Technical spec meets the technical trail. Overbuilt with 8 inches of coil-over Maestro Suspension,
onePointfive headset and freeride-specific geometry. Because out there, there’s no substitute for
strength. Or the confidence and talent to make it stick.
— Marzocchi 66 RC3 180mm suspension fork, Marzocchi Roco TST-R coil rear shock
— SRAM X.7 shifters/X.9 rear derailleur with Hayes Stroker Ace hydraulic disc brakes
— Race Face Evolve DH handlebar and seatpost
— WTB SpeedDisc DH rim/Formula disc 20mm hub wheelset
*Seat angle is effective
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
FRAME
SIZES XS,S,M,L
COLORS Gray Anodized
FRAME ALUXX SL-Grade Aluminum, 8.0"
Maestro Suspension
FORK Marzocchi 66 RC3, onePointfive
steerer tube, 180mm travel w/
20mm Thru Axle
SHOCK Marzocchi Roco TST-R, coil
COMPONENTS
HANDLEBAR Race Face Evolve DH mid rise, 31.8
STEM Race Face Diabolus D2
SEATPOST Race Face Evolve DH 350x30.9mm
SADDLE Giant FRO
PEDALS Alloy Platform
DRIVETRAIN
SHIFTERS SRAM X7, trigger
FRONT DERAILLEUR Shimano Saint w / Race Face Atlas
Shiftguide
REAR DERAILLEUR SRAM X9
BRAKES Hayes Stroker Ace, Custom for
Giant 203F/203R
BRAKE LEVERS Hayes
CASSETTE Shimano HG50 11/34, 9-speed
CHAIN Shimano HG-73
CRANKSET Race Face Evolve DH, 24/36/RG
BOTTOM BRACKET Race Face X Type, External
WHEELS
RIMS WTB Speed Disc DH
HUBS Formula DH thru axle
SPOKES DT Competiton, 14/15g
TIRES WTB Dissent/Prowler MX, 26x2.5
DH
EXTRAS
Specifications and availability subject to change without notice.
freeride
Mountain
Key Upgrades (over Glory 1)
Frame TechnologySpecifications
Actual
Frame Size Part Number Head Angle Seat Angle* Toptu be** Headtube Chainstay Wheelbase Standover
Height***
inches degrees degrees inches inches inches inches inches
XS/15 348642 67.0 69.0 20.9 4.6 17.5 43.3 34.4
S/16.5 348643 67.0 69.0 22.3 4.6 17.5 43.9 33.9
M/17 348644 67.0 69.0 23.2 4.6 17. 5 44.7 33.7
L/18 348645 67. 0 69.0 25.4 5.1 17.5 46.2 33.1
frame geometry
For Giant freerider Kurt Sorge, every ride is a chance to rewrite what’s possible. That’s why he
rides the Glory. This is bombproof performance. DH tough, with the steering precision to pick
impossible lines and make them real. Floats like a butterfly…hits like a sledge.
glory 0
