sedona lx
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Actual
Frame Size Part Number Head Angle Seat Angle* Toptube** Headtube Chainstay Wheelbase Standover
Height***
inches degrees degrees inches inches inches inches inches
XS 14 2118500 71.0 73.0 21.8 5.0 17.0 39.9 28.6
S 17 2118501 71.0 73.0 23.0 6.5 17.0 41.2 29.3
M 19 2118502 71.0 73.0 23.4 7.1 17.0 41.7 30.8
L 21 2118503 71.0 73.0 23.8 7.7 17.0 42.3 31.8
XL 23 2118504 71.0 73.0 24.1 8.3 17.0 42.8 32.8
frame geometry
Specifications and availability subject to change without notice.
Specifications
frame
SIZES XS,S,M,L,XL
COLOUR Blue
FRAME ALUXX-grade aluminum
FORK SR Suntour NEX 4100 V2 63mm travel
SHOCK N/A
componentS
HANDLEBAR Steel low-rise 25.4mm
STEM Alloy adjustable
SEATPOST Suspension 30.9x300mm
SADDLE Giant Comfort Groove
PEDALS Comfort platform
DriVetrain
SHIFTERS Shimano EF51 EZ-Fire
FRONT DERAILLEUR Shimano M191
REAR DERAILLEUR Shimano Alivio
BRAKES Hayes MX 4 160mm mechanical disc
BRAKE LEVERS Shimano EF51
CASSETTE SRAM PG-820 11-32T 8SPD
CHAIN KMC Z51
CRANKSET Shimano M171 28/38/48T
BOTTOM BRACKET Cartridge
WHeeLS
RIMS Alloy 32H double wall
HUBS Alloy QR
SPOKES Steel 14g
TIRES Kenda multi-surface 26x1.95”
EXTRAS Kickstand
Spec Features
— Shimano EZ-Fire 8-speed drivetrain w/ triple crankset
— SR Suntour NEX suspension fork w/ 63mm travel & suspension seatpost
— Hayes MX 4 mechanical disc brakes
