winter climatic curve
8. summer regulation: indicate whether from climatic curve, external probe or
internal dew point
9. summer climatic curve
10. number of zones present: indicate the number of thermostats connected
11. type of probes/thermostats: indicate the code of the Giacomini
thermostat connected
12. number of dehumidiers
13. number of integrators
14. humidity set
15. integration oset
16. conrm conguration
PROGRAMMING of the regulation unit: KPM30Y003, KPM31Y003

10
Main screen
The main screen allows a quick check of the
system's main water mixing functions.
Displays time, outside temperature
if congured, date, the mixing valve
displayed, the water temperature, the set
water temperature must reach and the mixing valve position as a percentage.
Visible symbols:
Summer / winter
Circulator running
Mixing valve closing
SCREED SET-UP screed set-up operation
Main navigation
It is possible to navigate using the up and down arrow keys.
To enter the main menu, press the PRG key.
To enter the thermostat temperature menu, press the PRG key.
The temperature set can be changed and associate the time schedule in the
days of the week.
For the time scheduling, refer to the Main Menu-Programs.

11
Service menu
The service menu is accessible to the installer only. It allows to modify
additional parameters and reset the guided conguration.
1. Mixer parameters PI.
2. Summer mixer parameters.
3. Winter mixer parameters.
4. Displaying of winter compensation.
5. Winter compensation parameters.
6. Displaying of summer compensation.
7. Summer compensation parameters.
8. Enabling set up of screed.
9. Set-up parameters.
10. Alarms parameters.
11. Season change parameters from external probe.
12. Buzzer management.
13. Serial bus communication.
14. Language.
15. Guided conguration reset.
Main menu
The sub-menu can be entered via the main menu for the detailed control of
the system.
1. STATE UNIT: Allows to enable and disable the entire system. If it is set by
the conguration, it allows the summer/winter change from the terminal and
change the date and time.
2. SERVICE: allows to enter the technical parameters menu with password.
3. PROGRAMS: allows to set time slots between the Comfort and Economy
sets of 5 summer and 5 winter programs, selecting the desired half hour, the
space is blackened and Comfort is set.
4. VERSION: allows to analyse the version of the installed program.
To navigate, use the Up Arrow and Down Arrow selecting with ENTER. ESC
to exit.

12
Terminals
J1 - G - G0 24Vac +10/-15% 50/60Hz from safety transformer Class II
J2 - SYNC 24Vac +10/-15% 50/60Hz from safety transformer Class II
J2 - B1 Delivery probe radiant1
J2 - B2 Not used
J2 - B3 External probe
J2 - B4 Not used
J2 - B5 Not used
J2 - B6 Summer open/winter closed
J2 - GND Common J2
J2 - +5Vref Not used
J2 - +VDC Not used
J2 - ID1 Consensus activation radiant 1
J2 - GND Common J2
J3 - C1 - NC1 - NO1 Circulator command radiant 1
J4 Connection RJ12 for KD201
J5 - Rx/Tx - GND Primary Bus
J6 Not used
J7 - TLAN - GND Not used
J8 - Rx/Tx - GND Thermostats secondary Bus
J9 - Y1 PWM Not used
J9 – Y2 0..10V 0..10V output for mixer radiant 1
J9 - GND Common for Y1 – Y2
J10 - NO2 - C2 Summer/winter consent
J11 - C3 Common J11
J11 - NO3 Consent TA1 addr128
J11 - NO4 Consent TA2 addr129
J11 - NO5 Consent TA3 addr130
J11 - NO6 Dehumidier consent
J11 - C3 Integration consent:
J12 - GND Common J12
J12 - ID2 Not used
J12 - B7 External alarm radiant 1
J12 - B8 External alarm radiant 2
Use the Up Arrow and Down Arrow selecting with ENTER to navigate the
various parameters in the window until the cursor is in the upper left to move
to the next window.
Press ESC repeatedly to exit and return to the main screen.

13
Electric connections KPM30Y003 / KPM31Y003

14
Commands
Legend
1Alarm button, allows to analyse the type of alarm and disable it after having
xed the problem
2PRG button, allows to access the menus
3ESC button, return to the previous menu
4DOWN button, allows to navigate the menus
5UP button, allows to navigate the menus
6ENTER button, allows to select and conrm
First start-up
Warning.
The installation and initial start-up of the system must only be carried
out by qualied personnel, in strict accordance with the regulations
in force.
The control unit is not congured at the rst start-up, warned by the rst
screen that appears on the display.
This screen allows to set the system installed in the control unit by following
the wizard.
1. language: select the desired language with the arrows and conrm with
enter.
2. external probe: indicate if the external probe is connected.
3. summer/winter selection: probe=from external probe, digital input=from
external contact, terminal=from display.
4. system type: indicate the type of system if oor, ceiling or radiators.
5. winter set point
6. summer set point
7. winter climatic curve
8. summer regulation: indicate whether from climatic curve, external probe or
internal dew point
9. summer climatic curve
10. number of zones present: indicate the number of thermostats connected
11. type of probes/thermostats: indicate the code of the Giacomini
thermostat connected
12. number of dehumidiers
13. number of integrators
14. humidity set
15. integration oset
16. conrm conguration
PROGRAMMING of the regulation unit: KPM30Y004, KPM30Y005, KPM31Y004, KPM31Y005

15
Main screen
The main screen allows a quick check of the
system's main water mixing functions.
Displays time, outside temperature
if congured, date, the mixing valve
displayed, the water temperature, the set
water temperature must reach and the mixing valve position as a percentage.
Visible symbols:
Summer / winter
Circulator running
Mixing valve closing
SCREED SET-UP screed set-up operation
Main navigation
It is possible to navigate using the up and down arrow keys.
To enter the main menu, press the PRG key.
To enter the thermostat temperature menu, press the PRG key.
The temperature set can be changed and associate the time schedule in the
days of the week.
For the time scheduling, refer to the Main Menu-Programs.

16
Service menu
The service menu is accessible to the installer only. It allows to modify
additional parameters and reset the guided conguration.
1. Mixer parameters PI.
2. Summer mixer parameters.
3. Winter mixer parameters.
4. Displaying of winter compensation.
5. Winter compensation parameters.
6. Dew-point algorithm parameters
7. Displaying of summer compensation.
8. Summer compensation parameters.
9. Enabling set up of screed.
10. Set-up parameters.
11. Alarms parameters.
12. Season change parameters from external probe.
13. Humidity Set-point.
14. Dierentials.
15. Antifreeze parameters.
16. Buzzer enabling.
17. Serial communication.
18. Language.
19. Guided conguration reset.
Main menu
The sub-menu can be entered via the main menu for the detailed control of
the system.
1. STATE UNIT: Allows to enable and disable the entire system. If it is set by
the conguration, it allows the summer/winter change from the terminal and
change the date and time.
2. SERVICE: allows to enter the technical parameters menu with password.
3. PROGRAMS: allows to set time slots between the Comfort and Economy
sets of 5 summer and 5 winter programs, selecting the desired half hour, the
space is blackened and Comfort is set.
4. VERSION: allows to analyse the version of the installed program.
To navigate, use the Up Arrow and Down Arrow selecting with ENTER. ESC
to exit.

17
Terminals
J1 - G - G0 24Vac +10/-15% 50/60Hz from safety transformer Class II
J2 - SYNC 24Vac +10/-15% 50/60Hz from safety transformer Class II
J2 - B1 Delivery probe radiant1
J2 - B2 Delivery probe radiant2
J2 - B3 External probe
J2 - B4 Not used
J2 - B5 Not used
J2 - B6 Summer open/winter closed
J2 - GND Common J2
J2 - +5Vref Not used
J2 - +VDC Not used
J2 - ID1 Consensus activation radiant 1
J2 - GND Common J2
J3 - C1 - NC1 - NO1 Circulator command radiant 1
J4 Connection RJ12 for KD201
J5 - Rx/Tx - GND Primary Bus
J6 Not used
J7 - TLAN - GND Not used
J8 - Rx/Tx - GND Not used
J9 - Y1 PWM PWM output for K489M mixer radiant 2
J9 – Y2 0..10V 0..10V output for mixer radiant 1
J9 - GND Common for Y1 – Y2
J10 - NO2 - C2 Circulator command radiant 2
J11 - C3 Common J11
J11 - NO3 Summer/winter command
J11 - NO4 Not used
J11 - NO5 Chiller command
J11 - NO6 Boiler command
J11 - C3 Common J11
J12 - GND Common J12
J12 - ID2 Consensus activation radiant 2
J12 - B7 External alarm radiant 1
J12 - B8 External alarm radiant 2
Use the Up Arrow and Down Arrow selecting with ENTER to navigate the
various parameters in the window until the cursor is in the upper left to move
to the next window.
Press ESC repeatedly to exit and return to the main screen.

18
Electric connections KPM30Y004 / KPM31Y004

19
Electric connections KPM30Y005 / KPM31Y005

20
Additional information
For further information, visit the website www.giacomini.com or contact the technical service:'[phone]6+39 0322 923255*[email protected]
This information is intended as an example. Giacomini S.p.A. reserves the right to modify the contents - at any time and without prior warning - for technical or commercial reasons. The
information in this technical sheet does not exempt the user from scrupulously observing the existing regulations and standards relating to good technical practices.
Giacomini S.p.A. Via per Alzo, 39 - 28017 San Maurizio d’Opaglio (NO) Italy
Alarms lenged
By pressing the “alarm”button you can analyze the alarm type this:
No alarm present
Alarm from external source
control terminal J12 close
between GND-B7
Alarm from external source
control terminal J12 close
between GND-B8
Alarm ow sensor, control
terminal between GND J1-B1
Alarm ow sensor, control
terminal between GND J1-B2
Alarm outdoor sensor, control
terminal J1 between GND-B3
Low temperature alarm ow
sensor, check connections mixing
High temperature alarm ow
sensor, check connections mixing
Alarm device oine, check
connections and addresses
devices on the bus cable
After repairing the fault press the“alarm”button to delete the alarm memory.
Product specications
KPM30
Regulation unit for heating and/or cooling systems. With integrated display
panel for the monitoring, conguration, and management of the system.
Power supply 24 Vac, dimension 6 DIN modules. Possibility to control mixing
valve, circulator and voltage free contacts output. Optional connection with
remote terminal KD201. Possibility of connection with eld-bus, inputs/
outputs expansion boards KPM35 and with room sensors K492B and K495B/L.
CE Certication.
KPM31
Regulation unit for heating and/or cooling systems.Without built-in display, to
combine with remote terminal KD201 for the monitoring, conguration, and
management of the system. Power supply 24 Vac, dimension 6 DIN modules.
Possibility to control mixing valve, circulator and voltage free contacts output.
Possibility of connection with eld-bus, inputs/outputs expansion boards
KPM35 and with room sensors K492B and K495B/L. CE Certication.
0676EN June 2016
ThermoregulaTion
Regulation unit KPM30 and KPM31
