Giant ANTHEM X1 User manual

OFF-road |PERFORMANCE |Competition
GIANT’S WORLD CUP PROS LOVE RIPPING FAST
TRAIL RIDES NEARLY AS MUCH AS THEY DO
WINNING XC RACES. WITH THIS BIKE, THEY DO BOTH.
Start with an ALUXX SL aluminum frameset, a hydro-formed work of art with all the right angles,
then add 4 inches of active Maestro travel, and you get an XC race bike that’s light enough to waltz
up nasty climbs and stable enough to rail rutted descents. Test editors everywhere agree with
Giant pros: Anthem X nails it.
— RockShox SID Team, 100mm suspension fork
and Fox Float RP23 rear shock
— Shimano Deore XT/XTR components
— Giant Contact seatpost, stem and handlebar
— Shimano Deore XT wheelset
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Specifications and availability subject to change without notice.
Key Upgrades (over Anthem X2)
Frame TechnologySpecifications
Actual
Frame Size Part Number Head Angle Seat Angle* Toptube** Headtube Chainstay Wheelbase Standover Height***
inches degrees degrees inches inches inches inches inches
XS 14.5 342652 71.0 74.0 21.9 4.6 16.7 41.3 30.2
S 16 342653 71.0 73.5 22.6 4.6 16.7 41.9 30.4
M 18 342654 71.0 73.0 23.4 5.1 16.7 42.5 31.0
L 20 342655 71.0 73.0 24.2 5.7 16.7 43.3 32.1
XL 22 342656 71.0 72.5 25.0 6.3 16.7 44.1 32.6
frame geometry
ANTHEM X1
OFF-road |PERFORMANCE |Competition
FRAME
SIZES XS,S,M,L,XL
COLORS Red/Black
FRAME ALUXX SL-Grade Aluminum,
4" Maestro Suspension
FORK RockShox SID Team w/ Poploc,
100mm travel
SHOCK Fox Float RP23
COMPONENTS
HANDLEBAR Giant Contact, low rise 31.8
STEM Giant Contact
SEATPOST Giant Contact, 30.9
SADDLE Fi'zi:k Tundra w/ K:ium rails
PEDALS Not Included
DRIVETRAIN
SHIFTERS Shimano Deore XT Rapidfire
FRONT DERAILLEUR Shimano Deore XT
REAR DERAILLEUR Shimano XTR, top normal
BRAKES Shimano Deore XT 160mm
BRAKE LEVERS Shimano Deore XT
CASSETTE Shimano Deore XT 11x34, 9-speed
CHAIN Shimano HG-73
CRANKSET Shimano Deore XT, 22/32/44
BOTTOM BRACKET Shimano Deore XT, External
WHEELS
RIMS Shimano Deore XT
HUBS Shimano Deore XT
SPOKES Shimano Deore XT
TIRES Maxxis Crossmark, 26x2.1 Folding
EXTRAS
