Giga-tronics 3000-44 User manual

Manual 07500610 Model 3000-44
Page 1
Operation Manual
Model 3000-44
2(2x64) 2-wire Matrix
90400650

Manual 07500610 Model 3000-44
Page 2
Operation Manual
All technical data and specifications in this publication are subject to change without prior notice and do
not represent a commitment on the part of Giga-tronics, Incorporated.
© 2011 Giga-tronics Incorporated. All rights reserved. Printed in the U.S.A.
CONTACT INFORMATION
Giga-tronics, Incorporated
4650 Norris Canyon Road
San Ramon, California 94583
Telephone: [phone] (only within the United States)
925.328.4650
Fax: [phone]
On the Internet: www.gigatronics.com
Warranty
Giga-tronics Series 3000 Switching Modules are warranted against
defective materials and workmanship for three yearsfrom date of shipment,
or as detailed in the warranty section of this manual. Giga-tronics will, at its
option, repair or replace products that are proven defective during the
warranty period. This warranty DOES NOT cover damage resulting from
improper use, nor workmanship other than Giga-tronics service. There is no
implied warranty of fitness for a particular purpose, nor is Giga-tronics liable
for any consequential damages. Specification and price change privileges are
reserved by Giga-tronics.

Manual 07500610 Model 3000-44
Page 3
Operation Manual
Regulatory compliance information
This product complies with the essential requirements of the following applicable European
Directives, and carries the CE mark accordingly.
89/336/EEC and 73/23/EEC
EMC Directive and Low Voltage Directive
EN61010-1 (1993)
Electrical Safety
EN61326-1 (1997)
EMC –Emissions and Immunity
Manufacturer’s Name:
Manufacturer’s Address
Giga-tronics, Incorporated
4650 Norris Canyon Road
San Ramon, California 94583
U.S.A.
Type of Equipment:
Model Series Number
Switching Module
3000-44
Declaration of Conformity on file. Contact Giga-tronics at the following;
Giga-tronics, Incorporated
4650 Norris Canyon Road
San Ramon, California 94583
Telephone: [phone] (only within the United States)
925.328.4650
Fax: [phone]

Manual 07500610 Model 3000-44
Page 4
Operation Manual
Record of Changes to This Manual
Use the table below to maintain a permanent record of changes to this document. Corrected
replacement pages are issued as Technical Publication Change Instructions (TPCI). When you
are issued a TPCI, do the following:
1. Insert the TPCI at the front of the manual binder.
2. Remove the pages from the manual binder that are noted in the TPCI.
3. Replace the page(s) removed in the previous step with the corrected page(s).
4. Record the changes in the table below.
TPCI
Number
TPCI Issue
Date
Date Entered
Comments

Manual 07500610 Model 3000-44
Page 5
Operation Manual
Revision History
Revision
Description of Change
Chg Order #
Approved By
A
Initial Release
B
Updated
C
Updated
D
Updated
E
Updated 11/10
F
Reformatted 3/12
RCW

Manual 07500610 Model 3000-44
Page 6
Operation Manual
Contents
Contents........................................................................................................................................................6
Chapter 1 Introduction .................................................................................................................................8
1.1 Safety and Manual Conventions.........................................................................................................8
1.1.1 Product Reference.......................................................................................................................8
1.1.2 Personal Safety Alert...................................................................................................................8
1.1.3 Equipment Safety Alert ...............................................................................................................8
1.1.4 Notes ...........................................................................................................................................8
1.1.5 Electrical Safety Precautions ....................................................................................................... 8
Chapter 2 Configuration Table...................................................................................................................... 9
Chapter 3 Functional Description ...............................................................................................................10
3.1 Introduction......................................................................................................................................10
3.2 General Description..........................................................................................................................10
Chapter 4 Block Diagram ............................................................................................................................11
Chapter 5 Controls and Indicators ..............................................................................................................12
5.1 VXI Logical Address...........................................................................................................................12
5.2 LEDs...................................................................................................................................................12
5.2.1 “BUS” LED..................................................................................................................................12
5.2.2 “PWR” LED.................................................................................................................................12
Chapter 6 Internal Settings ......................................................................................................................... 13
6.1 Fuse...................................................................................................................................................13
6.2 VXIbus Interrupt Level Selection.........................................................................................................13
Chapter 7 Specifications .............................................................................................................................14
Chapter 9 Register Map ..............................................................................................................................15
9.1 Functional Description......................................................................................................................15
9.2 Programming ....................................................................................................................................15
Chapter 10 Connector Pin Configuration....................................................................................................21
Chapter 11 Option “M” Register Maps.......................................................................................................35
Chapter 12 Front Panel Connections..........................................................................................................40
12.1 Input Signals ...................................................................................................................................40
12.2 OUTPUT SIGNALS............................................................................................................................42

Manual 07500610 Model 3000-44
Page 7
Operation Manual
12.2.1 128 x 2 MATRIX ( 90400650 ) .................................................................................................42
12.2.2 DUAL 64x2 MATRIX ( 90400650-001......................................................................................42
12.2.3 128 x 2 MATRIX ( 90400650 –101 ) –Extra Output Connections...........................................42

Manual 07500610 Model 3000-44
Page 8
Operation Manual
Chapter 1 Introduction
1.1 Safety and Manual Conventions
This manual contains conventions regarding safety and equipment usage as described below.
1.1.1 Product Reference
Throughout this manual, the term “Common Core Switching Platform, Series 8800” refers to all models
of within the series, unless otherwise specified.
1.1.2 Personal Safety Alert
WARNING: Indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
1.1.3 Equipment Safety Alert
CAUTION: Indicates a situation which can damage or adversely affect the product or
associated equipment.
1.1.4 Notes
Notes are denoted and used as follows:
NOTE: Highlights or amplifies an essential operating or maintenance procedure, practice, condition or
statement.
1.1.5 Electrical Safety Precautions
Any servicing instructions are for use by service-trained personnel only. To avoid personal injury, do not
perform any service unless you are qualified to do so.
For continued protections against fire hazard, replace the AC line fuse only with a fuse of the same
current rating and type. Do not use repaired fuses or short circuited fuse holders.
WARNING
!
CAUTION

Manual 07500610 Model 3000-44
Page 9
Operation Manual
Chapter 2 Configuration Table
Module 3000-44, (2x128) Standard Module
PL90400650
Assy 90400650
Module 3000-44 Option 1, (2x128) Module, also known as Option “M”, has two
additional inputs on DB
PL90400650-101
Assy 90400650-101
Module 3000-44, 2(2x64) Module
PL90400650-001
Assy 90400650-001
Schematics
MB PL85003420
Assy 85003420
SCH85003420
DB PL85003430
Assy 85003430
SCH85003430

Manual 07500610 Model 3000-44
Page 10
Operation Manual
Chapter 3 Functional Description
3.1 Introduction
This User Guide provides a basic description of the 3000-44 2 x 128 Coaxial Switch Matrix module. Also
included are installation and input connection procedures, programming information, service and
maintenance information.
3.2 General Description
This module is a dual wire 2 x 128 matrix switch. Each relay in the module is individually controlled. Any
and all relays can be closed. The module is designed to support precision testing designs such as ATE.
This module is ideal for high quality multi-channel measurement or stimulus switching. Each relay is
coaxially shielded to a separate analog ground plane. The Interface and mechanical construction meets
the specification of the VXIbus System Specification, rev 1.2 through 1.4. This module also has a factory
option for two independent 64 x 2 matricies.

Manual 07500610 Model 3000-44
Page 11
Operation Manual
Chapter 4 Block Diagram
16
Port 1 (L)
Shield
Port 1 (H)
Analog Groundplane
CH A (H)
Shield
Ch A (L)
Port 128 (L)
Shield
Port 128 (H)
CH B (H)
Shield
Ch B (L)
2x16
2x16
2x16
2x16
2x16
2x16
2x16
2x16
Jumpers in
for STD, -101
MB
DB Jumpers in for -001,-101
2x16 Detail

Manual 07500610 Model 3000-44
Page 12
Operation Manual
Chapter 5 Controls and Indicators
The following controls and indicators are provided to select and display the functions of the ASCOR
3000-44 Module’s operating environment.
5.1 VXI Logical Address
The Logical Address Switch is dual circular switches, D1 and D2 which are located at the rear of the
module. The address can be set to any value between 1 and 255 (decimal) or 1 and FF (hexadecimal),
(address 0 is reserved for the resource manager). However, the Module fully supports Dynamic
Configuration as defined in Section F of the VXI specification, address 255 (FF) should be selected only if
the Resource Manager also supports Dynamic Configuration.
5.2 LEDs
The following LEDs are visible at the Module’s front panel to indicate the
status of the module’s operation:
5.2.1 “BUS” LED
This green color LED is normally off and will flash on when the module is addressed by the system.
5.2.2 “PWR” LED
This red color LED is normally on when the Module is Powered up.

Manual 07500610 Model 3000-44
Page 13
Operation Manual
Chapter 6 Internal Settings
The following items are inside the module and can be reached by removing the side cover.
6.1 Fuse
The ASCOR VXI 3000-44 uses a 10 Amp fuse in the +5 Volt line and is located on
the Mother Board (MB) assembly.
6.2 VXIbus Interrupt Level Selection
The VXIbus interrupt level is set with three bits in the “3Eh” register.
See the section on “A16 ADDRESS SPACE REGISTER DESCRIPTION”.
The interrupt level is factory set to “no interrupt”.

Manual 07500610 Model 3000-44
Page 14
Operation Manual
Chapter 7 Specifications
Electrical:
DC parameters:
Switching voltage: 200 Volts
Switching current: 0.5 Amps
Carry current: 1.5 Amps
Contact rating: 10 Watts
AC Parameters:
Bandwidth: 45MHz minimum & 70MHz Typical, into 50Ω, each line
with respect to shield
Mechanical:
Thickness: 1.200 inches
Width: 10.317 inches
Length: 13.78 inches
Weight: 4 lbs. 10 oz.
Environmental Specifications
Temperature:
Operating: 0º to 55ºC
Storage: - 40º to 75ºC
Relative Humidity:
Operating: 0 to 90% non-condensing
Storage: 0 to 95% non-condensing

Manual 07500610 Model 3000-44
Page 15
Operation Manual
Chapter 9 Register Map
9.1 Functional Description
This module is a universal input/output multi-wire matrix switch. It contains eight 2x16 dual wire
matrices connected together through isolation relays. Isolation circuits are provided to maintain signal
performance by disconnecting unused sections of the matrices.
9.2 Programming
The Model 3000-44 a VXI register based module. The switch paths are controlled via VXIMAX™ which is
the 16/32 bit data controller. The Model 3000-44 can be programmed in 16 bit or 32 bit wide data.
Through your VXI controller, write the data to the appropriate register as shown on the register map for
the relay or relays in the register that is being closed. When the data bit is true, the relay chosen will be
closed. The state of the relays in a register can be determined by reading the desired register. The data
read back represents the value at the coil of the relay. This allows verification that the program register
has correctly controlled the relay coil.
The following register maps are shown in two configurations: 16 bit mode and 32 bit mode. In each
section,16 bit and 32 bit, the register map is organized to show the relay designation in each register. It
is followed by the register’s functionality and the path connections to the front panel.
Programming of the Model 3000-44 is very simple. The module is organized into 4 pins per register in16
bit mode or 8 pins per register in 32 bit mode. A pin is controlled by a group of 4 bits within the
program registers. These bits select one or more the the two available channels. Typically, only one
channel is assigned to a pin for optimum performance. Whenever a pin is selected in a group, the
appropriate channel isolation relay must be closed to complete the path. The isolation relays is the last
register in the mother board and daughter board.
For example:
To close pin 1 to channel A and to close pin 2 to channel B would set the following register:
Register 8000h: Control pins 1- 4
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
0
1
Register 8010h: Controls the isolation relays
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1

Manual 07500610 Model 3000-44
Page 16
Operation Manual
A16 Address Space Register Description
Offset Value
00h CFB5 hex
C = Register based, A16/A24
FB5 = ASCOR Manufacturer ID
02h 7F2C hex
7 = 10,000 hex space in the A24 Address space
F2C = HV Discrete Driver/Receiver VXI Module number
04h FFFC hex (typical after running Resource Manager)
In order to reset the module: read this address, set bit 0 high, then set
bit 0 low without altering the other bits.
Control Bit
3Eh 0 Low true output enable to the coil driver ICs.
1 When low enables read back of the coil state.
When high enables read back of the data registers.
2 Leave set to 0, reserved by Ascor.
3 Interrupt bit 0 (LSB) <_> Used to set the Module IRQ Level:
4 Interrupt bit 1 <_>0 = No Interrupts
5 Interrupt bit 2 (MSB) <_>1-7 = IRQ1-IRQ7
6-7 Don’t Care.
8-15 Mask Off.

Manual 07500610 Model 3000-44
Page 17
Operation Manual
DESCRIPTION: 2X64 DUAL WIRE MATRIX, MOTHER BOARD
PCB NUMBER: 85003420
MSB
MODE:
16
MODE:
32
15
14
13
12
11
10
9
8
8000h
8000h-
lower
K16
K15
K14
K13
K12
K11
K10
K9
LSB
MODE:
16
MODE:
32
7
6
5
4
3
2
1
0
8000h
8000h-
lower
K8
K7
K6
K5
K4
K3
K2
K1
MSB
MODE:
16
MODE:
32
15(31)
14(30)
13(29)
12(28)
11(27)
10(26)
9(25)
8(24)
8002h
8000h-
upper
K32
K31
K30
K29
K28
K27
K26
K25
LSB
MODE:
16
MODE:
32
7(23)
6(22)
5(21)
4(20)
3(19)
2(18)
1(17)
0(16)
8002h
8000h-
upper
K24
K23
K22
K21
K20
K19
K18
K17
MSB
MODE:
16
MODE:
32
15
14
13
12
11
10
9
8
8004h
8004h-
lower
K48
K47
K46
K45
K44
K43
K42
K41
LSB
MODE:
16
MODE:
32
7
6
5
4
3
2
1
0
8004h
8004h-
lower
K40
K39
K38
K37
K36
K35
K34
K33
MSB(MSB)
MODE:
16
MODE:
32
15(31)
14(30)
13(29)
12(28)
11(27)
10(26)
9(25)
8(24)
8006h
8004h-
upper
K64
K63
K62
K61
K60
K59
K58
K57
LSB
MODE:
16
MODE:
32
7(23)
6(22)
5(21)
4(20)
3(19)
2(18)
1(17)
0(16)
8006h
8004h-
upper
K56
K55
K54
K53
K52
K51
K50
K49

Manual 07500610 Model 3000-44
Page 18
Operation Manual

Manual 07500610 Model 3000-44
Page 19
Operation Manual
DESCRIPTION: 2X64 DUAL WIRE MATRIX, MOTHER BOARD
PCB NUMBER: 85003420
MSB
MODE:
16
MODE:
32
15
14
13
12
11
10
9
8
8008h
8008h-
lower
K80
K79
K78
K77
K76
K75
K74
K73
LSB
MODE:
16
MODE:
32
7
6
5
4
3
2
1
0
8008h
8008h-
lower
K72
K71
K70
K69
K68
K67
K66
K65
MSB(MSB)
MODE:
16
MODE:
32
15(31)
14(30)
13(29)
12(28)
11(27)
10(26)
9(25)
8(24)
800ah
8008h-
upper
K96
K95
K94
K93
K92
K91
K90
K89
LSB
MODE:
16
MODE:
32
7(23)
6(22)
5(21)
4(20)
3(19)
2(18)
1(17)
0(16)
800ah
8008h-
upper
K88
K87
K86
K85
K84
K83
K82
K81
MSB
MODE:
16
MODE:
32
15
14
13
12
11
10
9
8
800ch
800ch-
lower
K112
K111
K110
K109
K108
K107
K106
K105
LSB
MODE:
16
MODE:
32
7
6
5
4
3
2
1
0
800ch
800ch-
lower
K104
K103
K102
K101
K100
K99
K98
K97
MSB(MSB)
MODE:
16
MODE:
32
15(31)
14(30)
13(29)
12(28)
11(27)
10(26)
9(25)
8(24)
800eh
800ch-
upper
K128
K127
K126
K125
K124
K123
K122
K121
LSB
MODE:
16
MODE:
32
7(23)
6(22)
5(21)
4(20)
3(19)
2(18)
1(17)
0(16)
800eh
800ch-
upper
K120
K119
K118
K117
K116
K115
K114
K113

Manual 07500610 Model 3000-44
Page 20
Operation Manual
DESCRIPTION: 2X64 DUAL WIRE MATRIX, MOTHER BOARD
PCB NUMBER: 85003420
MSB
MODE:
16
MODE:
32
15
14
13
12
11
10
9
8
8010h
8010h-
lower
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
LSB
MODE:
16
MODE:
32
7
6
5
4
3
2
1
0
8010h
8010h-
lower
K136
K135
K134
K133
K132
K131
K130
K129
